NUVU PROW-8 Manuale utente
Food Service Systems
NU-VU®Proofer ®
Project
Item
Quantity
®NU-VU®Food Service Systems
www.nu-vu.com
5600 13th Street
Menominee, MI 49858
1-800-338-9886 Toll Free
1-906-863-4401 Phone
1-906-863-5889 Fax
PROW-8 Tabletop Proofer
NU-VU®PROW-8 Tabletop Proofer
STANDARD FEATURES:
•Stainless steel exterior
•Aluminum interior
•Set of 4” adjustable legs
•Full view tempered glass door
•Silicone rubber door gasket
•AutoMist humidity system
OPTIONAL FEATURES:
•Warmer
•Set of four casters
SIZE:
PROW-8 - 42-3/4” High, 24-1/4” Wide, 34-1/2” Deep
1086 mm High, 616 mm Wide, 876 mm Deep
NU-VU’s PROW-8 tabletop proofer has a stainless
steel exterior and tempered glass doors for full
view of your product. These units feature the
AutoMist humidity system, which eliminates the
need for a water pan; however, it does require a
1/4” waterline connection. This feature utilizes a
mist, which is sprayed directly onto a fan that
distributes the heat and humidity evenly throughout
the proofer cavity.
The PROW-8 has a capacity of 8 full size pans
and 16 half-size pans.
CONSTRUCTION:
•Welded stainless steel
•Fully insulated
•Control panel accessible through front
and top of unit
•Heating elements accessible inside of cabinet
and through top
CONTROLS:
•Mechanical controls
•Indicator light for thermostat
•Separate heat and humidity controls
LABORATORY CERTIFICATION AND APPROVAL
®NU-VU®Food Service Systems
www.nu-vu.com
5600 13th Street
Menominee, MI 49858
1-800-338-9886 Toll Free
1-906-863-4401 Phone
1-906-863-5889 Fax
®Food Service Systems
Approval / Stamp
PROW-8 Tabletop Proofer
NU-VU®PROW-8 Tabletop Proofer
SPECIFICATIONS:
ELECTRICAL:
• 120-Volt single phase is standard.
SERVICE CONNECTIONS:
• Unit is shipped from factory with cord and plug.
•A
1/4” water line is required.
• NEMA 5-20 P
INSTALLATION:
Allow four inches on each side and back of unit for
ventilation of oven.
DOOR SWING: Proofer - 24” (610 mm)
PACKING SIZE:
45” High, 36” Wide, 36” Deep
(1143 mm High, 914 mm Wide, 914 mm Deep)
SHIPPING WEIGHT:
230 Pounds (104 Kg), FOB Menominee, MI 49858
DIMENSIONS:
Height Width Depth
Exterior 42-3/4” 24-1/4” 34-1/2”
Interior 27” 18-1/2” 29”
Amp Draw 120/1
L1 16
ELECTRICAL:
CAPACITY:
18”x26” 13”x18”
Sheet Pans Sheet Pans Spacing
Proofer 8163-
1/4”
241/4”341/2”
6”
391/2”
423/4”
FRONTTOP SIDE BACK
ELECTRICAL INLET
1/4” WATER LINE
LISTINGS:
The PROW-8 has NSF and C-ETL-US listings.
