Panasonic KX-MB2010BL Manuale operativo
Important Information Guide
Multi-Function Printer
Model No.
KX-MB2010BL
KX-MB2030BL
Do NOT connect the unit to a computer with the USB cable until prompted to do so during the setup
of Multi-Function Station (CD-ROM).
12
Accessory information:
To ensure that the unit operates properly, we
recommend the use of Panasonic toner and
drum cartridges.
n Replacement accessory
–Toner cartridge
RModel No. (Part No.): KX-FAT411X
–Drum cartridge
RModel No. (Part No.): KX-FAD412X
The supplied Setup CD-ROM provides the
Operating Instructions in PDF format with a
detailed description on how to use the unit.
Adobe® Reader® is required to view them.
Please read before using the unit and save the
CD-ROM for future reference.
You can select the English, French or Dutch
language.
The display and reports will be in the selected
language. The default setting is English. If you
want to change the setting, see the operating
instructions (feature #110).
User record (for your future reference)
Date of purchase
Serial number (found on the rear of the unit)
Dealer’s name and address
Dealer’s telephone number
Attach your sales receipt here.
Note:
RSave the original carton and packing materials for
future shipping and transportation of the unit.
RAfter unpacking the product, take care of the packing
materials and/or power plug cap appropriately.
RThe suffix in the model number will be omitted in
these instructions.
RMost figures shown in these instructions are based
on a KX-MB2010.
Caution:
RWhen you operate this product, the power outlet
should be near the product and easily accessible.
RBe sure to use the telephone line cord supplied
with this unit (KX-MB2030 only).
RDo not extend the telephone line cord
(KX-MB2030 only).
RIn the event of problems, you should contact your
equipment supplier in the first instance
(KX-MB2030 only).
RThis equipment is designed for use on the
Belgium analogue telephone network
(KX-MB2030 only).
Declaration of Conformity (KX-MB2030 only):
RPanasonic System Networks Co., Ltd. declares that
this equipment is in compliance with the essential
requirements and other relevant provisions of Radio
& Telecommunications Terminal Equipment
(R&TTE) Directive 1999/5/EC.
Declarations of Conformity for the relevant
Panasonic products described in this manual are
available for download by visiting:
http://www.doc.panasonic.de
Contact to Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Information of Compliance with EU relevant
Regulatory Directives (KX-MB2010 only):
RContact to Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
ENERGY STAR:
RAs an ENERGY STAR® Partner, Panasonic has
determined that this product meets the ENERGY
STAR guidelines for energy efficiency. ENERGY
STAR is a U.S. registered mark.
Trademarks:
RAdobe and Reader are either registered trademarks
or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
RAll other trademarks identified herein are the property
of their respective owners.
Copyright:
RThis material is copyrighted by Panasonic System
Networks Co., Ltd., and may be reproduced for
internal use only. All other reproduction, in whole or
in part, is prohibited without the written consent of
Panasonic System Networks Co., Ltd.
© Panasonic System Networks Co., Ltd. 2011
Table of Contents
1.1 For your safety 3
1.2 Important safety instructions 5
1.3 Information for Users on Collection and
Disposal of Old Equipment and used
Batteries
5
1.4 Illegal copies 6
1.5 Turning the power switch ON 6
1.6 Selecting the operation mode (Scan/
Copy) (Fax: KX-MB2030 only)
6
1.7 Setting the original 7
1.8 Display messages 7
2
1.1 For your safety
To prevent severe injury and loss of life/property,
read this section carefully before using the unit to
ensure proper and safe operation of your unit.
RThe following symbols are used to classify and
describe the level of hazard and injury caused
when the denotation is disregarded and improper
use is performed.
Denotes a potential hazard that could result in serious
injury or death.
Denotes hazards that could result in minor injury or
damage to the unit.
RThe following symbols are used to classify and
describe the type of instructions to be observed.
This type of symbol is used to alert users
to a specific operating procedure that
must be performed carefully.
This type of symbol is used to alert users
to a specific operating procedure that
must not be performed.
This type of symbol is used to alert users
to a specific operating procedure that
must be emphasized in order to operate
the unit safely.
Power and ground connection
Unplug this unit from power outlets if it
emits smoke, an abnormal smell or
makes unusual noise. These conditions
can cause fire or electric shock. Confirm
that smoke has stopped and contact an
authorised service centre.
Use only the power source marked on the
unit. If you are not sure of the type of
power supplied to your home, consult
your dealer or local power company.
For safety purposes this unit is equipped
with a grounded plug. If you do not have
this type of outlet, please have one
installed. Do not ignore this safety feature
by tampering with the plug.
Do not place objects on the power cord.
Install the unit where no one can step or
trip on the cord.
Do not overload power outlets and
extension cords. This can result in the risk
of fire or electric shock.
Completely insert the AC adaptor/power
plug into the power outlet. Failure to do
so may cause electric shock and/or
excessive heat resulting in a fire.
Regularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from
the power outlet, then wiping with a dry
cloth. Accumulated dust may cause an
insulation defect from moisture, etc.
resulting in a fire.
Never touch the plug with wet hands.
There is a danger of electric shock.
Installation
Place the unit securely on a stable, level
surface. Serious damage and/or injury
may result if the unit falls.
To prevent the risk of fire or electrical
shock, do not expose this product to rain
or any type of moisture.
Use this unit in a well ventilated area.
Particularly, if you will be using the unit for
extended periods of time or will be
printing in large volumes, be sure to
ventilate the room sufficiently.
Operating safeguards
Turn the power switch OFF before
cleaning. Do not use liquid or aerosol
cleaners.
Do not cover slots and openings on the
unit. They are provided for ventilation and
protection against overheating. Never
place the unit near radiators, or in a place
where proper ventilation is not provided.
Detailed operating instructions are on the CD-ROM. 3
1. . Important Information
1. Important Information
Never push any objects through slots in
this unit. This may result in the risk of fire
or electric shock. Never spill any liquid on
the unit.
To reduce the risk of electric shock, do
not disassemble this unit. Take the unit to
an authorised service centre when
service is required. Opening or removing
covers may expose you to dangerous
voltage or other risks. Incorrect
reassembly can cause electric shock
when the unit is subsequently used.
Follow all warnings and instructions
marked on this unit.
Do not spill liquids (detergents,
cleansers, etc.) onto the telephone line
cord plug, or allow it to become wet at all.
This may cause a fire. If the telephone
line cord plug becomes wet, immediately
pull it from the telephone wall jack, and
do not use (KX-MB2030 only).
Unplug this unit from power outlets and
refer servicing to an authorised service
centre when any of the following
conditions occur:
RIf the power cord is damaged or
frayed.
RIf the unit has been exposed to rain or
water, or liquid has been spilled into
the unit. Do not use a microwave oven
to speed up the drying process of any
parts of the unit to avoid permanent
damage.
RIf the unit does not work normally by
following the operating instructions.
Adjust only controls covered by the
operating instructions. Improper
adjustment may require extensive
work by an authorised service centre.
RIf the unit has been dropped or
physically damaged.
RIf the unit exhibits a distinct change in
performance.
USB cable/LAN cable
To assure continued emission limit
compliance;
Ruse only shielded USB cable
(Example: Hi-Speed USB 2.0 certified
cable).
Ruse only shielded LAN cable
(category 5 straight cable).
Installation and relocation
After moving the unit from cold areas to
warmer areas, wait approximately 30
minutes before turning on the power
switch to allow the unit to adjust to the
ambient temperature. If the power switch
is turned on too soon after a sudden
climate change, condensation may form
inside the unit, causing malfunction.
Never turn the unit upside down or
sideways when moving it.
Never install telephone wiring during a
lightning storm (KX-MB2030 only).
Never install telephone jacks in wet
locations unless the jack is specifically
designed for wet locations (KX-MB2030
only).
Never touch uninsulated telephone wires
or terminals unless the telephone line has
been disconnected at the network
interface (KX-MB2030 only).
Use caution when installing or modifying
telephone lines (KX-MB2030 only).
Do not position the unit in a location
where it is unstable or subject to
vibrations.
4Detailed operating instructions are on the CD-ROM.
1. Important Information
Operating safeguards
When opening/closing the top cover, hold
the indentations on both sides of the unit
(A).
RTo prevent injuries, be careful not to
put your hands under the top cover.
A
A
Laser radiation
CLASS 1 LASER PRODUCT
The printer of this unit utilises a laser. Use
of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
See the operating instructions for the
Laser diodes properties.
LED light
CLASS 1 LED PRODUCT
Do not view directly with optical
instruments.
See the operating instructions for the
CIS’s LED light properties.
Fuser unit
During or immediately after printing, the
fuser unit gets hot. This is normal. Do not
touch the fuser unit.
Note:
RThe area near the output tray may also get warm.
This is normal.
Toner cartridge
Avoid ingestion, inhalation, eye or skin
contact.
RIf ingestion occurs, drink several
glasses of water to dilute stomach
contents.
RIf inhalation occurs, exit the area
immediately into the fresh air.
RIf skin contact occurs, wash
thoroughly with soap and cold water,
then air dry. Do not use hot water or
hair dryer.
RIf eye contact occurs, flush thoroughly
with water.
RIn all cases, seek medical treatment if
adverse symptoms occur.
1.2 Important safety instructions
When using this unit, basic safety precautions should
always be followed to reduce the risk of fire, electric
shock, or personal injury.
1. Do not use this unit near water, for example near a
bathtub, wash bowl, kitchen sink, etc.
2. During thunderstorms, avoid using telephones
except cordless types. There may be a remote risk of
an electric shock from lightning (KX-MB2030 only).
3. Do not use the telephone of this unit (if so equipped)
to report a gas leak, when in the vicinity of the leak
(KX-MB2030 only).
SAVE THESE INSTRUCTIONS
1.3 Information for Users on
Collection and Disposal of Old
Equipment and used Batteries
ABC
These symbols (A, B, C) on the products, packaging,
and/or accompanying documents mean that used
electrical and electronic products and batteries should
not be mixed with general household waste.
For proper treatment, recovery and recycling of old
products and used batteries, please take them to
applicable collection points, in accordance with your
national legislation and the Directives 2002/96/EC and
2006/66/EC.
Detailed operating instructions are on the CD-ROM. 5
1. Important Information
By disposing of these products and batteries correctly,
you will help to save valuable resources and prevent any
potential negative effects on human health and the
environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of
old products and batteries, please contact your local
municipality, your waste disposal service or the point of
sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this
waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment,
please contact your dealer or supplier for further
information.
Information on Disposal in other Countries outside
the European Union
These symbols (A, B, C) are only valid in the European
Union. If you wish to discard these items, please contact
your local authorities or dealer and ask for the correct
method of disposal.
Note for the battery symbol
This symbol (B) might be used in combination with a
chemical symbol (C). In this case it complies with the
requirement set by the Directive for the chemical
involved.
1.4 Illegal copies
RIt is unlawful to make copies of certain
documents.
Copying certain documents may be illegal in your
country. Penalties of fines and/or imprisonment may
be imposed on those found guilty. The following are
examples of items that may be illegal to copy in your
country.
– Currency
– Bank notes and cheques
– Bank and government bonds and securities
– Passports and identification cards
– Copyright material or trademarks without the
consent of the owner
– Postage stamps and other negotiable
instruments
This list is not inclusive and no liability is
assumed for either its completeness or accuracy.
In case of doubt, contact your legal counsel.
Notice:
RInstall your machine near a supervised area to
prevent illegal copies from being made.
1.5 Turning the power switch ON
Turn the power switch to the ON position (A).
A
1.6 Selecting the operation mode
(Scan/Copy) (Fax: KX-MB2030
only)
You can select the desired mode by pressing one of the
following buttons.
KX-MB2010 KX-MB2030
–MScanN: Select this mode when using the unit as a
scanner.
–MCopyN: Select this mode when using the unit as a
copier.
–MFaxN (KX-MB2030 only): Select this mode when
using the unit as a fax machine.
6Detailed operating instructions are on the CD-ROM.
1. Important Information
1.7 Setting the original
1.7.1 Using the scanner glass
A
B
1Open the document cover (A).
2Place the document FACE DOWN on the scanner
glass (B), aligning the top left of the document with
the corner where the mark is positioned.
3Close the document cover.
1.7.2 Using the automatic document feeder
A
1Insert the document (up to 20 pages) FACE UP into
the feeder until a single beep is heard.
2Adjust the width of the document guides (A) to fit the
actual size of the document.
1.8 Display messages
To indicate the unit’s status, one or more of the following
messages will appear on the display. See the operating
instructions for details.
–“CALL SERVICE”
–“CHANGE DRUM”
–“CHECK DOCUMENT”
–“CHECK DRUM”
–“CHECK PAPER #1”
–“CHECK PAPER TRAY #1”
–“CHECK PICK UP INPUT TRAY #2”
–“CHECK REAR COVER”
–“COOL DOWN FUSER”
–“DRUM LIFE LOW REPLACE SOON”
–“EMAIL SIZE OVER”
–“FAX IN MEMORY”
–“FILE SIZE OVER”
–“KEEP COPYING”
–“LOW TEMP.”
–“MEMORY FULL”
–“MODEM ERROR”
–“NO FAX REPLY”
–“OUT OF PAPER INPUT TRAY #2”
–“PAPER IN TRAY #2”
–“PAPER JAMMED”
“OPEN TOP COVER”
–“PC FAIL OR BUSY”
–“PHONEBOOK FULL”
–“PLEASE WAIT”
–“POLLING ERROR”
–“REDIAL TIME OUT”
–“REMOVE DOCUMENT”
–“REMOVE PAPER IN INPUT TRAY #2”
–“REPLACE DRUM CHANGE SUPPLIES”
–“RX MEMORY FULL”
–“SCANNER POSITION ERROR”
–“TONER EMPTY”
“CHANGE SUPPLIES”
–“TONER LOW”
“CHANGE SUPPLIES”
–“TOP COVER OPEN”
–“TRANSMIT ERROR”
Detailed operating instructions are on the CD-ROM. 7
1. Important Information
Manufacturer:
1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
0682 : KX-MB2030
with Fax function
: KX-MB2010
Global web site:
http://www.panasonic.net/
Sales Department:
Brusselsesteenweg 502, 1731 Zellik, Belgium
Tel: 070-223011
1/3
PNQW2832ZA CM0411DY0
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Panasonic Stampante tutto in uno
Panasonic
Panasonic DP-2330 Manuale utente
Panasonic
Panasonic WORKIO DP-C354 Manuale utente
Panasonic
Panasonic KX-MB3020 - Laser Multi-Function Printer Manuale di istruzioni
Panasonic
Panasonic KX-MB1520BL Manuale operativo
Panasonic
Panasonic Panafax UF-9000 Manuale utente
Panasonic
Panasonic Workio DP-C262 Manuale utente
Panasonic
Panasonic DP-8540 Manuale utente
Panasonic
Panasonic KX-MB2230JT Manuale utente
Panasonic
Panasonic KX-MB2061 Manuale utente
Panasonic
Panasonic KX-MC6260 Manuale utente
Panasonic
Panasonic KXFLB881 - Network Multifunction Laser... Manuale di istruzioni
Panasonic
Panasonic Workio DP-2310 Manuale utente
Panasonic
Panasonic FP-7818 Guida alla risoluzione dei problemi
Panasonic
Panasonic Workio DP-2310 Come usare
Panasonic
Panasonic KXFLB881 - Network Multifunction Laser... Manuale utente
Panasonic
Panasonic DP-1810P Manuale utente
Panasonic
Panasonic KX-MB778TW Manuale utente
Panasonic
Panasonic WORKIO DP-8060 Manuale utente
Panasonic
Panasonic DP-1510P Manuale utente
Panasonic
Panasonic DP-8130 Manuale utente
Manuali Stampante tutto in uno popolari di altre marche
Triumph Adler
Triumph Adler DC 2016 Manuale
Epson
Epson WorkForce WF-2510 Guida utente
Epson
Epson Stylus Scan 2000 Manuale di installazione e funzionamento
Epson
Epson PictureMate Snap PM 240 Manuale di istruzioni
Konica Minolta
Konica Minolta bizhub C35 Manuale utente
Brother
Brother MFC-J430w Manuale utente
