Radio-Controlled Travel Alarm

Clock With World Time

Model : RM323A

User Manual

CONTROL BUTTONS: FRONT PANEL

1. [SNOOZE/LIGHT] BUTTON

- Press to turn on the back-light for 5 seconds

- Press to activate the Snooze function when the alarm

goes off

-Press and hold for 3 seconds to turn off the alarm

when the alarm goes off

2. [WORLD TIME] BUTTON

- Press to enter the world time setting mode

3. [ MODE ] BUTTON

Press to change between the clock and calendar display modes

- Press and hold for 2 seconds to enter the clock and

calendar setting mode

RADIO-CONTROLLED TRAVEL ALARM

CLOCK WITH WORLD TIME

MODEL NO.: RM323A

USER MANUAL

INTRODUCTION

Congratulations on purchasing the RM323A Radio-controlled

Travel Clock with World Time.

This clock is a compact device for travellers. It is designed to

automatically synchronize its current time and date with the

U.S. Atomic clock.

In addition to the local time and calendar display, the users

can also select to display the corresponding time of 130 major

world cities.

This clock also comes with favorable features including key-

lock function, multilingual day-of-the-week display, EL back-

light, hourly chime and dual alarm with 8-minute snooze

function.

RM323A_M_Eng.p65 2004.10.21, 6:47 PM1

4. FOLDABLE TABLE STAND

BEFORE YOU BEGIN

Before operation, remember to slide the key-lock switch to

the left to release all key operations.

BATTERY INSTALLATION

1. Remove the battery compartment door.

2. Insert two (2) pieces of “AAA” 1.5V batteries as shown.

3. Press [RESET].

4. Replace the battery compartment door.

4. [ALARM] BUTTON

- Press to toggle among the calendar, weekday alarm

and single alarm modes

- Press and hold for 2 seconds to enter the setting modes

of the corresponding alarm in display

5. [ALARM ON/OFF] BUTTON

- Press to activate/deactivate the corresponding alarm

in display

CONTROL BUTTONS: REAR PANEL

1. [KEY-LOCK] SLIDE SWITCH

- Slide to lock the key-functions

2. [RESET] BUTTON (inside battery compartment)

- Press to return all settings to default values

3. ROTARY KNOB [UP] AND [DOWN] BUTTONS

Scroll up or down to increase/ decrease the value of a setting

RM323A_M_Eng.p65 2004.10.21, 6:47 PM2

When the battery power level is low, the low battery indicator [ ]

will light up. Replace the batteries accordingly.

CTIVATING THE BACK-LIGHT

When the unit is placed on the table, press [SNOOZE/LIGHT]

button downward to turn on the back-light for 5 seconds.

DISPLAY MODES

Press [MODE] button to display the following in sequence:

1Current Time with Seconds

World City Name Abbreviation & Time

2) Current Time with Weekday

World City Name Abbreviation & Time

3) Calendar

World City Name Abbreviation & Time

To display the dual alarm times, press [ALARM] button.

ABOUT RADIO RECEPTION

This clock is designed to automatically synchronize its calen-

dar clock once it is brought within the range of the WWVB

radio signal broadcast from Ft. Collins, Colorado. When the

unit is within range, its radio-control mechanism will override

all manual settings unless auto-reception of radio signal has

been manually deactivated.

When the clock is receiving radio signal, the radio reception

icon will start to blink. A complete reception generally takes

about 2 to 10 minutes, depending on the strength of the radio

signal. When the reception is complete, the radio reception

icon will stop blinking. The strength of the reception for the

last full hour will be indicated.

For better reception, place the unit away from metal objects

and electrical appliances to minimize interference.

Should you wish to deactivate the RF controlled function, press

and hold [DOWN] button for 3 seconds. The radio reception

icon will disappear. To reactivate the RF controlled function,

press and hold [UP] button for 3 seconds again and the radio

reception icon will be re-displayed.

RM323A_M_Eng.p65 2004.10.21, 6:47 PM3

SETTING THE CLOCK AND CALENDAR

CLOCK MANUALLY

1. Press and hold [MODE] button for 2 seconds.

2. Using the [UP]/[DOWN] button to scroll through the 4

U.S. time-zones (Pacific, Mountain, Central or Eastern)

or non-U.S.cities. Press [MODE] to confirm.

3. If non-U.S. city is selected, the world time city will be

flashing. Use [UP]/[DOWN] to select the city (for city

names abbreviation, please refer to the section “Selecting

the World Time”). Press [MODE] to confirm.

4. Repeat the same procedures to set the hours, minutes,

year, month, day, language of day-of-week and hourly-

chime on/off by using [UP]/[DOWN] button.

5. Press [MODE] button to save the changes and exit.

6. For the language for day-of-week, you can select “E” for

English, “D” for German, “F” for French, “I” for Italian or

“S” for Spanish. The day-of-week can be expressed as

an abbreviation in five different languages. The languages

and their selected abbreviations for each day of the week

are shown in the language chart below.

NOTE When changes are made to the minute, the sec-

onds will start from zero. The unit will also save all changes

and return to normal display automatically after the unit

has been left idle for a minute.

ABOUT THE HOURLY-CHIME FUNCTION

When the Hourly-Chime is set to on, the indicator [ ] will

light up and a beep sound will be given out at the beginning of

each hour.

Monday Tuesday Wed. Thursday Friday Saturday Sunday

Day-of-the-week

Language

English

German

French

Italian

Spanish

-Strong

-Weak

-No Reception

-Receiving

RM323A_M_Eng.p65 2004.10.21, 6:47 PM4

SETTING THE ALARM

This clock is equipped with 2 alarms: Weekday Alarm and

Single Alarm. For the Weekday Alarm, alarm will only sound

out at the preset times during weekday (i.e., from Monday to

Friday) and will be automatically disabled during the week-

end (i.e., Saturday and Sunday). For the Single Alarm, alarm

will sound out once at the preset time.

To set the alarm:

1. Press [ALARM] to change to the respective alarm-time

display mode.

2. Press and hold [ALARM] for 2 seconds.

3. Use [UP]/[DOWN] button to enter the hours. Press

[ALARM] button to confirm.

4. Use [UP]/[DOWN] to enter the minutes. Press [ALARM]

to exit.

The alarm will be automatically activated after setting. The

corresponding Alarm-On indicator [ ] or [ ]will appear.

To deactivate the alarm, press the [ ON/OFF ] button when

the corresponding alarm time is displayed. [ -: -- ] will be dis-

played to indicate such deactivation.

ALARM AND SNOOZE FUNCTION

An alarm will go off for 2 minutes in two-step crescendo

patterns if undisturbed. The Alarm-On indicator will flash and

the back-light will be activated for 5 seconds. To mute the

alarm, press any key. Pressing [SNOOZE/LIGHT] button

will activate the snooze function.

When the snooze function is activated, the alarm will be

muted temporarily and set off again after 8 minutes. To disable the

snooze function when the alarm goes off, you can press

and hold the [SNOOZE/LIGHT] button for 3 seconds.Alternatively

press [ALARM] or [ ON/OFF] button.

SETTING THE WORLD TIME

This clock features a World-time display function so that you

can check the corresponding time of different places in the

world instantly with DST [Daylight Saving Time] automatically

adjusted. The names of the world cities are shown in an abbre-

viated 3-letter format (e.g., “WDC” for Washington DC, U.S.).

To set the world time:

1. Press [WORLD TIME] button once. The World-Time icon

will be flashing.

2. Use the [UP]/[DOWN] button to select the world city.

3. Press the [WORLD TIME] button to confirm.

RM323A_M_Eng.p65 2004.10.21, 6:47 PM5

World City Abbreviations Reference Table

Country Name City code Time Offset DST Period

(GMT = 0)

Addis Ababa, Ethiopia ADD 3 No DST

Adelaide, Australia ADL 9.5 From Last Sunday in October to Last Sunday in March

Auckland, New Zealand AKL 12 From 1st Sunday in October to 3rd Sunday in March

Ankara, Turkey AKR 2 From Last Sunday in March to Last Sunday in October

Algiers, Algeria ALG 1 No DST

Amsterdam, Netherlands AMS 1 From Last Sunday in March to Last Sunday in October

Anchorage AK, USA ANC -9 From 1st Sunday in April to Last Sunday in October

Antananarivo, Madagascar ANT 3 No DST

Asuncion, Paraguay ASU -4 From 1st Sunday in September to 1st Sunday in April

Athen, Greece ATH 2 From Last Sunday in March to Last Sunday in October

Atlanta GA, USA ATL -5 From 1st Sunday in April to Last Sunday in October

Abu Dhabi, U.A.E AUH 4 No DST

Bucharest, Romania BBU 2 From Last Sunday in March to Last Sunday in October

Barcelona, Spain BCN 1 From Last Sunday in March to Last Sunday in October

Baghdad, Iraq BDD 3 From 1st April to 1st October

Belgrade, Yugoslavia BEG 1 From Last Sunday in March to Last Sunday in October

Beijing, China BEJ 8 No DST

Berlin, Germany BER 1 From Last Sunday in March to Last Sunday in October

Beirut, Lebanon BEY 2 From Last Sunday in March to Last Sunday in October

Bangkok, Thailand BKK 7 No DST

Brisbane, Australia BNE 10 No DST

Bogota, Colombia BOG -5 No DST

Boston MA, USA BOS -5 From 1st Sunday in April to Last Sunday in October

Bern, Switzerland BRN 1 From Last Sunday in March to Last Sunday in October

RM323A_M_Eng.p65 2004.10.21, 6:47 PM6

Brussels, Belgium BRU 1 From Last Sunday in March to Last Sunday in October

Brasilia, Brazil BSB -3 From 2nd Sunday of October to 3rd Sunday of February

Buenos Aires, Argentina BUA -3 No DST

Budapest, Hungary BUD 1 From Last Sunday in March to Last Sunday in October

Cairo, Egypt CAI 2 From Last Friday in April to Last Friday in September

Casablanca, Marocco CAS 0 No DST

Canberra, Australia CBR 10 From Last Sunday in October to Last Sunday in March

Caracas, Venezuela CCS -4 No DST

Calcutta, India CCU 5.5 No DST

Chicago IL, USA CGX -6 From 1st Sunday in April to Last Sunday in October

Colombo, Sri Lanka CMB 6 No DST

Copenhagen, Denmark CPH 1 From Last Sunday in March to Last Sunday in October

Cape Town, South Africa CPT 2 No DST

Dhaka, Bangladesh DAC 6 No DST

Damascus, Syria DAM 2 From 1st April to 1st October

New Delhi, India DEL 5.5 No DST

Detroit MI, USA DTW -5 From 1st Sunday in April to Last Sunday in October

Dublin, Ireland DUB 0 From Last Sunday in March to Last Sunday in October

Frankfurt, Germany FRA 1 From Last Sunday in March to Last Sunday in October

Guatemala City, Guatemala GUA -6 No DST

Geneva, Switzerland GVA 1 From Last Sunday in March to Last Sunday in October

Hamburg, Germany HAM 1 From Last Sunday in March to Last Sunday in October

Hanoi, Vietnam HAN 7 No DST

Havana, Cuba HAV -5 From 1st Sunday in April to Last Sunday in October

Ho Chi Minh City, Vietnam HCM 7 No DST

Helsinki, Finland HEL 2 From Last Sunday in March to Last Sunday in October

Hong Kong, China HKG 8 No DST

Honolulu HI, USA HNL -10 No DST

RM323A_M_Eng.p65 2004.10.21, 6:47 PM7

Houston TX, USA HOU -6 From 1st Sunday in April to Last Sunday in October

Indianapolis, IN, USA IND -5 No DST

Istanbul, Turkey IST 2 From Last Sunday in March to Last Sunday in October

Jakarta, Indonesia JKT 7 No DST

Johannesburg, South Africa JNB 2 No DST

Kabul, Afghanistan KBL 4.5 No DST

Khartoum, Sudan KHA 3 No DST

Kiev, Ukraine KIE 2 From Last Sunday in March to Last Sunday in October

Kingston, Jamaica KIN -5 No DST

Kathmandu, Nepal KTM 5.75 No DST

Kuala Lumpur, Malaysia KUL 8 No DST

Kuwait City, Kuwait KWI 3 No DST

Las Vegas NV, USA LAS -8 From 1st Sunday in April to Last Sunday in October

Los Angeles CA, USA LAX -8 From 1st Sunday in April to Last Sunday in October

Lima, Peru LIM -5 No DST

Lisbon, Portugal LIS 0 From Last Sunday in March to Last Sunday in October

London, UK LON 0 From Last Sunday in March to Last Sunday in October

Lagos, Nigeria LOS 1 No DST

La Paz, Bolivia LPB -4 No DST

Luxembourg, Luxembourg LUX 1 From Last Sunday in March to Last Sunday in October

Madrid, Spain MAD 1 From Last Sunday in March to Last Sunday in October

Melbourne, Australia MEL 10 From Last Sunday in October to Last Sunday in March

Mexico City, Mexico MEX -6 From 1st Sunday in April to Last Sunday in October

Managua, Nicaragua MGA -6 No DST

Miami FL, USA MIA -5 From 1st Sunday in April to Last Sunday in October

Milan, Italy MIL 1 From Last Sunday in March to Last Sunday in October

Manama, Bahrain MNA 3 No DST

Manila, Philippines MNL 8 No DST

RM323A_M_Eng.p65 2004.10.21, 6:47 PM8

Montreal, Canada MON -5 From 1st Sunday in April to Last Sunday in October

Moscow, Russia MOW 3 From Last Sunday in March to Last Sunday in October

Montevideo, Uruguay MVD -3 No DST

Nassau, Bahamas NAS -5 From 1st Sunday in April to Last Sunday in October

Nairobi, Kenya NRB 3 No DST

New York NY, USA NYC -5 From 1st Sunday in April to Last Sunday in October

Oslo, Norway OSL 1 From Last Sunday in March to Last Sunday in October

Ottawa, Canada OTW -5 From 1st Sunday in April to Last Sunday in October

Port-au-Prince, Haiti PAP -5 No DST

Paris, France PAR 1 From Last Sunday in March to Last Sunday in October

Perth, Australia PER 8 No DST

Pheonix, AZ, USA PHE -7 No DST

Phnom Penh, Cambodia PNH 7 No DST

Port-Of-Spain, Trinidad & Tobago

POS -4 No DST

Papeete, French Polynesia PPT -10 No DST

Prague, Czech Republic PRG 1 From Last Sunday in March to Last Sunday in October

Portland OR, USA PTL -8 From 1st Sunday in April to Last Sunday in October

Pretoria, South Africa PTR 2 No DST

Panama City, Panama PTY -5 No DST

Yangon, Myanmar RGN 6.5 No DST

Rio de Janeiro, Brazil RIO -3 From 2nd Sunday of October to 3rd Sunday of February

Reykjavik, Iceland RKV 0 No DST

Rome, Italy ROM 1 From Last Sunday in March to Last Sunday in October

Riyadh, Saudi Arabia RUH 3 No DST

San Salvador, El Salvador SAL -6 No DST

Santiago, Chile SCL -4

From 1st Sunday on or after 9th October to 1st Sunday on or after 9th March

Seattle WA, USA SEA -8 From 1st Sunday in April to Last Sunday in October

Seoul, South Korea SEL 9 No DST

RM323A_M_Eng.p65 2004.10.21, 6:47 PM9

Altri manuali per RM323A

Indice

Lingue:

Altri manuali Oregon Scientific Sveglia

Oregon Scientific

Oregon Scientific RM983A Manuale utente

Oregon Scientific

Oregon Scientific RM103A Manuale utente

Oregon Scientific

Oregon Scientific RM106A Manuale utente

Oregon Scientific

Oregon Scientific RM932A Manuale utente

Oregon Scientific

Oregon Scientific RMB383 Manuale utente

Oregon Scientific

Oregon Scientific VR101 Manuale utente

Oregon Scientific

Oregon Scientific RM938 Manuale utente

Oregon Scientific

Oregon Scientific RM313PNA Manuale utente

Oregon Scientific

Oregon Scientific RM926 Manuale utente

Oregon Scientific

Oregon Scientific EW96 Manuale utente

Oregon Scientific

Oregon Scientific RM510 Manuale utente

Oregon Scientific

Oregon Scientific World Time Alarm Clock with USB Hub RAS200 Manuale utente

Oregon Scientific

Oregon Scientific RM308P Manuale utente

Oregon Scientific

Oregon Scientific EW98 Manuale utente

Oregon Scientific

Oregon Scientific RESONANCE CIR600 Manuale utente

Oregon Scientific

Oregon Scientific WS902 Manuale utente

Oregon Scientific

Oregon Scientific AS-688NE Manuale utente

Oregon Scientific

Oregon Scientific RM106A Manuale utente

Oregon Scientific

Oregon Scientific RM323A Manuale utente

Oregon Scientific

Oregon Scientific RM313PNA Manuale utente

Oregon Scientific

Oregon Scientific IWA-80055 Manuale utente

Oregon Scientific

Oregon Scientific RM981A Manuale utente

Oregon Scientific

Oregon Scientific AS-316NE Manuale utente

Oregon Scientific

Oregon Scientific RM818P Manuale utente

Manuali Sveglia popolari di altre marche

Steren

Steren CLK-210 Manuale utente

COP-USA

COP-USA ALCDVR32-SL Manuale utente

Philips

Philips HF3505/70 Manuale tecnico

Casio

Casio PQ-70 Manuale utente

iHome

iHome IA63 Manuale utente

Coopers

Coopers 9765 Manuale utente

ANJANK

ANJANK AC-190 Guida

TFA

TFA 98.1075 Manuale utente

Sharper Image

Sharper Image 204050 Manuale utente

Lumie

Lumie Zest Manuale utente

Dexford

Dexford RCT200 Manuale utente

Philips

Philips AJL303/37B Manuale utente

RST

RST Q754 Manuale utente

iHome

iHome iKT50 Manuale utente

Sony

Sony dash HID-B7 Manuale utente

SVINZ

SVINZ SCC009 Manuale utente

Clas Ohlson

Clas Ohlson 918863 Manuale utente

IKEA

IKEA FNURRA Manuale utente
