INSTRUCTION,USEAND

MAINTENANCE HAND-BOOK

Machine: STEAMCLEANER Type: GP.92.5.00

O.M.E.C Snc di R. Carnevale & C. - Via dell’Artigianato 3/5/7 -20835 Muggiò (MB? - Italy

Ph. No. +39-039-793740 - Fax no. +39-039-2780689 - E-mail export@omec-snc.com

Web site www.omecitalia.com

INDEX

SIDEI WARNINGS, PRECAUTIONSANDGENERALADVICES Page No.

1.1.1 Warnings 1/11

1.2.1 Precautions 1/11

1.3.1 General advices 1/11

SIDEII PRODUCTDESCRIPTION

 2.1.1 Technical data 1/11

2.2.1 External body description 2/11

2.3.1 Boiler description 2/11

2.4.1 Heating element description 2/11

2.5.1 Machine built-in safety devices 2/11

2.6.1 Safety check description 2/11

SIDEIII ASSEMBLING, INSTALLATIONANDUSEINSTRUCTIONS

3.1.1 Warning against work-risks 3/11

3.2.1 Assembling instructions 3/11

3.3.1 Use instructions 4/11

3.4.1 Danger notices 4/11

3.5.1 Picture No. 1 5/11

3.6.1 Picture No. 2 - TAV A 6/11

3.7.1 Picture No. 2 - TAV B 6/11

3.8.1 Spare part list 6/11

SIDEIV MAINTENANCEINSTRUCTIONS

4.1.1 Boiler cleaning 7/11

4.1.2 Routine maintenance 7/11

4.1.3 Survey of main anomalies 7/11

SIDEV ELECTRICDIAGRAM

5.1.1 Electric diagram 8/11

SIDEVI STANDARDS

6.1.1 Standards CEI - UNI - EC 9/11

6.1.2 Waste 9/11

The present instruction hand-book informs about the basic requirements

for THE SAFETY AND HEALTH OF THE USERS.

These requirements are stated by the MACHINE DIRECTION 2006/42/EC

(Issue No. 02 of 19th February 2010)

SIDEI WARNINGS, PRECAUTIONSANDGENERALADVICES

1.1.1 WARNINGS

Before connecting the plug of the OMEC STEAM CLEANER TYPE GP.92.5 into

the current intake check the feeding voltage which must be the same as

the voltage written on the machine plate.

Example: machine plate VOLT 230-HZ 50 = feeding voltage VOLT 230-HZ 50.

Do not dip machine into the water.

Do not let the supply electric wire hang.

1.2.1 PRECAUTIONS



a) The OMEC STEAM CLEANER TYPE GP.92.5 must be used ONLY AND

EXCLUSIVELY to clean articles and goods manufactured by dental

technicians and goldsmiths.

b) Before checking or controlling the machine, TAKE OFF the plug

which connects the machine to the intake.

c) Never take away the plug by pulling the supply wire.

d) Make sure that your electrical equipment is in conformity with the EC

2006/95/EC Standards - LOW VOLTAGE.

OMECISNOT GUILTYFORA WRONGORIMPROPERUSOFITS STEAMCLEANER

TYPEGP.92.5

1.3.1 GENERALADVICES



a) On receiving the unit check the package integrity and then make sure

that the machine is perfect and not damaged (due to bad carrying).

b) Follow carefully the instructions for installing the machine.

c) The OMEC STEAM CLEANER TYPE GP.92.5 must be used only by a skilled

worker, and therefore use the machine ONLY AFTER HAVING READ

CAREFULLY and understood the instruction hand book.

d) The machine is supplied complete with the following accessories:

- no. 1 pistol with actuator

- no. 1 unloading water cock

- no. 1 instruction hand-book which must ALWAY go together with

the machine even if it is sold as a second-hand machine

- no. 1 warranty certificate

- no. 1 conformity declaration

SIDEII PRODUCTDESCRIPTION

2.1.1 TECHNICALDATA



OMEC STEAM CLEANER TYPE GP.92.5

Absorbed power : Kw 1.8

Supply : A. Current - Volt 230

Absorbed current : Amp. 7

Frequency : Hz. 50/60

Nominal tank capacity: 5 litres

Pressure : 5 bar

- Page 1/11 -

2.2.1 EXTERNALBODYDESCRIPTION

The OMEC STEAM CLEANER TYPE GP.92.5 has an external structure of iron

sheet, it is fire painted by epoxy resins (powder).

2.3.1 BOILERDESCRIPTION

The boiler is made of stainless steel type AISI 304 and tested at 8

(eight) atmospheres.

2.4.1 HEATINGELEMENTDESCRIPTION

The heating element is made of stainless steel type AISI 321 high

efficiency INCOLOJ.

2.5.1 MACHINEBUILT-INSAFETYDEVICES

The pressure and temperature checking is made by an air pressure switch

and by a thermostat rated by the manufacturer. In case one of these two

components or both are out of service they inter-work: the loading water

plug works for the air pressure switch (6) - pict. 2 - page 6/11 - while

in case of water shortage and the consequently raise of temperature

there is a manual reset thermostat which stops all machine functions and

works a sound alarm.

2.6.1 SAFETYCHECKDESCRIPTION

The OMEC STEAM CLEANER TYPE GP.92.5 has to pass a first general

check (electrical - mechanical) during its assembly. The final

conformity of the machine is stated and confirmed by an electronic

system which checks automatically the safety of the machine by itself.

SIDE III ASSEMBLING, INSTALLATIONANDUSEINSTRUCTIONS

INTRUDUCTION

Before starting-up the machine, follow precisely the following

instructions.

Please refer to pict. 1 - page 5/11.

3.1.1 WARNINGSAGAINSTWORK-RISKS

a) Make sure that your electrical equipment has a good earth and that

it is in conformity with the 2006/95/EC Standards - Low voltage.

b) The OMEC STEAM CLEANER TYPE GP.92.5 must work with DEMINARALIZED

water or with water coming from the hydro plant through a anti-lime /

water softener. ABSOLUTELY AVOID using any liquid or detergent

which will make the machine DANGEROUS.

- Page 2/11 -

c) During the working of the OMEC STEAM CLEANER TYPE GP.92.5 a high

temperature is produced inside it, some of it is transmitted by

conduction to the case of the machine and it could cause (if

touched) severe scalds. So the machine MUST be handle WIHT CARE and

users must be warned about dangers (steam under pressure, hot

water, etc.).

d) Be present when the machine is working (do not abandon it).

e) The actuator (1) and (2) on the pistol works in series with the

actuator (7). The latter must be on any time you want to use the

pistol. When you finish using it, it is recommended to disconnect

the actuator (7) placed on the front panel of the machine. This is

in order to avoid the coming out of the steam in case the actuator

placed on the pistol is pushed by accident. It is strictly

recommended to check if the nozzle of the pistol is towards the user

f) In case you are using the steam CLEANER and it happens that any steam

comes out from the loading plug (3), or the pressure steam gauge

shows a pressure further to the max. point of working 5 bars,

immediately switch off the machine and ask the intervention of the

OMEC authorized assistance centre.

THE MACHINE MUST BE DISCONNECTED WHEN:

a) Before loading or unloading the water into the boiler.

b) Before leaving the room, even if for little time.

c) Before each cleaning or maintenance intervention

DO NOT START THE MACHINE WHEN:

a) The supply wire or the steam pipe is damaged.

b) The machine has fallen down and is visibly damaged.

3.2.1 ASSEMBLINGINSTRUCTIONS



Put the OMEC STEAM CLEANER TYPE GP.92.5 on a piece of furniture

assuring a good stability to the machine. The rear part of the machine

must have a distance of at least 10 cm. from the wall. This helps the

air circulation. Check the plate data of the machine. They must be same

as those one of your electric equipment. In case of anomaly,

immediately apply to your supplier informing him about the nature of

the defect. Should you have any doubt about the safety of the machine DO

NOT USE it.

- Page 3/11 -

3.3.1 USINGINSTRUCTIONS



a) All under mentioned operations must ALWAYS be DONE when the

machine is COLD. Refer to Picture No. 1 - Page 5/11:

b) Push on the actuator (5).

c) Unscrew the water loading plug (3) and fill the tank by water

until the level is reached, as shown by the spy hole.

d) Screw the water loading plug (3) properly.

e) Wait until the machine reaches the optimal pressure of about 4.5-

5 bars which will be indicated by the steam pressure gauge (11),

the lighting up of the led (12).

f) Push on the actuator (7) and handle the pistol. When pushing on

the left actuator (1) the steam comes out. When pushing the right

actuator (2) on the pistol, water mixed with steam comes out. The

cock (10) controls the quantity of steam and the cock (4) controls

the quantity of water mixed with steam.

g) When the led (7) lights up this means that the water level

inside the machine is the minimal one. Consequently you must

turn off the machine immediately and refill the water.

3.4.1 DANGERNOTICES

The lighting up of the led (13) means the lever water Inside the tank

is minimal. If the sound alarm (hum) plays, the red led (13) lights up

meaning the total absence of water in the tank. In this event the

machine must be immediately switched off.

OMECISNOT GUILTYFORA WRONGORIMPROPERUSOFITS STEAMCLEANER

TYPEGP.92.5

- Page 4/11 -

3.5.1 PICTURENO. 1

1 –OUTGOING STEAM ACTUATOR 8 –FUSE

2 –WATER OUTGOING ACTUATOR 9 –ELECTRO-VALVE

3 –SAFETY WATER LOADING PLUG 10 –WATER QUANTITY REGULATING

COCK

4 –QUANTITY STEAM REGULATING 11 –STEAM PRESSURE GAUGE

COCK 12 –MAX. PRESSURE LED

5 –WATER HEATING ACTUATOR 13 –NO WATER LED

6 –WATER LEVEL SPY HOLE 14 –WATER UNLOADING COCK

7 –PISTOL STEAM ACTUATOR A - FASTENING SCREW OF THE FRONT

B PANEL

- Page 5/11 -

3.6.1 PICTURENO. 2-TAVA

- Page 6/11 -

3.7.1 PICTURENO. 2-TAVB

- Page 7/11 -

3.8.1 SPAREPATLIST

1 TAV A GP.92.4.01 BASE

2 TAV B GP.92.3.72 UNLOADING PIPE DIAM. 10 X 7 X 300

3 TAV A GP.92.3.16 RUBBER FOOT 19X13-ART. 730

4 TAV A GP.92.4.14 SCREW 4x10 TCR

5 TAV B GP.92.3.69 BALL COCK 1/4 “ F/F C/BLOCCO

6 TAV A GP.92.4.15 SCREW 4x20 TCR

7 TAV B GP.92.4.16 STICKER (6PCS)

8 TAV B GP.92.3.19 NIPPLE M/M CO. ¼”

9 TAV A GP.92.4.05 CENTRAL BASE

10 TAV A GP.92.4.09 ELECTRIC PLANT BOARD

11 TAV A GP.92.4.17 SCREW 3x5 TCR

12 TAV A GP.92.4.18 SCREW 4x5 TCR

13 TAV B GP.92.4.22 ELECTRIC PLAN

14 TAV B GP.92.4.31 RED LED D.10 FASTON

14 TAV B GP.92.4.32 GREEN LED D.10 FASTON

15 TAV B SD.84.53 BLACK BIPOLAR ACTUATOR. GREEN LED

16 TAV B GP.21.B.06 WATER GAUGE DIAM. 40

17 TAV A CONTROL PANEL

18 TAV B GP.21.B.03 LOW TENSION CIRCUIT BOARD V.18

19 TAV B GP.92.3.70 UNION ATT. 9 X ¼”

20 TAV B GP.92.3.53 SOUND ALARM FOR WATER LEVEL

21 TAV B GP.92.3.28 CAPILLARY THERMOSTAT 50'/200'x6x100

22 TAV B GP.92.4.06 CARBON TERMINAL N.6 PA27

23 TAV B GP.92.4.07 PIN FOR CARBON TERMINAL PA27-PIN PA197

24 TAV B GP.92.3.67 MANUAL RESET THERMOSTAT 165'FASTON

25 TAV A GP.92.4.10 BOILER REST

26 TAV B GP.92.3.25 COPPER SPIRAL(FOR MANOMETER)D.3 1/8F-1/M

27 TAV B GP.92.3.22 CORNER (EXTENSION) ¼” M/F X 50

28 TAV B GP.92.3.27 CORNER UNION M/F ¼”

29 TAV B GP.92.3.54 BOILER COATING LT. 4,5

30 TAV B GP.21.B.04 STAINLESS STELL BOILER 4,5L

31 TAV B GP.92.4.03 VITON SEAL DIAM. 52X41,2X3

32 TAV B GP.92.3.73 UNION “T” 6X1/8” –M - X ¼” F

33 TAV B GP.92.3.24 HEAT. ELEMENT 1'1/4”INOX W.1600xL.175

34 TAV B GP.92.3.18 AIR PRESSURE SWITCH 1/8” - 4 BAR

35 TAV B GP.92.3.71 STRAIGHT FEMALE UNION-346-6X1/8”-1100

36 TAV B GP.92.3.20 AIR PRESSURE SERPENTINE DIAM. 6xL.170

37 TAV A GP.92.4.11 CENTRAL FRAME

38 TAV A GP.92.4.12 FRONT PANEL

39 TAV A GP.92.3.17 SCREW 4x15 TCR TRILOBATA

40 TAV A GP.92.3.75 COVER HOLE CAP DIAM. 8

41 TAV B GP.92.3.56 ELECTRIC WIRE 3x1,5 SCHUKO 16 AMP.MT.2

42 TAV A GP.92.4.13 REAR PANNEL

43 TAV B SD.84.53.01 PROTECTION FOR BIPOLAR ACTUATOR

44 TAV B STEAM PIPE

45 TAV B GP.92.3.04 FASTENING IRON SCREW TCR

46 TAV B GP.92.3.60 CABLE 4 X 1-MT. 2,5

47 TAV B MC.009.56 COMPLETE STEAM GUN WITH TUBE

48 TAV B GP.92.3.15 HANDLE

49 TAV B GP.92.4.19 SCREW 8x20 TCE

50 TAV B GP.92.3.37 CABLE HOLDER ROD 4 X L.535

51 TAV B GP.92.3.57 CABLE RUBBER PROTECTION DIAM. 11

52 TAV B GP.92.3.06 GASKET EUR 28x22

53 TAV B GP.92.4.33 PLUG VITON GASKET

54 TAV B GP.92.4.08 LOADING CAP–PLUG 3/8”-4,3BAR +/- 0,3

55 TAV A GP.92.4.23 FUSE HOLDER 15A-6,3x32 FASTON MOD.1886

56 TAV A GP.92.4.24 FUSE 16A 6,3x32 MOD.GF CERAMIC

57 TAV B GP.92.3.62 CABLE PLASTIC PROTECTION PA 244-C

58 TAV B GP.92.3.38 CABLE STRAIGHT CASE 3/4/6 P

59 TAV B GP.92.4.20 SCREW 3x10 TCR TRILOBATA

60 TAV B GP.92.3.21 PLUG 3P + T

61 TAV B GP.92.3.66 INTAKE 3P + T

62 TAV B GP.92.3.36 CABLE MOVABLE CASE 3/4/6 P

63 TAV B GP.21.B.07 UNION “T” 4000 - ¼” F –¼” F - ¼” F

64 TAV B GP.92.3.03 SOLENOID WITH REGULATION 1/4”- D.2,8

65 TAV B GP.92.4.21 SCREW 3x30 TCR

66 TAV B GP.21.74 UNION WITH CABLE 45 CM.

67 TAV B GP.92.4.25 SCREW 3x5 TPS CR

68 TAV B MC.000.62 SPRING

70 TAV B GP.92.3.22 CORNER (EXTENSION) ¼” M/F X 50

71 TAV B GP.21.28 CORNER UNION 9280 - ¼”M - 6M

72 TAV B GP.92.3.19 NIPPLE M/M CO. ¼”

73 TAV B GP.21.08 UNION ATT. 3040 - 7 X ¼”

74 TAV B GP.21.B.08 COPPER SPIRAL(FOR SOLENOID)

75 TAV B GP.21.28 CORNER UNION 9280 - ¼”M - 6M

76 TAV B GP.21.B.09 COPPER SPIRAL (WATER LEVEL UP)

77 TAV B GP.21.B.10 COPPER SPIRAL (WATER LEVEL DOWN)

78 TAV B GP.21.B.02 WATER LEVEL GLASS

78 TAV B GP.21.B.05 O-RING FOR WATER LEVEL

- Page 8/11 -

SIDE IV MAINTENANCEINSTRUCTIONS



When you start the machine for the first time you may smell an acrid

smell. This is perfectly normal and disappears using and using the

machine.

4.1.1 BOILERCLEANING

If the machine is not used over a long period of time we recommend to

empty the boiler it and to wash it.

The evacuation of the stagnant water or of eventual solid rests is

eased by a drain plug (14) - pict. 1 –page 5/11 - that is placed under

the base of the machine. This operation must be carried out when the

machine is OFF and the plug is not inside the current intake.

Indice

Altri manuali Omec Pulitore a vapore

Omec

Omec OMT1 Manuale

Manuali Pulitore a vapore popolari di altre marche

Oreck

Oreck STEAM-IT STEAM100LRH Manuale utente

Beautural

Beautural YPZ-146 Manuale utente

MPM

MPM MZP-02 Manuale utente

Electrolux

Electrolux Refine 500 Manuale utente

Kärcher

Kärcher SC 3 Premium Manuale utente

Shark

Shark PRO Steam & Spray Istruzioni operative e di manutenzione

Jula

Jula 802-337 Manuale utente

Haan

Haan Floor Sanitizer MS-30 Manuale utente

Black & Decker

Black & Decker HSM13E1 Manuale utente

HOFFEN

HOFFEN GS-1231 Manuale utente

POLTI

POLTI VAPORETTO SYSTEME PRO Manuale utente

eta

eta AQUASIM PRO Manuale utente

Maxwell

Maxwell MW-3715 G Manuale utente

VAPamore

VAPamore Primo MR-100 Manuale

Bestron

Bestron AZQ016 Manuale utente

Nilfisk-ALTO

Nilfisk-ALTO Steamtec 312 Manuale utente

Tempo di saldi

Tempo di saldi SPINSCRUBBER Manuale utente

DOMENA

DOMENA HYGIAFLOR Manuale utente
