RADIO CONTROLLED WATCH

MODEL NO.: RMW128C/ RMW128S

USER’S MANUAL

Congratulations on your purchasing the RMW128C/ RMW128S

Radio-controlled Watch.

The R Watch is a compact, easy-to-handle device with smart-

looking design. The RMW128C (Classic Design) and RMW128S

(Sport Design) are designed to automatically synchronize its current

time and date when brought within an approximate 1500km radius

of the radio signal generated from rankfurt, Germany (DC 77).

This unit also comes with features such as Daily Alarm, Stopwatch,

2nd zone-time and Countdown Timer functions as well as EL back

light.

FEATURES AND KEY CONFIGURATIONS

1. MODE BUTTON

-Press to change the display mode

-Press and hold to enter the setting routine

2. ALARM BUTTON

-Press to display the daily alarm function

-Press and hold to enable/disable the alarm

3. START/STOP (UP) BUTTON

-Press to increase the value of a setting

-Press to start or stop the stopwatch function

-Press and hold to enable auto-reception of radio signal

4. SPLIT (DOWN) BUTTON

-Press to decrease the value of a setting

-Press to reset or change the display of the stopwatch function

-Press and hold to disable auto-reception of radio signal

5. LIGHT BUTTON

-Press to turn on the back light for 3 seconds

6. ZONE BUTTON

-Press to change to 2nd zone time and date display

7. WEEKDAY INDICATOR

8. 2ND ZONE-TIME DISPLAY MODE

9. ALARM MODE

10. ALARM-ON INDICATOR

11. STOPWATCH MODE

12. TIMER MODE

13. RADIO RECEPTION INDICATOR

8913

10 11 12

BATTERY

The battery is pre-installed at time of manufacture and should be

replaced by authorized dealer only.

Replace the battery when the weekday indicator starts flashing.

BACK LIGHT

Press the LIGHT button to turn on the back light for 3 seconds.

Note: requent use of the backlight will shorten the barttery life.

DISPLAY ODES

Press the ODE button to display the following in sequence:

• Time with Seconds

• Time with Calendar

• Zone Time and Date

• Daily Alarm

• Stopwatch

• Countdown Timer

You can also press ALAR to display the alarm clock and details.

Display will return to the last display mode upon release of the

ALARM button.

MODE

Press ZONE to display the 2nd zone-time and calender. After 3

seconds the display will return to the Time with seconds display

mode.

ABOUT RADIO RECEPTION

When the unit is within range of its respective radio signals, its

radio-control mechanism will override all manual settings unless

the auto-reception function is mannally disabled by the users.

When the unit is receiving radio signal, the RADIO RECEPTION

icon [ ]will start to blink. A complete reception generally takes

about 2 to 10 minutes, depending on the strength of the radio signal.

After that, the periodical scanning will only take a few seconds.

When the reception is complete, the icon will stop blinking.

For better reception of radio signals, place the watch away from

metal objects and electrical appliances to minimize interference.

To improve the signal reception place the watch on a stable surface

as shown:

NOTES ON RADIO RECEPTION

Signals from other electrical devices such as mobile phones,

computers or other household appliances may cause interference

with this product and results in failure of reception of radio signal.

Metal furniture such as steel table also has similar effect on the

reception. Radio signal reception can also become difficult or even

impossible when the product is situated near radio stations, airports,

in tunnels or underground. This is normal and does not affect the

general performance of the product. In case auto-reception of radio

signalfails, you can manually activatethe receptionagain by pressing

and holding the START/STOP (UP) button for 2 seconds.

To enhance reception of radio signal, you can also:

(a) Move the product to a location which is near to a window; for

optimization you can even leave the product overnight as it will

search for signal automatically at 2:00 am (summer time)/ 3:00

am (winter time); or

(b) Go outdoor and position the product towards the transmission

tower.

TO ENABLE OR DISABLE AUTO-

RECEPTION

If you wish to disable the auto-reception feature while the unit is

within range, press and hold the SPLIT (DOWN) button for 2

seconds. The antenna indicator will disappear and the unit will

NOT respond to radio signals.

To enable the feature again, press and hold the START/STOP (UP)

button for 2 seconds. The antenna indicator will start blinking to

initiate reception automatically.

SETTING THE CALENDAR CLOCK

ANUALLY

When the unit is not within range of the radio signal, you can set the

time and calendar manually.

1. Press and hold the MODE button for 2 seconds.

2. Enter the year using the START/STOP(UP) orSPLIT (DOWN)

buttons. Hold down either button to rapidly increase or decrease

the value.

3. Press the MODE button to confirm the entry.

4. Enter the months using the START/STOP (UP) or SPLIT

(DOWN) buttons. Press theMODE button to confirm the entry.

5. Follow the same pattern to set the days, hours, minutes, seconds

and 2nd time-zone hour-offset (+/- 12 hours).

6. For second-setting, if its value is between 0 to 29, press either

START/STOP (UP) or SPLIT (DOWN) button will return to

thepresent minute. If its value is between 30to 59, it will proceed

to the next minute. (e.g., when the time is 12:46:28, it will return

to 12:46:00; when the time is 12:46: 48, it will go to 12:47:00).

7. For the 2nd time-zone setting, please note that the 2nd time-

zone hour-offset function comes with automatic Daylight Saving

Time (DST) compensation. When the hour-offset is set from+1

to -12 hours, the 2nd zone-time will synchronize with DCF-DST

and be adjusted automatically. However, when the hour-offset

is set from+2 to +12 hours, no DST compensation will be made.

8. Press the MODE button to save the changes and exit. The unit

will also save all changes and return to normal display

automatically after the unit has been left idle for 2 minutes.

ABOUT THE ALARM

To set the alarm:

1. In the Alarm time display mode, press and hold the MODE

button for 2 seconds and the hours will flash.

2. Use the START/STOP(UP) or SPLIT(DOWN)buttons to enter

the hours.

3. Press the MODE button to confirm.

4. Use the START/STOP(UP) or SPLIT(DOWN)buttons to enter

the minutes.

5. Press the MODE button to confirm.

To activate the alarm, press and hold the ALARM button for 2

seconds and the ALARM-ON indicator will appear. To deactivate

the alarm, press and hold the ALARM button again.

TO USE THE DAILY ALAR

An alarm will go off for 1 minute in 3-step crescendo patterns if

undisturbed. The ALAR -ON indicator will flash and the alarm

sound will be activated. To mute the alarm, press the ODE,

ZONE, START/STOP (UP) or SPLIT (DOWN) button . If the

Alarm sound is not turned off manually, the alarm will go off again

for once after 8 minutes.

TO USE THE STOPWATCH FUNCTION

To use the stop-watch:

1. Press the ODE button repeatedly to display the Stopwatch function

2. Press the START/STOP (UP) button to start or stop the

stopwatch. The maximum accumulated time is 99 hours, 59

minutes, 59 & 99 1/100 seconds.

To show

ST/SP

(

Start

)

Elapsed Time

ST/SP

(Stop)

ST/SP

(Start)

ST/SP

(Stop)

SPLIT

(

Clear

)

To show

Note:

The stopwatch can continue to operate in other display modes.

The CHRONO icon will flash to indicate its operation.

SETTING THE COUNTDOWN TI ER

This Timer function can measure up to 99 hours, 59 minutes and 59

seconds.

1. Press and hold the ODE button for 2 seconds in the Timer mode.

2. Enter the hours using the START/STOP (UP) or SPLIT

(DOWN) buttons. Hold down either button to rapidly increase

or decrease the value.

3. Press the ODE button to confirm the entry.

4. Enter the minutes using the START/STOP (UP) or SPLIT

(DOWN) buttons. Press the ODE button to confirm the entry.

5. Then, enter the seconds using the START/STOP (UP) or SPLIT

(DOWN) buttons. Press the ODE button to save the changes

and exit.

TO USE THE COUNTDOWN TI ER

To start or stop the Countdown Timer function, press the START/

STOP (UP) button. The Countdown function will continue to

operate in other display modes. The TI ER icon will be flashing

to indicate its operation.

Upon completion of the Countdown function, beep sound will be

turned on for 1 minute.

ST/SP

(

Start

)

Split Time

SPLIT

(

Split

)

SPLIT

(

Split release

)

ST/SP

(

Stop

)

SPLIT

(

Clear

)

RESETTING THE UNIT

The reset function is used to enhance synchronization of signals

after battery replacement or when the unit is operating in an

unfavorable way or malfunctioning. To activate this function, press

and hold the ODE, ZONE, START/STOP (UP) and SPLIT

(DOWN) buttons together for 2 seconds. All settings will return to

their default values.

PRECAUTIONS

This unit is engineered to give you years of satisfactory service if

handled carefully.

- Though the watch is 50-meter water resistant, do not operate

buttons underwater nor wear it when snorkeling or diving.

- Though the watch is designed to withstand normal use, rough

usage or dropping the watch should be avoided.

- Avoid direct contact of the watch with chemicals like colognes,

sun block creams and other toiletries as this would cause

deterioration of the plastic parts of the watch. When the watch

comes into contact with such chemicals, remember to wipe it off

with it dry and soft cloth.

- Store the watch into its plastic container when not in use.

- Paintedor silk-screened finishing on the watch maybe discolored

and worn out by strong pressure, long-term rubbing as well as

frictions.

- Do not clean the unit with abrasive or corrosive materials.

- Do not subject the unit to snow or excessive force, shock, dust,

temperature or humidity.

- Do not tamper with the unit’s internal components.

TECHNICAL SPECIFICATIONS

Operating Temperature : -20ºC to 50ºC

Radio Control : Auto synchronizing time

and date by radio signal

generated from Germany

DC 77

Clock format : 24-hour format/ hh:mm:ss

2nd Zone time Hour-Offset : +/- 12 hours

Date format : dd:mm:with weekday

indication / Auto Calendar

from 2001 to 2098

Alarm Duration : 1-minute crescendo

Stopwatch unction : Up to 99 hours 59 minutes

59 & 99/100 seconds

Countdown Timer unction : Up to 99 hours 59 minutes

59 seconds

Water Resistant : 5 ATM (50 meters)

Battery Type : 1 x CR1620 3V lithium cell

NOTE ON COMPLIANCE

Warming: Changes or modifications to this unit not expressly

approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

CAUTION

- Thecontent of this manual is subject to change without

further notice.

- Due to printing limitation, the displays shown in this

manual may differ from the actual display.

- The contents of this manual may not be reproduced

without the permission of the manufacturer.

R&TTE Compliance Note

This product complies with the essential requirements of Article 3

of the R&TTE 1999/5/EC Directives, if used for its intended use

and that the following standard(s) has/have been applied:

Efficient use of radio frequency spectrum (Article 3.2 of the R&TTE

Directive) applied standard(s): N / A

Electromagnetic compatibility (Article 3.1.b of the R&TTE

Directive) applied standard(s): ETS 300 683:1997

Safety of information technology equipment (Article 3.1.a of the

R&TTE directive) applied standard(s): EN 60950:1997

Additional information:

The product is therefore conform with the Low Voltage Directive

73/23/EC, the EMC Directive 89/336/EC and R&TTE Directive

1999/5/EC (appendix II) and carries the respective CE marking.

VS-Villingen / Germany August 2001

Gerhard Preis

EC representative of manufacturer

RTTE Compliant Countries :

All EU countries, Switzerland

And Norway

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Oregon Scientific Orologio

Oregon Scientific

Oregon Scientific Tracker RA122 Manuale utente

Oregon Scientific

Oregon Scientific PE603 Manuale utente

Oregon Scientific

Oregon Scientific SE900 Manuale utente

Oregon Scientific

Oregon Scientific SE900 Manuale utente

Oregon Scientific

Oregon Scientific RA122 Manuale utente

Oregon Scientific

Oregon Scientific RA126 Manuale utente

Oregon Scientific

Oregon Scientific RA121 Manuale utente

Oregon Scientific

Oregon Scientific VIBRA Trainer Elite Manuale utente

Oregon Scientific

Oregon Scientific OUTBREAKER RS109 Manuale utente

Oregon Scientific

Oregon Scientific RA121 Manuale utente

Oregon Scientific

Oregon Scientific RA121 Manuale utente

Oregon Scientific

Oregon Scientific SW202 Manuale utente

Oregon Scientific

Oregon Scientific SL210 Manuale utente

Oregon Scientific

Oregon Scientific CP600 Manuale utente

Oregon Scientific

Oregon Scientific SL110 Manuale utente

Oregon Scientific

Oregon Scientific SW202 Manuale utente

Oregon Scientific

Oregon Scientific RA126 Manuale utente

Oregon Scientific

Oregon Scientific RA121 Manuale utente

Oregon Scientific

Oregon Scientific Outbreaker Mountain-Ski RA103 Manuale utente

Oregon Scientific

Oregon Scientific Scientific RX109 series Manuale utente

Oregon Scientific

Oregon Scientific TS1X0 series Manuale utente

Oregon Scientific

Oregon Scientific AT108A Manuale utente

Oregon Scientific

Oregon Scientific SE900 Manuale utente

Oregon Scientific

Oregon Scientific SL928D Manuale utente

Manuali Orologio popolari di altre marche

Pandora

Pandora WATCH2 Manuale utente

Casio

Casio QW-4343 Manuale utente

Suunto

Suunto X6 Manuale utente

Seiko

Seiko N830 Manuale utente

MotionX

MotionX 365 Manuale utente

Garmin

Garmin VENU SQ 2 Manuale utente

QCY

QCY Watch GTC Manuale utente

Canyon

Canyon Cindy CNE-KW41WP Manuale utente

Esq

Esq Watches Guida all'installazione

Crane

Crane AA5-CDSM-3A Manuale utente

Timex

Timex W-214 Manuale utente

DETOMASO

DETOMASO MATERA Manuale utente

Geemarc

Geemarc Watch N Shake Manuale utente

LORUS

LORUS W590 Manuale utente

STENLILLE

STENLILLE Actío Manuale utente

Casio

Casio 5594 Manuale utente

Sinn

Sinn HUNTER'S WATCH 3. Edition Manuale utente

Slazenger

Slazenger SLZ800 Manuale utente
