smart, seamless and sliceable

CJ1-SERIES

A new strategy in machine control

Advanced Industrial Automation

To stay competitive in the machine building industry you have to be flexible, efficient and fast.

Omron’s C 1 series gives you this competitive edge. This new family of PLCs ranges from powerful

CPU models that offer total machine control, to very small CPUs that enable you to modularise

or ‘slice’ your machine into logical sections. You don’t even need to consider where to slice the

machine! Any I/O units can be mounted on any CPU, enabling you to distribute all the functions

you need to wherever you need them. And no matter how complex your machine becomes,

there’s always a CPU and a combination of I/Os to match your needs. It’s the ultimate in

machine sliceability and scalability!

odularising machines

was never so flexible!

Fast and easy to configure

C 1 modules connect together using reliable, high-quality

locking connectors. This eliminates the need for a bulky

PLC rack, and makes the C 1 fast and easy to configure

and install in control panels.

Actual

size

Seamless communication throughout

Built-in routing functions allow seamless communication over multiple network

layers. Programming and data transfer are fully transparent through open

networks like Ethernet, PROFIBUS-DP and DeviceNet, as well as Omron’s

cost-effective proprietary networks. C 1’s open communication units allow

the PLCs to communicate to nearly any 3rd party device.

Intelligence built-in

The core of intelligence of your machine control

system is the PLC CPU. The C 1-series CPUs range

from cost-effective units for simple sequence

control, to ultra-fast high-capacity models

handling up to 2560 I/O points. The main benefit

to you is that any PLC module can be mounted on

any CPU type. This reduces the number of different

product families for which you have to keep

modules in stock.

Analogue and digital I/O units

C 1 I/O units, ranging from basic to ultra-compact high-density

models, can be placed anywhere in the system, enabling you

to distribute all the functions you need, to wherever you

need them.

Control units

Specialised control units for motion control and

temperature control take the load off the CPU tasks

and allow for easy structured programming.

And Omron’s seamless communication allows fully

distributed machine control, configurable through

any access point in the network.

Omron’s supporting software suite

Omron’s CX-automation suite is designed to help you

unleash the power and flexibility of the C 1 series.

With these software tools you can configure, program,

commission, visualise and maintain all Omron’s PLCs,

and all using the same seamless communication.

You simply choose the software tools you need now,

and add other software components later.

When it comes to PLCs, Omron’s reputation for quality, reliability and advanced

technology is unsurpassed. The C 1 series is no exception. With C 1 you can mix and

match CPU power, special function units, and an extensive range of standard I/O units

to suit every machine automation need. With its credit-card size profile, C 1 offers the

best size/performance ratio in the industry. And without a separate back-plane,

the mounting space required is never more than the units you install.

CJ1 – the best size/performance

ratio in the business

Features and benefits at a glance

Features

Benefits to you:

• Wide range of compatible CPUs and I/O units

- One scaleable PLC family to match all your needs

•High-speed CPUs with instruction times down to 20 nanoseconds

- Processing speed up to five times faster than typical CPU

•Ultra-compact design

- 90mm 65mm – a profile slightly larger than a credit card

•No need for a back-plane

- No restrictions on width, and is fast and easy to install

and configure

•Supports DeviceNet, CompoBus/S, PROFIBUS-DP, Ethernet,

and Controller Link

- High-performance data e change and programming using

these network systems

•A full suite of compatible software tools

- Omron’s CX Automation suite supports the entire Omron

PLC product line.

SF8P_CJ1_ENG01_1002
