Olympus Stylus 1000 Guida all'installazione

Advanced

Manual

Menu operations

Button operations

Printing pictures

Using OLYMPUS Master

Getting to know your

camera better

Appendix

Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please

read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual

in a safe place for future reference.



We recommend that you take test shots to get accustomed to your camera before taking important photographs.



In the interest of continually improving products, Olympus reserves the right to update or modify information

contained in this manual.



The screen and camera illustrations shown in this manual were produced during the development stages

and may differ from the actual product.



DIGITAL CAMERA

Quick Start Guide

This manual will help you get started

using your camera right away.

2EN

Contents

Test out the functions of the camera

buttons by following along with the

illustrations.

Learn how to print pictures you have

taken.

Learn how to transfer and save

pictures to a computer.

Find out more about camera

operations and how to take better

pictures.

Read about convenient functions and

safety precautions on how to use your

camera more effectively.

Learn about the menus that control the

functions and settings for basic

operation.

Button operations

Menu operations

Printing pictures

Getting to know your camera

better

Appendix

P. 10

P. 17

P. 35

P. 50

P. 63

Using OLYMPUS Master

P. 41

Quick Start Guide

P. 3

EN 3

Quick Start Guide

Gather these items (box contents)

Pull the strap tight so that it does not come loose.

Digital Camera Strap LI-12B

Lithium Ion Battery

LI-10C Battery Charger USB Cable AV Cable OLYMPUS Master

Software CD-ROM

Items not shown: Advanced Manual (this manual), Basic Manual, and warranty card.

Contents may vary depending on purchase location.

Attach the strap

4EN

Quick Start Guide

Prepare the battery

a. Charge the battery

Battery comes partially charged.

b. Insert the battery in the camera

For details on inserting an optional xD-Picture Card™ (hereinafter referred

to as “the card”), please refer to “Inserting and removing the card” (P. 64).

Charging Indicator

Light On (Red): Charging

Light On (Green): Charging complete

(Charging time: Approx. 2 hours)

AC Wall Outlet

Power Cable

Battery Charger

Lithium Ion Battery

•

To remove the battery, slide the

battery lock knob in the

direction of the arrow.

•

Make sure to insert the battery in the

direction of the symbol until locked in

place.

Battery lock knob

EN 5

Quick Start Guide

Turn the camera on

This explains how to turn on the camera in shooting mode.

a. Set the mode dial to K.

Still picture shooting modes

b. Press the obutton

To turn off the camera, press the obutton once again.

This function allows you to shoot with the camera's automatic settings.

This function allows you to shoot pictures by selecting a scene according to the

shooting condition.

This function allows you to set the target items by following the shooting guide

displayed on the screen.

•

When the date and time have

not yet been set, this screen

will appear.

When viewing pictures

(playback mode)

When shooting movies

(shooting mode)

When shooting still pictures (shooting mode)

oButton

CANCEL

Y/M/D

Y / M / D

TIME

T I M E

----.--.-- --:--

Hint

The directions of the arrow pad (1243) is indicated

with 1243 in this manual.

6EN

Quick Start Guide

Set date and time

a. Press the 1Fbutton and the 2Ybutton to select [Y].

•

The first two digits of the year are fixed.

b. Press the 3#button.

c. Press the 1Fbutton and the 2Ybut-

ton to select [M].

d. Press the 3#button.

About the date and time setting screen

CANCEL

Y/M/D

Y / M / D

TIME

T I M E

----.--.-- --:--

Y-M-D (Year-Month-Day)

Exits a setting.

Minute

Date formats (Y-M-D,M-D-Y,D-M-Y)

Hour

2YButton

1FButton

CANCEL

2006

.--.-- --:--

TIME

T I M E

Y/M/D

Y / M / D

3#Button

2006

.-- --:--

CANCEL

TIME

T I M E

Y/M/D

Y / M / D

EN 7

Set date and time

Quick Start Guide

e. Press the 1Fbutton and the 2Ybut-

ton to select [D].

f. Press the 3#button.

g. Press the 1Fbutton and the 2Ybut-

ton to select “hour”, “minute”.

•

The time is displayed in the 24-hour format.

h. Press the 3#button.

i. Press the 1Fbutton and the 2Ybut-

ton to select [Y/M/D].

j. After all items have been set, press the obutton.

•

For precise time setting, press the

button as the time signal strikes 00 seconds.

2006

--:--

CANCEL

TIME

T I M E

Y/M/D

Y / M / D

CANCEL

SET

2006

TIME

T I M E

Y/M/D

Y / M / D

CANCEL

SET

2006

Y/M/D

Y / M / D

TIME

T I M E

oButton

3648

×2736

2736

[IN

]

[ ]

8EN

Quick Start Guide

Take a picture

a. Hold the camera

c. Shoot

Horizontal grip Vertical grip

b. Focus

The card access lamp blinks.

Shutter Button

(Pressed

halfway)

3648

×2736

2736

[IN

]

[ ]

The green lamp indicates the focus and

exposure are locked.

Place this mark over your

subject.

The number of remaining

still pictures is displayed.

(Pressed

completely)

Shutter Button

EN 9

Quick Start Guide

Review your pictures

a. Set the mode dial to q.

a. As described in a. above, display the picture you want to erase.

b. Press the Sbutton.

c. Press the 1Fbutton to select [YES] and press the obutton to

erase the image.

12:30

'06.11.26

100-0001

1 0 0 - 0 0 0 1

[IN

]

Mode Dial

Arrow Pad

Next Picture

Prev. Picture

Erase pictures

SButton

SET

BACK

YES

[IN]

ERASE

1FButton

SET

BACK

YES

ERASE

10 EN

Button operations

Shooting still pictures

Set the mode dial to

and lightly press the shutter button (halfway). The green

lamp lights when the focus and exposure are locked (focus lock). Press the shutter button all the

way (completely) to take the picture.

Focus Lock - Locking the focus before composing your

shot

Compose your picture with the focus locked, and then completely

press the shutter button to shoot a picture.

•

When the green lamp blinks, the focus is not adjusted properly. Try

locking the focus again.

1obutton Turning the camera on and off

Power on: Shooting mode

•

Monitor turns on

•

Lens extends

Playback mode

•

Monitor turns on

2Shutter button Shooting pictures

[IN

]

[ ]

3648

×2736

2736

3Playback mode

Shooting modes

Shooting mode

1 2

Flash mode

Self-timer

Macro mode/

Super macro mode

3648

×2736

2736

[IN

]

[ ]

Green lamp
