Oregon Scientific BAR332ES Manuale utente
User Manual
+ECO Solar Weather Clock
Model: BAR332ES / BAR332ESA / BAR332ESU
EN
1
+ECO Solar Weather Clock
Model: BAR332ES / BAR332ESA /
BAR332ESU
USER MANUAL
CONTENTS
Earth Friendly................................................................... 2
Overview........................................................................... 2
Front View ...................................................................... 2
Top View ........................................................................ 3
Bottom View ................................................................... 3
Solar Panel..................................................................... 4
Remote Sensor .............................................................. 4
Getting Started................................................................. 4
Solar Panel..................................................................... 4
Backup Power ................................................................ 6
Remote Sensor................................................................. 6
Clock and Calendar ......................................................... 7
Clock Reception ............................................................. 7
Manually Set Clock......................................................... 7
Alarm................................................................................. 8
Temperature ..................................................................... 8
Weather forecast.............................................................. 8
Backlight........................................................................... 9
Reset ................................................................................. 9
Specications................................................................... 9
Precautions ...................................................................... 9
About Oregon Scientific................................................ 10
EU-Declaration of Conformity....................................... 10
FCC Statement ............................................................... 10
EN
2
EARTH FRIENDLY
The +ECO line embodies our commitment to environmental
concerns. Aware of threats facing the world we live in,
Oregon Scientic™ has combined technological know-how,
practicality and style to create this line of environmentally
friendly products. These products provide practical solutions
while enabling you and us to fulll our environmental
responsibility.
Simply detach the solar panel and face it directly towards
the sun for a few hours to receive the amount of energy
necessary to power the device.
Together we can improve the world we live in.
OVERVIEW
FRONT VIEW
1
10
11
12
13
14
15
16
2
3
4
5
6
7
8
9
1. : Remote sensor reception indicator and outdoor
channel selected
2. Outdoor temperature
3. Indoor temperature
4. Weather forecast
EN
3
5. : Clock signal reception indicator
6. : Alarm time is displayed
7. : Daily alarm is On
8. AM / PM
9. Rechargeable battery status LED indicator
10. : Outdoor remote sensor battery low
11. : Main unit back-up batteries low / no battery
12. : AC adaptor connected
13. : Rechargeable battery is low / solar panel detached
14. : Rechargeable battery level indicator
15. : Time zone offset
16. Calendar / Clock with weekday / seconds
TOP VIEW
1 2 3 4 5 6
1. SNOOZE: Activate snooze alarm / backlight
2. / : Increase / decrease value of the setting;
activate / deactivate clock reception signal
3. : Change display; set clock
4. : Toggle between outdoor temperature channels
(1-3); initiate auto-toggle
5. : View alarm status; set alarm
6. : Activate / deactivate alarm function
BOTTOM VIEW
1 2 3
1. SEARCH: Initiate sensor search
2. RESET: Reset unit to default settings
3. °C / °F: Select temperature unit
EN
4
SOLAR PANEL
1 2 3
4
5
1. CHARGING: charging in process
2. FULL: batteries fully charged (when TEST is pressed)
3. Solar panel
4. TEST establish if battery is full
5. Battery compartment
REMOTE SENSOR
1
2
3
4
5
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET: Reset unit to default settings
5. CHANNEL switch
GETTING STARTED
SOLAR PANEL
This product uses two AAA rechargeable batteries which
should be charged via the solar panel. For the batteries’
rst charge, it is strongly advised to charge it for at least
12 hours.
EN
5
To charge the battery:
1. Detach solar panel by exerting downward pressure and
pulling at a 45° angle (approx.) away from main unit.
2. Insert 2 AAA rechargeable batteries in battery
compartment located at the back of the solar panel.
IMPORTANT Place ONLY NiMH type rechargeable
batteries in the solar panel battery compartment. Do not
charge non-rechargeable batteries.
3. Expose the solar panel directly to sunlight for
approximately 5-6 hours to charge the battery. The
(red) CHARGING LED on solar panel will light up
indicating there is sunlight and unit is charging.
TIP Press and hold TEST located at the back of the solar
panel. (Green) FULL LED indicates batteries have been fully
charged.
4. Align holes with protruding plastic. Push solar panel
towards main unit and snap into place.
5-6 hours of battery charging will normally provide power to
operate unit for 2 months.
When the rechargeable battery is nearly at or when solar
panel has been detached, the (green) LED indicator on the
main unit and will ash.
TIPS
• For best results when charging the battery, place the
solar panel directly with view to sunlight.
• Direct solar panel as follows:
Solar panel facing: if you reside in the:
North Southern Hemisphere
South Northern Hemisphere
• Do not scratch the solar panel’s surface or wipe it with
strong detergent.
• Do not expose the solar panel to rain, snow or
moisture.
• The duration of the rechargeable battery’s charging or
operating time is determined by either the intensity of
sunlight or the position of the solar panel towards the
sun.
• Do not overcharge the batteries.
EN
6
BACKUP POWER
1 piece AAA battery
In the case when the rechargeable battery is at or nearly
at or when the solar panel has been detached, the AAA
battery can act as backup power supply for the main unit.
1. Remove the battery compartment located at the base
of the unit.
2. Insert the battery, matching the polarity.
3. Press RESET after each battery change.
Power adaptor (not included)
The adaptor powers the unit and can also be used for
charging the rechargeable battery. When connected to the
main unit, will be displayed.
NOTE The main unit and adaptor should not be exposed to
wet conditions. No objects lled with liquid, such as vases,
should be placed on the main unit and adaptor.
REMOTE SENSOR
This product can work with up to 3 sensors at any one time
to capture temperature readings in various locations.
To set up the remote sensor:
1. Slide open the battery compartment.
2. Slide channel switch to select a channel (1, 2, 3).
Ensure you use a different channel for each sensor.
3. Insert the battery, matching the polarities.
4. Press RESET after each battery change.
5. Close the battery compartment.
6. Press and hold SEARCH for 2 seconds to initiate a
sensor search.
NOTE Use alkaline batteries for longer usage and
consumer grade lithium batteries in temperatures below
freezing.
The remote sensor reception icon will show the following
status:
ICONS MEANING
Main unit is searching
for sensor(s)
A sensor channel has
been found
No sensor found
TIP Ideal placements for the sensor would be in any
location on the exterior of the home at a height of not more
than 1.5 m (5 ft) and which can shield it from direct sunlight
or wet conditions for an accurate reading.
EN
7
1.5 m (5 ft)
CLOCK AND CALENDAR
CLOCK RECEPTION
This product is designed to synchronize its clock
automatically with a clock signal.
BAR332ES: EU: DCF-77 signal: within 1500 km (932 miles)
of Frankfurt, Germany.
BAR332ESU: UK: MSF-60 signal: within 1500 km (932
miles) of Anthorn, England.
BAR332ESA: WWVB-60 signal: within 3200km (2000
miles) of Fort Collins Colorado.
To enable / disable clock signal reception:
Press and hold to enable or to disable clock signal
reception.
NOTE Reception takes 2-10 minutes. If the signal is weak,
it can take up to 24 hours to get a valid signal. If signal
reception is unsuccessful, place your unit next to a window,
press and hold to force another signal search.
Clock signal reception indicator:
STRONG SIGNAL WEAK / NO SIGNAL
MANUALLY SET CLOCK
To set the clock manually, disable the clock signal reception
rst.
1. Press and hold .
2. Press / to change the settings.
3. Press to conrm.
EN
8
The settings order is: time zone, 12/24 hr format, hour,
minute, year, calendar mode (month – day / day – month),
month, day and language.
BAR332ES / BAR332ESU: Time zone offset sets the clock
+/- 23 hours from the received clock signal time. If you have
deactivated the clock signal reception, do not set a value
for time zone.
NOTE If you enter +1 in the time offset setting, this will
give you your local time plus one hour. If you are in the US
(BAR332ESA) set the clock to:
PA for Pacic time MO for Mountain time
CE for Central time EA for Eastern time
NOTE The language options are English (E), German (D),
French (F), Italian (I), Spanish (S) and Russian (R).
To select clock display:
Press to toggle between clock with seconds, clock with
weekday and calendar.
ALARM
To set the alarm:
1. Press and hold to enter alarm setting.
2. Press / to set hour / minute.
3. Press to conrm.
indicates alarm is ON.
To activate / deactivate alarm:
Press .
To silence the alarm:
• Press SNOOZE to silence it for 8 minutes
OR
• Press any key to turn the alarm off and activate it again
after 24 hours.
To display alarm:
Press .
TEMPERATURE
To toggle temperature unit:
Press °C / °F.
To toggle between each outdoor sensor’s readings:
• Press repeatedly
OR
• Press and hold for 2 seconds to initiate auto toggle
of outdoor channels.
WEATHER FORECAST
This product forecasts the next 12 to 24 hours of weather
forecast within a 30-50 km (19-31 mile) radius.
Altri manuali per BAR332ES
3
Questo manuale è adatto per i seguenti modelli
2
Indice
Lingue:
Altri manuali Oregon Scientific Orologio
Oregon Scientific
Oregon Scientific BAR669H Manuale utente
Oregon Scientific
Oregon Scientific RMB899P Manuale utente
Oregon Scientific
Oregon Scientific BAR623PU Manuale utente
Oregon Scientific
Oregon Scientific RRM320PU Manuale utente
Oregon Scientific
Oregon Scientific Slim Projection Clock RA368P Manuale utente
Oregon Scientific
Oregon Scientific BAR339P Manuale utente
Oregon Scientific
Oregon Scientific JM889N Manuale utente
Oregon Scientific
Oregon Scientific RM988P Manuale utente
Oregon Scientific
Oregon Scientific 983U Manuale utente
Oregon Scientific
Oregon Scientific BAR223P Manuale utente
Oregon Scientific
Oregon Scientific Imola FST-301 Manuale utente
Oregon Scientific
Oregon Scientific RM939P Manuale utente
Oregon Scientific
Oregon Scientific RM962U Manuale utente
Oregon Scientific
Oregon Scientific WS902 Manuale utente
Oregon Scientific
Oregon Scientific RM303P Manuale utente
Oregon Scientific
Oregon Scientific RRM320P Manuale utente
Oregon Scientific
Oregon Scientific DP100 Manuale utente
Oregon Scientific
Oregon Scientific RM826 Manuale utente
Oregon Scientific
Oregon Scientific Glaze JW208 Manuale utente
Oregon Scientific
Oregon Scientific BAR623PA Manuale utente
