OPTI-UPS DS1000B Manuale utente

DS1000B / DS1500B / DS2000B / DS3000B

* DS1000B

30.

Online Double Conversion UPS Technology

Features

Backup Time (Typical)

1PC+1LCD 80 mins

1PC+1LCD 90 mins

DS1000B

DS1500B

* Zero transfer time (online)

* Smart fan speed control

* Saves more power and minimizes noise

* 4 hours recharge time

* Cold start (DC power on)

* EPO port ready: emergency power off switch

* SNMP card slot available

* Hot swappable / replaceable battery: continuous

operation even when battery is being replaced

* Extended battery pack (optional)

* RS232 and USB port

* Full version of OPTI-SAFE Xtreme software

Specifications

68.5 / 74.1 72.8 / 78.337.7 / 41.9

Pure

36.4 / 40.6

CONFORMANCE

Approvals

Battery Pack (Net / Gross) (kg) 21.1 / 22.6 40 / 44.5

Battery Pack Dimensions (Physical / Packing) (in) 16.5 x 6 x 9.4 / 21.5 x 11 x 14 16.5 x 8.9 x 14.1 / 20.7 x 13.8 x 19.1

(L x W x H) (mm) 420 x 152 x 238 / 545 x 280 x 355 420 x 225 x 358 / 526 x 350 x 485

windows

2000 / XP

2003 / Vista

IBM

IBM OS/2

IBM AIX

SUN Solaris

HP-UX

SGI Irix

Novell Netware

Linux

FreeBSD

Sine Wave

An Online UPS is not a further improvement of the standby technology, but a completely different approach to providing the

highest level of power supply. A double-conversion refers to converting the incoming AC power into DC power, and inverting it

back to AC power. This ensures the newly reproduced power to be of a quality standard set by UPS, to be completely cleared

of all imperfections of the power coming from the AC mains. Regardless of what is going on the AC mains side, the UPS

output voltage, frequency and signal purity are kept up to the highest standards. The current flow is absolutely uninterruptible,

the transfer time is zero. The UPS can work in pair with diesel generator, and can accommodate additional battery cabinets

for a longer backup time.

Beside those, the Durable Series UPS offer a set of essential features that make these UPS a flexible power supply control

and power saving tool.

By now the Durable Series UPS perfectly serve their purpose in numerous data processing, medical, banking and other

mission critical centres around the globe.

Line Interactive

UPS Series

On Line UPS

Series

AVR Series

Inverter Series

Surge Series Standby UPS

Series

Networking

Series

Green Power

Series

DS2000B

DS3000B

1PC+1LCD 120 mins

1PC+1LCD 140 mins

31.

Front Panel

DS1000B / DS1500B / DS2000B / DS3000B

A) Function

B) Enter

C) On / Off

FUNC ENTER

ON/OFF

ON ON-LINE ON-BAT

BYPASS FAULT

Rear Panel

DS1000B / DS1500B

100V/110V/120V

220V/230V/240V

RS232

EPO

Data Line

Protection

Circuit Breaker

Input

USB

Extended Battery

Connector

Battery Backup Outlets

EPO

Data Line

Protection

RS232

Circuit Breaker

Input

Battery Backup Outlets

Extended Battery

Connector

USB

DS2000B / DS3000B

RS232

EPO

Data Line Protection

Battery Backup Outlets

Circuit Breakers

Extended Battery Connector

USB

RS232

EPO

Data Line Protection

Circuit Breaker

Input

USB

Extended Battery Connector

Battery Backup Outlets

Circuit Breakers

100V/110V/120V

220V/230V/240V

SNMP Card Slot

SNMP Card Slot SNMP Card Slot

Line Interactive

UPS Series

On Line UPS

Series

AVR Series

Inverter Series

Surge Series Standby UPS

Series

Networking

Series

Green Power

Series
