Explorer WA ED-R Monocular

User Instructions and Warranty

North America

Models

8x32

8x42

10x42

Main Features

A3 stage locking rotating

retractable eyecup assembly

BWide band focusing

CObjective lens

DLug for connecting monocular

strap

Speciﬁcations 8x32 8x42 10x42

Product Code

Field (ft/1000yd)

Close Focus (ft)

Eye Relief (mm)

HxW (in)

Weight (oz)

30784

408

6.6

4.7x2

9.2

30785

393

6.2

5.4x2.1

11.6

30786

339

6.2

5.4x2.1

11.3

Accessories (included)

Soft Case

Neoprene Strap

Rubber Objective

Lens Cover

Cleaning Cloth

30443 Tripod Mount

(42mm models only)

A bespoke sleeve mount

providing a secure connection

to any photo/video panhead

with a 1/4” thread. Mount

secures over objective lens

housing.

Accessories (optional)

40951 Universal Tele-Adapter

UTA 2x + connection ring

Converts monocular into a

pocket telescope.

8x32 with 40942 -> 16x32

8x42 with 40943 -> 16x42

10x42 with 40943 -> 20x42

Monoculars can open up a whole range of new and exciting impressions when traveling on holiday, taken to

sporting and leisure events or used as part of a hobby such as birdwatching or astronomy. To help you get the

best results from your equipment please read the following instructions carefully.

Focusing

To focus at different distances simply rotate the central focusing band until a clear and sharp image is

obtained.

Retractable rubber eyecups and wearing glasses

Opticron Explorer WA ED-R monoculars provide the full ﬁeld of view when wearing glasses. To get the

maximum ﬁeld of view with glasses on, turn the eyecup clockwise into the ‘down’ position. Remember to

return it to the upright position if you or anybody else wants to use the instrument without glasses.

User Instructions

Care and cleaning

Monoculars require little maintenance but occasionally the outside surfaces of the eyepieces and objective

lenses will need cleaning. To avoid damaging these surfaces please read the following carefully.

(i) Gently remove excess dirt and dust using compressed air or a lens cleaning brush.

Caution: Hard and persistent rubbing of dirty surfaces can cause abrasive scratches on the surface of the

glass which may distort viewing.

(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth in a circular motion until

the surface is clean again.

Do not attempt to dismantle the instrument as this will invalidate the warranty.

Cold weather

In cold weather the external lens surfaces may steam up when moving the instrument from cooler air outside

to warmer air inside. If this occurs, leave the instrument to stand for a few minutes until any condensation

evaporates.

WARNING Never under any circumstances use this monocular to view the Sun. Doing so will cause serious

damage to your eyes.

We hope you will get a great deal of pleasure from your new Opticron monocular. If you have any problems

or damage it in any way our Service Department is on hand to help you.

User Instructions

Opticron Explorer monoculars are of a very high quality both in their performance and construction and for

your peace of mind we offer a Premier Limited Lifetime Warranty.

The Premier Limited Lifetime Warranty covers all the optical and mechanical components as well as the outer

protective armor, but not accessories such as neck straps, rainguards, dust caps, objective lens covers etc.

which are covered by our Standard Warranty.

In the case of accidental damage or defects attributable to faulty parts or assembly we will assume

responsibility for the full costs of repair up to 5 years from the date of purchase. We reserve the right to

decide whether defective parts or products should be repaired or replaced.

The Premier Limited Lifetime Warranty does not cover loss, theft or deliberate damage to the instrument.

Please keep this Warranty Card in a safe place

Warranty

Model:.............................................................................................................................................................

Purchase Date:...................................................... Dealer:..........................................................................

Registration

It is important you register your new purchase to activate your Premier Limited Lifetime Warranty. To register

your product and activate the warranty please visit www.opticronusa.com and complete the online Product

Registration Form.

Premier Limited Lifetime Warranties are available on new instruments purchased from participating dealers in

North America and are transferable. If you part with your instrument please make sure the new owner has a

copy of your original proof of purchase and re-registers their ownership at www.opticronusa.com.

Privacy

Opticron takes your privacy seriously and we do not share personal information with other companies.

Address: Unit 21, Titan Court, Laporte Way, Luton, LU4 8EF, UK

Email: [email protected]

Servicing & Repair:

If you have a problem with your product please visit the Help and Support section at www.opticronusa.com
