OWNER’S MANUAL

Portable Triple Play

Please read before using this equipment.

CD-3322

with AM/FM Stereo

Cassette Recorder

Compact Disc Player

14-547.fm Page 1 Wednesday, June 30, 1999 4:23 PM

FEATURES

RadioShack is a trademark used by Tandy Corporation.

Your Optimus CD-3322 Portable Triple

Play Compact Disc Player with AM/FM

Stereo Cassette Recorder is a com-

pact, portable, all-in-one music sys-

tem. It lets you listen to your favorite

CDs, AM andFM radio stations, orpre-

recorded cassette tapes, and record

onto a cassette tape from a CD or the

radio. You can take the CD-3322 with

you almost anywhere — indoors or

out, at work or play.

CD PLAYER FEATURES

Automatic Search Music System

(ASMS) — lets you quickly locate and

play any track on a CD.

Audible Search — helps you locate a

particular section of a CD by rapidly

playing it in either direction.

Direct Track Selection — lets you se-

lect and play any track on a CD by sim-

ply pressing the track number on the

remote control.

Programmable Play — lets you pro-

gram and play up to 20 tracks in any

order.

Random Play — lets you set the sys-

tem to automatically play a CD’s tracks

in random order.

INTRO (Introduction) Scanning — lets

you review the first 10 seconds of each

track on a CD, so you can easily find a

track you want to listen to.

Repeat Play — lets you automatically

repeat a single track, all tracks on the

CD, or a programmed sequence of

tracks.

3- or 5-Inch CD Compatible — lets you

play either 3- or 5-inch CDs on the sys-

tem.

CASSETTE DECK FEATURES

Multiple Source Recording — lets you

record onto a cassette tape from the

CD player or radio.

Automatic Level Control (ALC) — au-

tomatically adjusts the recording level.

Auto-Stop — to protect the tape and

tape-handling parts, automatically

stops the cassette tape when it reach-

es the end.

Soft Cassette Tape Eject — slowly

opens the cassette compartment door

so the tape does not pop out.

14-547.fm Page 2 Wednesday, June 30, 1999 4:23 PM

We recommend you record your sys-

tem’s serial number here. The number

is on the bottom of the CD-3322.

Serial Number __________________

Warning: This CD player employs a la-

ser light beam. Only a qualified service

person should remove the cover or at-

tempt to service this device, due to

possible eye injury.

This symbol is intended to

alert you to the presence of

uninsulated dangerous volt-

age within the product’s en-

closure that might be of

sufficient magnitude to con-

stitute a risk of electric

shock. Do not open the prod-

uct’s case.

RISK OF ELEC-

TRIC SHOCK.

DO NOT OPEN.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER OR BACK.

NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO

QUALIFIED PERSONNEL.

Warning: To prevent fire or shock

hazard, do not expose this product

to rain or moisture.

CAUTION

OTHER SPECIAL FEATURES

Memory Tuning — lets you store and

easily select up to 20 of your favorite

AM and FM radio stations (10 AM and

10 FM).

Remote Control — lets you control

most of the system’s functions from a

distance.

Liquid Crystal Display — clearly dis-

plays your system’s indicators for easy

viewing in almost any lighting condi-

tion.

Bass Boost Control — boosts low

tones for an emphasized bass sound.

Four Preset Equalizer Settings — at

the press of a button, provide you with

common sound settings for enhancing

rock, jazz, classical, or vocal (like

acappella or opera) music.

Three Power Options — let you power

your system from internal batteries

(not supplied), AC power, or your vehi-

cle’s cigarette lighter socket (using an

optional DC-to-AC inverter).

Note: The remote control requires two

AAA batteries (not supplied) for power.

Read this manual carefully. It will help

you get the most enjoyment from your

CD-3322.

14-547.fm Page 3 Wednesday, June 30, 1999 4:23 PM

This symbol is intended to inform you that important operating and main-

tenance instructions are included in the literature accompanying this prod-

uct.

14-547.fm Page 4 Wednesday, June 30, 1999 4:23 PM

CONTENTS

Connecting Power 6

Using Batteries ................................................................................................ 6

Using AC Power .............................................................................................. 7

Using Vehicle Battery Power ........................................................................... 7

Installing Batteries in the Remote Control ....................................................... 8

Basic Operation ..................................................................................................... 9

Using the Remote Control ............................................................................... 9

Turning Power On/Off ..................................................................................... 9

Turning On/Off Main Power ...................................................................... 9

Using the Remote Control to Turn Power On/Off ................................... 10

Setting the Sound ......................................................................................... 10

Adjusting the Volume .............................................................................. 10

Adjusting the Balance ............................................................................. 11

Using the Preset Equalizer Settings ....................................................... 11

Boosting the Bass ................................................................................... 11

Using Headphones ....................................................................................... 12

Listening Safely ...................................................................................... 12

Traffic Safety ........................................................................................... 12

Radio Operation .................................................................................................. 13

Listening to the Radio ................................................................................... 13

Memory Tuning ............................................................................................. 14

Storing a Station in Memory ................................................................... 14

Recalling a Stored Station ...................................................................... 15

CD Player Operation ........................................................................................... 16

Loading and Playing a CD ............................................................................ 16

Special CD Player Features .......................................................................... 17

Automatic Search Music System (ASMS) .............................................. 17

Direct Track Selection ............................................................................. 18

Cue ......................................................................................................... 18

Audible Search ....................................................................................... 18

Random Play .......................................................................................... 18

INTRO Scanning .................................................................................... 19

Repeat Play ............................................................................................ 20

14-547.fm Page 5 Wednesday, June 30, 1999 4:23 PM

Programmed Play 20

Storing/Playing a Pro-

grammed Sequence 20

Reviewing/Replacing a Pro-

grammed Sequence 22

Erasing a Programmed

Sequence 22

CD and CD Player Care Tips 23

Cassette Deck Operation 24

Loading a Tape 24

Playing a Tape 24

Fast-Forwarding/Rewinding

25 Recording a Cassette Tape 26

Recording from the Radio 26

Recording from the CD Player

27 Tape Tips 28

Erasing a Cassette Tape 28

Preventing Accidental Era-

sure 28Restoring Tape Tension and

Sound Quality 28

Troubleshooting 29

Resetting the System 30

Care and Maintenance 31

The FCC Wants You to Know 32

Cleaning the Tape-Handling Parts

Specifications 33

Notes:

• Most CDs that can be played on

this player have this mark on

them:

• Most material on compact discs

and prerecorded tapes is copy-

righted. Unauthorized duplication

of copyrighted material is a viola-

tion of the copyright laws of most

countries and such duplication

may result in fines and/or impris-

onment. Note, however, that in the

United States, it is not a violation

of U.S. copyright laws for a con-

sumer to use an audio recording

device to duplicate musical

recordings for noncommercial

(personal) use.

14-547.fm Page 6 Wednesday, June 30, 1999 4:23 PM

Connecting Power

You can power the CD-3322 from any of these power sources:

• Internal battery power, using eight

D batteries and two AA batteries

(not supplied — see “Using Bat-

teries”)

• AC power, using the supplied AC

power cord and a standard AC

outlet (see “Using AC Power” on

Page 8)

• Your vehicle’s cigarette lighter

socket, using an optional DC-to-

AC inverter (see “Using Vehicle

Battery Power” on Page 8)

Caution: Do not mix old and new bat-

teries, different types of batteries

(standard, alkaline, or rechargeable),

or rechargeable batteries of different

capacities.

Using Batteries

You can power your CD-3322 with

eight D batteries (for normal operation)

and two AA batteries (for memory

backup). For the best results, we rec-

ommend alkaline batteries, such as

RadioShack Cat. No. 23-550 (D cells)

and 23-552/557 (AA cells).

Caution: Only use fresh batteries of the

required size and type.

Follow these steps to install batteries.

1. Press down and pull out on the

tabs at the top of the battery com-

partment to remove the cover.

2. Put the AA then the D batteries in

the compartment (on top of the

attached ribbon) as indicated by

the polarity symbols (+ and –)

marked inside.

3. Replace the cover.

Notes:

• If you do not plan to use the CD-

3322 with batteries for a week or

more, or if you plan to use only AC

or vehicle battery power, remove

the D batteries.

• To save any radio stations stored

in memory in case power is dis-

connected or interrupted, always

leave the AA batteries installed.

• If the sound weakens or distorts,

or the CD-3322 does not operate

properly, replace the D batteries.

illustration

14-547.fm Page 7 Wednesday, June 30, 1999 4:23 PM

• Replace the AA batteries about

every 6 months, or more often if

power is frequently disconnected

or interrupted.

• To easily remove the batteries,

pull up on the attached ribbon.

Caution: Always dispose of old batter-

ies promptly and properly.

Using AC Power

To use AC power, plug the supplied

power cord into AC INPUT on the back

of the system, then plug the other end

into a standard AC outlet.

Caution: Your system’s power cord has

a polarized plug (one blade is wider

than the other). If you have difficulty in-

serting the plug into the outlet, do not

force it! Turn the plug over and try

again.

Notes:

• Always plug the power cord into

the CD-3322 before you plug it

into the AC outlet. Always unplug

the power cord from the outlet

before you unplug it from the CD-

3322.

• Connecting the power cord to the

CD-3322 automatically discon-

nects the internal D batteries.

Using Vehicle Battery Power

You can power the CD-3322 from your

vehicle’s cigarette lighter socket by

converting your vehicle’s DC power to

115V AC using an optional DC-to-AC

inverter, such as RadioShack Cat. No.

22-132.

Follow the instructions included with

the inverter to connect it to your vehi-

cle’s cigarette lighter socket. Then plug

the CD-3322’s power cord into AC IN-

PUT and plug the other end into the

AC outlet on the inverter.

Caution: Always plug the power cord

into the CD-3322 before you plug it into

the inverter. Always unplug the power

cord from the inverter before you un-

plug it from the CD-3322.

Note: If the CD-3322 hums when you

turn it off while using vehicle battery

power, this is not a malfunction. Simply

unplug the inverter from your vehicle’s

cigarette-lighter socket.

illustration

14-547.fm Page 8 Wednesday, June 30, 1999 4:23 PM

Installing Batteries in the Remote

Control

The remote control requires two AAA

batteries (not supplied) for power. For

the best performance and longest life,

we recommend alkaline batteries,

such as RadioShack Cat. No. 23-555.

Caution: Always use fresh batteries of

the required size and type.

1. To open the battery compartment

cover, slide the cover in the direc-

tion of the arrow, then lift the cover

away from the compartment.

2. Insert the batteries into the com-

partment (on top of the attached

ribbon) according to the polarity

symbols (+ and –) marked inside.

3. Replace the cover.

Notes:

• If you will not be using the remote

control for a month or more,

remove the batteries.

• To easily remove the batteries,

pull up on the attached ribbon.

• You can use the remote control up

to a distance of about 16 feet (5

meters), from an angle of up to

30° in front of the CD-3322. If it

does not operate properly within

this range, replace the remote

control’s batteries.

Caution: Always dispose of old batter-

ies promptly and properly.

illustration

14-547.fm Page 9 Wednesday, June 30, 1999 4:23 PM

Basic Operation

Important: After receiving a static elec-

tric shock, the CD-3322 might lock up

and become inoperable. If this hap-

pens, see “Resetting the System” on

Page 32 for instructions on resetting it.

Using the Remote Control

To use the remote control, be sure that

its front end is pointing with a clear

path toward REMOTE SENSOR on

the front of the CD-3322, then press

the desired button(s).

Caution: Exposing the remote control

or REMOTE SENSOR to direct sun-

light or strong lights, such as a spot-

light, will reduce the remote control’s

operating distance and can make it in-

operative.

Notes:

• Several control buttons on both

the system and the remote control

operate the same function.

• You cannot operate the tape deck

using the remote control (see

“Cassette Deck Operation” on

Page 25).

• You cannot operate the CD-3322

using the remote control if the

POWER indicator is off (see

“Using the Remote Control to Turn

Power On/Off” on Page 11).

Turning Power

On/Off

Turning On/Off Main Power

To turn on the CD-3322’s main power

for normal or remote control operation,

press POWER on top of the system.

The POWER indicator turns on.

To turn off the main power (if you will

not be using the remote control), press

POWER again so the POWER indica-

tor turns off.

illustration illustration

14-547.fm Page 10 Wednesday, June 30, 1999 4:23 PM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Optimus Lettore CD

Optimus

Optimus CD-5500 Manuale utente

Optimus

Optimus CD-3640 (42-5074) Manuale utente

Optimus

Optimus CD-3580 Manuale utente

Optimus

Optimus CD-3329 Manuale utente

Optimus

Optimus CD-3840 Manuale utente

Optimus

Optimus CD-8400 Manuale utente

Optimus

Optimus CD-3330 Manuale utente

Optimus

Optimus CD-8250 Manuale utente

Optimus

Optimus 14-546A Manuale utente

Optimus

Optimus CD-8150 Manuale utente

Optimus

Optimus CD-3520 Manuale utente

Optimus

Optimus CD-3590 Manuale utente

Optimus

Optimus CD-3720 Manuale utente

Optimus

Optimus CD-3620 (42-5073) Manuale utente

Optimus

Optimus CD-3680 (42-5075) Manuale utente

Optimus

Optimus CD-3790 Manuale utente

Optimus

Optimus CD-8400 Manuale utente

Optimus

Optimus CD-3540 Manuale utente

Optimus

Optimus CD-3327 Manuale utente

Optimus

Optimus CD-3327 Manuale utente

Optimus

Optimus CD-3860 Manuale utente

Optimus

Optimus High-Power In-Dash AM/FM Stereo CD Player Manuale utente

Optimus

Optimus CD-3680 (42-5075) Manuale utente

Manuali Lettore CD popolari di altre marche

RCA

RCA RP-7923 Manuale utente

Pioneer

Pioneer DEH-P3550MP XM Manuale utente

Philips

Philips AZ1207 Manuale utente

Philips

Philips CD582 Manuale utente

Philips

Philips AZ 6821 Manuale utente

Lasonic

Lasonic MSU-2020 Manuale utente

THOMSON

THOMSON RCD150 Manuale utente

Denon

Denon DCD-1420 Manuale utente

Panasonic

Panasonic SJ-MR100 Manuale utente

Onkyo

Onkyo DX-7210 Manuale utente

Sony

Sony MZ-R3 Manuale utente

Denon

Denon DVM-4800 Manuale utente

JBL

JBL MR-32 Manuale utente

RCA

RCA RCD152 Manuale utente

Technics

Technics SL-PS770A Manuale utente

Clarion

Clarion compact disc Manuale utente

Sony

Sony MZ-M10 Manuale utente

Philips

Philips Expanium AZ 1538 Manuale utente
