Osily LFP Series Manuale utente

AER, Zac du Caillou, Rue Jules Verne, 69630 Chaponost, France

YESSS House, Unit B Foxbridge Way, Normanton, WF6 1TN

User Manual - V3

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

osily.co.uk

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Osily Energy Product Manual

Thankyou for purchasing an Osily Energy battery, now you have the opportunity to enhance your solar powered

system. By reading this document following the purchase of your Osily Battery storage unit you conﬁrm that you agree

to the terms and conditions associated with purchasing and installing an Osily Energy 5kWh battery storage unit.

Osily Energy own the rights to the information within this document, No part of this document can be

reproduced, translated, annotated or duplicated in any form or by any means with out prior written permission

This product complies with the design requirements of UK and international battery manufacturing regulations.

The storage, use and disposal of the products shall be carried out in accordance with the product manual or as

advised by the manufacturing party or Osily Energy.

Please refer to the data sheet and installation guidance set out to correctly install and commission the unit.

Please note that modifying this product will void any warranties associated and provided to you upon

purchase of goods.

If you have any enquiries regarding the product, please contact [email protected].uk

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Warranty:

Osily LFP Series

Applicable product types:

Osily LFP 5000, LFP 5kWh Lithium batteries

This Limited Warranty Letter (hereinafter referred to as”Warranty”) as described below applies to the residential application with Osily New

Energy (hereinafter referred to as “Product”) supplied by Osily Energy (hereinafter referred to as “OSILY” ) with the types mentioned above to

User (User is thebuyer who puts the Product into operation for the ﬁrst time) via the way authorised by Osily.

1.1 Product warranty

1.1.1 The Product warranty period is Five (5) years from the date of purchase.

1.2 Battery capacity performance warranty

Conditions for warranty

The installation of the Product for the User shall be completed within 1 month. The operating temperature during the operation of the

Product must not exceed -10~50ºC temperature range and the Product shall not be exposed and stored in a temperature higher than

50ºC, and shall not be exposed in an installed area in direct sunlight. The Product installation location must be ventilated in accordance

with the requirements of the User Manual and Installation Guidance. The Product is not suitable for supplying power for lifesustaining

medical devices and automotive application.

APPLICATION ENERGY RETENTION OPERATING LIMITATION

Solar self-consumption

/backup only 70% at 10 years following the

initial date mentioned in 1.1.1 Unlimited cycles

Any other application or

combination of applications 70% at 10 years following the

initial date mentioned in 1.1.1 Throughout energy limitation

refer to the table below

PRODUCT TYPE NOMINAL DISCHARGE MAXIMUM

RECOMMENDED DOD

LFP 5kWh/LV 3KW 90%

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Replacement or Repair

In the event of any Product covered by this Warranty and conﬁrmed by Osily to be defective or non-conforming, Osily can replace

or repair the defective or non-conforming Product at its sole discretion. Any maintenance or replacement shall not be deemed as

extension or recalculation of the warranty period.

Exclusions of Warranty

Warranty period speciﬁed above has already expired. Product damage and defect caused by End User’s improper use, misuse,

abuse, which is non-conforming with User Manual. Misuse, abuse, neglect or accident during storage, transportation, handling,

installation, application and service. Unauthorised wiring and use with faulty or incompatible devices. Product arbitrarily modiﬁed

or its function changed without permission by Osily. Any changes to the installation are not done in accordance with the Installation

Guidance. Product damage caused by maintenance.

End User fails to provide correct product serial number or is or has been modiﬁed without permission

by Osily. External inﬂuences including unusual physical or electrical stress (power failure surges, inrush current, lightning,

ﬂood, ﬁre, accidental breakage) Product damage caused by external force, force majeure (causes of natural disasters such as

unforeseeable, unavoidable and insurmountable objective, unavailability of suitable and sufﬁcient labor or materials and other

events which are out of control of Osily or other third party.) The defect cannot be overcome under the technology condition when

the Product has been sold to End User. Defects of Product arise due to renewal of the national or regional laws or regulations.

Product damage caused by End User deliberately or by willful act.

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Installation guidelines

• Take considerable care when unboxing the battery unit, using a small or thin blade, keep it away from the unit itself.

• The total weight of the unit is 65KG, moving this battery requires 2 people.

• Once installed on the wall following instructions from this manual, ensure the cables are not reverse connected

and the cables have no visible defects.

• Do not connect positive and negative poles with a conductor or any external unit which is not a hybrid inverter

recommended to be compatible in this document.

• If the battery does fall over, is knocked or falls from its rack, please isolate and disconnect for 1 hour.

• Isolate the device when relocating or moving the battery, failure to do so could result in electric shock.

• Ensure the premises has a dry powder extinguisher should there be a battery ﬁre.

• For your safety, do not dismantle the unit.

• If the battery system needs to be relocated or maintenance work carried out the power must disconnected and the

battery is completely shutdown.

• Do not connect the battery with different type of battery.

• Do not connect the batteries with incompatible inverters

• In case of ﬁre, dry powder ﬁre extinguisher should be used, no other extinguisher should be used.

• Please do not open, repair or disassemble the Battery.

Installation and Storage

• Rigorous testing has been conducted to ensure the batteries are completely functional and operate at the speciﬁed

level however you should isolate the unit should you believe the unit is not functioning correctly and contact

your installer immediately.

• For your safety, the device must be ground connected properly before connection.

• To ensure the battery is only connected to inverters speciﬁed by Osily Energy, should you have an alternative inverter

• Do not install batteries in parallel from alternative manufacturers, new and old batteries or batteries that have

alternative voltage requirements, this will void your warranty.

• Dry storage will assist with increasing the lifespan of the battery, consider the location of the battery and do not

store in an area where damp or water could affect its operation.

• Charge the battery for 18 hours to full before discharging, this can be conﬁgured in battery settings.

• Formula of theoretical standby time: T=C/I (T is standby time, C is battery capacity, I is total current of all loads).

Safety

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Introduction

FIG1-1 Battery Energy Storage System nameplate

Battery is voltage higher than safe voltage, direct contact with electric shock hazard.

Be careful with your actions and be award of the dangers.

The battery product meet the United Nations regulations on transport of dangerous goods.

The scrapped battery cannot be put into the garbage can and must be professionally recycled.

This battery product meets European directive requirements.

All the parts of the battery meets TUV safety requirements.

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Product Speciﬁcation

Size and Weight

Table 2-1 LFP 5kWh/ LV Device Model

Performance Parameter

Table 2-2 LFP 5kWh/ LV performance parameter

PRODUCT

SERIES SPECIFICATION

MODEL NOMINAL

VOLTAGE NOMINAL

CAPACITY DIMENSION

(MM) WEIGHT

(KG) IP LEVEL

LFP 5kWh/ LV 5.12V 100Ah 550×700×216 65 IP65

MODULE

TYPE LFP 5KWH/ LV

Total Energy* 5.12kWh

Usable Energy (DC)* 4.6kWh

Nominal Dis-charge Power 3kW

Peak Power(Only Discharge) 7kW for 3 seconds

Voltage 43.2~56Vd.c

Nominal Voltage 51.2Vd.c

Nominal Current 60A

Max. Charge Voltage 58.4Vd.c

Max. Charge Current 60A

Max. Discharge Current 100A

Safety CE UN38.3

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Interface Deﬁnition

Table 2-3 Interface Deﬁnition

This section elaborates on interface functions of the front panel of the device

Figure2-1 LFP 5kWh/ LV the sketch of front interface.

ITEM NAME DEFINITION

1 Negative socket The battery DC output positive pole, which is connected to the negative

pole often inverter through the cable

2 Positive socket The battery DC output negative pole, which is connected to the negative pole often

inverter through the cable.

3 RS485 The RS485 communication interface is used for parallel communication between batteries

4 CAN CAN communication interface is used for communication between battery and inverter

5 LED1 Module capacity status indicator light

6 LED2 Module capacity status indicator light

7 LED3 Module capacity status indicator light

8 LED4 Module capacity status indicator light

9 ADD switch Use the switch to adjust the address when the battery is in parallel mode

10 Reset switch

Press the switch and the battery system turn on. When the battery is in the non use state such as storage,

transportation etc., it need to be turn off by switch button, and the battery system will automatically sleep

after the device without external load power

11 Main switch Open or cut off the main circuit, and ensure transportation safety after cutting off

LFP 5-10kWh/ LV User Manual

- 8 -

Interface Definition

This section elaborates on interface functions of the front panel of the device

Figure2-1 LFP 5-10kWh/ LV the sketch of front interface.

Table 2-3 Interface Definition

Item

Name

Definition

Negative socket

The battery DC output positive pole, which is connected to the negative pole often

inverter through the cable.

Positive socket

The battery DC output negative pole, which is connected to the negative pole

often inverter through the cable.

RS485

The RS485 communication interface is used for parallel communication between

batteries.

CAN

CAN communication interface is used for communication between battery and

inverter.

LED1

Module capacity status indicator light

LED2

Module capacity status indicator light

LED3

Module capacity status indicator light

LED4

Module capacity status indicator light

ADD switch

Use the switch to adjust the address when the battery is in parallel mode.

Reset switch

Press the switch and the battery system turn on. When the battery is in the non use

state such as storage, transportation etc., it need to be turn off by switch button, and

the battery system will automatically sleep after the device without external load

power.

Main switch

Open or cut off the main circuit, and ensure transportation safety after cutting off

Table 2-4 LED status indicators (Take LFP 10kWh/ LV as an example)

Flashing 1£ bright 0.25s Light out 3.75s

Flashing 2£ bright 0.5s Light out 0.5s

Flashing 3£ bright 0.5s Light out 1.5s

5 6 7 8

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Battery Management System (BMS)

Voltage Protection

Discharging Low Voltage Protection -

When battery cell voltage is lower than the rated protection

value or total voltage below 42V during discharge over-discharge

protection is activated and the battery alerts the user via alarm.

The battery will then isolate and cut-off. When the voltage of each

cell recovers to rated value and total voltage restored to above

45V, the protection resides.

Charging Over Voltage Protection -

When charging, the system stops charging when the total voltage

of the battery pack is higher than 54.75V or the voltage of any

single cell reaches the protection value. When the total voltage

returns to below 52V and the cell voltage returns to below the

rated protection value, the protection is release.

Temperature Protection

Less/ Over temperature protection in charging:

When the battery’s temperature is beyond range of 0~+45

during charging, temperature protection is enforced and

device stops charging. The protection is released when it

recovers to rated return range.

Less/ Over temperature protection in discharging:

When battery’s temperature is beyond range of -10~+45

during discharging, temperature protection starts and the

device stops supplying power to the outside. The protection

is released when it recovers to rated return range.

Other Protection

Short Circuit Protection:

When the battery is activated from the off state, if a short circuit

occurs, the DC circuit breaker will act ﬁrst. If the DC circuit

breaker does not operate, the BMS will start the short circuit

protection function and cut off the external voltage output.

Self Shutdown:

When device connects no external loads for over 72 hours

the device will activate dormant standby automatically.

Caution:

The maximum working current of the load which needs to be

powered should be less than the maximum discharge current

capacity of the battery system

Current Protection

Over Current Protection in Charging -

When the charging current is greater than the protection value an

internal alarm is activated and the system stops charging. After the

system delays the rated time for 1 min, the protection is released.

Over Current Protection in Discharging:

When the discharging current is greater than the protection value, the

battery signals an alarm and the system stops discharging. After the

system delays the rated time for 1 min, the protection is released.

SYSTEM

STATE RUNNING

STATE

RUN ALM SOC

EXPLAIN

Shut down Dormancy OFF OFF OFF OFF OFF OFF ALL OFF

Standby Normal Flashing 1 OFF OFF OFF OFF OFF

Charging

Normal Flashing 1 OFF According to the power prompt

Over current

alarm Flashing 1 Flashing 2 According to the power prompt

Over voltage

protection Flashing 1 OFF OFF OFF OFF OFF

Temperature Over current

protection Flashing 1 Flashing 1 OFF OFF OFF OFF

Discharge

Normal Flashing 3 Flashing 3 According to the power prompt

Alarm Flashing 3 Flashing 3 According to the power prompt

Temperature, Over current,

Short circuit protection OFF OFF OFF OFF OFF OFF Stop discharge, Mains offline

48h no action forced sleep

Under voltage protection OFF OFF OFF OFF OFF OFF Stop discharge

Flashing 1 = bright 0.25s Light out 3.75s

Flashing 2 = bright 0.5s Light out 0.5s

Flashing 3 = bright 0.5s Light out 1.5s

User Manual

LIFEPO4 BATTERY 

51.2V 100AH LFP 5KWH/LV

Installation Safety

• The safety regulations and local safety regulations listed below should always be followed during the installation.

• All circuits connected to this power system with an external voltage of less than 48V must meet the SELV requirements

deﬁned in the IEC60950 standard.

• If operating within the power system cabinet, make sure the power system is not charged. Battery devices should also be

switched off.

• Distribution cable wiring should be reasonable and has the protective measures to avoid touching these cables while

operation power equipment.

• When installing the battery system, please wear the protective items below:

Environmental Requirements

• Working temperature: -10OC~+50OC

• Charging temperature range is 0OC~+45 OC,

• Discharging temperature range is -10 OC ~+50 OC

• Relative humidity: 4%~100%RH (No condensed water)

• Elevation: no more than 4000m

• Operating environment: Indoor or outdoor installation, sites avoid the sun and no wind,

no conductive dust and corrosive gas.

And the following conditions are met:

• Installation location should be away from the sea to avoid brine and high humidity environment.

• The ground is ﬂat and level.

• There is no ﬂammable explosive near to the installation places.

• The optimal ambient temperature is +15OC~+30OC.

• Keep away from dust and dirty areas.

Gloves Safety Glasses Safety Shoes

Installation and Conﬁguration

Electrical Interface Check

Devices that can be connected directly to the battery can be user equipment, power supplies, or other power supplies.

• Conﬁrm whether the user equipment, the PV equipment or other power supply equipment has the DC standby interface,

and measure whether the output voltage of the standby interface meets the requirements of the voltage range of table 2-2.

• Verify that the maximum discharge current capacity of the user equipment, the PV equipment or other power supplies, the DC standby

interface, and the maximum discharge current shall be greater than the maximum charging current of the products used in table 2-2.

• If the user equipment DC prepared interface maximum discharge capacity is less than the maximum charging current products using

table 2-2, the user interface should have the power equipment of DC current limiting function, give priority to ensuring the normal work

of user equipment.

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Accessori per fotocamere popolari di altre marche

Viltrox

Viltrox EF-NEX Istruzioni per l'installazione

Calumet

Calumet 7100 Series CK7114 Manuale utente

Ropox

Ropox 4Single Series Manuale utente

Cambo

Cambo Wide DS Digital Series Istruzioni operative

Samsung

Samsung SHG-120 Manuale utente

Ryobi

Ryobi BPL-1820 Manuale operativo

Aegis

Aegis ABL-36020P Manuale utente

Pentax

Pentax Data Back Fc Manuale utente

Fantasea

Fantasea EyeGrabber F Series Manuale utente

Honeywell

Honeywell HDZ20HD Manuale utente

EGO

EGO BA1400T Manuale utente

Sima

Sima SRW-62 Manuale utente

Shape

Shape A7SSMKIT Manuale utente

Slide Kamera

Slide Kamera HST-2 Manuale utente

Power works

Power works 2902613 Manuale utente

SES

SES SE-2047-2 Manuale utente

Olympus

Olympus PT-EP05L Manuale utente

Starlite

Starlite OctoDome nxt Manuale utente

osily LFP Series Manuale utente

Manuali Accessori per fotocamere popolari di altre marche
