Panasonic EB-GD50 Manuale utente

Operating Instructions EB-GD50

Digital Cellular Telephone Main Kit

Before operating this equipment please read these instructions

completely.

The Serial Number can be found on the outside of the phone

under the battery. For your convenience we recommend that you

note the following details as a record of your purchase.

Part Number

Serial Number

Dealer Name

Purchase Date

Printed in UK

www.mcuk.panasonic.co.uk 1104

Contents

Introduction........................1

Symbols Used ......................1

Using This Manual....................1

Safety ...........................3

Getting Started ......................4

Fitting/Removing the SIM ................4

Fitting/Removing the Battery ..............5

Charging the Battery ..................6

Low Battery Warning ..................6

Location of Controls ...................7

Display..........................8

Basic Operation .....................9

Power On/Off ......................

Making a Call ......................

Automatic Redial ....................10

Ending a Call ......................10

Answering a Call ....................10

Volume Control.....................11

Vibration Alert .....................12

Key Guard .......................12

Phone Clock ......................13

Calculator .......................15

Currency Convertor ..................16

Phone Security .....................17

Phone Lock ......................17

PIN...........................18

Changing Security Codes ...............18

Advanced Operation ..................19

Desktop Handsfree...................1

DTMF Tones ......................1

Alert Profile.......................20

Call Hold and Call Waiting ...............21

Call Transfer ......................22

Multi-party Calls ....................22

Phonebook Basics ...................24

Storing a Number ...................24

Browsing Phonebooks by Name or Location .....25

Retrieving a Number ..................25

Editing Phonebook Entries ...............26

Hot Key Phone Numbers................26

Advanced Phonebook .................27

Note Pad ........................27

Recent Numbers ....................27

Fixed Dial .......................28

Service Dial ......................2

Short Text Messages ..................30

Setting your Phone for Short Text Messages .......30

Sending a Short Text Message ............30

Using Pre-Defined Messages .............31

Receiving Short Text Messages ............32

Cell Broadcasts ....................32

Alpha Entry .......................34

Menu Structures.....................35

Key Guard .......................35

Phonebook .......................35

Messages .......................36

Applications ......................37

Personalise.......................37

Call Service ......................38

Call Divert .......................3

Security ........................40

Network ........................40

Care and Maintenance .................42

Glossary of Terms ...................43

Trouble Shooting ....................45

Important Error Messages ...............48

Specifications ......................49

EU Warranty .......................50

Notes...........................57

Introduction

Thank you for purchasing this Panasonic GD50 digital cellular

phone. This phone is designed to operate on the Global System

for Mobile Communications (GSM), GSM 00 or GSM1800.

These operating instructions detail use of the equipment

contained in the Main Kit.

Some services are network dependent or may only be available

on a subscription basis. Some functions are SIM dependent.

For more information contact your Service Provider.

Symbols Used

FShows that you should press the following key(s).

,Text-Shows that the display text will be flashing.

Shows that the information is a Quick Tip.

Using This Manual

This manual is designed in sections to guide you through the

many functions of this phone. Listed below is a brief outline of

each section, to help you find the information you need.

Getting Started: Details how to fit the battery, insert the SIM

card, introduces the controls and display of the phone.

Basic Operation: Details how to make and receive calls,

change the phone volume, use Vibration Alert and Key Guard

the Clock/Alarm, Calculator/Currency Convertor.

Phone Security: Details how to use the Phone Lock and PIN

Security features as well as how to change security codes.

Advanced Operation: Details how to use the phone’s Desktop

Handsfree, send DTMF tones, create Alert Profiles, use Call

Waiting, Call Transfer and Multi-party.

Phonebook Basics: Details how to create, store, retrieve, and

browse a number in a Phonebook as well as the more

advanced Phonebook features.

Advanced Phonebook: Details the operation of the Note Pad,

Recent Number recall and limiting the numbers available using

Fixed Dialling.

Introduction

Short Text Messages: Details how to set up your phone to

receive and send Short Text Messages and to receive Cell

Broadcasts.

Alpha Entry: Details how to access alternative characters with

the keypad.

Menu Structures: Details the features that can be accessed

from the phone menu.

The remaining sections details how to take care of your phone,

lists terms used in this manual, a Troubleshooting and Error

Message section and the Specifications.

Introduction

Safety

This equipment is intended for use when supplied

with power from the built-in charger or Dual Charger

(EB-CRD30) through the AC Adaptor

(EB-CAD70Vxx)*. Other usage will invalidate any

approval given to this apparatus and may be

dangerous. The use of approved accessories is

recommended to ensure optimum performance and

avoid damage to your phone.

Switch off your cellular phone when in an aircraft. The

use of cellular phones in an aircraft may be

dangerous to the operation of the aircraft, disrupt the

cellular network and may be illegal. Failure to observe

this instruction may lead to the suspension or denial

of cellular phone services to the offender, or legal

action or both.

You are advised not to use the equipment at a

refueling point. You are reminded of the need to

observe restrictions on the use of radio equipment in

fuel depots, chemical plants or where blasting

operations are in progress. Never expose the battery

pack to extreme temperatures (in excess of 60°C) or

charge the battery pack for much longer than

recommended.

You MUST exercise proper control of your vehicle at

all times. Do not use a hand held phone or

microphone while you are driving. Find a safe place to

stop first. Do not speak into a hands free microphone

if it will take your mind off the road. Acquaint yourself

thoroughly with restrictions concerning the use of

cellular phones within the country you are driving and

observe them at all times.

Care must be taken when using the phone in close

proximity to personal medical devices, such as

pacemakers and hearing aids.

* Where xx identifies the specific AC Adaptor region, eg CN, EU, HK, TW, UK.

Safety

Getting Started

Fitting/Removing the SIM

The SIM is fitted into a holder at the back of the phone

underneath the battery.

Fitting the SIM

Removing the SIM

To remove the SIM follow the above steps in reverse.

Getting Started

Fitting/Removing the Battery

Fit a fully charged battery pack. If the battery pack is not fully

charged then it must be charged as shown in “Charging the

Battery”.

Fitting the Battery

Removing the Battery

Getting Started

Charging the Battery

The battery pack must be attached to the phone before the AC

Adaptor.

DO NOT force the connector as this may damage the phone and/or

the AC Adaptor.

When charging is complete remove the AC Adaptor.

NOTE: If the Battery Pack is deeply discharged, the phone may

take some time to detect which type of Battery Pack it is

charging. During this period leave the phone connected to the

charger until the charge LED and Battery Level Indicator

appears and charging is complete.

To maintain maximum performance of Ni-MH Battery Packs

always use until the Low Battery Warning and then fully recharge.

Operation of Battery Level Indicator

While charging Charging complete

Telephone on KH

Telephone off KIndicator off

Low Battery Warning

When the battery power is low a warning tone

will sound and a LOW BATTERY message will

flash. The power will automatically shut off

shortly after the warning tone. Fully charge the

battery pack or replace it with a fully charged

one. During conversation finish your call immediately.

Getting Started

ABCDEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

ABCDEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

LOW

BATTERY
