Oreck QUEST MC1000 Manuale utente

User’s

Guide

Important!

Read this manual carefully, and keep for future reference.

MIN MAX

Oreck Quest™Compact Canister

MC1000

Other Oreck ac cessories a vail able at:

Other Oreck ac cessories avail able at:

Other Oreck ac cessories a vail able at:

Thank You for purchasing an Oreck Quest™Compact Canister!

This state of the art vacuum cleaner will help you have a

healthier clean home.

At Oreck we understand that our customers are unique and

expect superior service. To meet your needs, we offer

different customer service options to work with your lifestyle

and preferences.

Welcome to our Call. Click. Visit. customer service program.

Enjoy

Click

Call

Visit

To speak with an Oreck representative call:

USA: 1•800•989•3535

Canada: 1•888•676•7325

On the web, point and click at: www.oreck.com

and click locate a store on the top right.

Visit us in person at one of nearly 450 store

locations. To find the nearest store, please call

888•oreck (1•888•673•2578).

Contents

General Warnings ................................... 4

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operation ..................................... 4

Parts ............................................. 6

Product Components & Accessories . . . . . . . . . . . . . . . . 6

Assembly ......................................... 7

Assembling the Oreck Quest™Compact Canister . . . . . 7

Use .............................................. 8

Operating the Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Maintenance ....................................... 9

Replacing the Disposable Filter Bag . . . . . . . . . . . . . . . . 9

Cleaning/Replacing the Motor Filter. . . . . . . . . . . . . . . .10

Cleaning/Replacing the Exhaust Filter . . . . . . . . . . . . . .11

Troubleshooting ....................................12

Replacement Parts ..................................13

Warranty ..........................................14

Safety

IMPORTANT SAFETY

INSTRUCTIONS

General Warnings

When using an electrical appliance, basic precautions should

always be followed, including the following:

Read all instructions before using this vacuum cleaner

WARNING! To reduce the risk of fire, electric shock, or injury:

• The vacuum is intended for household use only.

• Use the vacuum only as described in this manual.

• Use only manufacturer’s recommended attachments.

Environment

Use of the vacuum outdoors or on wet surfaces may result in

damage to the appliance and void the warranty. Do not use

outdoors or on wet surfaces.

Use of the vacuum on stairs may cause imbalance, slippage or

tumbling. Always check your balance and ensure your footing

when cleaning on stairs.

Use of the vacuum in an enclosed space containing flam-

mable, explosive materials or toxic vapors may result in an

unexpected spark or fire. Do not use the vacuum in such an

enclosed space. Always check exposed wiring and wire con-

nections before use.

Operation

This appliance has powerful suction capability. Do not allow

it to be used as a toy and always maintain close attention when

used by or near children.

Loose clothing, jewelry and long hair may become entangled

in the suction of the vacuum and cause personal injury.

Always keep loose clothing, jewelry, fingers and all parts of

body away from openings.

Use of the vacuum with an opening blocked may reduce air-

flow. Keep all openings free of dust, lint, hair etc. Ensure the

filter bag assembly is in place before use.

Improper handling of the power cord may result in wiring,

connection damage and potential sparking or shock. Always

follow these instructions when handling the power cord:

Do not pull or carry the vacuum by the cord

Do not use the cord as a handle

Do not unplug the vacuum by pulling on the cord

Do not close a door on the cord

Do not pull the cord around sharp edges or corners

Keep the cord away from heated surfaces

Do not run the vacuum or other appliance over

the cord

A damaged cord or plug may cause a spark, shock and fire.

Always grasp the plug, not the cord, when unplugging the

vacuum. If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or similarly qualified

person in order to avoid a hazard.

Always check the cord and plug before use. If appliance is

not working as it should, has been dropped, damaged, left

outdoors, or dropped into water, return it to a service center

or call customer service at: U.S.: 1-800-989-3535 Canada:

1-888-676-7325.

Do not use the machine without a motor protection filter

installed

If abnormal noise, smell, smoke or any other failure or break-

age is found during the operation, you should turn off the

switch and unplug it. Then contact your service center for

repair. Do not attempt to repair by yourself.

Using the vacuum with wet hands and on wet surfaces may

result in unexpected shock, slippage and personal injury.

Do not handle the plug or appliance with wet hands or on

wet surfaces.

Vacuuming burning or smoking objects, flammable or com-

bustible liquids and toxic material may result in a fire and

personal injury. Do not vacuum burning or smoking objects,

flammable or combustible liquids.

Unplugging the vacuum while the controls are ON may cause

sparking and fire. Turn OFF all controls before unplugging.

Do not leave appliance unattended when plugged in. Unplug

from outlet when not in use and before servicing.

•

SAVE THESE

INSTRUCTIONS

Residential Use Only

11. Telescopic Wand

12. Bare Floor Adjustment

13. Disposable Filter Bag

14. Removable Bag Dock

15. Motor Filter Grill

16. Motor Filter

17. Exhaust Filter

18. Multi-Surface Floor Tool

19. Release Tab

MIN MAX

1. Intake

2. Top Cover

3. Variable Speed Slide Control

4. Bag Full Indicator

5. Cordwinder Pedal

6. Power Cord

7. Power ON/OFF Pedal

8. 2-in-1 Crevice Tool

9. Handle with Hose

10. Suction Control

Product Components

& Accessories

Parts

Assembling the

Oreck Quest™Compact Canister

Connect hose by firmly inserting end of hose into canister

intake opening.

Firmly press handle nozzle into telescopic wand.

Insert smaller end of telescopic wand into the multi-sur-

face floor tool or 2-in-1 crevice tool.

Extend telescopic wand by pushing button on wand and

pulling out to extend to desired length.

Assembly

Important!

Make sure disposable filter bag is in place. DO NOT

operate the cleaner without a dust bag.

Use

Note: Accessories can be used with the

telescopic wand or handle alone.

MIN MAX

Operating the Vacuum

MIN MAX

1. Pull plug from unit and insert into

wall outlet.

2. Press the ON/OFF pedal located at

the rear of the canister to turn on.

3. To adjust suction, use the suction

control on the handle.

4. To adjust the power of the motor,

use the variable slide control on top

of the unit.

5. The multi-surface floor tool is adjustable

for use on carpets (without brush).

Gently step on the bar floor adjustment

switch to engage brushes.

Switch the unit off. Unplug unit from the wall outlet.

Open top cover by lifting the latch in front of the intake.

Remove disposable filter bag by raising up on the

removable bag dock and lifting it out of the unit.

Gently pull bag cardboard collar upward out of the

bag dock.

Performing maintenance on the vacuum while

it is plugged into a wall outlet may result in

unexpected vacuum operation, shock and

personal injury. Always turn the vacuum OFF

and unplug before performing inspection and

maintenance.

If the power cord is damaged, replace it only by

the factory or maintenance center or similarly

qualified person.

Maintenance

WARNING!

Replacing Disposable Filter Bag

To keep your cleaner operating at maximum efficiency, change

the dust bag frequently or when the bag full indicator turns red.

Bag Removal:

Locking Tab

Insert a new bag into dock by sliding cardboard collar

under clamps until bag is fully inserted.

Insert tab of bag dock into wall brackets until locking tab

locks into place.

Remove the bag dock to access the motor filter grill. Slide

motor filter grill up and out of the unit.

Remove motor filter from grill.

Wash motor filter with warm water without any additives.

Reinstall the filter after it has had time to thoroughly dry.

Note: If the filter is damaged, it should be discarded and

replaced with a new filter.

Replace the dry filter over the tabs in the motor filter grill.

Bag Installation:

Cleaning/Replacing the Motor Filter:
