Olympus VR-350 Manuale utente

Instruction Manual

VR-360/D-760

VR-350/D-755

VR-340/D-750

DIGITAL CAMERA

●Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please read these

instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for

future reference.

●We recommend that you take test shots to get accustomed to your camera before taking important photographs.

●In the interest of continually improving our products, Olympus reserves the right to update or modify information

contained in this manual.

●The screen and camera illustrations shown in this manual were produced during the development stages and may

differ from the actual product. Unless otherwise speciﬁed, the explanation about these illustrations is provided for

VR-360/D-760.

Other accessories not shown: warranty card

Contents may vary depending on purchase location.

Checking the contents of the box

LI-50B Lithium

Ion Battery

USB cable

(CB-USB7)

OLYMPUS

Setup

CD-ROM

Strap AV cable

(CB-AVC5)

F-2AC

USB-AC adapter

Digital camera

Camera unit

1Connector cover*1

2HDMI mini connector*1

3Strap eyelet

4Multi-connector

5Battery/card compartment

cover

6Battery/card compartment

lock

7Flash

8Self-timer lamp

AF illuminator

9Lens

10 Microphone

Tripod socket

12 Speaker

Names of Parts

*1 VR-360/D-760 only

1 4

1nbutton

2 Shutter button

3Monitor

4Zoom lever

5Rbutton (shooting movies)

6qbutton (switch between

shooting and playback)

7Indicator lamp

8Arrow pad

INFO button (change

information display)

button (erase)

9Qbutton (OK)

Ebutton (camera guide)

button

Attaching the camera strap

Pull the strap tight so that it does not come loose.

Monitor

Shooting mode display

F3.0F3.01/1001/100

0.00.0

AUTO

ISO

AUTO

ISO

0:00:340:00:34

Date

ORM

151718

19 16 1114 13

222324

1Shooting mode ....... p.16, 24

2Flash..............................p.19

Flash standby/ﬂash charge

.................................... p. 55

3Macro ........................... p. 30

4Self-timer ...................... p. 30

5Exposure compensation

.................................... p. 31

6White balance............... p. 31

7ISO ............................... p. 32

8Drive ............................. p. 32

Image size

(still images)................ p. 33

Recording with sound

(movies) ...................... p. 36

Image size (movies) ..... p.34

Recording length

(movies) ...................... p. 63

Movie recording icon .... p. 17

World time .................... p. 48

Image Stabilizer

(still images)................ p. 35

Date stamp ................... p. 37

Compression

(still images)................ p. 34

Number of storable pictures

(still images)................ p. 16

Current memory ........... p. 61

Battery check................ p. 12

AF target mark.............. p. 17

Aperture value .............. p. 17

Shutter speed ............... p. 17

Camera shake warning

Playback mode display

●Normal display 1Battery check................ p. 12

23D image*1 .................... p. 23

3Eye-Fi transferred......... p. 42

4Protect .......................... p. 41

5Adding sound ............... p. 39

6Print reservation/number of

prints ...................p. 53/p. 52

7Current memory ........... p. 61

8Frame number/

total number of images

.................................... p. 20

Elapsed time/

total shooting time

(movies) ...................... p. 21

9P............................ p. 27

10 Shutter speed ............... p. 17

11 Shooting mode ....... p. 16, 24

12 ISO ............................... p. 32

13 Aperture value .............. p. 17

14 Exposure compensation

.................................... p. 31

15 White balance............... p. 31

16 File number

17 Compression

(still images)................ p. 34

Frame rate

(movies) ...................... p. 34

18 Date and time ............... p. 15

19 Image size .................... p. 33

20 Volume ......................... p. 44

12:30’12/02/26’12/02/26 12:30

1010

4/304/30

3D3D

1 8732 4 5 6

Still image Movie

00:12/00:3400:12/00:34

●Detailed display

4/304/30

1010

2.02.0F3.0F3.01/10001/1000

100-0004

AUTO

100

ISO

100

ISO

ORM

MAGICMAGIC

’12/02/26 12:30

2.02.0F3.0F3.01/10001/1000

100-0004

AUTO

100

ISO

100

ISO

MAGICMAGIC

’12/02/26 12:30

ORM

32 4 5 61 87 1110 12913

*1 VR-360/D-760 only

Camera Settings

Using the Direct Buttons

Frequently used functions can be accessed using the direct buttons.

H(left)

G(down) /

button (erase) (p. 21)

F(up) /

INFO button (change information

display) (p. 19, 22)

I(right)

Qbutton

Arrow pad

Zoom lever (p. 18, 22)

Shutter button (p. 17)

Rbutton (shooting movies) (p. 17)

qbutton (switch between shooting and

playback) (p. 20)

button (p. 9)

Ebutton (camera guide) (p. 23)

The symbols FGHI displayed for image selections

and settings indicate that the arrow pad is to be used.

ORM

‘12/02/26 12:30

ORM

16M

‘12/02/26 12:30

Sel. Image Back

Single Print More

4/30

100-0004

4/30

100-0004

02 26 12 30:..

2012

XBack

Y/M/D

Y M D Time

Operation guides displayed on the screen indicate that the

button, Qbutton, or zoom lever can be used.

Sel. Image

Erase/Cancel

(1)

4/30

Operation guide

Back

Camera Menu 1

Image Stabilizer

ResetReset

Compression

AF Mode

Digital Zoom

AF Illuminat.

Icon Guide

Normal

Face/iESP

Off

Back

Operation guide

Using the Menu

Use the menu to change camera settings such as the shooting mode.

There may be menus that are unavailable depending on other related settings or the mode (p. 26).

Function menu

Press Hduring shooting to display the function menu. The function menu is used to choose the shooting mode and

provides access to frequently used shooting settings.

To select the shooting mode

Use HI to select a shooting mode and press the Qbutton.

To select the function menu

Use FG to select a menu and use HI to select a menu option. Press the Q

button to set the function menu.

0.00.0

AUTO

ISO

AUTO

ISO

MENUMENU

Program Auto

Shooting

Function menu

Shooting mode

Selected option

Setup menu

1 Press the button.

●The setup menu is displayed.

Camera Menu 1 Back

ResetReset

Compression

AF Mode

Digital Zoom

Normal

Face/iESP

Off

Image Stabilizer

AF Illuminat.

Icon Guide

2Press Hto highlight the page tabs. Use FG

to select the desired page tab and press I.

Settings Menu 2

Pixel Mapping

Back

Power SavePower Save

World TimeWorld Time

TV Out

Bright

English

Off

X’12.02.26 12:30

Page tab

Pixel Mapping

Settings Menu 2

Power SavePower Save

World TimeWorld Time

TV Out

Back

Bright

English

Off

X’12.02.26 12:30

Submenu 1

3Use FG to select the desired submenu 1 and

then press the Qbutton.

Power SavePower Save Off

Settings Menu 2

Pixel Mapping

Back

World TimeWorld Time

TV Out

Bright

English

X’12.02.26 12:30

Power SavePower Save

Pixel Mapping

Settings Menu 2 Back

World TimeWorld Time

TV Out

Off

Submenu 2

4Use FG to select the desired submenu 2 and

then press the Qbutton.

●Once a setting is selected, the display returns to

the previous screen.

There may be additional operations.

“Menu Settings” (p. 34 to 49)

Power SavePower Save On

Settings Menu 2

Pixel Mapping

Back

World TimeWorld Time

TV Out

Bright

English

X’12.02.26 12:30

5Press the button to complete the setting.

Setup menu

Press the button during shooting or playback to display the setup menu. The setup menu provides access to a

variety of camera settings, including options not listed in the function menu, display options, and the time and date.

Menu Index

1Shooting mode ...........p.16, 24

P(Program Auto)

M(iAUTO)

Q(Beauty)

(Scene Mode)

P(Magic Filter)

~(Panorama)

2Flash.................................p. 19

3Macro ...............................p. 30

4Self-timer ..........................p. 30

5Exposure compensation ...p. 31

6White balance...................p. 31

7ISO ...................................p. 32

8Drive .................................p. 32

9Image Size .......................p. 33

0K(Camera Menu 1) .......p.34

Reset

Compression

AF Mode

Digital Zoom

Image Stabilizer

AF Illuminat.

Icon Guide

aK(Camera Menu 2) .......p.37

Date Stamp

bA(Movie menu) ..............p. 34

Frame Rate

IS Movie Mode

R(Movie sound recording)

cq(Playback menu) ........p. 38

Slideshow

Edit

Erase

Print Order

R(Protect)

y(Rotate)

dd(Settings Menu 1)..........p.42

Memory Format/Format

Backup

Eye-Fi

USB Connection

qPower On

Keep KSettings

Sound Settings

ed(Settings Menu 2)..........p.44

Pixel Mapping

s(Monitor)

TV Out*1

NTSC/PAL*2

Power Save

W(Language)

X(Date/time)

World Time

fd(Settings Menu 3)..........p.49

Beauty Settings

*1 VR-360/D-760 only

*2 VR-350/D-755 and VR-340/D-750 only

0.00.0

AUTO

ISO

AUTO

ISO

MENUMENU

Program Auto

Camera Menu 1

Image Stabilizer

ResetReset

Compression

AF Mode

Digital Zoom

AF Illuminat.

Icon Guide

Normal

Face/iESP

Off

Back

Altri manuali per VR-350

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Olympus Macchina fotografica digitale

Olympus

Olympus Epic - Stylus - Camera Manuale utente

Olympus

Olympus E-P3 Istruzioni per il montaggio

Olympus

Olympus FE 3000 - Digital Camera - Compact Guida all'installazione

Olympus

Olympus SP-620UZ Istruzioni per il montaggio

Olympus

Olympus CAMEDIA C-450 Zoom Manuale utente

Olympus

Olympus FE 200 - Digital Camera - 6.0 Megapixel Manuale utente

Olympus

Olympus C 4000 - CAMEDIA Zoom Digital Camera Manuale utente

Olympus

Olympus 170 Manuale utente

Olympus

Olympus 550WP - Stylus Digital Camera Manuale utente

Olympus

Olympus Stylus 1050SW Istruzioni per il montaggio

Olympus

Olympus Camedia C-750 Ultra Zoom Manuale utente

Olympus

Olympus AZ-220 WIDE ZOOM Manuale utente

Olympus

Olympus E-M1 Guida all'installazione

Olympus

Olympus BondMaster 600 Guida all'installazione

Olympus

Olympus EVOLT E-300 Manuale utente

Olympus

Olympus CAMEDIA C-8080 Wide Zoom Manuale utente

Olympus

Olympus FE 130 - 5.1MP Digital Camera Manuale utente

Olympus

Olympus FE 5020 - Digital Camera - Compact Manuale utente

Olympus

Olympus E-3 Manuale utente

Olympus

Olympus D-600L D-500L Manuale utente

Olympus

Olympus 225690 - Stylus 600 6MP Digital Camera Guida alla configurazione

Olympus

Olympus STYLUS 300 Guida all'installazione

Olympus

Olympus IR 300 - Digital Camera - 5.0 Megapixel Guida all'installazione

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Manuale di formazione

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
