URC-1666

Instruction manual

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 2

Introduction

Congratulations on the purchase of the URC-1660. The URC-1660 is a

replacement remote control that can be set up to control 2 devices.

sat - Satellite Receiver, Digital Box or Cable Box

tv - Television, Plasma- or LCD TV

The URC-1660 is preprogrammed to control your SKY+ Box (no set

up required). Simply press the “sat” device key and your will

obtain SKY+ Box functionality.

Table of Contents

THE KEYPAD

CODE BLINK OUT

(To find out which code is currently programmed) 7

QUICK CODE REFERENCE

EXTRA FEATURE

•

Volume Punch-Through 8

TROUBLE-SHOOTING

CUSTOMER SERVICE

Installing the Batteries

1660

“

R6”a

1Remove the battery cover from the back of your URC-1660.

2Match the batteries to the + and - marks inside the battery case,

then insert the batteries.

3Press the battery cover back into place.

WWW.ONEFORALL.COM

: Television LCD Plasma Projector Rear Projector .......... 10

K....................

: Cable Converter Set-Top-Box DVB-C........................... 22

: Video Accessory like Media Centres AV Accessories

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 3

The Keypad

1 Power

The POWER key operates the same function it did on

the original remote control.

3 sat (LED) - device key for:

Satellite Receiver, Cable Converter, DSS

Video

Accessory (e.g.Media Centres) Personal Video

Recorder or Hard Disc Recorder.

The redLED (Light Emitting Diode) underneath the

sat key willlight up every time a key is pressed in sat

mode.

As default: when in “sat” mode your URC-1660

will be set to control your SKY+ Box.

2 tv (LED) - device key for:

Television, LCD, Plasma, Projector orRear Projector.

The red LED (Light Emitting Diode) underneath the

tv key will light up every time a key is pressed in tv

mode.

tv guide

This key gives you the possibility to preview the

complete tv listings.

box office

This key allows you to access the Box Office programs.

services

This key provides a range of features such as e.g.

parental controls, subtitles and favourites. For your

particular device this key may provide menu control.

interactive

This key provides a selection of interactive services.

8volume +/- Keys

These keys operate in the same way as the keys on

your original remote. In

“tv”

mode you may obtain

Colour + / - when you press and release the magic

key and then press Volume + / - .

9channel +/- Keys

These keys operate in the same way as the keys on

your original remote. In

“tv”

mode you may obtain

Brightness + / - when you press and release the magic

key and then press Channel + / -.

Directional Keys

If available on your original remote, these keys will

allow you to navigate through the menu mode of

your device.

select

The select key will confirm your choice in the corre-

sponding menu.

Mute Key

The Mute key operates the same function it did on

your original remote control.

WWW.ONEFORALL.COM

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 4

i (info) Key

This key provides information about the pro

gram you’re watching.

back up Key

This key allows you to go back to the previous page.

text

Puts the television in the Teletext mode.

text off

Switches the television back to regular viewing mode. On

some televisions, this may be done by pressing the text

key several times.

17 16:9

This key provides you the (16:9) wide screen

view function, if available on your original remote).

help

This key provides help in Sky Guide and is also

used for subtitles or audio description.

Transport Keys

If available these keys operate the transport functions

(PLAY,FF, REW etc.) of your SKY+ Box

Satellite

Receiver

Set Top Box

Cable Box. To prevent

accidental recording, the RECORD key mustbe pressed

twice to start recording.

red, green, yellow, blue

After pressing the tv key and accessing the text mode,

the keys marked red, green, yellow and blue, allow

you to access the Fastext functions of your

television. If on your original remote control these

keys are used for Menu navigation, the ONE FOR ALL

Fastext keys may operate in the same way.

Number Keys

The Number keys (0-9,

-/--) provide functions just like

your original remote. If your original remote has an

20 key, this function can be found under the AV key.

magic Key

The magic key is used to set up your URC-1660.

tv/sat Key

In tv mode you will obtain the AV

Input function. In

e y

ill

e “

”

r “

”

function, if available on your original remote.

Please note that the key pad description is mainly based on SKY+

Box functionality. This may differ from your particular device.

WWW.ONEFORALL.COM

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 5

_ _ _ _

Setting up the URC-1660

Before you start, please read these instructions carefully

Direct code set up

Example: To set up the URC-1660 for your television:

1Find the code for your device in the Code list (page 10 - 23).

Codes are listed by device type and brand name.

The most popular code is listed first.

Make sure your

device is switched on (not on standby).

2Press the tv key on the URC-1660 for the device you wish

to Set-Up.

3Press and hold down the magic key

until the red LED underneath the tv key

blinks twice (the red LED will blink once

then twice). x2

4Enter your (four-digit device code) using the number

keys. The red LED will blink twice.

5Now, aim the URC-1660 at your device and

press POWER If your device switches off, the URC-

1660 is ready to operate your device.

6Turn your device back on and try all the remote’s functions to ensure

they are working properly. If the functions do not work properly,

repeat steps 1-5 using another code listed under your brand.

If your device does not respond, follow steps 1 to 5 with

each code listed for your brand. If none of the codes listed

for your brand operate your device, or if your brand is not

listed at all, try the search method described on page 6.

WWW.ONEFORALL.COM

Important notes:

- If your Set Top Box is not a standard BSkyB Sky+ Box, please follow

the steps above pressing “sat” instead of “tv” during step 2.

Most Televisions do not switch on pressing the POWER key. Please try press-

ing a “number” key or the “TV-text off” key to switch your TV back on.

Some codes are quite similar. If your device does not respond or is not func-

tioning properly with one of the codes, try another code listed under your

brand.

CBL and VAC codes can be set up in “sat” mode.

Remember to press the correct device key before operating your device.

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 6

The Search Method

If your device does not respond to the URC-1660 after you have tried all

the codes listed for your brand, try searching for your code. The Search

Method allows you to find the code for your device by scanning through all

the codes contained in the memory of the URC-1660. The Search Method

may also work if your brand is not listed at all.

Example: To search for your TV code:

1Switch your television on (not on standby) and aim your ONE FOR ALL

at your TV.

2Press the tv key on your URC-1660.

Press and

hold down

the

magic key

until the red LED underneath the POWER key

blinks twice (the red LED will blink once

then twice). x2

4 Press 9 9 1. The red LED will blink twice.

5Next, press POWER.

6Aim the URC-1660 at your Television. Now press CH+ over

and over, until your Television turns off (everytime you

press the CH+ key the URC-1660 will send out a POWER

signal from the next code contained in the

memory). You may have to press this key many times (up

to 150 times) so please be patient. If you skip past a code,

you can go to the previous code(s) by pressing the CH -

key. Remember to keep pointing the URC-1660 at your

Television while pressing this key.

7As soon as your television turns off, press the MAGIC key

to store the code.

WWW.ONEFORALL.COM

Important notes:

- If your Set Top Box is not a standard BSkyB Sky+ Box, please follow

the steps above pressing “sat” instead of “tv” during step 2.

Most Televisions do not switch on pressing the POWER key. Please try press-

ing a “number” key or the “TV-text off” key to switch your TV back on.

To search for the code for another device follow the instructions above

only press the appropriate device key instead of TV during step 2.

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 7

Once you have Set-Up your URC-1660, you can blink back your

SET-UP CODE for future reference.

Example: To blink out your Television code:

1Press tv once.

Press and

hold down

the

magic key

until the red LED underneath the POWER key

blinks twice (the red LED will blink once

then twice). x2

3 Press 9 9 0. The red LED underneath the POWER key will

blink twice.

4 For the first digit of your four-digit code, press 1 and

count all the red blinks. If there are no blinks, the digit is

For the second digit, press

and count all the red blinks.

ere are

For the third digit, press

and count all the red blinks.

ere are

For the fourth digit, press

and count all the red blinks.

ere are

Now

your four-digit code.

Quick Code Reference

Device Code

sat_________________________

tv_________________________

WWW.ONEFORALL.COM

Code Blink out

(To find out which code is currently programmed)

Important notes:

- If your Set Top Box is not a standard BSkyB Sky+ Box, please follow

the steps above pressing “sat” instead of “tv” during step 2 to

blink out the code programmed in “sat” mode.

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 8

Volume Punch Through

When controlling your Set-Top-Box (e.g. Sky+ Box) you normally need to

press the “tv” button first if you wish to control the volume for your

Television. The URC-1660 gives you the possibility to punch though

TV-VOLUME without pressing the tv mode key. This is only possible if you

have programmed the URC-1660 to also control your Television.

To punch through to TV volume while in “sat” mode:

1. Press and hold down the magic key until the

red LED underneath the POWER key blinks twice

(the red LED will blink once then twice).

Press 9 9 3.

3. Then press the tv key and the red light will

blink twice.

To cancel the „Volume Punch Through“:

1 Press and hold down the magic key until the

red LED underneath the POWER key blinks twice

(the red LED will blink once then twice).

Press 9 9 3.

3. Press the Volume (+) key and the red light will

blink four times.

WWW.ONEFORALL.COM

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 9

Problem & Solution

Problem: Solution:

Your brand is not listed in

the code section?

Try the search method on page 6.

The ONE FOR ALL does

not operate your

device(s)?

A) Try all the codes listed for

your brand. B) Try the search

method on page 6.

The ONE FOR ALL is not

performing commands

properly?

You may be using the wrong

code. Try repeating the Direct

Set-Up using another code listed

under your brand or start the

search method over again to

locate the proper code.

Problems changing

channels?

Enter the programme number

exactly as you would on your

original remote.

The ONE FOR ALL does

not respond after

pressing a key?

Make sure you are using new

batteries and are aiming the one

for all at your device.

The red LED does not

blink when you press

a key?

Replace batteries with 2 fresh,

new “AA” alkaline batteries.

Customer Service

In the UK

E-mail : [email protected] (*)

Fax : +31 53 432 9816

Tel. : 0901-5510010 (£ 0,50 per minute)

In Ireland

E-mail : [email protected] (*)

Fax : +31 53 432 9816

Tel. : 016015986

(*) Just send a blank message, you’ll get auto-reply.

WWW.ONEFORALL.COM

URC-1660_ECHO-SKY:7950 Manual_gedrukt 28-10-10 15:48 Pagina 10

A.R.Systems 0037 0373 0556

Accent

0037 0556

Accusound

0860

Acer

1339

Acoustic Solutions 1667 1727 1545 1523

1865 1037

Adcom 0625

Admiral 0093 0264

Advent 1613

AEA 0037 0556

AEG 0606 1556 1037 1324

1667 1163 2239 2197

Aftron 0891

Agashi 0264

Aiko 0037 0556 0371 0035

1681 0880 0361 0191

0264

Aim 0037 0556 0753 0208

0706 0698 0634 0606

0499

Airis 1833

Aiwa 0701 1916 1505

Akai 0361 1326 0208 0371

0037 0191 0035 0753

0806 0714 0706 0698

0715 0556 0480 0264

0178 0606 1037 0473

0812 1248 1727 1308

1865

Akashi 0860

Akiba 0037 0556

Akira 2241 0753 0037

Akito 0037 0556

Akura 0037 1687 0556 0668

1667 1645 1770 1585

0264 0714 1982 1983

1363 2239 2059

Alba 0037 1037 0556 0714

0371 0668 0487 0443

1997 1865

Alkos 0035

Allstar 0037 0556

All-Tel 0865

Amitech 1849

Amstrad 0264 0371 0037 0556

1037 1324 1982

Anam 0037 0556 0650

Anam National 0037 0650 0556

Andersson 1163 1667 1585

Anglo 0264

Anitech 0264 0037 0556

Ansonic 0037 0556 0668 0292

AOC 0625 1588 2111 2214

Apollo 0473

AquaVision 1606

Arc en Ciel 0109

Arçelik 0714

Ardem 0714 0486 0633 0037

0556

Arena 0037

Aristona 0556 0037

Art Mito 1585

Asberg 0037 0556

Astra 0037 0556

Asuka 0264

ATD 0698

Atec 1606

Atlantic 0037 0556

Audiosonic 0037 0820 0556 1308

1681 0109 0714 0715

0264 0486 1983

Audioton 0486 0264

Audioworld 0698

AWA 0037 0556 0606 0108

0264 0178 0698 1681

2241

Axxon 0714

Azuki 2239

Baier 1324 2239

Baird 0109 0343 0208 0606

Bang & Olufsen 0565 0620

Base 0780

Basic Line 1667 0037 0668 0556

1037

Bauer 0698 0706 0264

Baur 0535 0195 0512 0037

0556 0191 0361 1505

BBK 1523 1645

Beaumark 0178

Beko 0714 0486 0035 0715

0037 0556 2125 0606

1308 0808 1652

Belson 2241 2032

Bennett 0556 0037

BenQ 1562

Bensten 1326 1413

Beon 0037 0556

Berthen 0668 0556

Bestar 0037 0556

Bestwell 1326

Black Diamond 0820 1037 0556 1163

0753 0587

Black Strip 0035

Blaupunkt 0195 0191 0535 0170

Blue Media 1606

Blue Sky 0037 1324 1037 0714

1709 1667 0487 0668

0715 0625 1652 0624

0556 0808 1363 1916

Boman 1324

Bork 1363

BPL 0037 0556 0373

Brandt 0625 0109 0287 0335

0343 0560

Brandt

Electronique

0287 0335

Brimax 1709

Brinkmann 0037 0556 0668 0486

Brionvega 0037 0556

Brother 0264

Bruns 0486

BSR 0361

WWW.ONEFORALL.COM

Indice

Altri manuali One Forall Telecomando universale

One Forall

One Forall URC-6532 Manuale utente

One Forall

One Forall URC 1635 Manuale utente

One Forall

One Forall URC-44 Manuale utente

One Forall

One Forall URC-7800 Cinema 7+ Manuale utente

One Forall

One Forall URC-3720 Manuale utente

One Forall

One Forall Audio Zapper Manuale utente

One Forall

One Forall URC-7940 Manuale utente

One Forall

One Forall OARC05G Manuale utente

One Forall

One Forall URC-6420 Guida per l'amministratore

One Forall

One Forall URC-4220 Manuale di installazione e funzionamento

One Forall

One Forall URC-3445 Guida per l'amministratore

One Forall

One Forall BIG EASY URC-2585 Manuale utente

One Forall

One Forall URC-7540 Manuale utente

One Forall

One Forall URC-3415 Manuale utente

One Forall

One Forall URC-3910 Manuale utente

One Forall

One Forall 3 Zapper Manuale utente

One Forall

One Forall Kameleon Manuale utente

One Forall

One Forall URC10820N Manuale utente

One Forall

One Forall 704918 Manuale utente

One Forall

One Forall Little Easy Manuale utente

One Forall

One Forall URC-3710 Guida per l'amministratore

One Forall

One Forall URC-7711 Manuale utente

One Forall

One Forall Easy 2 Manuale utente

One Forall

One Forall URC-6211 Manuale utente

Manuali Telecomando universale popolari di altre marche

Pronto

Pronto Peel Manuale utente

GE 24929 Manuale utente

Radio Shack

Radio Shack Wireless Remote Control System Manuale utente

AUVIO

AUVIO Universal Home Theater Remote Manuale utente

Philips

Philips Icon SRU4106 Manuale utente

THOMSON

THOMSON ROC4309 Manuale utente

Philips

Philips pm625S Manuale utente

GE RM94931 Manuale utente

RCA

RCA RCU600WMS - Universal Remote Control Manuale utente

Blackweb

Blackweb BWB17AV002 Manuale utente

Marmitek

Marmitek DoorGuard 300 Manuale utente

Chunghop

Chunghop RM-L618 Manuale utente

GE RM24965 Manuale utente

Anderic

Anderic KTN828 Manuale utente

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manuale utente

Medion

Medion E74023 Manuale utente

intensity

intensity RM02A Manuale utente

GE RM24950 Manuale utente
