Olympus CAMEDIA C-2020 Zoom Guida alla configurazione
OLYMPUS DIGITAL CAMERA
4
PRINTING
PICTURES
140
PRINTING PICTURES
There are two types of printing available with this camera.
One is Card-Print, which stores data conforming to the “Design rule for
Camera File system/DCF” standard in the card for making prints using a
printer or lab that supports this system. (p. 141 ~ 145)
The other is Direct-Print, which is for use with the Olympus P-330N, P-
330 or P-300 printer.
●When using the P-330N/P-330 printer, simply insert a card that
contains images into the printer and direct-print them. No cables are
necessary.
(The procedure for making prints must be performed on the printer.
See the printer instructions for details.)
●When using the P-300 printer, connect the camera to the printer to
make prints. (p. 146 ~ 156)
141
CARD-PRINT
PRINT-RESERVE (CARD)
You can store data for making prints with a printer or at a lab that
supports this system. (p. 140)
Set the Mode dial to .
Display the picture you want
to print, then press the
Shutter release button.
•appears on
the LCD monitor.
• To cancel, press the Shutter
release button again.
Press the right/left arrows on
the Jog dial to select the
number of pictures to be
printed.
Press the OK button.
•appears on the LCD
monitor.
Repeat until all the selections
are made.
5
4
3
2
1
Note:
•With the P-330N/P-330 printer, the number of pictures to be printed must
be set on the printer. Pictures with a frame number greater than 256
cannot be printed.
• The data will remain in the card until the setting is changed.
•To cancel all of the selections, select in the Print-All (card) mode.
(p. 143)
• Functions may not work fully depending on the printer or the lab used.
• It may take a while to store data in the card.
1
2
4
53
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
’99.12.23 21:56 32
0123456
SQ
x
142
Monitor display
Use
For storing data for Print-All (card). (p. 143)
For storing data for Date-Print (card). (p. 144)
For storing data for Index-Print (card). (p. 145)
CARD
INDEX
➠
➠
➠
* When the Mode dial is set to and a still picture is displayed on the
LCD monitor. (Page 2/2 of the Menu.) (p. 39)
STILL PICTURE DISPLAY MENU
(CARD-PRINT)
143
PRINT-ALL (CARD)
You can store data for printing all the pictures in the card. (p. 140)
Set the Mode dial to , and
display a still picture.
Press the Menu button to
display the Menu.
Press the top/bottom arrows
on the Jog dial to select .
•To cancel, press the Menu
button.
Press the right arrow on the
Jog dial, then press the
top/bottom arrows to select
ON.
Press the left arrow on the
Jog dial to confirm the setting.
Press the OK button to save
the setting and cancel the
Menu.
• Make sure to press the OK
button while is displayed
on the LCD monitor.
6
5
4
3
2
1
Note:
•The last number set for the number of pictures to be printed in Print-
Reserve (p. 141) will be used for printing all the pictures.
• Pictures taken after this function is selected will not be printed.
• cancels all the settings made for Card-Print. (p. 141 ~ 145)
• The data will remain in the card until the setting is changed.
•With the P-330N/P-330 printer, pictures with a frame number greater
than 256 cannot be printed.
• It may take a while to store data in the card.
1
6
543
2
SHQ
32
[2/2]
OFF
ON
CARD
INDEX
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
144
DATE-PRINT (CARD)
You can store data for printing the date with pictures. (p. 140)
Set the Mode dial to , and
display a still picture.
Press the Menu button to
display the Menu.
Press the top/bottom arrows
on the Jog dial to select .
• To cancel, press the Menu
button.
Press the right arrow on the
Jog dial, then press the
top/bottom arrows to select
TIME or DATE.
Press the left arrow on the
Jog dial to confirm the setting.
Press the OK button to save
the setting and cancel the
Menu.
• Make sure to press the OK
button while is displayed
on the LCD monitor.
6
5
4
3
2
1
Note:
• Set the date beforehand.
• Pictures taken after this function is selected will not be printed.
•Unless OFF is selected in All Reset, the setting will be canceled when
the power is turned off. (p. 172)
•When using the P-330N/P-330 printer, Date-Print must be set on the
printer.
•It may take a while to store data in the card.
1
6
543
2
SHQ
32
[2/2]
CARD
INDEX
OFF
TIME
DATE
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
145
INDEX-PRINT (CARD)
You can store data for making index prints. (p. 140)
Set the Mode dial to , and
display a still picture.
Press the Menu button to
display the Menu.
Press the top/bottom arrows
on the Jog dial to select CARD
INDEX.
• To cancel, press the Menu
button.
Press the right arrow on the
Jog dial, then press the
top/bottom arrows to select
ON.
Press the left arrow on the
Jog dial to confirm the setting.
Press the OK button to save
the setting and cancel the
Menu.
• Make sure to press the OK
button while CARD INDEX is
displayed on the LCD monitor.
6
5
4
3
2
1
Note:
• The print format varies depending on the printer or lab used.
• Pictures taken after this function is selected will not be printed.
•Unless OFF is selected in All Reset, the setting will be canceled when
the power is turned off. (p. 172)
•When using the P-330N/P-330 printer, Index-Print must be set on the
printer.
•It may take a while to store data in the card.
1
6
543
2
SHQ
32
[2/2]
CARD
INDEX
OFF
ON
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
146
DIRECT-PRINT
PRINTING WITH THE P-300
By connecting the camera to the P-300 printer with the direct connect
cable, pictures can be printed directly from the camera.
Make sure that the power of the printer and the camera are off before
connecting.
Remove the lens cap.
Connect the computer connector of the camera to the serial
port of the printer with the provided RS-232C cable and
conversion connector for Mac. Turn on the printer.
2
1
Serial port
Computer connector
P-300
147
Set the Mode dial to to
turn on the LCD monitor.
Select the picture you want to
print using the Jog dial.
Enter the number of copies to
be printed on the printer, then
press the DIRECT PRINT
button on the printer to start
printing.
5
4
3
Note:
•The power of the printer and the camera must be OFF in order to be
connected.
•If the printer does not start printing when the DIRECT PRINT button is
pressed, turn off the printer, connect the cables correctly, turn on the
printer and press the DIRECT PRINT button again.
•The LCD monitor display goes off during printing, and other operations
are disabled.
• The date can be printed as well. (p. 156)
• The use of the optional AC adapter is recommended.
• Images taken in TIFF (non-compression) cannot be printed.
3
4
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
148
INDEX PRINT (P-300)
Index prints can be made.
Connect the camera to the
printer, then set the Mode dial
to .
• See page 146 for connection to
the printer.
Select the Index-Display
mode. (p. 95)
Enter the number of copies to
be printed on the printer, then
press the DIRECT PRINT
button to start printing.
• After printing, the display
advances to the next group of
index pictures.
• The date will be always printed
in Index Print. Set the date
beforehand.
3
2
1
1
49 50 51
52 53 54
55 56 57
P
A/S/M
OFF
P
O
W
E
R
/
M
O
D
E
D
I
A
L
