Optica D104; D204M Manuale utente

00P3NX323ZXSEA5
Optica HD Indoor Dome Network Camera
Models: D104, D204M
User’s Manual
Ver1.5

1
Table of Contents
1. Overview.................................................................................................................................. 2
1.1 Features ........................................................................................................................ 2
1.2 Package Contents ......................................................................................................... 3
1.3 Camera Dimensions...................................................................................................... 4
1.4 Connectors .................................................................................................................... 5
2. Camera Cabling....................................................................................................................... 6
2.1 Connect Power.............................................................................................................. 6
2.2 Connect Ethernet Cable ................................................................................................ 6
2.3 Connect Alarm I/O......................................................................................................... 6
3. System Requirements ............................................................................................................ 7
4. Access Camera....................................................................................................................... 8
5. Setup Video Resolution........................................................................................................12
6. Configuration Files Export/ Import...................................................................................... 13
Appendix A: Technical Specifications........................................................................................ 14
Appendix B: Delete the Existing Optica Viewer..................................................................... 1616
Appendix C: Setup Internet Security ...................................................................................... 1717
Appendix D: Video Resolution ................................................................................................ 1818
D104 - Quad Streams ......................................................................................................... 1818
D104 - Triple Streams......................................................................................................... 2222
D104 - Dual Streams .......................................................................................................... 2424
D104 - Single Stream.......................................................................................................... 2424
D204M - Quad Streams ...................................................................................................... 2525
D204M - Triple Streams...................................................................................................... 2929
D204M - Dual Streams ....................................................................................................... 3232
D204M - Single Stream....................................................................................................... 3333

2
1. Overview
The IP Camera features decent low light performance, high resolution up to 2
Megapixel, various video resolution combination, multiple video compression
formats, etc. It supports true day / night and 3DNR function, which display clear
images in low light conditions. Moreover, the proprietary SPQ (Smart Picture
Quality) function allows delivering quality images especially under intensive
motion and low light conditions. With the built-in IR LED module, the IP Camera
makes visibility in nearly total darkness.
With H.264 High / Main / Baseline profile and MJPEG video compression
formats support, it is beneficial for optimization of bandwidth and network
resources. Video quad-stream support allows various surveillance applications
and facilitates working with other back-end devices.
1.1 Features
zProgressive Scan CMOS Sensor
zQuad Streams Compression: H.264 Baseline/ Main/ High Profile + MJPEG
zMulti-language Support
zTampering Alarm
zRemote Zoom & Focus (Motorized Lens)*
zWide Dynamic Range
zMotion Detection
zPrivacy Masks
zSmart Picture Quality/ 3D Noise Reduction
zVertical View Mode (Image rotation by 90 degrees)
zSmart IR Mode
zNetwork Failure Detection
zDay/Night (ICR)
zIR LED Module (working distance up to 25m)*
zMicro SD support
zBNC analog output
(*) D204M only

3
1.2 Package Contents
Please check the package contains the following items listed below.
Camera Package Contents
Indoor Dome IP Camera
Power Terminal Block
Security Torx
Self Tapping Screws
(×4)
Plastic Screw Anchors
(×4)
Rubber Washers (×6)
CD
(bundled software and
documentation)
Quick Start Guide

4
1.3 Camera Dimensions
The IP Dome Camera’s dimensions are shown below.

5
1.4 Connectors
The diagram below shows the IP Dome Camera’s reset button and various
connectors. Definition for each connector will be given as follows.
No. Connector Pin Definition Remarks
1 Reset Button - Restore to factory default
2 BNC - Analog Video Output
3 Alarm I/O
1 GND (Input-)
Alarm connection
2 Input+
3 Output-
4 Output+
4 Audio I/O
1 Output (L)
Two-way audio transmission
2 Output (R)
3 GND
4 Input
5 Power
DC 12V
1 Power
Power connection
2 Reserved
3 GND
AC 24V
1 Power-1
2 Earth GND
3 Power-2
6 RJ-45 - 10/100 Mbps Ethernet / PoE

6
2. Camera Cabling
Please follow the instructions below to complete IP Camera connection.
2.1 Connect Power
Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to
the camera’s PoE port and plug the other end of the cable into a PoE switch.
NOTE: If using PoE, make sure Power Sourcing Equipment (PSE) is in
use in the network.
2.2 Connect Ethernet Cable
Use of Category 5 Ethernet cable is recommended for network connection; to
have best transmission quality, cable length shall not exceed 100 meters.
Connect one end of the Ethernet cable to the RJ-45 connector of the IP Dome
Camera, and the other end of the cable to the network switch or PC.
NOTE: In some cases, you may need use an Ethernet crossover cable
when connecting the IP Dome Camera directly to the PC.
Check the status of the link indicator and activity indicator LEDs; if the LEDs are
unlit, please check LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
2.3 Connect Alarm I/O
The camera equips one alarm input and one relay output for alarm application.
Refer to alarm pin definition below to connect alarm devices to the IP Camera if
needed.
PIN 1: GND (Input-)
PIN 2: Input+
PIN 3: Output-
PIN 4: Output+

7
3. System Requirements
To perform the IP Camera via web browser, please ensure your PC is in good
network connection, and meet system requirements as described below.
Items System Requirement
Personal Computer
1. Intel®Pentium®M, 2.16 GHz or
Intel®CoreTM2 Duo, 2.0 GHz
2. 2 GB RAM or more
Operating System Windows VISTA / Windows XP / Windows 7
Web Browser Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE

8
4. Access Camera
For initial access to the IP Camera, users can search the camera through the
installer program: DeviceSearch.exe, which can be found in “DeviceSearch”
folder in the supplied CD.
Device Search Software Setup
Step 1: Double click on the program Device Search.exe. After its window
appears, click on the <Device Search> button on the top side.
Step 2: The security alert window will pop up. Click on <Unblock> to continue.
Device Search
Step 3: Click on <Device Search> again, and all the finding IP devices will be
listed in the page. The IP Camera’s default IP setting is DHCP.
Step 4: Double click or right click and select <Browse> to access the camera
directly via web browser.
Step 5: Then the prompt window of request for entering default username
and password will appear for login to the IP Dome Camera.
The default login ID and password for the Administrator are:
Login ID Password
Admin 1234
NOTE: ID and password are case sensitive.
NOTE: It is strongly advised that administrator’s password be
altered for the security concerns. Refer to Full HD Multiple
Streams IP Camera Menu Tree for further details.

9
Additionally, users can change the IP Camera’s network property, either DHCP
or Static IP directly in the device finding list. Refer to the following section for
changing the IP Camera’s network property.
Example of Changing IP Camera’s Network Property
Users can directly change an IP Camera’s network property, ex. from static IP to
DHCP, in the finding device list. The way to change the IP Camera’s network
property is specified below:
Step 1: In the finding device list, click on the IP Camera that you would like
to change its network property. On the selected item, right click and
select “Network Setup.” Meanwhile, record the IP Camera’s MAC
address, for future identification.
Step 2: The “Network Setup” page will come out. Select “DHCP,” and press
“Apply” button down the page.
Step 3: Click on <OK> on the Note of setting change. Wait for one minute to
re-search the IP Camera.
Step 4: Click on the <Device Search> button to re-search all the devices. Then
select the IP Camera with the correct MAC address. Double click on
the IP Camera, and the login window will come out.
Step 5: Enter User name and Password to access the IP Camera.
Installing Optica Viewer Software Online
For the initial access to the IP Camera, a client program, Optica Viewer, will be
automatically installed to your PC when connecting to the IP Camera.
If the Web browser doesn’t allow Optica Viewer installation, please check the
Internet security settings or ActiveX controls and plug-ins settings (refer to
Section: Internet Security Settings) to continue the process.
The Information Bar (just below the URL bar) may come out and ask for
permission to install the ActiveX Control for displaying video in browser. Right
click on the Information Bar and select <Install ActiveX Control…> to allow the
installation.
