Operating Instructions
3D Eyewear
TY-EW3D10U
Model No.
Thank you for purchasing a Panasonic product.
Before operating this product, please read the instructions carefully, and save this
manual for future use.
Before using this product, be sure to read “Safety Precautions" ( pages 2 - 3).
TQZJ230
This product cannot be used as
sunglasses.
This product can be worn over vision
correction glasses.
Contents
Safety Precautions ······························ 2
Identifying Controls ····························· 4
Using Precautions ······························· 5
Using for the rst time ························· 7
Accessories ········································· 7
Using the 3D Eyewear ························ 8
Storage and Cleaning ························· 9
Replacing the batteries ······················· 9
Troubleshooting/Q&A ························ 10
Speci cations ···································· 11
Limited Warranty
(for U.S.A. and Puerto Rico only) ······ 12
Limited Warranty (for Canada) ·········· 14
ENGLISH
This product can be worn over vision
This 3D Eyewear can be used
only for Panasonic Plasma HDTVs
supporting 3D.
For the latest information on
applicable models, visit our web site.
http://panasonic.net/
2 - ENGLISH
Safety Precautions
Warning
About Prevention of Accidental Ingestion
Do not store batteries, the band accessory or the nose pad in
places where small children can reach.
There is a danger small children could swallow such parts by mistake.
If a child accidentally swallows such parts, seek immediate medical attention.
About Prohibition of Disassembly
Do not disassemble or modify the 3D Eyewear.
About Lithium Battery
Batteries must not be exposed to excessive heat such as
sunshine, re or the like.
Caution
About 3D Eyewear
Do not drop, exert pressure on, or step on the 3D Eyewear.
Doing so may damage the glass section, which may result in injury.
Always store the 3D Eyewear in the case provided when not in use.
Be careful of the tips of the frame when putting on the 3D Eyewear.
Accidentally inserting the tip of the frame into the eye may cause injury.
Be careful not to trap a nger in the hinge section of the
3D Eyewear.
Doing so may result in injury.
Pay special attention when children are using this product.
About Use of 3D Eyewear
Parents/guardians should monitor children’s viewing habits to
avoid their prolonged use without rest periods.
Only use the 3D Eyewear for the specied purpose.
Do not move around while wearing the 3D Eyewear.
The surrounding area appears dark, which may result in falling or other accidents that
may cause injury.
ENGLISH - 3
About Viewing of 3D Images
In the event that you experience dizziness, nauses, or other
discomfort while viewing 3D images discontinue use and rest
your eyes.
Do not use if the 3D Eyewear is cracked or broken.
About Lithium Battery
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the Panasonic Service Center or an experienced radio/TV technician for help.
FCC Caution:
To assure continued compliance, follow the attached installation instructions. Any
changes or modications not expressly approved by Panasonic Corp. of North
America could void the user’s authority to operate this device.
Responsible Party: Panasonic Corporation of North America
One Panasonic Way, Secaucus, NJ 07094
Contact Source: Panasonic Consumer Electronics Company
1-877-95-VIERA (958-4372)
CANADIAN NOTICE:
For Model TY-EW3D10U
This Class B digital apparatus complies with Canadian ICES-003.
4 - ENGLISH
Identifying Controls
Battery case
Fitting the battery ( page 9)
When using for the rst time, remove the insulating sheet.
( page 7)
Liquid Crystal Shutter
(lens)
Controls the images for 3D viewing.
The left and right liquid crystal
shutters are alternately opened
and closed in time with the left
side and right side images that
are alternately displayed on the
television to achieve the 3D effect.
Nose pad installation section
(3D Eyewear inner section)
( page 7)
Specialized band can be attached
here. ( page 7)
Infra-red receiver
Receives infra-red signals from the television.
The liquid crystal shutter open/close timing is controlled by
receiving infra-red signals from the television, which provide 3D
expression of the images.
If the eyewear stops receiving infra-red signal from the television,
the power automatically switches off after 5 minutes.
Power button (bottom side of
3D Eyewear)
Switches on the 3D Eyewear power.
Press and hold the power button for
approximately 1 second to switch the
power on, and the indicator lamp lights
for approximately 2 seconds. (When the
battery is low, the indicator lamp ashes
5 times on switching the power.)
To switch the power off, press and hold the
power button for approximately 1 second.
The indicator lamp ashes 3 times, then the
power switches off.
Power button
Indicator lamp
ENGLISH - 5
Using Precautions
Liquid Crystal Shutter (Lens)
Do not apply pressure to the liquid crystal shutter. Also, do not drop or bend the
3D Eyewear.
Do not scratch the surface of the liquid crystal shutter with a pointed instrument etc.
Doing so may cause damage to the 3D Eyewear, and reduce the quality of the 3D
image.
Infra-red receiver section
Do not soil the infra-red receiver section or attach stickers etc. to it.
• Doing so may prevent the receiver from receiving signals from the television,
which may prevent the 3D Eyewear from operating normally.
If the 3D Eyewear is affected by other infra-red data communication equipment, the
3D images may not be displayed correctly.
Cautions during viewing
Do not use devices that emit strong electromagnetic waves (such as cellular
phones or personal transceivers) near the 3D Eyewear. Doing so may cause the
3D Eyewear to malfunction.
The 3D Eyewear cannot operate fully at high or low temperatures.
Please use within the specied usage temperature range ( page 11).
If the 3D Eyewear is used in a room in which uorescent lights (50 Hz) are used,
the light within the room may appear to be ickering. In this case, either darken or
switch off the uorescent lights when using the 3D Eyewear.
Wear the 3D Eyewear correctly. 3D images will not be correctly visible if the
3D Eyewear is worn upside down or back-to-front.
Other kinds of displays (such as computer screens, digital clocks, or calculators
etc.) may be difcult to see while wearing the 3D Eyewear. Do not wear the
3D Eyewear when watching anything other than 3D images.
6 - ENGLISH
For comfortable viewing
View the screen at a distance at least 3 times of the effective height of the screen.
Recommended distance:
For a 50-inch television about 6’ 2” (1.9 m)
For a 54-inch television about 6’ 6” (2.0 m)
For a 58-inch television about 7’ 6” (2.3 m)
For a 65-inch television about 7’10” (2.4 m)
Using the 3D Eyewear at a distance closer than the recommended distance may
cause eyesight fatigue.
When the top and bottom area of the screen is blackened, such as movies, view the
screen at a distance 3 times of the height of the actual image.
(That makes the viewing distance closer than above recommended distance.)
Stop using the 3D Eyewear immediately if your skin feels unusual.
In rare cases, the paint or materials used in the 3D Eyewear may cause an allergic
reaction.
Stop using the 3D Eyewear immediately if you experience any redness, pain, or
itching on the nose or temples.
Prolonged use may cause such symptoms due to excess pressure, which may result
in the user feeling unwell.
Viewing 3D images
When watching 3D movies, take an appropriate length break after watching a movie.
When watching 3D content on interactive devices such as 3D games or computers,
take an appropriate length break after using for 30 - 60 minutes.
Prolonged use may cause eyesight fatigue.
ENGLISH - 7
Using for the rst time
Remove the insulating sheet
Insulating sheet
Attach the specialized band
If the 3D Eyewear slips out of place, use
the specialized band included to hold it in
place.
Attach the band to the
left and right tips of the
frame, and adjust the
length.
Specialized band
Attach the nose pad
If required, use the included nose pad.
Nose pad A adjusts the attachment position
of the 3D Eyewear between 2 vertical levels.
(Slot 2 of the 3 protrusions on the 3D Eyewear
into the holes on nose pad A.)
When using nose pad B, ensure that all
3 protrusions on the 3D Eyewear are inserted
into the 3 holes on nose pad B.
Make sure that the nose pad is inserted all
the way and attached securely.
Accessories
< > indicates the quantity.
3D Eyewear case ·······················<1>
Specialized band ························<1>
When the end of the specialized band is
straightened, form a loop at the end of
the band, and x the twisted part.
Nose pad A/B ·····························<1>
A B
Select the nose pad that suit you from A
and B.
It is recommended to wear the 3D
glasses over correction glasses without
the nose pad.
Nose pad A
8 - ENGLISH
Using the 3D Eyewear
Using the television menu controls, set so that 3D images are
shown.
1. (When 3D image signals are being received) press the MENU button on
the television remote control.
2. Select "Setup", and press the OK button.
3. Select "3D settings", and press the OK button.
4. Select "3D Eyewear", and use to select "On" or "Off".
The procedure above is only an example. For details, see the television operating
instructions.
Wearing the 3D Eyewear
1. Press and hold the power button on the 3D Eyewear for approximately
1 second. (The indicator lamp lights for approximately 2 seconds.)
2. Put on the 3D Eyewear.
If the 3D Eyewear slips out of place, hold it in place using the specialized band, and
adjust the length of the band. ( page 7)
If the 3D images are not displayed correctly, adjust the 3D image-related settings.
For details, see the television operating instructions.
* The perceived three dimensional effects of the 3D Eyewear differ from person to
person.
After Use
Press and hold the power button on the 3D Eyewear for approximately 1 second.
(The indicator lamp on the 3D Eyewear ashes 3 times, then the power switches off.)
After using the 3D Eyewear, store it in the case provided.
ENGLISH - 9
Storage and Cleaning
Clean using a soft, dry cloth.
Wiping the 3D Eyewear with a soft cloth that is covered in dust or dirt may scratch the
eyewear. Shake off any dust from the cloth before use.
Do not use benzene, thinner, or wax on the 3D Eyewear, as doing so may cause the
paint to peel off.
Do not dunk the 3D Eyewear in liquid such as water when cleaning.
Avoid storing the 3D Eyewear in hot or highly humid locations.
Replacing the batteries
When the battery is low, the indicator lamp ashes 5 times on switching the
power. (Early battery replacement is recommended.)
1. Loosen the screw and
remove the cover using the
screwdriver (included with the
television).
2. Replace the batteries, and then
replace the cover.
CR2032 H
Always tighten the screw to hold the
battery case cover in place.
NOTE:
Use the specied type of battery (coin-shaped lithium battery CR2032).
Do not insert the battery with the polarity (plus and minus ) backwards.
Dispose of the old batteries as non-burnable garbage, or in line with the garbage
regulations in your local area.
10 - ENGLISH
Troubleshooting/Q&A
Images are not 3D.
Are the image settings switched to 3D images?
Some 3D image signals are not automatically
recognized as 3D images.
Set “3D Eyewear” to “On”.
For details, see the television operating
instructions.
Is there a sticker or other such item blocking
the infra-red reception section on the
3D Eyewear?
If the eyewear stops receiving infra-red signal from
the television, the power automatically switches off
after 5 minutes.
Check that there are no objects blocking the path
between the television and 3D Eyewear.
Individual differences may occur in which the
3D images are difcult to see, or cannot be
seen, especially in users that have a different
level of eyesight between the left and right
eyes.
Take the necessary steps (wearing glasses etc.) to
correct your eyesight before use.
The power of the
3D Eyewear turns off
by itself.
Are there any objects between the eyewear and
television?
Is there a sticker or other such item blocking
the infra-red reception section on the
3D Eyewear?
If the eyewear stops receiving infra-red signal from
the television, the power automatically switches off
after 5 minutes.
Check that there are no objects blocking the path
between the television and 3D Eyewear.
There is something
wrong with the 3D
images.
Are the left and right sides of the 3D image
reversed?
Switch the left and right sides of the 3D image.
For details, see the television operating
instructions.
The indicator lamp
does not light when
switching on the
power.
The battery is too low to operate the
3D Eyewear.
The indicator lamp does not light when switching
on the power by pressing on the power by pressing
and hold the power button for 1 second; that
indicates the battery is completely at. Replace the
battery with new one.
Altri manuali per TY-EW3D10U
1
Indice
Altri manuali Panasonic Occhiali 3D
Panasonic
Panasonic TY-EW3D3LU Manuale utente
Panasonic
Panasonic TY-ER3D6ME Manuale utente
Panasonic
Panasonic TY-EW3D3LW Manuale utente
Panasonic
Panasonic TY-EW3D3LW Manuale utente
Panasonic
Panasonic TY-ER3D5MA Manuale utente
Panasonic
Panasonic TY-EW3D3LE Manuale utente
Panasonic
Panasonic TY-EW3D2SU Manuale utente
Panasonic
Panasonic TY-EP3D20E Manuale utente
Panasonic
Panasonic TY-EW3D3LE Manuale utente
Panasonic
Panasonic TY-ER3D4ME Manuale utente
Panasonic
Panasonic TY-ER3D6ME Manuale utente
Panasonic
Panasonic TY-ER3D5MW Manuale utente
Panasonic
Panasonic TY-ER3D4ME Manuale utente
Panasonic
Panasonic TY-ER3D5ME Manuale utente
Panasonic
Panasonic TY-EP3D10EB Manuale utente
Panasonic
Panasonic TY-EW3D10U Manuale utente
Panasonic
Panasonic TY-EW3D3LE Manuale utente
Panasonic
Panasonic TY-ER3D4SW Manuale utente
Panasonic
Panasonic TY-EP3D10WB Manuale utente
Panasonic
Panasonic TY-EW3D3LU Manuale utente
