≥Please read these instructions carefully before using this product and save this manual for future use.

CD Player/Receiver with Dot Matrix LCD and CD Changer Control

Operating Instructions

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

SET/AUTO

•

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

CQ-DF701W

❐Use this Product Safely

Panasonic welcomes you to our ever growing family of electronic product owners. We know that this prod-

uct will bring you many hours of enjoyment. Our reputation is built on precise electronic and mechanical

engineering, manufactured with carefully selected components and assembled by people who take pride in

their work. Once you discover the quality, reliability, and value we have built into this product, you too will

be proud to be a member of our family.

When Driving

Keep the volume level low enough to be aware of

road and traffic conditions.

When Car Washing

Do not expose the product, including the speakers

and CDs, to water or excessive moisture. This

could cause electrical shorts, ﬁre, or other damage.

When Parked

Parking in direct sunlight can produce very high

temperatures inside your car. Give the interior a

chance to cool down before switching the unit on.

Use the Proper Power Supply

This product is designed to operate with a 12 V DC,

negative ground battery system.

Disc Mechanism

Do not insert coins or any small objects. Keep

screwdrivers and other metallic objects away from

the disc mechanism and disc.

Use Authorized Servicenters

Do not attempt to disassemble or adjust this preci-

sion product. Please refer to the Servicenter list in-

cluding with this product for service assistance.

For Installation

This product should be installed in a horizontal po-

sition with the front end up at a convenient angle,

but not more than 30x.

≥Operating instructions .................................... 1

≥Installation hardware................1 set (➡page 28)

≥Power connector ............................................ 1

≥Remote control unit ........................................ 1

≥Lithium battery (CR2025)................................ 1

❐Components

このページは

繁体中国語のため

本社で作成しております。

CQ-DF701W 11

Remote Control Unit Preparation

CQ-DF701W

Features

Full-dot expressiveness <3D dot matrix display>

You can select an operation quickly because operation items are shown on the display. You can also enjoy vari-

ety of actions and direction.

Audio control functions

≥S•HDB (Super High Deﬁnition Bass) (➡page 14)

≥CD changer control (➡page 20)

Anti-theft removable face

You can remove the face plate when you leave your car. (➡page 33)

You can operate this unit by pressing buttons on the main unit and the remote control.

∫These instructions describe buttons that are concerned with operations as follows.

Example: Press [P. SET "]or [P. SET #]/["]or [#].

∫Some operations can be activated by pressing buttons only on main unit or remote control.

Those cases are described in the instructions.

Example: Press [D•M] on the main unit to select the preset station.

Battery Installation

Remove the battery holder.

Pull the holder by the position B while pushing posi-

tion A in the direction indicated by the arrow.

Install the battery on the battery holder.

Set a new battery properly with its (i) side facing up

as shown in the ﬁgure.

Insert the battery holder.

Push in the battery holder back into its original posi-

tion.

Battery Notes

Remove and dispose of an old battery immediately.

Battery Information:

≥Battery type: Panasonic lithium battery (CR2025) (included)

≥Battery life: Approximately 6 months with normal use (at room temperature)

Back side

Lithium battery

(included)

Battery holder Position A

Position B

≥Do not disassemble or short the battery. Do not throw a battery into a ﬁre.

≥Keep batteries away from children to avoid the risk of accidents.

≥Be careful to the local disposal rules when you dispose of batteries.

Caution:

≥Improper use of batteries may cause overheating, an explosion or ignition, resulting in injury or a ﬁre.

Battery leakage may damage the unit.

Before Reading these Instructions

[buttons on the main unit]/[remote control]

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

SET/AUTO•P

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

Point the remote control unit at

the main unit’s sensor (REMOTE).

CQ-DF701W 13

CQ-DF701W

General

Mute/Attenuator

ON: Press [MUTE].

OFF: Press again.

Decreasing volume range depends on setting.

(➡page 26)

Note:

≥When the power is switched on for the ﬁrst time,

a demonstration message appears on the display.

To cancel this display, press [DISP].

Volume

["VOL]: Up

[#VOL]: Down

Setting range: 0 to 40

ACCON

Open/Close the Front Panel

OPEN: Press [OPEN] on the front panel.

CLOSE: Raise the panel by hand.

: No sound.

Cautions:

≥To avoid damaging the front panel, do not push it down or place objects on it while it is open.

≥Do not pinch your ﬁnger or hand in the front panel.

≥Do not insert foreign matter into the disc slot.

VOL

TUNE

SOURCE

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

•

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

HDB

S•HDB

;

PWR

CQ-DF701W

SET/AUTO•P

Radio

CD player

CD changer control

(When a CD is inserted.)

(When a CD changer is connected and

magazine is in the changer.)

Source

AUX-IN setting (When AUX-IN setting is activated.)

( page 26)

[MUTE]

[SOURCE]

(POWER)

[VOL "]

[VOL #]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

Power

Turn the key in the ignition until the accessory

indicator lights.

ON: Press [SOURCE] (PWR).

OFF: Press [SOURCE] (PWR) again for more

than 1 second.

≥After turning off the ignition key, a security

message is displayed, and the panel remov-

able alarm that reminds you to take the panel

is activated.

(When S-LED is set to ON ➡page 26)

Source

Press [SOURCE] (PWR) to change the source.

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

SET/AUTO•P

Note:

≥The sound level for each source is stored in

memory.

(For radio, one volume setting for AM, one

volume setting for all FMs)

: Decrease the volume to 1/10 .

CQ-DF701W 15

CQ-DF701W

General (Continued)

Display Change

When Power is ON

Press [DISP].

Notes:

≥Set the spectrum analyzer pattern in a separate procedure. (➡page 24)

≥: Displays before adjusting the clock. (➡page 24)

Press and hold [DISP] for more than 2 seconds.

≥The audio indicator is displayed for 15 seconds and returns to the pre-

vious display.

≥When the indicator lights, the audio function (S•HDB/SUB•W) is now

activated.

Press [DISP] again to cancel.

Display and light off (when it is turned on.)

If you press a button, the light is turned on, the mode display

appears for 5 seconds, and the light is turned off again.

When Power is OFF

Press [DISP].

Mode display

Mode and spectrum analyzer display

Mode and clock display

Clock display

Display and light off

S•HDB

(Super High Deﬁnition Bass)

Especially for rock music, the bass-sound will be more

powerful.

Press [S•HDB] on the main unit to change the Super

High Deﬁnition Bass on.

Dimmer

(Display Brightness Setting Range)

Press [DIM] on the main unit to change the dimmer level.

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

SET/AUTO•P

[DISP]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

: Default

: The bass sounds of the speakers are

strongly emphasized.

: The bass sounds of the speakers are

moderately emphasized.

(The sounds of the subwoofer can

be heard clearly.)

: Bright

Default

: Medium

: Dark

Spectrum analyzer display

If you press a button, the mode and spectrum analyzer display

appear for 5 seconds.

Note:

≥When S•HDB is on, the indicator (S•HDB BOOM or TIGHT)

is shown on the audio indicator display. (➡page 15)

CQ-DF701W 17

CQ-DF701W

Radio

Band

Press [BAND] to change the band.

Radio Mode

Press [SOURCE] to change to the radio mode.

Tuning

[TUNE $]/[$]: Up

[TUNE %]/[%]: Down

Press and hold [TUNE $]or [TUNE %]/[$]or

[%] for more than 0.5 seconds, then release.

Seeking will start.

One-Touch Selection of a Preset Station

Up to 6 stations each can be saved in the FM1, FM2, FM3 and AM preset station memories.

Manual Preset

Memory

Manually save a sta-

tion in the preset

memory

Entering Numbers Directly from the Remote Control

Select a band and frequency (step 1, 2and 3on the previous page).

Press and hold [1] to [6] on the remote control for more than 2 sec-

onds to memorize.

Auto Preset

Memory

(AUTO•P)

Automatically save

strong stations in the

preset memory

Select a band (steps 1and 2 on the

previous page).

Press and hold [BAND] (AUTO•P) for

more than 2 seconds.

Note:

≥New stations are overwritten on existing saved stations after following this procedure.

Preset Station

Calling

Select a band (steps 1and 2on the previous page).

Press [P. SET "]or [P. SET #]/["]or [#]to select the preset

number for tuning in the preset station.

Entering Numbers Directly from the Remote Control

Press [1] to [6] on the remote control.

VOL

SET/AUTO•P

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

[SOURCE]

[%] [$]

(TUNE)

[1] to [6]

Preset button

[BAND]

["] [#]

(PRESET

MEMORY)

(SELECT)

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

FM1

FM2

FM3

Source

Note:

≥Frequency setting can be performed even after selecting a preset num-

ber.

Select a band and frequency (steps 1, 2and 3on the previous

page).

Press and hold [P. SET "]or [P. SET #]/["]or [#]for more than

2 seconds until the preset number blinks.

Press [P. SET "]or [P. SET #]/["]or [#]to select a preset num-

ber.

Press and hold [P. SET "]or [P. SET #]/["]or [#]for more than

2 seconds to memorize.

Direct Memory

Your favorite radio station can be memorized in

[D•M] on the main unit.

Default: FM 87.50 MHz

Memorize

Recalling the Direct Memory

Select a band and frequency (steps 1, 2and

3).

Press and hold [D•M] for more than 2 seconds.

Frequency blinks once and is saved in the mem-

ory.

Press [D•M].

Scanning:

Radio mode display

Press [D•M] again to cancel and return to the previ-

ous source.

Note:

≥You can recall the direct memory when the power

is off.

FM stereo indicator

≥The display blinks once, and a re-

ceiving station is saved in the

memory. Preset number

≥The 6 strongest available stations will be automatically saved in the

memory under preset number 1to 6.

≥Once set, the preset stations are sequentially scanned for 5 seconds

each.

≥Press [P. SET "]or [P. SET #]/["]or [#]for the broadcast you

want to listen to.

(Press [1] to [6] on the remote control.)

Note:

≥The new station is overwritten on existing saved

stations after following this procedure.

: Repeat the current track.

: Cancel

CQ-DF701W 19

CQ-DF701W

CD Player

Notes:

≥Do not insert a disc when this indicator

lights.

≥Loading a CD when the power is off allows the

power to be turned on.

≥Ejecting the CD when the unit is in the CD player

mode allows the power to be turned off.

Track Selection

[TRACK 5]/[$]: Next track.

[TRACK 6]/[%]: Beginning of the current track.

Previous track (Press twice.)

CD Player Mode

Press [SOURCE] to change to CD player mode and

playback starts.

Open the front panel.

Press [OPEN] on the front panel.

Insert the disc.

Close the front panel manually.

Playback will start automatically.

Pause

Press [BAND] ([ [ /1) during CD playing.

Press [BAND] ([ [ /1) again to cancel.

Cautions:

≥Only 12 cm CD is available for this unit.

≥To avoid damaging the front panel, do not push it down or place objects on it while it is open.

≥Do not use irregularly shaped CDs (heart-shaped, octagon, etc.).

≥Do not pinch your ﬁnger or hand in the front panel. Do not insert foreign matter into the disc slot.

Menu Setting on CD Player Mode

Press [MENU]/[SEL] (MENU) during CD playing.

Press [P. SET "]or [P. SET #]/["]or [#]to select a submenu.

Press [BAND] (SET) to change the setting.

Notes:

≥Operations except setting should be performed after returning to the mode display.

≥The display returns to the previous one with no operation for 15 seconds after changing to the menu display.

≥Press [DISP] to return to the regular mode.

Play Setting

Random Play Select

RAND

: All the available tracks plays in a random se-

quence.

: Cancel

Scan Play Select

SCAN

: The ﬁrst 10 seconds of each track plays in

sequence.

: Cancel

Repeat Play Select

REP

Direct setting on the remote control when the menu is not displayed:

OFF

SOURCE

•

Q-DF701W

OPEN

DISP

MOSFET

50W

PWR

[DISP]

SET/AUTO•P

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

[5] (SCAN)

[%] [$] (TRACK)

[4] (RAND)

[BAND]

["] [#]

(MENU SELECT)

[6] (REP)

[SEL] (MENU)

[DISP]

[SOURCE]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

Listening to a CD

Disc Insert and Playback

Stop and Disc Eject

Press [<] (EJECT) to stop CD play and eject the disc.

Random Play Press [4] (RAND). Press again to cancel.

Scan Play Press [5] (SCAN). Press again to cancel.

Repeat Play Press [6] (REP). Press again to cancel.

OFF

(EJECT)

Label side

CD player mode display

CD player menu display

≥Lights when the disc is loaded.

≥Blinks when the disc is played.

Play setting

Track Search

Press and hold.

[TRACK 5]/[$]: Fast forward

[TRACK 6]/[%]: Fast backward

Release to resume the regular play.

When CD is in the player

Press [SOURCE] to change to CD player mode.

CQ-DF701W 21

CQ-DF701W

CD Changer

Caution:

≥Do not use irregularly shaped CDs (heart-

shaped, octagon, etc.).

CD changer functions are designed for optional Panasonic CD changer unit.

Preparation:

≥Connect the CD changer, and load a magazine (disc).

Notes:

≥Loading a magazine when the power is off allows the power to be turned on.

≥Ejecting the magazine when the unit is in the CD changer mode allows the power to be turned off.

≥Pausing does not function in the CD changer mode.

Track Selection

[TRACK 5]/[$]: Next track.

[TRACK 6]/[%]: Beginning of the current track.

Previous track (Press twice.)

Track Search

Press and hold.

[TRACK 5]/[$]: Fast forward

[TRACK 6]/[%]: Fast backward

Release to resume the regular play.

CD Changer Mode

Press [SOURCE] to change to CD changer mode

and playback starts.

Note:

≥: Load a magazine

with CDs.

Disc Selection

[DISC "]/["]: Next disc.

[DISC #]/[#]: Previous disc.

Menu Setting on CD Changer Mode

Press [MENU]/[SEL] (MENU) during CD changer playing.

Press [P. SET "]or [P. SET #]/["]or [#]to select a submenu.

Press [BAND] (SET) to change the setting.

Notes:

≥Operations except setting should be performed after returning to the mode display.

≥The display returns to the previous one with no operation for 15 seconds after changing to the menu display.

≥Press [DISP] to return to the regular mode.

Play Setting

Random Play

Select

RAND

: All the available tracks on all discs in the maga-

zine plays in a random sequence.

: Cancel

Select

D•RAND

: All the available tracks on the current disc plays

in a random sequence.

: Cancel

Scan Play

Select

SCAN

: The ﬁrst 10 seconds of each track on the discs

plays in sequence.

: Cancel

Select

D•SCAN

: The ﬁrst 10 seconds of the ﬁrst track of all the

discs in the magazine plays in sequence.

: Cancel

Repeat Play

Select

REP

: Repeat the current track.

: Cancel

Select

D•REP

: Repeat the current disc.

: Cancel

Direct setting on the remote control when the menu is not displayed:

OFF

Change the CD Changer Unit

Press [BAND] (CH•C !@) to select the CD chang-

er 1 or 2 mode.

CD-CH1: CD changer 1 mode

CD-CH2: CD changer 2 mode

[DISP]

SET/AUTO•P

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

•

MOSFET

50W

S•HDB

HDB

;

PWR

[5] (SCAN)

[%] [$] (TRACK)

[4] (RAND)

[BAND]

["] [#]

(DISC/MENU

SELECT)

[6] (REP)

[SEL] (MENU)

[DISP]

[SOURCE]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

Random Play Press [4] (RAND). Press again to cancel.

Disc Random Play Press and hold [4] (RAND). Press and hold again to cancel.

Scan Play Press [5] (SCAN). Press again to cancel.

Disc Scan Play Press and hold [5] (SCAN). Press and hold again to cancel.

Repeat Play Press [6] (REP). Press again to cancel.

Disc Repeat Play Press and hold [6] (REP). Press and hold again to cancel.

OFF

CD changer menu display

CD changer mode display

Play setting

≥Lights when the changer (maga-

zine) is connected.

≥Blinks when the disc is played.

CQ-DF701W 23

CQ-DF701W

Audio Settings

Bass and Treble

You can adjust the bass and treble

sound.

Default: BAS (Bass) 0 dB

TRE (Treble) 0 dB

Setting range: j12 dB to i12 dB

by 3 dB step

Subwoofer Level

When the subwoofer is activated, you

can change the subwoofer volume level.

Default: 4

Setting range: 0 (MUTE) to 8

Cut-off Frequency Control

The maximum lower frequency level can

be adjusted to match your subwoofer and

the acoustics inside your car.

Default: 120 Hz

Setting range: 120 Hz/80 Hz

Press [MENU]/

[SEL] (MENU) to select

“AUDIO”on the menu

display.

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

BAS/TRE

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

BAL/FAD

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

SUB WOOFER

Notes:

≥Operations except setting should be performed after

returning to the mode display.

≥The display returns to the previous one with no op-

eration for 15 seconds after changing to the menu

display.

≥Press [DISP] to return to the regular mode.

BAS (Bass) TRE (Treble)

[P. SET "]/["]: Increase the bass.

[P. SET #]/[#]: Decreases the bass.

[P. SET "]/["]: Increases the treble.

[P. SET #]/[#]: Decreases the treble.

BAL (Balance) FAD (Fader)

[TUNE $]/[$]: Right enhanced.

[TUNE %]/[%]: Left enhanced.

[P. SET "]/["]: Front enhanced.

[P. SET #]/[#]: Rear enhanced.

Press [BAND] (SET) to set.

SET/AUTO•P

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

CH•C

MOSFET

50W

S•HDB

HDB

;

PWR

[BAND] (SET)

[TUNE %] [TUNE $]

(BAS/TRE/BAL/FAD/

LEVEL/LPF)

[P.SET "] [P.SET #]

(MENU SELECT)

[MENU] [DISP]

[%] [$]

(BAS/TRE/BAL/

FAD/LEVEL/LPF)

[BAND] (SET)

["] [#]

(MENU

SELECT)

[SEL] (MENU)

[DISP]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

Balance and Fader

You can adjust the sound balance among

the front, rear, right and left speakers.

Default: BAL (Balance) Center

FAD (Fader) Center

Setting range: 15 levels each

Press [TUNE $]or [TUNE %]/[$]or [%]to select BAS or TRE.

LEVEL

LPF

[TUNE $]/[$]: Increase the level.

[TUNE %]/[%]: Decrease the level.

Press [TUNE $]or [TUNE %]/[$]or [%]to select

120 Hz or 80 Hz.

Press [BAND] (SET) to set.

Press [P. SET "]or [P. SET #]/["]or [#]to select LEVEL or LPF.

12 3

Audio menu display

Menu Submenu Setting

Regular mode

display

AUDIO


FUNCTION

Note:

≥When subwoofer level is set 0, the indicator

(SUB•W) is not shown on the audio indicator

display. (➡page 15)

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

CLOCK-ON

CQ-DF701W 25

CQ-DF701W

Picture (Display) Settings

Spectrum Analyzer (S•A)

Display Pattern

Default: Pattern A

Variety: 6 types

Contrast

Allows you to adjust the display contrasts

for better viewing.

Default: Level 3

Setting range: Level 1 to level 5

Clock on the Mode Display

Default: ON

(“--:--”will appear before adjust-

ing the clock.)

Clock Adjustment

(12 hour system)

Default: Not adjusted.

Press [MENU]/

[SEL] (MENU) to select

“PICTURE”on the

menu display.

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

S•A PATTERN

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

CONTRAST

Press [P. SET "]or

[P. SET #]/["]or [#]

to select

Press [BAND] (SET) to

set.

CLOCK ADJ

Press [TUNE $]or [TUNE %]/[$]or [%]to select the pattern.

[TUNE $]/[$]: level up

[TUNE %]/[%]: level down

: Display showing a cube that continues to

change

: Display showing a globe that continues

to change

: Display showing a ﬂower or doll pattern

Press [BAND] (SET) to set.

Note:

≥Change the display to show the spectrum analyzer display. (➡page 15)

D: Display showing a bird ﬂapping its wings

: Display showing the image of a circuit

: Standard spectrum analyzer display

(9 bands)

OFF

: Clock display ON

: Clock display OFF

Hour/Minute Switch Hour/Minute Adjustment

[TUNE %]/[%]: The hour display high lights.

[TUNE $]/[$]: The minutes display high lights.

Press [BAND] (SET) to set.

[P. SET "]/["]: Put forward hour/minute.

[P. SET #]/[#]: Put back hour/minute.

Notes:

≥Operations except setting should be performed after

returning to the mode display.

≥The display returns to the previous one with no op-

eration for 15 seconds after changing to the menu

display.

≥Press [DISP] to return to the regular mode.

VOL

TUNE

SOURCE

•

CQ-DF701W

CD RECEIVER WIITH FULL DOT MATRIX DISPLAY

DIM

OPEN

TRACK

DISC

•

SET

BAND

REMOTE

MUTE

DISP

CH•C

MOSFET

50W

S•HDB

HDB

;

PWR

[BAND] (SET)

[TUNE %] [TUNE $]

(S A PATTERN/

CONTRAST/CLOCK ADJ)

[P.SET "] [P.SET #]

(MENU SELECT/CLOCK ADJ)

[MENU] [DISP]

•

SET/AUTO•P

[%] [$]

[BAND] (SET)

[SEL] (MENU)

[DISP]

SEL

Car Audio

SOURCE

POWER

VOL

DISPMUTE

RAND

REP

SCAN

BAND

(S A PATTERN/

CONTRAST/

CLOCK ADJ)

•

["] [#]

(MENU

SELECT/

CLOCK ADJ)

Press [BAND] (SET) to set.

Display menu display

STD

CLOCK-OFF

Clock display

1Menu 2Submenu 3Setting

Regular mode

display

AUDIO


FUNCTION

Press [BAND] (SET)

to select

Altri manuali per CQ-DF701W

Indice

Altri manuali Panasonic Ricevitore per auto

Panasonic

Panasonic CQ-C1001W1 Manuale utente

Panasonic

Panasonic CQ-C1315N Manuale utente

Panasonic

Panasonic CQ-DPX35 Manuale utente

Panasonic

Panasonic CQ-VAD9300U Manuale utente

Panasonic

Panasonic CQ-C9701N Manuale utente

Panasonic

Panasonic CQ5335U - AUTO RADIO/CD TRUCK Manuale utente

Panasonic

Panasonic CQ-HX2083N Manuale utente

Panasonic

Panasonic CX-DP880U - CD Changer Manuale utente

Panasonic

Panasonic CQE15EUC - AUTO RADIO/CASSETTE Manuale utente

Panasonic

Panasonic CQ-DFX572U Manuale utente

Panasonic

Panasonic CQ-DFX572N Manuale utente

Panasonic

Panasonic CQC1303U - AUTO RADIO/CD DECK Guida all'installazione

Panasonic

Panasonic CQRG131U - AUTO RADIO/CASSETTE Manuale utente

Panasonic

Panasonic CQ-R145U Manuale utente

Panasonic

Panasonic CQC500U - CD Receiver With Changer Control Manuale utente

Panasonic

Panasonic CQ-MR500N Manuale utente

Panasonic

Panasonic CQ-HX2083U Manuale utente

Panasonic

Panasonic CQ-R115U Operating Manuale utente

Panasonic

Panasonic CQC300U - 50Wx4 iPod-Ready Multi-Format Car Audio... Manuale utente

Panasonic

Panasonic CQ-C7703N Manuale utente

Panasonic

Panasonic CQC700U - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic CQD5501U - AUTO RADIO/CD/DVD PL Manuale utente

Panasonic

Panasonic CQC700U - AUTO RADIO/CD DECK Manuale utente

Panasonic

Panasonic CQR111SEUC - AUTO RADIO/CASSETTE Manuale utente

Manuali Ricevitore per auto popolari di altre marche

Motorola

Motorola VWA63 Manuale utente

Nextar

Nextar D3201 Manuale utente

Alpine

Alpine CDE-163BT Manuale utente

Pioneer

Pioneer DEH-P645R Manuale utente

Axxera

Axxera XDMA7600 Istruzioni operative

XM OnyX Manuale utente

Sound Storm

Sound Storm STM93R Manuale utente

Soundstream

Soundstream VIR-5000 Manuale utente

Avson

Avson MKT Platform Manuale utente

Sony

Sony MEX-1HD - Audio Library System Manuale utente

Pioneer

Pioneer DVH-P500UB Manuale utente

JVC

JVC KD-AHD69 Manuale utente

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuale utente

Sony

Sony CDX-4160 - Cd Receiver Manuale utente

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuale utente

VDO

VDO CD 2253 Manuale utente

Volvo

Volvo 13 84 580 Manuale utente

ZENEC

ZENEC ZE-160DVD Manuale utente
