OHAUS Traveler Manuale utente

Traveler™ Scales

Instruction Manual

Básculas Traveler™

Manual de instrucciones

Balances Traveler™

Manuel d’instructions

Traveler™ Waagen

Bedienungsanleitung

Bilance Traveler™

Manuale di istruzioni

Compliance

Compliance to the following standards is indicated by the corresponding mark on the

product

This product conforms to the EMC directive 2004/108/EC and the Low

Voltage Directive 2006/95/EC. The complete declaration of Conformity is

available from Ohaus Corporation

AS/NZS4251.1 Emission; AS/NZS4252.1 Immunity

Disposal

In conformance with the European Directive 2002/96 EC on Waste

Electrical and Electronic Equipment (WEEE) this device may not be

disposed of in domestic waste. This also applies to countries outside the

EU, per their specific requirements.

Please dispose of this product in accordance with local regulations at the

collecting point specified for electrical and electronic equipment.

If you have any questions, please contact the responsible authority or the

distributor from which you purchased this device.

Should this device be passed on to other parties (for private or professional

use), the content of this regulation must also be related.

Thank you for your contribution to environmental protection.

ISO 9001 Registration

In 1994, Ohaus Corporation, USA, was awarded a certificate of registration to ISO 9001

by Bureau Veritus Quality International (BVQI), confirming that the Ohaus quality

management system is compliant with the ISO 9001 standard’s requirements. On May

15, 2003, Ohaus Corporation, USA, was re-registered to the ISO 9001:2000 standard.

iii

FCC Note

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Note

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Conformidad

La conformidad a los estándares siguientes es indicada por la marca correspondiente

en el producto

Este producto se conforma con el EMC 2004/108/EC directivo y la baja

tensión 2006/95/EC directivo. El declaración completo de la conformidad

está disponible de Ohaus Corporation.

Eliminación de residuos

De conformidad con las exigencias de la directiva europea 2002/96 CE

sobre residuos de aparatos eléctricos y electrónicos (RAEE), este equipo no

puede eliminarse como basura doméstica. Esta prohibición es asimismo

válida para los países que no pertenecen a la UE cuyas normativas

nacionales en vigor así lo reflejan.

Elimine este producto, según las disposiciones locales, mediante el

sistema de recogida selectiva de aparatos eléctricos y electrónicos.

Si tiene alguna pregunta al respecto, diríjase a las autoridades

responsables o al distribuidor que le proporcionó el equipo.

Si transfiere este equipo (por ejemplo, para la continuación de su uso con

fines privados, comerciales o industriales), deberá transferir con él esta

disposición.

Muchas gracias por su contribución a la conservación medioambiental

Registro ISO 9001

En 1994, Bureau Veritus Quality International (BVQI) le otorgó a Ohaus Corporation,

EE.UU., un certificado de registro ISO 9001 el cual confirma que el sistema

administrativo de calidad de Ohaus cumple con los requerimientos del estándar ISO

9001. En mayo 15 del 2003, Ohaus Corporation, EE.UU., fue registrada nuevamente

al estándar ISO 9001:2000.

Conformité

La conformité aux normes suivantes est indiquée par la marque correspondante sur le

produit

Ce produit se conforme à l'EMC 2004/108/EC directif et la basse tension

2006/95/EC directif. La déclaration complète de la conformité est fournie

par Ohaus Corporation.

Elimination

En conformité avec les exigences de la directive européenne 2002/96 CE

relative aux déchets d‘équipements électriques et électroniques (DEEE), cet

appareil ne doit pas être éliminé avec les déchets ménagers. Logiquement,

ceci est aussi valable pour les pays en dehors de l’UE conformément aux

règlementations nationales en vigueur.

Veuillez éliminer cet appareil conformément aux prescriptions locales dans

un conteneur séparé pour appareils électriques et électroniques.

Pour toute question, adressez-vous aux autorités compétentes ou au

revendeur chez qui vous avez acheté cet appareil.

En cas de remise de cet appareil (p. ex. pour une utilisation privée ou

artisanale/industrielle), cette prescription doit être transmise en substance.

Merci pour votre contribution à la protection de l’environnement.

Enregistrement ISO 9001

En 1994, le Bureau Veritus Quality International (BVQI) a octroyé la certification

d’enregistrement ISO 9001 à Ohaus Corporation, États-Unis d’Amérique, confirmant que

le système de gestion de la qualité Ohaus était conforme aux conditions normalisées de

l’ISO 9001. Le 15 mai 2003, Ohaus Corporation, États-Unis d’Amérique, a été ré-

enregistrée à la norme ISO 9001:2000.

Befolgung

Befolgung zu den folgenden Standards wird durch die entsprechende Markierung auf

dem Produkt angezeigt

Dieses Produkt paßt sich an das EMC richtungweisendes 2004/108/EC und

die Niederspannung richtungweisendes 2006/95/EC an. Die komplette

Erklärung der Übereinstimmung ist von Ohaus Corporation vorhanden.

Entsorgung

In Übereinstimmung mit den Anforderungen der Europäischen Richtlinie

2002/96 EG über Elektro- und Elektronik-Altgeräte (WEEE) darf dieses

Gerät nicht mit dem Hausmüll entsorgt werden. Sinngemäss gilt dies auch

für Länder ausserhalb der EU entsprechend den geltenden nationalen

Regelungen.

Bitte entsorgen Sie dieses Produkt gemäss den örtlichen Bestimmungen in

einer getrennten Sammlung für Elektro- und Elektronikgeräte.

Bei allfälligen Fragen wenden Sie sich bitte an die zuständige Behörde oder

den Händler, bei dem Sie dieses Gerät erworben haben.

Bei Weitergabe dieses Gerätes (z.B. für private oder gewerbliche/industrielle

Weiternutzung) ist diese Bestimmung sinngemäss weiterzugeben.

Vielen Dank für Ihren Beitrag zum Schutz der Umwelt.

Registrierung nach ISO 9001

Im Jahr 1994 wurde der Ohaus Corporation, USA, ein Zertifikat der Registrierung nach

ISO 9001 vom Bureau Veritus Quality International (BVQI) verliehen, in dem bestätigt

wird, dass das Ohaus-Qualitätsmanagementsystem den Anforderungen der Norm ISO

9001 entspricht. Am 15. Mai 2003 wurde die Ohaus Corporation, USA, gemäß der

Norm ISO 9001:2000 neu registriert.

Conformità

La conformità ai seguenti campioni è indicata dal contrassegno corrispondente sul

prodotto

Questo prodotto è conforme al EMC 2004/108/EC direttivo e la bassa

tensione 2006/95/EC direttivo. La dichiarazione completa di conformità è

disponibile da Ohaus Corporation.

Smaltimento

In conformità a quanto stabilito dalla Direttiva Europea 2002/96 CE in

materia di apparecchi elettrici ed elettronici (RAEE), questo strumento non

può essere smaltito come i normali rifiuti. Tale presupposto resta valido

anche per i Paesi al di fuori dei confini della UE, conformemente alle norme

nazionali in vigore.

Si prega quindi di smaltire questo prodotto separatamente e in modo

specifico secondo le disposizioni locali relative alle apparecchiature

elettriche ed elettroniche.

Per qualsiasi chiarimento, rivolgersi agli enti preposti o al rivenditore

dell‘apparecchiatura stessa.

In caso di cessione dello strumento (per es. per ulteriore utilizzo privato o

aziendale/industriale), si prega di comunicare anche questa disposizione.

Si ringrazia per il contributo alla tutela dell‘ambiente.

Registrazione ISO 9001

Nel 1994, Ohaus Corporation, USA, ha ricevuto il certificato di registrazione ISO 9001

da Bureau Veritus Quality International (BVQI), come conferma che il sistema di

gestione della qualità Ohaus risponde alle caratteristiche standard di ISO 9001. Il 15

Maggio 2003, Ohaus Corporation, USA, è stata riregistrata per la normativa ISO

9001:2000.

vii

viii

Traveler™ Scales

EN-1

1. INTRODUCTION

This manual contains installation, operation and maintenance instructions for the

Traveler Scales. Please read the manual completely before using the scale.

1.1 Safety Precautions

Please follow these safety precautions:

• Verify that the Power Adapter input voltage matches the local power supply

voltage.

• Use the scale only in dry locations.

• Do not operate the scale in hostile environments.

• Do not drop loads on the pan.

• Do not place the scale upside down on the pan.

• Service should be performed only by authorized personnel.

1.2. Controls

Figure 1-1. Controls.

TABLE 1-1. CONTROL FUNCTIONS

Key Name Function

•Primary function (Short Press) – If scale is Off, turn On. If

scale is on, perform Zero/Tare function

•Secondary function (Long Press) – Turn scale Off

On-Zero

Off

Yes

•Menu function – (Yes) This key is used to accept the

currently displayed setting

•Primary function (Short Press) – Send the current display

value to serial port if installed

Cal •Secondary function (Long Press) – Starts Span

calibration as available in Menu

Traveler™ Scales

EN-2

Key Name Function

•Primary function (Short Press)– Advances to next

available unit

Unit

No •Menu function – (No) This key is used to reject the

displayed setting and advance to next available setting

2. INSTALLATION

2.1 Package Contents

• Scale

• Pan

• Draft Shield

• Power Adapter

• Calibration Weight (on some models, see Table 6.1)

• Instruction Manual

• Warranty Card

2.2. Location

Use the scale on a firm, steady surface. Avoid locations with excessive air currents,

vibrations, heat sources, or rapid temperature changes.

2.3. Transportation Lock, Calibration Lock & Pan Installation

Before using the scale the Transportation Lock must be released. At the bottom of the

scale slide the locking pin to the position. See Figures 2-1.

If the scale is to be calibrated by the user ensure that the Calibration Lock is set to

position. See Figure 2-2.

Install the metal pan over the plastic sub-platform.

Figure 2-1. Release Transportation Lock Figure 2-2. Release Calibration Lock

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali OHAUS Scala

OHAUS

OHAUS Pioneer Manuale utente

OHAUS

OHAUS CL Series Manuale utente

OHAUS

OHAUS SCOUT PRO Manuale utente

OHAUS

OHAUS Valor 1000 Manuale utente

OHAUS

OHAUS Emerald Manuale utente

OHAUS

OHAUS AV412 Manuale utente

OHAUS

OHAUS Voyager Balances Manuale utente

OHAUS

OHAUS Courier 3000 Manuale utente

OHAUS

OHAUS 4000W Series Manuale utente

OHAUS

OHAUS CS Series Manuale utente

OHAUS

OHAUS Ranger Count Plus Manuale utente

OHAUS

OHAUS Adventurer Pro AV53 Manuale utente

OHAUS

OHAUS 1119D Manuale utente

OHAUS

OHAUS Defender 3000 Series Manuale utente

OHAUS

OHAUS TROOPER COUNT Manuale utente

OHAUS

OHAUS Voyager V10640 Manuale utente

OHAUS

OHAUS VN Series Manuale utente

OHAUS

OHAUS a-AB33PH Manuale utente

OHAUS

OHAUS Ranger Manuale utente

OHAUS

OHAUS Defender 2000 Series Manuale utente

OHAUS

OHAUS Compass CX Series Manuale utente

OHAUS

OHAUS SKIPPER 6000 Guida rapida

OHAUS

OHAUS Ranger 3000 Series Manuale utente

OHAUS

OHAUS SD Series Manuale utente

Manuali Scala popolari di altre marche

AWS

AWS ZEO-50 Manuale utente

Gima

Gima Glass Body Fat Analyzer Manuale elenco delle parti

Seca

Seca 374 Manuale utente

TEC

TEC TEC SL59 SERIES Manuale utente

Axis

Axis B/E Series Manuale utente

Alecto

Alecto ACW-40 Manuale utente

Rice Lake

Rice Lake MSI-4260 IS Manuale utente

IKA

IKA RCT basic safety control Manuale utente

ADE

ADE M20011 Manuale utente

Duronic

Duronic KS3000 Manuale utente

Digi

Digi SM-720 Manuale utente

Cardinal

Cardinal CS Series Manuale utente

Korona

Korona Kastella Manuale utente

A&D

A&D FC-50Ki Manuale utente

BDA

BDA CAMARGUE Manuale utente

Tanita

Tanita HD-357 Manuale utente

Leifheit

Leifheit 03173 Manuale utente

Lumme

Lumme LU-1340 Manuale utente
