Omega VRT330 Manuale utente
gasket
VRT330
www.omegajuicers.com
OMEGA PRODUCTS, INC
Instruction Manual
Please read the instructions carefully
before using.
Please keep the user’s guide where
it is easily accessible.
Design and product development may be
upgraded without a public notice.
IMPORTANT SAFEGAURDS
SAVE THESE INSTRUCTIONS
1. When using electrical appliances, basic safety precautions should always
be followed including the following.
Read all instructions.
2. To protect against risk of electrical shock, do not put the main body
(motor) in water or any other liquid.
3. Close supervision is necessary when any appliance is used by or near
children.
4. Unplug from outlet when not in use, before assembling or taking of
parts and before cleaning.
5. Avoid contact moving parts.
6. Do not operate any appliance with a damaged cord or plug of after
the appliance malfunctions, or is dropped or damaged in any manner.
Return appliance to the nearest authorized service facility for examination,
repair or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the manufacturer
may cause fire, electric shock or injury.
8. Do not let cord hang over edge of table or counter.
9. Always make sure juicer locking clip is locked while juicer is in operation.
10. Be sure to turn switch to off position after each use of your juicer.
Make sure the motor stops completely before disassembling.
11. Do not put your fingers or other objects into the juicer while it is in
operation. If food becomes lodged in opening, use food plunger or
another piece of fruit or vegetable to push it down. When this method
is not possible, turn the motor off and disassemble juicer to remove
the remaining food.
12. Do not use outdoors.
13. Do not place on or near a hot gas or electric burner or in a heated oven.
14. Do not use appliance for other than intended use.
gasket
Omega Vert juicer USERS
Omega Vert juicer TABLE OF CONTENTS
The Omega Vert Juicer is a completely different mechanism where fresh juice comes
from squeezing rather than grinding. Omega Vert Juicer is a newly developed patent
product which is capable of making soy milk, vegetable extracting, fresh squeezed
fruit juice, etc.
LSJS (Low Speed Juicing System) squeezes instead of grinding which allows the
juice to maintain it’s pure color, natural taste, nutrients and vitamins.
For better use and maintenance of the product please follow the instructions carefully.
Please refer to the user’s guide when you are having technical difficulties or unsure of
the usage of this product. Omega Products, Inc is not liable for any damages or
injuries that may occur due to the lack of understanding of the user’s guide.
Introduction ------------------------------------------------------------- 01
Attachment Listing ----------------------------------------------------- 02
Assembly Instruction -------------------------------------------------- 03
How to use Vert juicer ------------------------------------------------ 05
Warning while operating ---------------------------------------------- 07
How to disassemble and clean ---------------------------------------- 08
Before requesting for repair service ---------------------------------- 09
Product Specification --------------------------------------------------- 10
01
Base
Auger
Hopper
Crushing
Rib
Strainer(white)
- less pulp Strainer(yellow)
- more pulp
Top Set
Auto Cleaning
Brush
Bowl
pulp ejection Juice Spout
Cleaning
brush
Pusher Container(2)
As shown below, the hopper edge must
point to “close” sign on the base in order
for the machine to operate properly.
Do not pre-operate before inputting
materials or do not operate with an
empty bowl.
Notice
IMPT
Attachment Listing
02
Assembly instruction
Place the strainer into the auto cleaning brush
Place the strainer +auto cleaning brush
into the bowl
make sure the red dot on the strainer
and the red dot on the bowl is aligned
Push in the Auger into the strainer
Auger
Strainer
auto cleaning
brush
Red dot
on the
auto cleaning brush
Red dot
on the bowl
Bowl
Crushing Rib
Strainer
Bowl
03
Assemble the hopper onto the bowl.
①Make sure the arrow on the hopper and the red
dot on the bowl is aligned.
②Make sure the arrow on the hopper is pointing
to close sign on the base.
Assemble the entire top set onto the base.
As shown below, assemble the bowl onto the
base and twist the bowl so that the hopper edge
is pointing to “close” sign
OPEN
CLOSE
Hopper
Bowl
The arrow
on the hopper
Red dot
on the bowl
Juice
spout
Base
04
Assembly instruction
gasket
Assembly instruction
Must connect the power cord.
Place containers under both ejections.
(Juice & pulp ejection)
Underneath the bowl, there is a yellow rubber gasket which allows all the juice to only
discharge from the fresh juice spout.
The rubber gasket is removable, simply grab onto one side of the rubber pad and pull out.
rubber pad
05
gasket
How to use Omega vert juicer
The machine has three(3) settings.
“On” starts motor, Start making juice.
“Rev” is reverse. Only use when something is
stuck and you need to unclog.
“Off” is at center position. This allow the
machine to turn off.
Please rinse everything thoroughly
before putting into the machine.
After rinsing, put material into the machine
using the pusher.
Please remove any hard seeds before using.
Any unused juice should be refrigerated.
Do not operate with wet hands.
Do not pre-operate before inputting materials
or do not operate with an empty bowl.
Warning
ON
REV
“ON” “REV”
Pusher
“ON” “REV”
ON
REV
06
Do not place the attachment
parts in the dishwasher
Warning while operating
07
Do not use longer than
30minutes at a time. Violating the warning may cause serious
damage to the product.
Do not use anything as a
pusher (fork , chopsticks,
spoons, etc) other than
the pusher itself.
Violating the warning may cause serious
damage to the product.
Violating the warning may cause serious
damage to the product.
Remove any hard seeds. Violating the warning may cause serious
damage to the product especially the screw.
Do not operate with wet
hands. Violating the warning may cause serious
injuries or electrocution.
When the machine is stuck and not operable, Please…
Turn off the machine and put it reverse for few
seconds then try operating again.
When reverse switch does not work, turn off the
machine and reassemble following the instructions
given. After reassemble, please try turning on the
machine.
ON
OFF
2.Auger
4.Auto cleaning
brush
How to disassemble and clean
08
Turn machine “Off”.
Twist the hopper to unlock by
grabbing the two ejections.
Make sure the arrow is aligned
with the open sign before pulling
off the bowl.
Order to disassemble.
1.Hopper
3.Strainer
5.Bowl
on rev
Use the brush to clean
thoroughly after operating.
Do not use metal sponge to clean,
it will damage the machine.
Do not use dishwasher to clean.
Do not rinse the base with
direct water, use dry towel or
wet towel to clean.
Please dry the attachments
after cleaning.
