Palm Treo 750v Manuale utente

Quick Start Guide 3

Beknopte handleiding 22

ML_TOC.fm Page 1 Wednesday, August 16, 2006 4:49 PM

Welcome to your new smartphone, combining

the best aspects of a mobile phone with the

high-speed Vodafone 3G data network and

organizer features.

This quick guide focuses on the phone features

that might be different from those on a standard

mobile phone. It also

describes some of the

unique smartphone

features and services.

If you need more help,

please see the User

Guide or your local

Vodafone website.

Getting Started 3

Smartphone Overview 4

Navigation and Text Entry 6

Using the Phone 8

Email Setup 11

Receiving Email 13

Sending Email 14

Contacts & Calendar 15

Messaging & Camera 17

Internet 18

Other Functions 19

If You Need Help 20

GroovyIIQSG_TOC.fm Page 2 Wednesday, August 16, 2006 4:33 PM

Getting Started

1. Insert your SIM card

Press the battery door release and slide the

door to open the battery compartment. With

the metal contacts facing the compartment,

slide the SIM card into the cutout in the lower-

right corner of the compartment until you feel

the card snap into place. Align the notches to

make sure you have the card oriented correctly.

2. Insert the battery

Align the metal contacts on the battery with

the contacts inside the battery compartment,

insert the battery into the compartment at a

45-degree angle, and then press it into place.

Slide the battery door back into place.

3. Follow onscreen instructions

Follow the onscreen instructions to finish the

installation. Installation is complete when you

press Finish (right action key).

If the screen turns off, press Power/End ,

and then press Center to turn off

Keyguard.

4. Charge the battery

Connect the AC charger to a wall outlet and to

the bottom of your smartphone. When your

battery is fully charged, your smartphone’s

indicator light glows green.

Notch

Battery contacts

Compartment

contacts

Indicator light

Battery door

release

QSG_EN_NL.book Page 3 Wednesday, August 16, 2006 4:26 PM

Smartphone Overview

Front view

Indicator light (phone and

charge indicator)

Multi-connector

5-way navigator with Center

button; see “Using the 5-way”

on page 6

Earpiece

Microphone

Headset jack

Side button

Volume

Screen

Keyboard; see “Using

the keyboard” on page 7

QSG_EN_NL.book Page 4 Wednesday, August 16, 2006 4:26 PM

Back view

Top view

Camera lens

Speaker

Self-portrait mirror

Infrared (IR) port

Expansion card slot

Reset button

(located inside

expansion card slot

door)

Battery door release

SIM card slot (located

inside battery

compartment,

beneath battery)

Ringer switch

Stylus

External antenna

socket (for use with

car kits)

QSG_EN_NL.book Page 5 Wednesday, August 16, 2006 4:26 PM

Navigation and Text Entry

Your Palm®Treo™ 750v smartphone offers several

options for navigating around the screen and

entering information.

Waking up the screen

To save battery power, the screen is set to turn off

after a preset interval. To wake up the screen if it is

off, press Power/End . When the screen turns

on, press Center to turn off Keyguard.

You can set how long the screen stays on. Press

Start, select Settings, select the System tab, and

then select Power. Select the Advanced tab. Use

the On battery power setting to specify how

many minutes your smartphone stays idle before

the screen turns off.

Using the 5-way

Using the 5-way, press Right X, Left W, Up S, or

Down Tto move around the screen. Press

Center to highlight and select items.

Using the stylus

To use the stylus, slide it out of its holder on the

back of the device (see “Top view” on page 5), and

tap gently on the screen to select an item or icon.

You can also use the stylus to enter and correct

text and to draw on the screen. For many onscreen

elements, tapping and holding with the stylus

opens a menu of further options.

Using the onscreen keyboard

You can use the onscreen keyboard to enter

letters, numbers, and other characters in

applications that support this feature. Tap the

onscreen keyboard icon

in the center at

the bottom of any screen where it appears. After

opening the keyboard, tap the icon to the right of

the keyboard icon to set various input options. Tap

anywhere on the keyboard to close it.

Up S

Down T

Left WRight X

Center

QSG_EN_NL.book Page 6 Wednesday, August 16, 2006 4:26 PM

Using the keyboard

Using your Today screen

From your Today screen you can look up a

contact, make a call, see your appointments, see

the number of unread email or text messages, and

perform a web search. To access your Today

screen, press Phone/Send .

Opening applications

Press Start . On the Start menu, highlight the

application you want, or select Programs to view

additional applications. Press Center to open

the application.

Closing applications

Press and hold OK to open Memory Settings.

On the Running Programs tab, select an

application and then select Stop to close it, or

select Stop All to close all your open applications.

Changing input settings

To adjust the text entry settings, press Start ,

and then select Settings > Personal > Input >

Options.

Right action key

Activates the onscreen

command directly

above the key

Power/End

Turns the phone and the

screen on and off

Returns to the application

you were in previously

Left action key

Activates the onscreen

command directly

above the key

Phone/Send

Opens the Today screen

Start

Opens the Start menu

Option

Lets you enter the characters

that appear above the letters

on each key Alt

Lets you enter additional

characters for each key

5-way navigator

(See “Using the 5-way”

on page 6)

QSG_EN_NL.book Page 7 Wednesday, August 16, 2006 4:26 PM

Using the Phone

Making calls

Turning your phone on

From the Today screen, press Menu (right

action key), select Wireless Manager, and then

select Phone. Your phone is ready to make calls

when your network operator’s name appears in

the upper-left of the Today screen and the signal-

strength icon appears at the top of the screen.

Dialing from the Today screen

Go to your Today screen. Using the numbered

keys on the keyboard, enter a phone number.

Press Phone/Send to dial.

Dialing by contact name

Go to your Today screen. Using the keyboard,

begin entering the first or last name of the contact

you want. When the number you want appears,

select it and press Phone/Send to dial.

Dialing using the onscreen Dial Pad

Go to your Today screen. Press Phone/Send

and select Dial Pad. Use the keyboard keys or tap

the onscreen Dial Pad to enter the number. Press

Phone/Send to dial.

QSG_EN_NL.book Page 8 Wednesday, August 16, 2006 4:26 PM

Creating a speed-dial button

Go to your Today screen. Press Menu

(right action key) and select

New Speed Dial.

Select Link to link this button to an existing

contact number (see “Creating a new contact” on

page 15), and then select the contact and the

number.

If the number is not in your Contacts list, select

Label and enter a name for this button, and then

select Number and enter the phone number you

want to dial with this button.

Optionally, you can enter a number or letter as the

Quick Key. When the Today screen is showing, you

can press and hold the Quick Key to instantly dial

this number.

If prompted, select either Text Speed Dial or

Picture Speed Dial to indicate which type of

button you want to create.

Dialing with a speed-dial button

On your Today screen, select a speed-dial button

with the 5-way, and then press Center . Or tap

a speed-dial button with the stylus.

If you entered a Quick Key for this number, simply

press and hold the Quick Key.

Dialing a recently called number

Go to your Today screen, press Phone/Send ,

and then select Call Log. Highlight the number

you want to call, and then press Call (left

action key) to dial.

Receive a call

To answer a call, press Answer (left action

key).

To ignore a call and send it to voicemail, press

Menu (right action key) and select Ignore.

To ignore a call and send a text message to the

caller, press Menu (right action key) and select

Ignore with text message.

QSG_EN_NL.book Page 9 Wednesday, August 16, 2006 4:26 PM

Using voicemail

Setting up voicemail

Go to your Today screen. Press and hold 1on the

keyboard and follow the voice prompts to set up

your voicemail.

Listening to messages

Go to your Today screen. Press and hold 1, enter

your password, and then select Play .

Other call functions

Using the speakerphone

During a call, press Menu (right action key)

and select Speakerphone or Speakerphone off.

Muting a call

Press Menu (right action key) and select

Mute or Cancel Mute.

Swapping calls

When you are on a call, press Answer (left

action key) to answer a second incoming call.

Press Swap (left action key) to move

between callers.

Making a conference call

Answer a second call or put the first call on hold,

and make a second call. Press Conference

(right action key) to join the two calls in a

conference.

You can make more calls and join them in the

conference. When you’ve finished, press

Power/End to hang up all calls.

QSG_EN_NL.book Page 10 Wednesday, August 16, 2006 4:26 PM
