OCZ VERTEX 2 - DATASHEET 2 Manuale utente

to change prices, products, or specifications without notice.

OCZ Vertex 2 SATA II 1.8”Solid State Drives deliver the same industry-leading performance as the 2.5”

edition in a smaller form factor to accommodate a wider range of mobile applications and devices. Designed to

excel in both sequential and random read/write speeds (up to 50,000 4KB random write IOPS), the 1.8”

Vertex 2 maximizes productivity for state-of-the-art computing. Using the latest controller technology, the 1.8”

Vertex 2 not only provides a faster, more responsive PC experience, but promotes cooler, quieter, and more

energy efficient conditions compared to traditional mechanical hard drives. Built with SATA 3Gb/s, the Vertex 2

easily integrates into today’s mobile platforms and comes complete with TRIM support for the ultimate Windows

7 notebook upgrade.

D e s i g n & T e c h n o l o g y :

A p p l i c a t i o n s :

Part Numbers

UPC

Vertex 2 40GB

OCZSSD1-2VTX40G

842024021889

Vertex 2 60GB

OCZSSD1-2VTX60G

842024018063

Vertex 2 90GB

OCZSSD1-2VTX90G

842024021872

Vertex 2 120GB

OCZSSD1-2VTX120G

842024018087

Vertex 2 180GB

OCZSSD1-2VTX180G

842024021896

Vertex 2 240GB

OCZSSD1-2VTX240G

842024018070

High-End Notebooks

Notebooks

Netbooks

O C Z V e r t e x 2 S e r i e s

S A T A I I 1 . 8 i n S o l i d - S t a t e D r i v e s

to change prices, products, or specifications without notice.

P E R F O R M A N C E

Max Read¹

up to 285 MB/s

Max Write¹

up to 275 MB/s

Sustained Write²

up to 250 MB/s

4KB Random Write³

50,000 IOPS

Seek Time

0.1 ms

P H Y S I C A L

Usable Capacities (IDEMA)

40GB, 60GB, 90GB, 120GB, 180GB, 240GB

NAND Components

Multi-Level Cell (MLC)

Interface

SATA II / 3Gbps

Form Factor

1.8 Inch

Controller

SandForce 1222

Dimensions (L x W x H)

78.5 x 54 x 5 mm

Weight

29g

E N V I R O N M E N T A L

Power Consumption

Idle: 0.5 Watts Active: 2 Watts

Operating Temperature

0°C ~ +70°C

Storage Temperature

-45°C ~ +85°C

Shock Resistance

1500G

Certifications

RoHS, CE, FCC

R E L I A B I L I T Y

MTBF

2 million hours

ECC Recovery

Up to 24 bytes correctable per 512-byte sector

Product Health Monitoring

Self-Monitoring, Analysis and Reporting Technology (SMART)

C O M P A T I B I L I T Y

Serial ATA (SATA)

Fully compliant with Serial ATA International Organization: Serial ATA Revision 2.6. Fully compliant with

ATA/ATAPI-7 Standard Native Command Queuing (NCQ)

Operating System

Windows XP 32-Bit and 64-Bit; Windows Vista 32-Bit & 64 Bit; Windows 7 32-Bit and 64-Bit;

Linux, Mac OSX (Qualified at Apple Labs)

Power Requirements

Micro SATA Power Connector

A D D I T I O N A L F E A T U R E S

Performance Optimization

TRIM (requires OS support)

Service & Support

3-Year Warranty, Toll-Free Tech Support, 24 Hour Forum Support, Firmware Updates

¹ Maximum Sequential Speeds are determined using ATTO

² Sustained transfer rate is measured using Iometer 2008, Queue Depth 32, 128KB

³ Small file I/O performance is measured using Iometer 2008, Queue Depth 32, 4KB Aligned

S p e c i f i c a t i o n s :

O C Z V e r t e x 2 S e r i e s

S A T A I I 1 . 8 i n S o l i d - S t a t e D r i v e s

to change prices, products, or specifications without notice.

M e c h a n i c a l S p e c i f i c a t i o n s :

O C Z V e r t e x 2 S e r i e s

S A T A I I 1 . 8 i n S o l i d - S t a t e D r i v e s
