OPERATION OF RADIO
- PRESS THE ON/STANDBY KEY ONCE TO SWITCH ON THE UNIT.
- PRESS THE KEY REPEATEDLY UNTIL THE DISPLAY SHOWS
"FM" SYMBOL.
- TO IMPROVE FM-RADIO RECEPTION, FULLY EXTEND THE FM-ANTENNA WIRE AND
ADJUST IT'S POSITION.
- WHEN THE FM RADIO SIGNAL IS STRONG, THE UNIT WILL AUTOMATICALLY SWITCH
ON THE FM-STEREO MODE FOR BETTER SOUND QUALITY. THE ST SYMBOL
WILL BE DISPLAYED IN SUCH CASES.
F U N C T IO N
MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)
- PRESS (AND IMMEDIATELY RELEASE) THE
KEY TO “SCAN” (MANUALLY ADJUST) THE RADIO FREQUENCY “UP” OR “DOWN”
BY 1-STEP AT A TIME.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH
STEP’S POSITION.
- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED
INTO ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
OR
TUNE -
RADIO MEMORY (STATION PRESET MEMORY STORAGE)
- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE
STORED INTO ONE OF THE MEMORY POSITION.
- PRESS AND HOLD KEY
- PRESS KEY TO SELECT DESIRED MEMORY POSITION.
(THERE ARE 20 MEMORY POSITIONS).
- PRESS KEY ONCE TO SAVE THE SELECTED STATION INTO
THE SELECTED MEMORY POSITION.
AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)
- PRESS AND HOLD (FOR 2 SECONDS) THE
KEYS TO “SEEK” (AUTOMATICALLY ADJUST) THE RADIO FREQUENCY “UP” OR
“DOWN”TO THE NEXT AVAILABLE RADIO STATION.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE
NEXT STATION THAT IS FOUND.
- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE
“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
ELECTRONIC VOLUME CONTROL
- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL .
- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS
THE VOLUME UP (+) OR VOLUME DOWN (-) KEYS RESPECTIVELY.
- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.
- SOMETIMES, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE
A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR
DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL
DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE
DESIRED VOLUME LEVEL).
(PUSH BUTTON TYPE)
AUTOMATIC POWER OFF SLEEP FUNCTION
- THIS SET HAS A SPECIAL SLEEP TIMER FUNCTION WHICH CAN AUTOMATICALLY
SWITCH OFF THE UNIT. THIS IS USEFUL FOR SLEEPING TO MUSIC AT NIGHT.
- AT ANY TIME WHILE THE UNIT IS OPERATING, PRESS AND HOLD THE KEY
TO ACCESS THE "SLEEP TIME". THEN PRESS THE KEY REPEATEDLY
TO CHOOSE THE AUTOMATIC OFF TIME. THE SYMBOL WILL BE SHOW ON
THE DISPLAY.
SLEEP
90
MINS 80
MINS 70
MINS 60
MINS 50
MINS OFF
40
MINS 30
MINS 20
MINS 10
MINS
SLEEP
DIMMER FUNCTION
THIS SET HAS A DIMMER FUNCTION TO ADJUST THE BRIGHTNESS LEVEL
OF THE DISPLAY. SIMPLY ADJUST IT AS DESIRED BY PRESSING
THE DIMMER KEY REPEATEDLY (HIGH/ NORMAL/ OFF = BRIGHTNESS 100/ 50/ 0)
TO REDUCE EYE STRAIN, AND TO SAVE ENERGY.
THE DISPLAY WILL ALWAYS RETURN TO NORMAL-DIMMER AFTER RESET THE UNIT.
S L
RADIO MEMORY (RECALL PRESET MEMORY STATION)
- RECALL ANY SAVED MEMORY, SIMPLY SHORT PRESS KEY.
- PRESS TO SELECT DESIRED MEMORY POSITION.
- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION
TO THE SAME MEMORY POSITIONS.
TUNE +
TUNER MEMORY
OR
TUNE - TUNE +
TUNER MEMORY
OR
TUNE - TUNE +
MEMORY
OR
TUNE - TUNE +
AUTO MEMORY
- PRESS AND HOLD (FOR 2 SECONDS) THE AUTO MEMORY KEY, THE UNIT WILL
SEARCH FOR THE FIRST 20 RADIO STATIONS AND SAVE THESE INTO MEMORY
AUTOMATICALLY.
- MAXIMUM 20 MEMORY POSITIONS CAN BE SAVED.
