OpenEye OE-C3212D8-S Manuale utente
OE-C3212D8-S Hardware Manual - Features and Contents
OE-C3212D8-S Hardware Manual - Features and Contents
Important Safeguards
Warranty
Product Description
Camera Dimensions
Connections
Features
Box Contents
Important Safeguards
View Important Safeguards before installing the camera.
Warranty
View the Product Warranty for the camera.
Product Description
The OE-C3212D8-S is a 8MP full size IP dome camera equipped with a 2.8~12mm varifocal, autofocus, zoom lens
and person, vehicle, and line crossing detection analytics. True WDR and true day/night functionality allow the camera
to adapt to changing lighting conditions throughout the day to ensure high-quality images.
The IK10 and IP67-rated housing and large size make it well-suited for installation in high-traffic areas to provide a
strong visual deterrent without concern for inclement weather or vandalism. Adaptive IR technology prevents
overexposure of objects close to the camera further enhancing the low-light performance.
The OE-C3212D8-S is compatible with all 32-Series mounting accessories to fit a broad range of applications making it
an excellent choice for users looking for a cost-competitive, full-featured smart camera.
Combine the analytics capabilities of this camera with OpenEye Web Services to receive real-time alerts, on person,
https://answers.openeye.net/Install/Hardware_and_OS/Cameras/OpenEye_Cameras/OE-C3212D8-S/OE-3212D8-S_Hardwa…
Updated: Sun, 24 Sep 2023 17:33:32 GMT
Powered by
1
vehicle, or line crossing detection, sent directly to your mobile device or PC.
Camera Dimensions
Connections
1 RJ45 For network and PoE connections
2 Power (12vDC) Power Connection (12vDC power input should be plugged when not in use)
https://answers.openeye.net/Install/Hardware_and_OS/Cameras/OpenEye_Cameras/OE-C3212D8-S/OE-3212D8-S_Hardwa…
Updated: Sun, 24 Sep 2023 17:33:32 GMT
Powered by
2
3 Audio I/O
Ground
Audio In
Audio Out
4 Alarm I/O
Ground
Alarm In
Alarm Out -
Alarm Out +
5 Reset Button
To restore the camera to factory defaults:
1. Disconnect power for 30 seconds.
2. Reconnect power and wait 30 seconds.
3. Press and hold the reset button for 20 seconds.
6 microSD Card Slot Supports up to 512GB microSD card for Edge storage.
Do not add or remove the microSD card when the camera is powered on.
7 Built-in microphone
Power Connection
For an adequate power connection, use a 12vDC adaptor. Alternatively, you can power the camera by PoE if a Power
Sourcing Equipment (PSE) switch is available. Ensure that the camera’s power cable is correctly and firmly connected.
NOTE: OpenEye recommends against using more than one power source at a time. Do not use a PoE power
source when providing the camera with 12vDC power.
If using Power over Ethernet (PoE), make sure Power Sourcing Equipment (PSE) is in use in the network.
Features
• Person, Vehicle, Line Crossing Detection Analytics
• Corridor Mode
• NDAA Compliant
• 2.8~12mm VF, AF, Zoom Lens
https://answers.openeye.net/Install/Hardware_and_OS/Cameras/OpenEye_Cameras/OE-C3212D8-S/OE-3212D8-S_Hardwa…
Updated: Sun, 24 Sep 2023 17:33:32 GMT
Powered by
3
• 8MP | up to 20FPS
• Audio I/O
• Alarm I/O
• Adaptive IR | up to 131' range
• True WDR @ 8MP
• Built-in microphone
• IK10 Impact Protection Rating
• IP67 Ingress Protection Rating
• Optional Paintable Dome Cover (Free Upon Request)
Box Contents
OpenEye C3212D8-S cameras come with self-tapping screws and plastic anchors, mounting template, a torx tool, and a
waterproof cable connector. Identify the following components to make sure everything has been properly included with
your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement.
OE-C3212D8-S Dome Camera Self-Tapping Screws and Plastic Anchors x3
Mounting Template Waterproof Cable Connector
https://answers.openeye.net/Install/Hardware_and_OS/Cameras/OpenEye_Cameras/OE-C3212D8-S/OE-3212D8-S_Hardwa…
Updated: Sun, 24 Sep 2023 17:33:32 GMT
Powered by
4
