FCC ID ACJ9TGWL22A

WLAN+BT module adapter

Model number: WL22A

User Manual

GENERAL

This device is a 2x2 Wi-Fi+Bluetooth® adapter.

Integration to the end product

1. WL22A module is mounted on the main board.

2. Insert Antenna Unit into Antenna Connectors of WL22A module.

Technical Specification

a) Dimensions (W x L x H): 22mm x 30mm x 2.4mm

b) Weight: Approx. 3.0g

c) IEEE WLAN Standard: IEEE 802.11a/b/g/n/ac/ax

d) Bluetooth: BDR, EDR, Low energy

e) Operating Temperature: -10 to 50 degree Celsius

f) Humidity: 30 to 80 %RH

g) Host interface: M.2: CNVio2

FCC ID ACJ9TGWL22A

Regulatory Information

Federal Communications Commission Radio Frequency Interference

Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment.

This equipment may not be collocated or operated with any other antenna or transmitter.

This device meets the government’s requirements for exposure to radio waves.

This device is designed and manufactured not to exceed the emission limits for exposure

to radio frequency (RF) energy set by the Federal Communications Commission of the

U.S.Government.

The exposure standard for wireless device employs a unit of measurement known as the

Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.

* Tests for SAR are conducted using standard operating positions accepted by the FCC

with the device transmitting at its highest certified power level in all tested frequency

bands.

Although the SAR is determined at the highest certified power level, the actual SAR level

of the device while operating can be well below the maximum value. This is because the

device is designed to operate at multiple power levels so as to use only the poser required

to reach the network. In general, the closer you are to a wireless base station antenna, the

lower the power output.

FCC ID ACJ9TGWL22A

Caution: Exposure to Radio Frequency Radiation.

To comply with FCC RF exposure compliance requirements, a separation distance of at

least 5mm must be maintained between the antenna of this device and all persons. This

device must not be co-located or operating in conjunction with any other antenna or

transmitter.

Instructions to OEM Integrators

A User manual provided to the end user must indicate the operating requirements and

conditions that must be observed to ensure compliance with the above-mentioned FCC RF

Exposure guideline.

If this module is intended for use in a portable device, integrators are responsible for

separate evaluation and/or approval to satisfy FCC RF Exposure requirements.

If other radio devices are to be integrated with this module, an additional evaluation and

FCC submission may be required. Integrators are responsible for such additional

evaluation and FCC submission.

The following information must be indicated on the host device of this module;

Model : WL22A

FCC ID : ACJ9TGWL22A

IC : 216H-CFWL22A
