Panasonic HDVC-MPCS Manuale utente

Expandable to a

Maximum of 16 Sites

Choose the conference mode that matches the conditions.

Allows you to hold a meeting by

simply selecting a preset group of

sites.

Allows you to hold a meeting by

freely selecting the sites you want

at that moment.

Group A Group B

HD Videoconferences

Select from Two Conference Modes

(Normal Mode or Ad-Hoc Mode)

Content

Sharing

Clear, easy-to-see HD images show

even the fine facial expressions of the

other party. Regardless of how distant

the sites are, you can communicate

almost as if you were in the same room.

You can easily share PC

content, such as graphics

and PowerPoint materials,

for smooth meetings.

Videoconferences can be conducted

simultaneously at up to 16 sites.

The system can be

expanded from 8 to 12 sites,

and from 12 to 16 sites.

Normal Mode Ad-Hoc Mode

HD Visual

Communications System

HDVC-MPCS

Item Specification Item

Up to 16 sites*1

(depending on the number of the license ports)

Conference Modes Normal mode, Ad-Hoc mode

1 conference

No. of Simultaneous Conferences

Number of Sites in Conference

2.0 Mbps (IP rate)

1920 Kbps (Video IP rate)

80 Kbps (Audio IP rate)

Maximum Bandwidth

Call

Control

Standard

Connection Method

SIP(UDP)

Dial-in

Dial-out based on Web operation

Video

Reception

Capacity Profile

Profile

No. of Screen

Windows

CPn

Codec Profile

H.264 Baseline Profile Level 3.1

720p (1280 x 720)*2

4SIF (704 x 480)

VGA

SVGA

XGA

H.264 Baseline Profile Level 1.3 to 3.1

CP1, CP4 , CP6, CP8 , CP10, CP13 , CP16

G.722

Japanese, English

Configuration

Data Backup

Address Book

Log

Operation

Settings,

Management

Basic Device Settings

Meeting Room Management

(Status Display, Profile Settings)

Meeting Mode Settings

Meeting Start (Dial-Out Transmission)/End

Layout Control

Display Position Control

Mute Control

Log Acquisition/Display

Max. 200 addresses

Backup*3/Restore Function

Specification

Transmission

Capacity

Video

Resolution

PC Resolution

Window

Screen

Audio

Language

Web

User Interface

Choose

the optimal

display from

seven patterns.

Auto

Layout Change

Manual

Layout Change

Fixed Layout

Voice Switching

Versatile Screen Layouts Match Your Situation

Choose the Site Number

You Want, and Expand

It After Purchasing

6Sites

Sites

8Sites

No. of Sites

Dial In/Dial Out Address Book Function

Window

Screen

Window

Screen

Window

Screen

Window

Screen

Window

Screen

Window

Screen

You can choose the number of sites you want

6, 8,

12, or 16. And you can expand from 8 sites to 12 sites,

or from 12 sites to 16 sites.*

Connect by dialling in from a terminal, or dialling out from the server. Register up to 200 addresses.

* When a 6-site system has been purchased, the number of sites cannot

be increased.

• Cannot be used together with the NAT Traversal Service.

• Connection is not possible with an other-brand device or an MCU.

Connectable with the KX-VC600, KX-VC300, and KX-VC500. The KX-VC500 requires software version

2.20 or newer, and the AV communication protocol expansion must be activated. To activate the

AV communication protocol expansion, you need to purchase an AV Communication Protocol

Expansion Activation Key Card (KX-VCS101) and register for a license.

*2 Maximum resolution and frame rate are 720/30p.

*3 Data that has been backed up cannot be edited.

Site

Expansion

Specification

The screen layout automatically changes according to the number of

HD Visual Communications Systems participating.

Change the layout manually while the meeting proceeds.

Determine the screen layout based on ones that you have set in advance.

Display the participating device with the highest sound volume as Priority 1

(upper left screen).

• Specifications are subject to change without notice.

(MG-HDCL004EN)

DISTRIBUTED BY :

HDVC-MPCS:

http://panasonic.net/psn/products/hdvc/product/mpcs/index.html
