Olympus DM-550 Manuale utente

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

DM-550

• built-in Stereo Noise

cancelling microphones

• Versatile recording quality

options, including high

quality PCM recording (CD

quality)

• Enhanced voice guidance

system

• Simple to manage: five

storage folders plus

music folder (up to 200

messages per folder),

one music folder, plus

automatic archiving and

synchronisation

• Audible support • Podcast function with

bookmarking for easy stop-

and-go listening

• Advanced Euphony

options: expands the sound

space to convey more

realistic playback

• Manual recording level

control

High quality stereo in PCM format

With the very latest audio processing technology on board, the Olympus DM-550 bring high quality to users’ fingertips. This model

record every detail in order to ensure peace of mind and let you enjoy your favourite music, audio books or podcasts during breaks.

They offer incredible Olympus recording and playback quality, not to mention great style at an affordable price. It even boasts linear

PCM recording quality. It make navigation a breeze with Voice Guidance and multiple language menus. In addition, 51 hours of battery

life, battery save technology and a USB charge function ensure that you’ll never be left hanging. With a range of practical accessories

and Olympus Sonority software, the new models are the ideal companion to capture important moments anywhere from the meeting

table to the lecture hall.

Specifications

Storage Media

Internal / Removable Media Internal + Removable

SD / SDHC Slot No

microSD / microSDHC card Yes

Internal memory 4GB

USB functionality

USB Speed USB 2.0 High Speed

USB Classes USB Storage class

USB Audio class

USB HID

Display

Display Type Full Dot Matrix Display

Display Size 27.3 x 28.5mm / 1.56''

Display colour White

Display Backlit Yes

Device operation

Main Switch Push

HOLD switch Yes

Power switch Yes

Programmable button 2

PC control function

Control Buttons 2

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Recording Modes

Recording format PCM (WAV) / MP3 / WMA

48kHz 5h 25min

44.1kHz / 16bit 5h 55min

LP 1005h

SP 505h

HQ 256h

STSP 256h

STHQ 128h

STXQ 64h

320 kbps 26h

256 kbps 32h 30min

192 kbps 43h 30min

128 kbps 65h 30min

PCM (WAV) format

WMA format

MP3 format

Playback Modes

Playback format PCM (WAV) / MP3 / WMA

Sampling frequency

PCM 44.1 - 48kHz / 16bit

MP3 8 - 44.1kHz / 8 - 320kbps

WMA 8 - 44.1kHz / 5 - 256kbps

Frequency response

PCM (WAV) format -

48kHz 40 - 23.000Hz

44.1kHz 40 - 21.000Hz

MP3 format -

320 kbps 40 - 20.000Hz

256 kbps 40 - 20.000Hz

192 kbps 40 - 19.000Hz

128 kbps 40 - 17.000Hz

WMA format -

STXQ 40 - 19.000Hz

STHQ 40 - 16.000Hz

STSP 40 - 9.000Hz

HQ 40 - 13.000Hz

SP 40 - 8.000Hz

LP 40 - 3.000Hz

Record function

Index Up to 16 per file

Operation

Auto recording VCVA recording

Timer recording

Sound control Rec Monitor

Manual Rec level control

Low Cut-Filter

Zoom Mic. Setting (DVM)

Advanced recording Direct recording

Playback function

Playback speed Adjustable (50 - 200%)

Playback control Cue/Review

File operation Fast forward and rewind

Skip Playback

Repeat functions Repeat playback

Automatic playback Alarm playback

Continuous playback

Random playback

Sound enhancement Noise canceling function

Voice Filter

EUPHONY

Data organisation

No. of folders for Voice 5

Files per folder 999

Folder Audible 1

Temp mark Yes

File move Yes

File divide Yes (only PCM mode)

File Copy (Folder to Folder) Yes

File Copy (internal memory -

external memory)

Yes

Folder Podcasts 1

Erase Erase all files

Erase single files

Partial (PCM only)

Workflow function

Author ID Setting No

Pending File No

Priority setting No

Worktype ID Setting No

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Other Features

Audible support Yes (advantages: one

file, bookmark function,

chapter marks, speech

optimized compression,

additional informations like

title description, author

informations)

Podcast support Yes

Voice feedback / guidance Yes

Remote Control RS-30W (optional)

Software

corresponding Audio software

(type)

Audio Management Software

Corresponding Audio software

(name)

Sonority

Interfaces Input

Microphone sensitivity / gain High / Middle / Low

Microphone jack 3.5 ø mm mini-jack,

impedance 2.2 k�

PC interface USB Cable

Microphones Built-in stereo microphones

Interfaces Output

Speaker Diameter Built-in ø23 mm round

dynamic speaker

Max. working output 320 mW or more (8 � speaker)

Earphone jack 3.5 ø mm jack, impedance 8�

or more

Power Supply

Device standalone recharge

function via USB

Yes

Power Supply 2 x AAA Ni-MH rechargeable

batteries (charge inside

device) or AAA batteries

External power supply USB connecting AC adapter

(A-514)

Ni-MH battery life Recording: 41h (LP mode)

Playback: 16h via speakers

Alkaline battery life Recording: 51h (LP mode)

Playback: 19h via speakers

Dimensions

Weight 84g (incl. batteries)

WxHxD 110 x 38.9 x 16mm (without

protrusions)

Housing material Metal

Housing colour Black

Languages

Menu languages English, German, French,

Spanish, Italian, Russian

Voice Guidance languages Czech, Danish, Dutch,

English, Finnish, French,

German, Greek, Hindi,

Italian, Norwegian, Polish,

Portuguese, Russian,

Swedish, Spanish, Turkish,

Urdu

Languages Audio Using

Instruction

Yes
