Wiring Diagram
1. Connect the air connection cable to your screens source.
2. If your screen source has RCA connection only, use the Air to RCA connector.
Note: Only a qualified technician should install the camera. Please consult your nearest
reseller to arrange installation.
Do not try to repair the unit yourself. If you are experiencing any problems with this product,
please inform your nearest retailer. The product is comprised of many electronic components.
Attempting to repair or disassemble may cause the product to malfunction and void warranty.
www.optionaudio.com
Option Audio Pty Ltd, (OA) warrant all OA product to be free of defects in material and
workmanship for a period of (1) year form the date of original purchase provided they are
purchased from an authorized OA reseller in Australia. However, the effective warranty period
will be two (2) years if the products were purchased from and installed by an Authorised OA
Reseller. Do not try to repair the unit yourself. If you are experiencing any problems with this
product, please turn power off immediately and inform your nearest retailer. The product is
comprised of many electronic components. Attempting to repair or disassemble may cause
the product to malfunction and void warranty.
WHAT IS COVERED - Parts and labour to effect or, at the sole discretion of OA, replace of
either any malfunction or defective part(s) to or the entire system should the system or any
component part(s) there of ail to perform as designed.
WHAT IS NOT COVERED - Installation or setup and repair or replacement of the system or
any parts thereof which, in OA judgment, fail or become damaged as a result of negligence,
improper use, abuse, unauthorised modification or service, improper or inadequate packaging
during shipment, installation by a non-authorized dealer, accident, or use for any purpose
other than those for which this product was originally intended, or where the model’s serial
number has been removed, altered or defaced. The warranty is non transferable. Option
Audio will not accept consequential damages as a result of product failure.
Warranty
Precautions
Monitor
Air Connection
Camera
Additional Air to RCA Connector
