Oricom CARE80 Manuale utente

User Guide

CARE80

Amplied Phone with direct dial picture buttons

Please keep this user guide for future reference.

Care80 user manual.indd 3 2009-11-5 17:37:59

Care80 user manual.indd 2 2009-11-5 17:37:59

Table of contents

General Information ...............................................................2

Installation.............................................................................4

Location of Controls...............................................................6

Operation...............................................................................7

Memory...............................................................................10

Consumer Support and Troubleshooting............................... 11

Care80 user manual.indd 1 2009-11-5 17:38:00

General Information

WARNING

It is very important that you read the User Guide

carefully as it contains detailed information on

installation, programming and operational issues which

you will need to be aware of to ensure the Care Phone

operates properly. Following is a list of some of the

important issues and important warnings which you

need to be aware of.

This is a summary of the important issues you must

still read the User Guide in full.

• Thetelephoneisdesignedforindooruseonly.Donot

install the telephone in areas where there is the risk

of an explosion, excessive exposure to smoke, dust,

vibrations, chemicals, moisture and heat.

• Donotuseyourtelephoneduringanelectrical

thunderstorm as it is possible to get an electric

shock. Refer to information contained in Telstra White

pages directory.

• Theearpieceofthehandsetmayattractsmallmetal

objects such as staples and pins. Care should be

taken when placing the handset near these items.

• Settingthereceivervolumetomaximummay,under

some situations cause ear damage. We suggest

returning the handset volume control to the “0”

position after each call.

• Donotinstallindamplocationssuchasabathroom

or laundry, do not expose the unit to direct sunlight.

Care80 user manual.indd 2 2009-11-5 17:38:00

General Information

Notes for operation in New Zealand

The grant of a Telepermit for any item of terminal equipment indicates

only that Telecom has accepted that the item complies with the minimum

conditions for connection to its network. It indicates no endorsement

of the product by Telecom, nor does it provide any sort of warranty.

Above all, it provides no assurance that any item will work correctly in

all respects with another item of Telepermitted equipment of a different

make or model, nor does it imply that any product is compatible with all

of Telecom’s network services.

This equipment shall not be set to make automatic calls to the Telecom

“111”EmergencyService.

This equipment may not provide for the effective hand-over of a call to

another device connected to the same line.

This equipment should not be used under any circumstances that may

constitute a nuisance to other Telecom Customers.

REN (RN for New Zealand)

The REN (Ringer Equivalence Number) or (RN) is of signiﬁcance only if you

wish to connect more than 1 telephone to your telephone line. A standard

telephone line has a maximum REN capacity of 3 (RN of 5). It is possible

to connect 3 devices with a REN of 1 (RN of 1) with no degradation to the

product’s performance. Exceeding this limit may cause the volume of the

ringer in any phone to decrease or not ring at all.

Care80 user manual.indd 3 2009-11-5 17:38:00

Installation

Connecting the telephone

1. Plug one end of the telephone cable supplied into the TEL. LINE jack

at the back of the telephone base.

2. Plug the other end of the telephone cable into the wall outlet.

3. Plug one end of the curly cord into the socket on the handset.

4. Plug the other end of the curly cord into the left side of the telephone.

Wall Mounting

Method A. To ﬁt to an existing telephone wall plate with modular

connector simply,

1. Press and lift out the handset holder

on base. Rotate it 180°, and snap it

into place (see Fig A) so it will hold the

handset in place when the phone is

mounted on the wall.

2. Insert the mounting bracket’s two tabs

into the matching slots on the phone’s

base. (see Fig B)

3. Then press down and slide the bracket

Upward until the tabs snap into place.

4. Plug the short telephone line cord

(supplied) into the base of the phone and

plug the other end into the telephone

wall plate socket.

5. Position the mounting holes on the base of the phone over the two

protruding screws on the wall plate. Gently push the phone flush

against the wall plate then slide the phone downwards locking it into

place.

4 4

Fig A

Fig B

Care80 user manual.indd 4 2009-11-5 17:38:00

Installation

Method B. Attach directly to a wall

1.Drilltwoholesvertically,oneabovetheother,83mmapart,andleave

the screws protruding from the wall by 5mm.

2. Follow steps 1 and 2 above.

3. Then press down and slide the bracket upward until the tabs snap into

place.

4. Plug one end of the telephone cable into the TEL. LINE jack at the

back of the base.

5. Plug the other end of the telephone cable into the telephone socket,

then align the base’s keyhole slots with the screws and slide the phone

downward to secure it.

Care80 user manual.indd 5 2009-11-5 17:38:00

Location of Controls

1. Hook switch

2. Handset holder

3. Coil cord socket

4. Receiver volume controller

5. Storebutton

6. Telephone line socket

7. One touch button(M1-M6)

8. Ring Hi/Mid/Off switch

9. RecallTimeSwitch

10. Memory button

11. Recall button

12. Tone Hi/Low switch

13. Redial button

14. Amplify key

15.RingLEDindicator

16. Keypad

17.AmplifyLEDindicator

15 16

Care80 user manual.indd 6 2009-11-5 17:38:02

Operation

Recall switch Setting

For Australia the Recall switch should be set to 100.

For New Zealand the Recall switch should be set to 600.

Making a call

1. Pick up the handset and wait for a dial tone.

2.Dialthenumberyouwishtocall.

3. When you have completed your call, hang up the handset.

Receiving a Call

Whenyoureceiveacall,thetelephonerings,theRingerLEDashes.

If you want to talk to the caller:

1. Pick up the handset to answer the call.

2. At the end of the call, return the handset to the cradle.

Redial function

If a number that you have dialed is engaged or you were unable to get

through to anybody. The last number dialed will be saved in the telephone

automatically.

To use the redial facility, proceed as follows:

1. Lift the handset.

2. Press the REDIAL button. The last saved redial number will now be

dialled.

Pause

If needed for phone banking or behind a PBX system. You can insert a

3.6 seconds pause while dialing or storing a number into MEM. Press

REDIAL button at the desired point in number to insert a pause.

Care80 user manual.indd 7 2009-11-5 17:38:03

Operation

Recall and call waiting

Press the Recall button followed by the extension number to transfer

calls when connected to a PBX.

Access to additional network services can be gained by using the Recall

button * and # keys. Contact your network operator for more information.

To Turn on Telstra call waiting (Australia)

You can use the recall button to answer a second call while you are on

the phone. However this service will need to be turned on. For example to

turn on Telstra’s Call Waiting service:

1. Lift the handset and wait for dial tone then Press *43#.

2. You will hear the service message and then hang up.

Take two different calls at the same time

Duringacall,youwillheartwoloudbeepsperiodicallytonotifyyouof

another incoming call. If you wish to answer this call

1. Press Recall button listen for dial tone then Press 2 to put the

current call on hold and talk with the second caller.

2.SubsequentpressesofRecall button listen for dial tone then Press

2will toggle you between these 2 callers.

Ringer Volume Control

The ringer sound level can be adjusted by sliding the RINGER switch to

select high (HI) or soft (MID) sound level. When you don’t

want to be disturbed, slide the RINGER switch to the Off position.

ThebrightRedlight(LED)onthebasewillashwithallincomingcalls.

Care80 user manual.indd 8 2009-11-5 17:38:03
