Quick Start Guide Valor™2000

Ohaus Corporation www.ohaus.com iValor

™

2000 Quick Start Guide

PREPARATION FOR USE

IMPORTANT: Unscrew the two rear leveling

feet slightly, to allow proper airflow inside the

scale, and relieve any internal pressure. Then

level the scale.

Before cleaning the scale, the rear leveling

feet must be screwed in tightly to avoid entry

of water inside the scale.

AC power may be used when battery power is

not available. Remove the rubber seal in the

back. Connect the AC adapter plug to the

input jack and plug it into a power outlet.

Note: To prevent water ingress during use,

insert rubber Seal into the input jack recess.

SELECTING THE LOCATION

Place on a firm, steady surface.

Avoid locations with excessive air current,

vibrations, heat sources, or rapid temperature

changes.

Level the scale: Adjust leveling feet so bubble

is centered.

SAFETY PRECAUTIONS

For safe and dependable operation of this product, please comply with the following

safety precautions:

•Verify that the input voltage printed on the power Adapter and the plug type matches

the local power supply.

•Make sure that the power cord does not pose an obstacle or tripping hazard.

•Disconnect the product from the power supply when cleaning.

•Do not operate this product in hazardous or unstable environments.

•Do not drop loads on the pan.

•Use only approved accessories and peripherals, as available.

•Operate the product only under ambient conditions specified in the Instruction Manual.

•Service should be performed by authorized personnel only.

Level

Bubble

Seal

Leveling

Feet

Valor™2000 Quick Start Guide

Valor

™

2000 Quick Start Guide ii Ohaus Corporation www.ohaus.com

CONTROLS

Front Display

Rear Display

Button

Primary Function

(Short Press)

ON/ >O/T<

Turns scale ON.

If scale is On: Sets zero.

Performs a tare operation.

UNITS

Changes the weighing Unit.

Secondary Function

(Long Press)

Off

Turns scale off.

Enter the User menu.

Menu Function

(Short Press)

Yes

Accepts the current setting

on the display.

Advances to the next menu

or menu item.

Rejects the current setting on

the display and advances to

the next available setting.

Quick Start Guide Valor™2000

Ohaus Corporation www.ohaus.com iii Valor

™

2000 Quick Start Guide

OPERATION

Turning Scale On/Off

Press ON. The scale performs a display test, displays the model/software

version, and then enters the active weighing mode.

To turn the scale off, press and hold Off until OFF is displayed.

Zero Operation

Press 0/T to zero the weight display. The scale must be stable to accept

zero operation.

Manual Tare

Place a container on the weighing pan and press 0/T.

The display shows a net value of “0”.

To clear the Tare value, press 0/T with the pan empty.

Changing Units of Measure

Press UNITS to display the next available measuring unit.

Choose from kg, g, lb, and oz.

Only measuring units enabled in the Unit Menu will be displayed.

(See back page.)

Verify the scale: place a known mass on it and check if the reading is accurate.

If not, calibrate, using the Calibration Guide.

Valor™2000 Quick Start Guide

Valor

™

2000 Quick Start Guide iv Ohaus Corporation www.ohaus.com

MENU NAVIGATION

Press and hold Menu until MENU is displayed, then release it.

Press Yes to enter the displayed menu or press No to advance to the next menu.

When viewing the menu setting, press Yes to accept the setting, or press No to change it, then

press Yes to accept the setting and move to the next menu.

When End is displayed, press Yes to exit the menu.

MENU STRUCTURE

Programmable features of the Valor 2000 scales are contained in menus which are accessed

through the Display Panel’s control switches. See the Instruction Manual for more details.

*When LFT is ON, the Calibration, Resolution, Unit, and AZT menus are inaccessible.

*80252980*

P/N 80252980
