Panasonic CQ-DP151W Manuale utente

ORDERNo. ACED010318C3

AUTOMOTIVE CONSUMERELECTRONICS

CQ-DP151W/ CQ-DP101W

CD Player/ Receiver

SPECIFICATIONS

Specification*

General

PowerSupply DC12V(11V-16V),

TestVoltage14.4V

NegativeGround

ToneAdjustmentRange Bass ;±12dBat100Hz

Treble;±12dBat10kHz

CurrentConsumption Less than 2.2A(CDplaymode,

0.5W×4ch)

MaximumPowerOutput 45W×4ch (at1kHz, Vol. Max.)

SuitableSpeakerImpedance 4-8

Pre-AMPOutputVoltage 2V(CDplaymode;1kHz, 0dB)

OutputImpedance

<CQ-DP151W> 200

<CQ-DP101W> 600

FMStereo Radio

FrequencyRange 87.5-108.0MHz

UsableSensitivity 11.0dBf(1.25 V, 75 )

AMRadio

FrequencyRange 531 -1,602kHz

UsableSensitivity 28dB/ V(25 V, S/N20dB)

CDPlayer

Sampling Frequency 32 times oversampling

Pick-Up Type Astigma 3-beam

LightSource SemiconductorLaser

Wavelength 780nm

FrequencyResponse 20Hzto 20,000Hz(±1dB)

Signal to Noise Ratio 96dB

Wowand Flutter Belowmeasurablelimits

Channel Separation 75dB

Dimensions** 178(W)×50(H)×150(D)mm

Weight** 1.5kg

*Specificationsand thedesign aresubjectto possible

modification withoutnotice dueto improvements.

** Dimensionsand Weightshown areapproximate.

2001 Matsushita Communication Industrial Co., Ltd. All rights

reserved. Unauthorizedcopying and distribution isaviolation of

law.

1. FEATUERS

-PLL (Phase LockedLoop)synthesizedtuning.

-18-FM, 6-AMpresets withpreset scan

-Digital servoforreliableCD playback.

-Removableface plate.

2. REPLACEING THE FUSE

Use fuses ofthesamespecifiedrating (15A). Using differentsubstitutes or fuses withhigher

ratings, or connecting theunitdirectlywithoutafuse, couldcause fireor damagetothestereo

unit.

3. MAINTENANCE

Your productsisdesignedand manufacturedtoensureaminimum ofmaintenance. Use asoft

clothfor routineexterior cleaning. Neveruse benzine, thinneror othersolvents.

4. NOTES

[RADIOBLOCK]

Donotalign theAM/FMpackageblock. Whenthepackageblock isnecessary, itwill besupplied

alreadyalignedatthefactory.

[CD DECK BLOCK]

Thismodel has no servoalignmentpointsbecause microcomputercontrolstheservocircuit.

[OTHER]

Thefollowing tabledescribes thedifferences between2models.

CQ-DP151W CQ-DP101W

Pre-Ampoutput

connector Rear, Front Rear

Remotecontrol unit Included Notincluded

5. LASER PRODUCTS

6. DIMENSIONS

7. WIRING CONNECTION

8. BLOCK DIAGRAM

9. TERMINALSDESCRIPTION

9.1. MainBlock

IC600 :C2BBGE000526

No. Port Description I/O (V)

1INITC Initial C I 4.9

2LEVEL-R Notused - -

3LEVEL-L Notused - -

4AVSS Analog ground - -

5AFMUTE AFmute O 5.1

6P. IC

STBY PowerAmp. stand-by O 5.0

7AVREF Reference voltage - 5.1

8CD-SO CD data I 3.2

9CD-SI CD data O 3.8

10 CD-SCK CD clock O 5.0

11 CD.C

DATA Notused - -

12 NC Noconnection - -

13 CD.C

CLK Notused - -

14 REMOUT Notused - -

15 PLL CE PLL controllerchipenable O 0

16 PLL

DATA(MI) Datafrom PLL I 5.1

17 PLL

DATA

(MO)

Datafor PLL O 0

18 PLL CLK Clock for PLL O 0

19 NC Noconnection - -

20 NC Noconnection - -

21 CD-

RESET CD reset O 5.0

22 NC Noconnection - -

23 NC Noconnection - -

24 NC Noconnection - -

25 NC Noconnection - -

26 NC Noconnection - -

27 NC Noconnection - -

28 CD-ON CD poweron O 5.0

29 CD-MUTE CD mutecontrol I 0

30 CD-SW2 Notused - -

31 NC Noconnection - -

32 NC Noconnection - -

33 Vss Ground - 0

34 NC Noconnection - -

35 /ST FMstereodetection I 4.6

36 IC2-CLK Electronicvolumeclock O5.0

37 IC2-DATA Electronicvolumedata I/O 5.0

38 LED Notused - -

39 /HDB Notused - -

40 BZIN PowerSWdetection I 4.9

41 LCD-DI

(MO) LCD dataoutput O 0

42 LCD-DO

(MI) LCD datainput I 5.0

43 LCD-CLK LCD clock O 0

44 LCD-CE LCD chipenableoutput O 0.2

45 POWER

LED Pilotlampon O 0

46 ANT.CONTMotor antennacontrol O 0

47 NC Noconnection - -

48 NC Noconnection - -

49 NC Noconnection - -

50 BZOUT Notused - -

51 NC Noconnection - -

52 NC Noconnection - -

53 NC Noconnection - -

54 NC Noconnection - -

55 PANEL Panel detect I4.8

56 CD

POWER CD powercontrol O 5.1

57 PWRCNT Powercontrol O 5.1

58 ACC ACC detection I 4.5

59 RDS

DATA Notused - -

60 /RESET Resetinput I 4.7

61 REM Remocon datainput I 4.4

62 BATT Batterydetection I 4.7

63 RDS CLK Notused - -

64 CD.C.STB (Ground pull-down) I 0

65 MUTE Mutecontrol O 5.1

66 NC (Connecting toground) - 0

67 CD. C2 (Connecting toground) - 0

68 VDD +5V powersupply -5.1

69 X2 Crystal oscillator - 3.0

70 X1 Crystal oscillator - 1.7

71 Vss (Ground pull-down) - 0

72 NC Noconnection - -

73 TEL

MUTE Telephonemute I4.9

74 AVDD +5V powersupply -5.1

75 AVREF (Connecting toVDD) -5.1

76 NC (Connecting toground) - 0

77 SD Searchdetect I0.6

78 INITD Initial valueD I5.1

79 INITA Initial valueA I5.1

80 INITB Initial valueB I5.1

Note1:Voltagemeasuermentsarewithrespecttoground, withavoltmeter(internal resistance :

10Mohms).

9.2. DisplayBlock

IC901 :YEAMLC75853W

No. Port Description I/O (V)

1-8 SEG1-8 Notused - -

9-35 SEG9-35 LCD segment O 2.5

36-

40 NC Noconnection - -

41-

43 COM1-3 LCD common O 2.5

44-

49 KS1-6 Key dataoutput O 0.9

50-4 KI1-5 Key datainput I 0

55 TEST (Connecting toground) - 0

56 VDD +5V powersupply -5.1

57 VDD1 Ground through capacitor - 3.3

58 VDD2 Ground through capacitor - 1.7

59 Vss Ground - 0

60 OSC CR oscillator - 3.9

61 DO Key dataoutput O 4.4

62 CE Chipenable I 0

63 CLK LCD clock I 0

64 DI LCD datainput I 0

9.3. CD ServoBlock

IC201 :C2BBFD000188

No. Port Description I/O (V)

1A0 Address output O 3.8

2/RST Servoprocessor reset O5.1

3RFOK Servoprocessor RFOK

signal I4.9

4/PS2 IC301 mute O5.1

5/PC1 IC301 mute O 0

6TRV Toraverse motor control O 2.5

7LOD Loading motor control O 2.5

8PS2 Notused - -

9PC1 Notused - -

10 PC Notused - -

11 IFR (Connecting toground) - 0

12 NC Noconnection - -

13 VPP Notused - -

14 X2 Crystal oscillator - 3.3

15 X1 Crystal oscillator - 2.9

16 VSS Ground - 0

17 VDD +5V powersupply -5.1

18 /RESET Resetinput I 5.1

19 TP19 Notused - -

20 TP20 Notused - -

21 TP21 Notused - -

22 AMUTE AFmute O 0

23 CDON CD poweron I 5.0

24 INTP1 (Connecting toground) - 0

25 INTP0 (Connecting toground) - 0

26 SIMO Serial data I 0

27 SOMI Serial data O2.9

28 SCKM Shift clock for serial data I5.0

29 Q1SW1 Disc insensor signal I4.6

30 Q3SW3 Disc outsensor signal I4.6

31 Q6SW6 (Option sensor) I4.7

32 SW4 Disc clamp I 0

33 SW5 InnerSW I4.9

34 SW2 Feederarm I 5.1

35 TP35 Notused - -

36 TP36 Notused - -

37 TP37 Notused - -

38 VDD +5V powersupply -5.1

39 VSS Ground - 0

40 /XEN Servoprocessor XEN

signal

O 0
