Nuvo NV-P2100 Guida rapida

NV-P2100 Pure Sound Amplification

Compact, Flexible, Powerful.

Imagine relaxing at the end of a long day, listening to your favorite jazz from multiple

speakers in your own entertainment room. Now imagine entertaining friends on your

patio or deck to the sounds of a symphony playing through your garden speakers

with full, clear amplification. That’s the power of the NV-P2100 High Efficiency Audio

Amplifier from NuVo.

Powerful

With 200 watts of unadulterated sound amplification, the

NV-P2100 delivers enough power to fill even the largest

room with pure sound.

Compact

The half-rack design saves space.

Integrated

Designed to integrate easily with all the NuVo audio systems,

the NV-P2100 is the perfect complement for any multi-zone

distributed audio system.

Clear

The NV-P2100 gives you clean, pure sound with individual left and right channel

sensitivity adjustments to maximize the full potential of audio source equipment.

Efficient

The NV-P2100 uses less operating power and runs at significantly cooler temperatures

than other amplifiers, protecting surrounding equipment from damage.

Intelligent

Intelligent on/off capabilities allow the NV-P2100 to

automatically turn off or on by voltage or audio signal,

making operation simple.

Innovative, clear, affordable, simple.

For pure sound amplification that is as powerful and

flexible as it is compact, look no further than the NV-P2100

from NuVo.

Home never sounded so good.

P2100.indd 1 6/29/06 9:03:29 PM

www.nuvotechnologies.com

2395 Arbor Tech Drive, Hebron, KY 41048

Phone: 859-817-7200 Toll Free: 866-796-4904

Number of Channels 2

Power Output 70 Watts at 8 Ohms

Rated continuous power, each channel simultaneously driven, 20

Hz to 20 kHz at rated THD. Stable to 2 Ohms.

Power Output 100 Watts at 4 Ohms

Short Term continuous, each channel, both channels driven 1 kHz,

at rated THD.

Rated THD <0.8%

Frequency Response 20Hz to 20kHz

at 1 Watt + 1db

Input Sensitivity Variable

0dB - 1 Volt rms

+6dB - 2 Volts rms

-12dB - .25 Volts rms

Input Impedance 22 kOhms

Voltage Trigger AC or DC 3 to 30 Volts

Unit On/Off + 12 Volts DC 75 mA

AC Power 120 VAC, 60 Hz

240 VAC, 50 Hz

Power Consumption 4 Ohms 1 kHz Off 6.8 Watts

On, no signal 7.6 Watts

1/10 power 29.2 Watts

1/3 power 79.9 Watts

Full power 405 Watts

Line Fuse Rating 120 VAC version: 4 amp time lag

240 VAC version: 2 amp time lag

Unit Size Inches 8.5W x 3.75H x 13.5L

Unit Size Millimeters 214W x 96H x 340L

Unit Weight Pounds 12 (4.54kg)

Shipping Weight Pounds 17.2 (6.51kg)

NV-P2100 Wiring Diagram and

Specifications

PRD-205-0622

P2100.indd 2 6/29/06 9:03:38 PM
