Optronis CR450x2 Manuale utente

CamRecord

CR450x2

CR600x2

CR1000x2

CR4000x2

CR5000x2

Ver. -

User Manual

Ref. 1830-SU-02-G

CR Series Ref. 1830-SU-02-G Page 1

Contents

General 3

Declaration of conformity 3

RoHS compliance 3

Scope of delivery 4

Optronis customer service 7

Safety Instructions 8

Typical System Configuration 9

Quick Start Instructions 10

Nikon F-Mount 10

To mount the Nikon F-Mount lens 10

To unmount the Nikon F-Mount lens 11

C-Mount 12

To mount the C-Mount lens 12

To unmount the C-Mount lens 12

Start of operation 13

Camera 15

Lens Interface 15

Accessories 15

Camera Socket 15

Electrical Interface 16

VGA Connector 16

Power Supply Input / Power Connector 17

Power-LED 17

GigE Connector 17

GigE Communication-LEDs 17

Trigger / Sync Connector (Aux.) 17

External Trigger (Trig In) 18

Trigger Control-LED 18

External Synchronisation Input (Sync In) 18

Synchronisation Output 19

Power Supply 20

Laptop (PC) 20

CamControl Software 21

TimeBench Software 21

Technical Data 22

CR450x2 22

Spectral Response / Transmittance 22

Bayer Pattern 23

CR600x2 24

Spectral Response / Transmittance 24

Bayer Pattern 25

CR1000x2 26

Spectral Response / Transmittance 26

Bayer Pattern 27

CR Series Ref. 1830-SU-02-G Page 2

CR4000x2 28

Spectral Response / Transmittance 28

CR5000x2 30

Spectral Response / Transmittance 30

Bayer Pattern 31

Performance (Examples) 32

CR450x2 32

CR600x2 32

CR1000x2 32

CR4000x2 33

CR5000x2 33

Mechanical Dimensions 34

CR 450x2, CR600x2, CR1000x2, CR4000x2, CR5000x2 34

External Inputs 36

Trigger & Synchronisation input 36

Synchronisation Timing 36

Trigger Timing 37

External Outputs 38

Synchronisation output 38

Synchronisation Timing 38

Focal Length Calculation 40

CR450x2 40

Full Sensor Resolution 40

Reduced Sensor Resolution 40

Distance Washer 42

CR600x2 43

Full Sensor Resolution 43

Reduced Sensor Resolution 43

Distance Washer 45

CR1000x2 46

Full Sensor Resolution 46

Reduced Sensor Resolution 46

Distance Washer 48

CR4000x2 49

Full Sensor Resolution 49

Reduced Sensor Resolution 49

Distance Washer 51

CR5000x2 52

Full Sensor Resolution 52

Reduced Sensor Resolution 52

Distance Washer 54

Illumination 55

General

Declaration of conformity

Manufacturer: Optronis GmbH

Address: Honsellstr. 8, 77694 Kehl, Germany

We certify and declare under our sole responsibility that

the following apparatus

Product: CR450x2, CR600x2, CR1000x2, CR4000x2, CR5000x2

conform with the essential requirements of the EMC

Directive 2004/108/EC, based on the following

specifications applied:

Specifications: EN 61000-6-3 Emission

EN 61000-6-1 Immunity

Kehl, 21.04.2009

Optronis GmbH

Dr. Patrick Summ

Managing Director

RoHS compliance

CamRecord CR series cameras are Pb free manufactured.

CR Series Ref. 1830-SU-02-G Page 3

CR Series Ref. 1830-SU-02-G Page 4

Scope of delivery

CR450x2 CamRecord High-Speed camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

/1GB: 1 GByte Memory

/2GB: 2 GByte Memory

/4GB: 4 GByte Memory

/8GB: 8 GByte Memory

/16GB: 16 GByte Memory

/MS: Multisequence / Multisegment

CR-SDK: Software Development Kit

CR-Labview: Labview Driver

Lens mount: /CM: CMount

/FM: FMount

Power supply: +12Volt / 2,5Amp., 100 .. 240VAC/50-60Hz

External Synchronisation / Trigger Adapter cable

User Manual

CamControl software (CD-ROM)

TimeBench software (CD-ROM) for camerasystems after 03.2010

CR600x2 CamRecord High-Speed camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

/2GB: 2 GByte Memory

/4GB: 4 GByte Memory

/8GB: 8 GByte Memory

/16GB: 16 GByte Memory

/UF: Ultra Format

CR-SDK: Software Development Kit

CR-Labview: Labview Driver

Lens mount: /CM: CMount

/FM: FMount

Power supply: +12Volt / 2,5Amp., 100 .. 240VAC/50-60Hz

External Synchronisation / Trigger Adapter cable

CR Series Ref. 1830-SU-02-G Page 5

User Manual

CamControl software (CD-ROM)

TimeBench software (CD-ROM) for camerasystems after 03.2010

CR1000x2 CamRecord High-Speed camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

/2GB: 2 GByte Memory

/4GB: 4 GByte Memory

/8GB: 8 GByte Memory

/16GB: 16 GByte Memory

/UF: Ultra Format

/US: Ultra Speed

CR-SDK: Software Development Kit

CR-Labview: Labview Driver

Lens mount: /CM: CMount

/FM: FMount

Power supply: +12Volt / 2,5Amp., 100 .. 240VAC/50-60Hz

External Synchronisation / Trigger Adapter cable

User Manual

CamControl software (CD-ROM)

TimeBench software (CD-ROM) for camerasystems after 03.2010

CR5000x2 CamRecord High-Speed camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

/2GB: 2 GByte Memory

/4GB: 4 GByte Memory

/8GB: 8 GByte Memory

/16GB: 16 GByte Memory

/UF: Ultra Format

/US: Ultra Speed

CR-SDK: Software Development Kit

CR-Labview: Labview Driver

CR Series Ref. 1830-SU-02-G Page 6

Lens mount: /CM: CMount

/FM: FMount

Power supply: +12Volt / 2,5Amp., 100 .. 240VAC/50-60Hz

External Synchronisation / Trigger Adapter cable

User Manual

CamControl software (CD-ROM)

TimeBench software (CD-ROM) for camerasystems after 03.2010

CR4000x2 CamRecord High-Speed camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

/2GB: 2 GByte Memory

/4GB: 4 GByte Memory

/8GB: 8 GByte Memory

/UF: Ultra Format

/US: Ultra Speed

CR-SDK: Software Development Kit

CR-Labview: Labview Driver

Lens mount: /CM: CMount

/FM: FMount

Power supply: +12Volt / 2,5Amp., 100 .. 240VAC/50-60Hz

External Synchronisation / Trigger Adapter cable

User Manual

CamControl software (CD-ROM)

TimeBench software (CD-ROM) for camerasystems after 03.2010

CR Series Ref. 1830-SU-02-G Page 7

Optronis customer service

Optronis GmbH

Honsellstrasse 8

77694 Kehl

Tel: +49 (0) 7851 9126 0

Fax: +49 (0) 7851 9126 10

e-mail: [email protected]

For any questions or problems, please do not hesitate to ask our customer

service. Please prepare the following information:

•Name of the device:

(CamRecord CR450x2, CR600x2, CR1000x2, CR4000x2,

CR5000x2)

•Serial-Number:

(see label at the bottom side of the camera)

•Software Version:

(Info-Menu of the CamControl or TimeBench software)

•Short description of the problem

CR Series Ref. 1830-SU-02-G Page 8

Safety Instructions

•Please operate the CamRecord CR cameras from a 110 Volt to

240 Volt (50 Hz to 60 Hz a.c. frequency) power source. Other

voltage levels or frequencies may damage the camera.

•Do not orientate the optical input of the camera to direct sunlight.

•Keep the camera free protected from dirt, dust, grease and water.

•Make sure that all the connecting cables are in good condition and

that they are well mounted to their sockets.

•Please use the socket of the camera and connect it to a sufficiently

stable basis.

•Avoid strong system shocks and vibrations during transport or

during operation.

•Always unplug the camera before cleaning it. Do not use cleaning

liquids or sprays. Instead, use a dry and soft duster.

•For any further questions please do not hesitate to contact

Optronis GmbH, especially when the camera do not work as it is

described in the user manual.
