NVSBL Smartq T10 Manuale utente
MID USER MANUAL
COMPATIBLE
Designed in Mars. Made in Pluto.
SmartQ T10
INDEX
- NVSBL SmartQ T10 Quick Start Guide
- Outline
1 - Basic Uses
2 - Basic Operations
3 - Main Interface
4 - Input Method Switch
5 - Wi-Fi Network Connection
6 - Bluetooth
7 - Browser
8 - Memory and External Storage
9 - Manage Applications
10 - Settings
11 - Audio and Video Playback
12 - Intelligent Reader
13 - Firmware Upgrade
14 - FAQ - Frequently Asked Questions
SmartQ T10
NVSBL SmartQ T10
Quick Start Guide
Please open the package, and make sure it contains
the following items.
DC 5V 2A Charger Quick Start Guide (with warranty
certificate)
USB Cable NVSBL SmartQ T10
Understanding NVSBL SmartQ T10
SmartQ T10
Outline:
Welcome to use NVSBL SmartQ T10
NVSBL SmartQ T10 uses Google Android2.2 operating system, which is different from the traditional PC in that the
Tablet PC is mainly operated through the touch screen, assisted with physical buttons.
This Quick Start Guide is written based on NVSBL SmartQ T10 Android2.2 V1.0 firmware. For the subsequent firm-
ware update features, please refer to NVSBL official website about firmware upgrade instructions.
Firmware is similar to traditional computer operating systems, and NVSBL will update the product’s firmware to
enhance the T10 features and fixe identified problems. Please regularly check updates of the NVSBL official web-
site download center for the latest firmware. If you have system problems in the use of T10, please also follow the
firmware upgrade method to reinstall the T10 firmware. Reinstallation of the firmware, similar to reinstallation of
the computer system, can restore T10 to its original state so as to solve the usage problem caused by the system.
The Quick Start Guide gives general introduction of the use of NVSBL SmartQ T10 in the following 15 categories:
Basic Uses, Basic Operations, Main Interface, Input Method Switch, Wi-Fi Network Connection, 3G Network Con-
nection, Bluetooth File Transfer, Browser, Memory and External Storage, Manage Applications, Settings, Audio and
Video Playback, Intelligent Reader, Firmware Upgrades and FAQ.
SmartQ T10
1 - Basic Uses
Charge
Please connect the charger to the 220V mains power
outlet, the other end into the T10 charging port. The
logo backlight will blink, indicating it is being charged.
When the battery is fully charged, the logo backlight
will remain on but no longer blinking. If it is in the
power-on state, the battery charging icon on the upper
right corner of the screen will appear animation tips.
Power-on / Sleep / Shutdown:
Power-on: Press the power button, the screen will dis-
play the boot prompt. At this time, please wait a mo-
ment till the Android system is fully started and enters
the main interface.
Sleep:
When the system is powered on and you will not be
using it for a while, you can always press the power
button to get T10 into sleep state, it will then turn off
the screen and get Into standby state,
SmartQ T10
in which very little power will be consumed. When you
need to continue to use T10, just press the power but-
ton again to wake up T10 to resume your operations
suspended by the sleep state.
Shutdown:
When you expect not to use T10 for more than a week,
hold the power button for two seconds, the “Options”
window will be pop up. Choose the shutdown option to
completely shut down the T10 power.
If the system crashes and can not be properly turned
off, please press the power button for 6 seconds to
force power off.
2 - Basic Operations
Android operating system’s touch screen operations
have the following three main types:
1. Touch:
Use finger to lightly touch the icon, option or menu on
the screen to start or execute the appropriate proce-
dures and functions.
2. Press and Hold:
Press and hold down the icon on the screen for more
than 1 second, to simulate the mouse’s right button
click function for more options display.
3. Drag:
Press and hold down a list or a control bar, then move
your finger up and down or left and right to drag the list
or control bar.
If the pointing at the touch screen is not accurate,
touch screen calibration will be needed. Tap the Set-
tings tab -> “screen calibration.”
SmartQ T10
(Settings menu)
According to the system prompt, orderly and accurately
tap the center of the five cross icons, until the system dis-
plays the following window:
Tap “Yes” to complete the calibration, and the accu-
rate response of the touch screen will be restored.
SmartQ T10
Menu key: Bring up the menu function
Main interface key: Tap to return to the main screen. Hold
down to display the list of recently run applications. You can
switch the current application in the list
Return key: Get back to the previous screen;
Volume up key: Increase the volume
Volume down key: Decrease the volume
Screen rotation switch: Move up the switch to turn
on the automatic screen rotation, move down to turn
off feature.
3 - Main Interface
1
2
3
1 - Status Bar
2 - Quick Power Switch
3 - Tab Bar
SmartQ T10
The main interface contains three items: the status bar, fast
power switch and the tab bar, in which the tab bar from left
to right has the Settings tab, Intellectual Reading tab, All
Programs tab, Media Player tab and Browser tab.
The main interface consists of three screens. View the con-
tent of each screen by dragging around.
Tab for all programs:
Tap the tab for all programs to expand the list of application
programs, and browse all the installed applications. In this
list, tap an icon to run the corresponding application pro-
gram. Holding in different directions, the screen layout may
be different.
The firmware factory default functionalities of th
applications are as follows:
SmartQ T10
Multi-tasking switch:
Long press the main interface key to display the most
recent program. Tap the window application icon to
return to the application of last exit.
Status Bar:
The status bar can prompt various local conditions
of current executions, of which the commonly used
icons and their meanings are as follows:
SmartQ T10
