CQ-DF602W 11

General

CQ-DF602W

Before Reading these Instructions

You can operate this unit by pressing buttons on the main unit and the remote control unit.

∫These instructions describe buttons that are concerned with operations as follows.

Example: Press [P·SET "]or [P·SET #]/["]or [#].

∫Some operations can be activated by pressing buttons only on main unit or remote control unit.

Those cases are described in the instructions.

Example: Press [OPEN] on the main unit.

Battery Installation

1Remove the battery holder.

Pull the battery holder by the position B while pushing

position A in the direction indicated by the arrow.

2Install the battery on the battery holder.

Set a new battery properly with its “i” side facing up

as shown in the ﬁgure.

3Insert the battery holder.

Push the battery holder back into its original position.

Battery Notes

Remove and dispose of an old battery immediately.

Battery Information:

≥Battery type: Panasonic lithium battery (CR2025) (included)

≥Battery life: Approximately 6 months with normal use (at room temperature)

≥Do not disassemble or short the battery. Do not throw a battery into a ﬁre.

≥Keep batteries away from children to avoid the risk of accidents.

≥Be careful to observe proper local disposal rules when you dispose of batteries.

Caution:

≥Improper use of batteries may cause overheating, an explosion or ignition, resulting in injury or a ﬁre.

Battery leakage may damage the unit.

[buttons on the main unit]/[remote control unit]

Point the remote control unit at the main unit’s sensor.

Remote Control Unit Preparation

Lithium battery

(included)

Back side

Position B

Position ABattery holder

Note:

≥When the power is switched on for the

ﬁrst time, a demonstration message ap-

pears on the display.

To cancel this display, press [DISP] (dis-

play).

ACCON

[SOURCE]

(POWER)

[DISP]

(Display)

Power

Turn the key in the ignition until the accessory in-

dicator lights.

ON: Press [SRC] (PWR)/[SOURCE] (POWER).

OFF:Press and hold [SRC] (PWR)/[SOURCE]

(POWER) again for more than 1 second.

≥After turning off the ignition key, a security

message is displayed, and the panel removable

alarm that reminds you to take the panel is acti-

vated.

(When security function is set to on ➡page 28)

Source

Press [SRC] (SOURCE)/[SOURCE] to change the source.

Radio

CD player

CD changer control

AUX-IN setting

(When a CD is in the player.)

(When a CD changer is con-

nected and magazine is in the

changer.) (➡page 20)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOT MATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

Remote control signal sensor

CQ-DF602W 13

CQ-DF602W

General (Continued)

Mute/Attenuation

ON: Press [MUTE].

OFF: Press again.

Setting range:

0 to 40

Open/Close the Front Panel

OPEN: Press [OPEN] on the front panel.

CLOSE: Raise the panel by hand.

: No sound.

Caution:

≥To avoid damaging the front panel, do not push it down or place objects on it while it is open.

≥Do not pitch your ﬁnger or hand in the front panel.

≥Do not insert foreign matter into the disc slot.

Note:

≥The sound level for each source is stored in

memory.

(There is one volume setting for AM radio band

and one volume setting for FM radio band.)

: Decrease the volume to 1/10.

Decreasing volume range depends on setting.

(➡page 28)

Display Change

When Power is ON

Press [DISP] (display).

Press and hold [DISP] (display) for more than 2 seconds.

≥The audio indicator is displayed and returns to the previous display.

≥When the indicator lights, the audio function (S·HDB/SUB·W) is now

activated.

Press [DISP] (display) again to cancel.

Display and light off (when it is turned on.)

If you press a button, the light is turned on, the mode display appears

for 5 seconds, and the light is turned off again.

When Power is OFF

Press [DISP] (display).

Mode display

Mode and spectrum analyzer display

Mode and clock display

Clock display

Display and light off

Spectrum Analyzer (S·A) display

If you press a button, the mode and spectrum analyzer display

appear for 5 seconds.

Note:

≥Set the Spectrum Analyzer (S·A) display pattern in a separate procedure. (➡page 26)

≥: Displays before adjusting the clock. (➡page 28)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOT MATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

[VOL "]

[VOL #]

(Volume)

[MUTE] [DISP]

(Display)

PUSH

VOLUME

Volume

On the main unit:

Turn [VOLUME] dial

Clockwise: Up

Counterclockwise: Down

On the remote control unit:

[VOL "]: Up

[VOL #]: Down

Down Up

CQ-DF602W 15

CQ-DF602W

Radio

Band

Press [BAND] to change the band.

Radio Mode

Press [SRC] (SOURCE)/[SOURCE] to change to

the radio mode.

Tuning

[TUNE $]/[$]: Up

[TUNE %]/[%]: Down

Press and hold [TUNE $]or [TUNE %]/[$]or

[%] for more than 0.5 seconds, then release.

Seeking will start.

[SOURCE]

["] [#]

(Preset station/

select)

[%] [$] (Tune)

[1] to [6]

(Preset station)

[BAND]

(Auto preset memory)

FM1 FM2

FM3AM

Radio mode display

FM stereo indicator

One-Touch Selection of a Preset Station

Up to 6 stations each can be saved in the FM1, FM2, FM3 and AM preset station memories.

Manual Preset

Memory

Manually save a station in

the preset memory.

Entering numbers directly on the remote control unit

1Select a band and frequency (step 1, 2and 3on the previous

page).

2Press and hold [1] to [6] for more than 2 seconds to memorize.

Auto Preset

Memory (APM)

Automatically save rela-

tively strong stations in

the preset memory.

1Select a band (steps 1and 2 on

the previous page).

2Press and hold [BAND] (APM) for

more than 2 seconds.

Note:

≥Existing saved stations are overwritten with new stations after following this procedure.

Preset Station

Calling

1Select a band (steps 1and 2on the previous page).

2Press [P·SET "]or [P·SET #]/["]or [#]to select the preset

number for tuning in the preset station.

(Press [1] to [6] on the remote control unit.)

Note:

≥Frequency setting can be performed even after selecting a preset number.

1Select a band and frequency (steps 1, 2and 3on the previous

page).

2Press and hold [P·SET "]or [P·SET #]/["]or [#]for more than

2 seconds until the preset number blinks.

3Press [P·SET "]or [P·SET #]/["]or [#]to select a preset num-

ber (1j6).

4Press and hold [P·SET "]or [P·SET #]/["]or [#]for more than

2 seconds to memorize.

Scanning:

≥The display blinks once, and a re-

ceiving station is saved in the

memory. Preset number

≥The 6 strongest available stations will be automatically saved in the mem-

ory under preset number 1to 6.

≥Once set, the preset stations are sequentially scanned for 5 seconds

each. (Scanning)

≥Press [P·SET "]or [P·SET #]/["]or [#]for the broadcast you want

to listen to.

(Press [1] to [6] on the remote control unit.)

Caution:

≥To ensure safety, never attempt to preset sta-

tions while you are driving.

[P·SET "] [P·SET #]

(Preset station/select)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOT MATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

Note:

≥When pressing [MENU] in radio mode,

the following display appears. This is

because radio mode does not have any

menu settings.

CQ-DF602W 17

CQ-DF602W

CD Player

Note:

≥Loading a disc when the power is off allows the

power to be turned on.

Track Selection

[TRACK 5]/[$]: Advance to the next track.

[TRACK 6]/[%]: Back to the beginning of the

current track.

Back to the previous track.

(Press twice.)

Open the front panel.

Press [OPEN] on the front panel.

Insert the disc.

Playback will start automatically after the unit

recognized the loaded disc as an ordinary

music CD. (When a CD-R or CD-RW which has

CD-DA formatted data as the same as an ordi-

nary music CD is loaded, this unit recognizes it

as an ordinary music CD.)

Close the front panel manually.

CD Player Mode

(When CD is in the player.)

Press [SRC] (SOURCE)/[SOURCE] to change to CD

player mode.

Playback will start automatically.

Listening to a CD

Disc Insert and Playback

Stop and Disc Eject

1Press [OPEN] on the front panel.

2Press [<] (eject) to stop CD play and eject the

disc.

(Eject)

Label side

CD player mode display

≥Do not insert a disc when this indicator

lights.

≥Lights when the disc is loaded/played.

Scan, random and repeat indicator

Track Search

Press and hold.

[TRACK 5]/[$]: Fast forward

[TRACK 6]/[%]: Fast backward

Release to resume the regular play.

Note:

≥Ejecting the disc when the unit is in the CD player

mode allows the power to be turned off.

Track number Track playing time

Pause

Press [BAND] ([ [ /1).

Press [BAND] ([ [ /1) again to cancel.

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOT MATRIX DISPLAY

DISC

SET/APM

VOLUME

[SRC] (SOURCE)

SOURCE

MOSFET

50W

[SOURCE]

[%] [$]

(Track)

[DISP]

(Display)

[BAND]

(Pause)

Caution:

≥Only 12 cm CD, CD-DA data recorded CD-R and CD-RW discs are available for this unit.

≥This unit does not support CD text display.

≥This unit does not support MP3 disc playback.

≥Refer to page 35 about notes on CD-Rs/RWs.

≥To avoid damaging the front panel, do not push it down or place objects on it while it is open.

≥Do not use irregular shaped discs.

≥Do not use discs that have a seal or label attached.

≥Do not insert foreign matter into the disc slot.

CQ-DF602W 19

CQ-DF602W

CD Player (Continued)

Menu Setting on CD Player Mode

Random Play

Default: OFF

Repeat Play

Default: OFF

Press [BAND] (SET) to change setting.

12 3Menu Submenu Setting

Scan Play

Default: SCAN OFF

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ REP

: All the available tracks plays in a random se-

quence.

: Cancel

OFF

Press [BAND] (SET) to change setting.

: Repeat the current track.

: Cancel

OFF

Direct setting on the remote con-

trol unit when the menu is not

displayed

Press [4] (RAND) to change setting.

Press [6] (REP) to change setting.

Note:

≥Operations except setting should be performed after

returning to the mode display.

≥Press [MENU], [DISP] (display) to return to the reg-

ular mode.

Only for the remote control unit

Press [5] (SCAN) to change setting.

Press [MENU]/[SEL] (MENU)

during CD playing to display

“CD”tab.

: The ﬁrst 10 seconds of each track

plays in sequence.

: Cancel

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ RAND

When the menu is not displayed

[MENU] [DISP] (Display) [BAND] (Setting)

[P·SET "][P·SET #] (Submenu)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOTMATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

[SEL] (MENU)

["] [#]

(Submenu)

[5] (SCAN) [4] (RAND)

[6] (REP)

[BAND] (Setting)

[DISP] (Display)

PUSH

VOLUME

(Press.)

CQ-DF602W 21

[SOURCE]

[%] [$]

(Track)

[DISP]

(Display)

["] [#]

(Disc)

CQ-DF602W

CD Changer Control

CD changer functions are designed for optional Panasonic CD changer unit.

Preparation:

≥Connect the CD changer, and load a magazine (disc).

Note:

≥Loading a magazine when the power is off allows the power to be turned on.

≥Ejecting the magazine when the unit is in the CD changer mode allows the power to be turned off.

≥This unit does not support CD-ROM, CD-R or CD-RW playback through the CD changer. Use the CD changer

to listen to normal music CD exclusively.

≥This unit does not support CD text display of the CD changer control.

≥Pausing does not function in the CD changer mode.

CD Changer Mode

(When a CD changer is connected and a maga-

zine is in the changer.)

Press [SRC] (SOURCE)/[SOURCE] to change to

CD changer mode.

Playback starts automatically.

Note:

≥: Load a magazine

with CDs.

≥: Magazine is ejected

in the CD changer

mode.

Disc Selection

[DISC "]/["]: Next disc.

[DISC #]/[#]: Previous disc.

CD changer mode display

Scan, random and repeat indicator

≥Lights when the changer (magazine) is

connected.

≥Lights when the disc is played.

Track Selection

[TRACK 5]/[$]: Advance to the next track.

[TRACK 6]/[%]: Back to the beginning of the

current track.

Back to the previous track.

(Press twice.)

3Track Search

Press and hold.

[TRACK 5]/[$]: Fast forward

[TRACK 6]/[%]: Fast backward

Release to resume the regular play.

Disc number Track number

Track playing time

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOT MATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

CQ-DF602W 23

CQ-DF602W

CD Changer Control (Continued)

Random Play

Default: OFF

Scan Play

Default: SCAN OFF

Repeat Play

Default: OFF

Press [MENU]/[SEL] (MENU)

during CD changer playing to

display

“CD-CH”tab.

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ RAND

Disc Random Play

Default: OFF

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ D·RAND

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ REP

Disc Scan Play

Default: DISC SCAN OFF

Disc Repeat Play

Default: OFF

Press [P·SET "]or

[P·SET #]/["]or [#]to

select .

∫ D·REP

Press [BAND] (SET) to change setting.

: All the available tracks on all discs in the maga-

zine plays in a random sequence.

: Cancel

OFF

Press [BAND] (SET) to change setting.

: All the available tracks on the current disc plays

in a random sequence.

: Cancel

OFF

Press [5] (SCAN) to change setting.

Press [BAND] (SET) to change setting.

: Repeat the current track.

: Cancel

OFF

Press [BAND] (SET) to change setting.

: Repeat the current disc.

: Cancel

OFF

Press and hold [5] (SCAN) for more than 2 seconds to change

setting.

Direct setting on the remote con-

trol unit when the menu is not dis-

played

Press [4] (RAND) to change setting.

Press and hold [4] (RAND) for more

than 2 seconds to change setting.

Press [6] (REP) to change setting.

Press and hold [6] (REP) for more

than 2 seconds to change setting.

Only for the remote control unit

: Cancel

Menu Setting on CD Changer Mode

2Submenu 3Setting

Note:

≥Operations except setting should be performed after

returning to the mode display.

≥Press [MENU], [DISP] (display) to return to the reg-

ular mode.

1Menu

: The ﬁrst 10 seconds of each track on all

discs plays in sequence.

: The ﬁrst 10 seconds of the ﬁrst track of all

the discs plays in sequence.

When the menu is not displayed

[MENU] [DISP] (Display) [BAND] (Setting)

[P·SET "][P·SET #] (Submenu)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOTMATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

[SEL] (MENU)

["] [#]

(Submenu)

[5] (SCAN) [4] (RAND)

[6] (REP)

[BAND] (Setting)

[DISP] (Display)

PUSH

VOLUME

(Press.)

CQ-DF602W 25

CQ-DF602W

Audio Settings [AUDIO]

Note:

≥Operations except setting should be performed after

returning to the mode display.

≥Press [MENU], [DISP] (display) to return to the reg-

ular mode.

BAS

(Bass)

TRE

(Treble)

1Press [TUNE $]or [TUNE %]/[$]or [%]to select “BAS”.

2Press [P·SET "]/["]: Increase the bass.

Press [P·SET #]/[#]: Decreases the bass.

1Press [TUNE $]or [TUNE %]/[$]or [%]to select “TRE”.

2Press [P·SET "]/["]: Increases the treble.

Press [P·SET #]/[#]: Decreases the treble.

BAL

(Balance)

FAD

(Fader)

Press [TUNE $]/[$]: Right enhanced.

Press [TUNE %]/[%]: Left enhanced.

Press [P·SET "]/["]: Front enhanced.

Press [P·SET #]/[#]: Rear enhanced.

Press [P·SET "]or [P·SET #]/["]or [#]to change setting.

Press [TUNE $]/[$]: Increase the level.

Press [TUNE %]/[%]: Decrease the level.

3Setting

Bass and Treble

You can adjust the bass and treble sound.

Default: BAS (Bass) 0

TRE (Treble) 0

Setting range: j12 to i12 (by 2 steps)

Subwoofer Level

You can change the subwoofer volume

level.

Default: 0

Setting range:j∞(Subwoofer mute),

j6 to i6 (by 2 steps)

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select

2Press [BAND] (SET)

to set.

∫ S·HDB

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ BAS/TRE

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ BAL/FAD

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ SUB WOOFER

Balance and Fader

You can adjust the sound balance among

the front, rear, right and left speakers.

Default: BAL (Balance) Center

FAD (Fader) Center

Setting range: 15 levels each

Audio menu display

Menu Submenu

S·HDB (Super High

Deﬁnition Bass)

Especially for rock music, the bass-sound

will be more powerful.

Default: OFF

Setting range: OFF, BOOM, TIGHT

1Press [MENU]/[SEL]

(MENU).

2Press [TUNE $]or

[TUNE %]/[$]or [%]to

select

“AUDIO”tab.

: The bass sounds of the speakers are

strongly emphasized.

: The bass sounds of the speakers are mod-

erately emphasized. (The sounds of the sub-

woofer can be heard clearly.)

: S·HDB is non-active.

[MENU] [DISP] (Display) [BAND] (Setting)

[P·SET "][P·SET #] (Submenu/setting)

[TUNE $][TUNE %] (Menu/setting)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOTMATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

Note:

≥When S·HDB is on, the indicator (S·HDB

BOOM or TIGHT) is shown on the audio

indicator display. (➡page 13)

["] [#]

(Submenu/

setting)

[%] [$] (Menu/setting)

[BAND] (Setting)

[DISP] (Display)

PUSH

VOLUME

Note:

≥When subwoofer level is set “j∞”, the indicator

(SUB·W) is not shown on the audio indicator dis-

play. (➡page 13)

(Press.)

CQ-DF602W 27

CQ-DF602W

Picture (Display) Settings [PICTURE]

Press [TUNE $]or [TUNE %]/[$]or [%]to change setting.

Press [TUNE $]/[$]: Decreases the contrast.

Press [TUNE %]/[%]: Increases the contrast.

: Display showing a cube that continues to

change.

: Display showing a globe that continues

to change.

: Display showing the image of a soccer.

Note:

≥Change the display to show the Spectrum Analyzer (S·A) display.

(➡page 13)

: Display showing a text pattern.

: Display showing the image of a circuit.

: Standard spectrum analyzer display

(9 bands).

STD

: Clock display ON

: Clock display OFF

OFF

Note:

≥Operations except setting should be performed after

returning to the mode display.

≥Press [MENU], [DISP] (display) to return to the reg-

ular mode.

Clock display

3Setting

2Press [BAND] (SET) to set.

Spectrum Analyzer (S·A)

Display Pattern

Default: Pattern A

Variety: 6 types

Contrast

Allows you to adjust the display contrasts

for better viewing.

Default: 3

Setting range: 1 to 5

Clock on the Mode Display

Default: ON

(“jj:jj”will appear before

adjusting the clock.)

(Clock adjustment ➡page 28)

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ S·A PATTERN

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ CONTRAST

Picture (display) menu display

1Menu 2Submenu

Dimmer (display brightness

setting range)

Default: 3

Setting range: 1 to 3

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ DIMMER

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select

Press [TUNE $]or [TUNE %]/[$]or [%]to change setting.

: Bright : Medium : Dark

123

[MENU] [DISP] (Display) [BAND] (Setting)

[P·SET "][P·SET #] (Submenu/setting)

[TUNE $][TUNE %] (Menu/setting)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOTMATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

["] [#]

(Submenu/

setting)

[%] [$] (Menu/setting)

[BAND] (Setting)

[DISP] (Display)

PUSH

VOLUME

∫ CLOCK-ON

∫ CLOCK-OFF

1Press [MENU]/[SEL]

(MENU).

2Press [TUNE $]or

[TUNE %]/[$]or [%]to

select

“PICTURE”tab.

(Press.)

Increase Decrease

1Press [P·SET "]or

[P·SET #]/["]or

[#]to select .

2Press [BAND] (SET)

to set.

∫ CLOCK ADJ

CQ-DF602W 29

CQ-DF602W

Clock Basics

Press [BAND] (SET) to change setting.

: No sound.

: Decrease the volume to 1/10.

(Attenuation)

ATT

MUTE

Press [BAND] (SET) to change setting.

: Security function is active.

: Security function is non-active.

OFF

Security Function

When the key in the ignition is turned OFF.

≥Security message will be active.

≥The panel removable alarm will be active.

When the removable face plate is removed.

≥The security indicator blinks. (➡page 41)

3Setting

Mute/Attenuation

You can select how much to lower the

volume when [MUTE] is pressed.

Default: MUTE

Security Function

The security indicator blinks when the re-

movable face plate is removed from the

unit.

Default: ON

Press [P·SET "]or

[P·SET #]/["]or [#]

to select .

∫ MUTE KEY

Press [P·SET "]or

[P·SET #]/["]or [#]

to select .

∫ S-LED

Function menu display

1Menu 2Submenu

3Setting1Menu 2Submenu

Clock Adjustment

(24 hour system)

Default: “ADJUST”(not adjusted.)

Function Settings [FUNCTION]

1Press [MENU]/[SEL]

(MENU).

2Press [TUNE $]or

[TUNE %]/[$]or [%]to

select

“FUNCTION”tab.

Note:

≥Operations except setting should be performed after

returning to the mode display.

≥Press [MENU], [DISP] (display) to return to the reg-

ular mode.

Hours

set.

Minutes

set.

1[TUNE %]/[%]: The hour display highlights.

2[P·SET "]/["]: Put forward.

[P·SET #]/[#]: Put back.

1[TUNE $]/[$]: The minutes display highlights.

2[P·SET "]/["]: Put forward.

[P·SET #]/[#]: Put back. Highlighted.

[MENU] [DISP] (Display) [BAND] (Setting)

[P·SET "][P·SET #] (Submenu/hour/minute)

[TUNE $][TUNE %] (Menu/setting)

SRC

DISP P.SET

CQ-DF602W

;

/ 1

OPEN

BAND TUNE

TRACK

PWR

MUTE

PUSH

CD RECEIVER WITH FULL DOTMATRIX DISPLAY

DISC

SET/APM

VOLUME

SOURCE

MOSFET

50W

["] [#]

(Submenu/

setting)

[%] [$] (Menu/setting)

[BAND] (Setting)

[DISP] (Display)

PUSH

VOLUME

PUSH

VOLUME

1Press [MENU]/[SEL]

(MENU).

2Press [TUNE $]or

[TUNE %]/[$]or [%]to

select

“PICTURE”tab.

(Press.)

3Press [BAND] (SET) to set.

Altri manuali per CQ-DF602W

Indice

Altri manuali Panasonic Ricevitore per auto

Panasonic

Panasonic CQ-VX2200W Manuale utente

Panasonic

Panasonic CQDPX30EUC - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic CQVD6505U - IN-DASH DVD MONITOR Manuale utente

Panasonic

Panasonic CQ-C7703N Manuale utente

Panasonic

Panasonic CQDP383U - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic C9801W Manuale utente

Panasonic

Panasonic CQ-DFX777EW Manuale utente

Panasonic

Panasonic CQ-DP34LEE Manuale utente

Panasonic

Panasonic CQVA70EU - CAR AUDIO/VIDEO SYS Manuale utente

Panasonic

Panasonic CQVX777EUC - CD/CAS RECEIVER WITH Manuale utente

Panasonic

Panasonic CQ-R35LEE Manuale utente

Panasonic

Panasonic CQ-DPG570 Operating Manuale utente

Panasonic

Panasonic CQ-DFX600N Manuale utente

Panasonic

Panasonic CQ-VX303EW Manuale utente

Panasonic

Panasonic CR-CM120U Manuale utente

Panasonic

Panasonic CQC8803U - AUTO RADIO/CD DECK-MULTI-LANG Manuale utente

Panasonic

Panasonic C1305L Manuale utente

Panasonic

Panasonic CQ-DFX777EW Manuale utente

Panasonic

Panasonic CQ-5800U - Double DIN Heavy Duty MP3 Manuale utente

Panasonic

Panasonic CQC1300U - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic CQDP383U - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic CQ-VW120L Manuale utente

Panasonic

Panasonic CQ-RG133WA Manuale utente

Panasonic

Panasonic CQ-DP200LEE Manuale utente

Manuali Ricevitore per auto popolari di altre marche

Motorola

Motorola VWA63 Manuale utente

Nextar

Nextar D3201 Manuale utente

Alpine

Alpine CDE-163BT Manuale utente

Pioneer

Pioneer DEH-P645R Manuale utente

Axxera

Axxera XDMA7600 Istruzioni operative

XM OnyX Manuale utente

Sound Storm

Sound Storm STM93R Manuale utente

Soundstream

Soundstream VIR-5000 Manuale utente

Avson

Avson MKT Platform Manuale utente

Sony

Sony MEX-1HD - Audio Library System Manuale utente

Pioneer

Pioneer DVH-P500UB Manuale utente

JVC

JVC KD-AHD69 Manuale utente

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuale utente

Sony

Sony CDX-4160 - Cd Receiver Manuale utente

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuale utente

VDO

VDO CD 2253 Manuale utente

Volvo

Volvo 13 84 580 Manuale utente

ZENEC

ZENEC ZE-160DVD Manuale utente
