PADAUK 5S-P-003 Manuale utente
5S-P-003
Program Writer
User Manual
Version 0.07 –Oct. 14, 2022
Copyright 2022 by PADAUK Technology Co., Ltd., all rights reserved.
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 2 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
IMPORTATNT STATEMENT
PADAUK Technology reserves the right to make changes to its products or to terminate
production of its products at any time without notice. Customers are strongly
recommended to contact PADAUK Technology for the latest information and verify whether
the information is correct and complete before placing orders.
PADAUK Technology products are not warranted to be suitable for use in life-support
applications or other critical applications. PADAUK Technology assumes no liability for
such applications. Critical applications include, but are not limited to, those which may
involve potential risks of death, personal injury, fire or severe property damage.
PADAUK Technology assumes no responsibility for any issue caused by a customer’s
product design. Customers should design and verify their products within the ranges
guaranteed by PADAUK Technology. In order to minimize the risks in customers’ products,
customers should design a product with adequate operating safeguards.
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 3 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
Table of Contents
1. About 5S-P-003 Writer ..........................................................................................................6
1.1. The front.................................................................................................................................6
1.2. The back ................................................................................................................................7
1.3. The side face..........................................................................................................................7
1.4. Accessories of Program Writer...............................................................................................8
1.5. Writing application software and User Manual........................................................................8
2. Functional Description.........................................................................................................9
2.1. Steps of loading File............................................................................................................. 10
2.2. Blank Check..........................................................................................................................11
2.3. Verify.....................................................................................................................................11
2.4. Auto Program........................................................................................................................11
2.5. Rolling Code......................................................................................................................... 13
2.6. Read & Search..................................................................................................................... 14
2.7. Convert PDK ........................................................................................................................ 14
3. Version Update ...................................................................................................................14
3.1. Automatic update ................................................................................................................. 15
3.2. Manual update...................................................................................................................... 15
4. JUMPER Description..........................................................................................................17
4.1. Examples ............................................................................................................................. 17
5. Connecting Board Making Description.............................................................................18
5.1. Define the data of exclusive use packaged pin..................................................................... 18
5.2. Connecting Board making .................................................................................................... 19
5.3. Case 1.................................................................................................................................. 20
5.4. Case 2 (Customized package pin)........................................................................................ 22
5.5. The way to add package pin information to PDK file............................................................. 24
5.6. The description of package setting details............................................................................ 25
6. Semi-automatic Writing Handler Connection Description..............................................26
7. Set O/S Test and Blank Check...........................................................................................28
8. Writer LCM Information and Buzzer Sound Table ...........................................................30
9. Appendix Descriptions.......................................................................................................32
9.1 The difference between 5S-P-003 and 3S-P-002....................................................................... 32
9.2 The difference between 5S-P-003 and 5S-P-003Bx................................................................... 32
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 4 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
9.2 Special notes of MTP On-board writing...................................................................................... 32
9.3 Special notes of voltage while On-board or Multi-Chip-IC writing (OTP / MTP) .......................... 34
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 5 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
Revision History:
Revision
Date
Description
0.00
2016/07/20
1st version
0.01
2016/08/15
Modify explanation of making the Connecting Board
0.02
2016/09/13
1. Update typesetting
2. Add explanation of 4.1 JUMPER
0.03
2017/06/13
1. Add new description of Buzzer sound
0.04
2017/11/24
1. Update partial pictures
2. Amend 2.6 Read & Search
3. Add section 2.7 Convert PDK
4. Amend chapter 4
5. Update the LCM signal table of chapter 7
6. Add 8.2 On-line writing
0.05
2018/03/19
1. Update the address and telephone number of PADAUK Technology co., Ltd.
2. Update Partial pictures
3. Add description of O/S check or Blank check
4. Update and add the description of MTP On-line (On-board) writing
0.06
2018/10/30
1. Add section 9.3 Special notes of voltage while On-board or Multi-Chip-IC
writing (OTP / MTP)
0.07
2022/10/14
1. Update pictures and contents of accessories
2. Update the To Package operation UI picture and add the command option
3. Update LCDM display picture content
4. Update UI picture of on-board writing
5. Supplementary instructions for Manual update
6. Update picture of semi-automatic writing connection
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 6 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
1. About 5S-P-003 Writer
1.1. The front
(1) USB interface: Connect to PC.
(2) Power interface: Please use the exclusive power converter of Program Writer accessories. (Do not use other
power converters to avoid damaging the Program Writer)
(3) Power Switch: OFF/ON.
(4) Buzzer: Be used as alarm while failed to write.
(5) LED (OK & NG) lamp: Display the result of writing.
(6) LCM displayer: Display the information and result of writing.
(7) Program button: Start writing.
(8) Textool: Suitable for DIP package (available for 28 PIN at most).
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 7 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
1.2. The back
(1) JUMPER (JP1~JP16): Different IC or package would coordinate with different JUMPER position. Please
refer to chapter 4.
(2) JUMPER (JP7): When it comes to non-standard or unusual package, you need to use JP7 to transform
relevant information. About Connecting Board making, please refer to chapter 5.
(3) Forced update mode button: Forcing update the current version, please refer to section 3.1
1.3. The side face
(1) USB interface: Connect to PC.
(2) Power interface: Please use the exclusive power converter of Program Writer. (Do not use other power
converters to avoid damaging the Program Writer)
(3) Power Switch: OFF/ON.
(4) Semi-automatic writing connection port: About the connection method, please refer to chapter 6.
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 8 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
1.4. Accessories of Program Writer
(1) The exclusive power converter.
(2) The USB cable.
(3) 150G adapter plate.
1.5. Writing application software and User Manual
You can download the latest version of the application software at the following address (including the latest
version of the Program Writer)
http://www.padauk.com.tw/en/technical/index.aspx?kind=27
Or enter the home page of www.paduak.com.tw, obtain latest Program Writer version from home page >
technology application > technology development tool > Program Writer. Please refer to the chapter 3.
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 9 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
2. Functional Description
(A) Engineering type
(B) Simple type
No matter simple type or engineering type, they have the equal corresponding function.
5S-P-003
Program Writer
© Copyright 2022, PADAUK Technology Co. Ltd
Page 10 of 34
5S-P-003-UM-EN-V007 –Oct. 14, 2022
2.1. Steps of loading File
(1) Load PDK file from PC to Program Writer.
(2) Related information of PDK file would be displayed after loading successfully. (i.e. Check Sum, file name …)
(3) After loading successfully, the JUMPER position and IC placement would be prompted.
(4) The LCM also displays the messages and prompts synchronously.
(5) Users could also unplug the USB cable and write in alone mode after the file loaded successfully.
(6) Users should make sure that JUMPER & IC had been put in the correct position before starting 『Blank
Check』、『Verify』、『Read & Search』and『Auto Program』actions.
(7) About JUMPER & IC placement position, please refer to 『JUMPER Description』.
(8) When JUMPER & IC have been placed, the Program Writer’s LCM displays "IC ready".
