PaloAlto Networks TECHDOCS ION 9000 Guida all'applicazione
ION 9000 Hardware Reference
docs.paloaltonetworks.com
Contact Informaon
Corporate Headquarters:
Palo Alto Networks
3000 Tannery Way
Santa Clara, CA 95054
www.paloaltonetworks.com/company/contact-support.html
About the Documentaon
• For the most recent version of this guide or for access to related documentaon, visit the
Technical Documentaon portal docs.paloaltonetworks.com.
• To search for a specific topic, go to our search page docs.paloaltonetworks.com/search.html.
• Have feedback or quesons for us? Leave a comment on any page in the portal, or write to us
at documenta[email protected]om.
Copyright
Palo Alto Networks, Inc.
www.paloaltonetworks.com
©2020–2021 Palo Alto Networks, Inc. Palo Alto Networks is a registered trademark of Palo
Alto Networks. A list of our trademarks can be found at www.paloaltonetworks.com/company/
trademarks.html. All other marks menoned herein may be trademarks of their respecve
companies.
Last Revised
September 3, 2021
ION 9000 Hardware Reference 2©2021 Palo Alto Networks, Inc.
Table of Contents
Before You Begin................................................................................................5
Tamper Proof Statement............................................................................................................ 6
Third-Party Component Support............................................................................................. 7
Product Safety Warnings........................................................................................................... 8
ION 9000 Overview........................................................................................11
ION 9000.................................................................................................................................... 12
ION 9000 Ports......................................................................................................................... 13
ION 9000 Front Panel with LEDs......................................................................................... 14
ION 9000 Specificaons......................................................................................................... 15
ION Device Compliance Statement......................................................................................17
ION 9000 Installaon Kit Components...............................................................................19
Power on the ION 9000......................................................................................................... 20
Shut down the ION 9000............................................................................................20
Reboot the ION 9000...................................................................................................20
Install the ION 9000....................................................................................... 21
Rack Mount the ION 9000.....................................................................................................22
Install the ION 9000 in Virtual In-Path Configuraon..................................................... 27
Configure Controller Port............................................................................................ 27
Configure Peering Ports............................................................................................... 28
Configure Internet Ports.............................................................................................. 28
Install ION 9000 in High Availability....................................................................................30
ION 9000 Hardware Reference 3©2021 Palo Alto Networks, Inc.
Table of Contents
ION 9000 Hardware Reference 4©2021 Palo Alto Networks, Inc.
Before You Begin
Read the following topics before you install or service a Palo Alto Networks® next-
generaon firewall or appliance. The following topics apply to all Palo Alto Networks
firewalls and appliances except where noted.
>Tamper Proof Statement
>Third-Party Component Support
>Product Safety Warnings
5
Before You Begin
Tamper Proof Statement
To ensure that products purchased from Palo Alto Networks were not tampered with during
shipping, verify the following upon receipt of each product:
• The tracking number provided to you electronically when ordering the product matches the
tracking number that is physically labeled on the box or crate.
• The integrity of the tamper-proof tape used to seal the box or crate is not compromised.
• The integrity of the warranty label on the firewall or appliance is not compromised.
ION 9000 Hardware Reference 6©2021 Palo Alto Networks, Inc.
Before You Begin
Product Safety Warnings
To avoid personal injury or death for yourself and others and to avoid damage to your Palo Alto
Networks hardware, be sure you understand and prepare for the following warnings before you
install or service the hardware. You will also see warning messages throughout the hardware
reference where potenal hazards exist.
All Palo Alto Networks products with laser-based opcal interfaces comply with 21 CFR
1040.10 and 1040.11.
The following safety warnings apply to all Palo Alto Networks firewalls and appliances, unless a
specific hardware model is specified.
• When installing or servicing a Palo Alto Networks firewall or appliance hardware component
that has exposed circuits, ensure that you wear an electrostac discharge (ESD) strap. Before
handling the component, make sure the metal contact on the wrist strap is touching your skin
and that the other end of the strap is connected to earth ground.
French Translaon: Lorsque vous installez ou que vous intervenez sur un composant matériel
de pare-feu ou de disposif Palo Alto Networks qui présente des circuits exposés, veillez
à porter un bracelet anstaque. Avant de manipuler le composant, vérifiez que le contact
métallique du bracelet anstaque est en contact avec votre peau et que l’autre extrémité du
bracelet est raccordée à la terre.
• Use grounded and shielded Ethernet cables to ensure agency compliance with electromagnec
compliance (EMC) regulaons.
French Translaon: Des câbles Ethernet blindés reliés à la terre doivent être ulisés pour
garanr la conformité de l'organisme aux émissions électromagnéques (CEM).
• (ION 7000 and ION 9000 only) At least two people are recommended for unpacking, handling,
and relocang the heavier firewalls.
• Do not connect a supply voltage that exceeds the input range of the firewall or appliance. For
details on the electrical range, refer to electrical specificaons in the hardware reference for
your firewall or appliance.
French Translaon: Veillez à ce que la tension d’alimentaon ne dépasse pas la plage d’entrée
du pare-feu ou du disposif. Pour plus d’informaons sur la mesure électrique, consulter la
rubrique des caractérisques électriques dans la documentaon de votre matériel de pare-feu
ou votre disposif.
• Do not replace a baery with an incorrect baery type; doing so can cause the replacement
baery to explode. Dispose of used baeries according to local regulaons.
French Translaon: Ne remplacez pas la baerie par une baerie de type non adapté, cee
dernière risquerait d’exploser. Meez au rebut les baeries usagées conformément aux
instrucons.
• I/O ports are intended for intra-building connecons only and not intended for OSP (Outside
Plant) connecons or any network connecons subject to external voltage surge events.
ION 9000 Hardware Reference 8©2021 Palo Alto Networks, Inc.
Before You Begin
•(All Palo Alto Networks appliances with two or more
power supplies)
Cauon: Shock hazard
Disconnect all power cords (AC or DC) from the power
inputs to fully de-energize the hardware.
French Translaon: (Tous les appareils Palo Alto
Networks avec au moins deux sources d’alimentaon)
Débranchez tous les cordons d’alimentaon (c.a. ou
c.c.) des entrées d’alimentaon et meez le matériel
hors tension.
ION 9000 Hardware Reference 9©2021 Palo Alto Networks, Inc.
Before You Begin
ION 9000 Hardware Reference 10 ©2021 Palo Alto Networks, Inc.
