Panasonic CF-W2 Series Manuale utente

Personal Computer

Reference Manual

Model No. CF-W2 Series

XP For backup proposes Panasonic recommends that this Reference

Manual be printed.

To magnify the screen

display of this

Reference Manual

To magnify the icon

display (for example, )

etc.

Read Me First

zSome of the illustrations in this manual may differ slightly in shape from the actual items

on your computer. This should make the explanations easier to understand

zIf a user has logged on to Windows without the administrator authority, some functions

may not be executable, and some screens may not be displayed as shown in this manual.

If this happens, log-on to Windows with the administrator authority to enable these

functions

zIn this manual, “Microsoft®Windows®XP Professional” is indicated as “Windows” or

“Windows XP”

zIn this manual, the following software packages are described as follows:

• "WinDVD™ 5 (OEM Version)" as "WinDVD"

• "B's Recorder GOLD7 BASIC" as "B's Recorder"

• "B's CLiP 5" as "B's CLiP"

zCircular media such as DVD-ROM and CD-ROM is described as a "disk"

zIf the icon on the notification area (A) being explained in this manual is hidden and not

displayed, click on the icon to display all icons

(The icons on the notification area used in this manual are only examples. They may

differ from the actual icons shown.)

zOptional Products or Accessories

Confirm the latest information on optional products or accessories from various sources

Read Me First

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in minor

or moderate injury.

Enter

This illustration means to press the

Enter

key.

This illustration means to press and hold the

key,

then press the

key.

When using with the

and

Ctrl

key functions

interchanged, read with

and

Ctrl

reversed.

[start] - [Run] This illustration means to click [start], then to click [Run].

For some applications, you may need to double-click.

Îor ⇒These symbols indicate related pages.

Î:If this is clicked, it will jump to the page correspond-

ing Reference Manual

⇒:Refer to the Operating Instructions

xxxx*1 If *1 is clicked, it will jump to a related topic.

Read Me First

The terminology in ( ) is the one used in [Intel(R) 82852/82855 GM/GME Graphics Controller

Properties].

To display [Intel(R) 82852/82855 GM/GME Graphics Controller Properties]:

Click [start] - [Control Panel], from the [See Also] area click [Other Control Panel Options],

and then click [Intel(R) Extreme Graphics].

About Display Mode

Internal LCD (Notebook) This computer's display

External Display (Monitor) External display connected to this computer

Simultaneous Display

(Intel(R) Dual Display Clone)

To display the same screen on both the LCD and

external display

Extended Desktop To use both the internal LCD and the external display as

an extended display domain. You can drag a window

between the internal LCD and the external displays

How to Use this Reference Manual

In this Reference Manual, you can use the following method to display the desired page, or

search for a page using a text string. (The screen shown is only an example.)

If the bottom of the screen is hidden at the notification area, expand the window to its

maximum size.

How to Use this Reference Manual

If the characters, icons, etc. in the Reference Manual are too small

and too difficult to see, you can magnify them as follows.

1Click to use Zoom In Tools.

2To magnify the display and make it easier to see, position

the cursor and click on the segment you want to expand.

zIf it is magnified too much, click on the same segment while

holding down the

Ctrl

key to reduce the size.

3When required, click on and drag it to the screen to

display the segment you want to see.

This Reference Manual is displayed using Acrobat®Reader. Acrobat®Reader uses the

following methods to magnify and reduce the display size.

zTools for magnifying/reducing the display

A. Zoom In Tool: Click to enlarge the display in the area around the position that was

clicked. Drag to magnify the display in the area selected.

B. Zoom Out: Display size is reduced each time this button is clicked.

C. Enter the percentage for magnification/reduction, and press the

Enter

key to

change the display to the specified size.

D. Zoom In: Display size is magnified each time this button is clicked.

Magnify this Reference Manual Display

How to Use this Reference Manual

zTools for displaying contents at a selected magnification

E. Actual Size: Click to display contents at the size used when the Reference

Manual is opened from the [start] menu.

F. Fit In Window: Click to display the contents for a single page.

G. Fit Width: Click to magnify or reduce the size of the display to match the width of

the screen.

NOTE

zA printer (sold separately) is required to print out this Reference Manual

zDepending on the printer, the illustrations and screen samples may not be printed

clearly

1Confirm the page to be printed.

zTo print out only the page currently being displayed: Leave that page on the

display

zTo print out a specified page: Confirm the page number

2Click on .

3Set [Name], [Paper], and other settings, and click [OK].

zIf the page is printed with a different orientation: Remove the check mark from

[Auto-rotate and center pages]

Print this Reference Manual

Using the Touch Pad

Use the touch pad to move the cursor on the screen and perform computer operations.

A. Work Surface (touch pad)

B. Left Button

C. Right Button

Function Operation

Moving the Cursor

Move the tip of your finger lightly over the work

surface.

Tapping/Clicking

tapping or clicking

zTo right-click: Can only be performed by clicking the right

button.

Double-Tapping/Double-

Clicking

double-tapping or double-clicking

Dragging

Two quick taps, but on the second tap leaving your finger

down (applying pressure) and moving it on the work surface.

While holding down the button, moving your finger on the work

surface.

Scroll Trace a circle around the touch pad. (Îpage 9)

Using the Touch Pad

NOTE

zYou can change the speed of the double-click or the operations of mouse buttons

using [Mouse Properties] screen

To display [Mouse Properties]:

Click [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse]

zSensitivity when touching the touch pad can be adjusted (Îpage 14)

zWhen an external mouse is connected and the cursor does not operate properly:

In the [Main] menu of the Setup Utility, set [Touch Pad] to [Disable]. When you want to

use the touch pad again, return the setting to [Enable] (Îpage 120)

You can scroll easily by tracing a circle around the touch pad.

NOTE

zThis scroll function is operated using the Touch Pad utility

zWhen the external mouse driver is installed, the scroll function may not operate prop-

erly

1Select the screen you want to scroll.

2Position the cursor over the area you want to scroll.

Scroll

Using the Touch Pad

3Lift up your finger, and place it in the area around the Touch Pad

( position in the figure).

When you touch the scroll startup area on the touch pad, the icon on the notifica-

tion area will change to the icon.

4Trace a circle around the edge of the touch pad as indicated in the

diagrams.

To scroll down (trace clockwise)

The Scroll Icon will rotate.

To scroll up (trace counter-clockwise)

Scrolling will begin more easily if you start from the position marked by and trace

as indicated by the arrow.

zOn screens that cannot be scrolled (e.g., desktop screen), if you scroll, the

computer may try to scroll the screen, causing the cursor to freeze. If this

happens, remove your finger from the touch pad and begin again, this time

starting from the center of the touch pad

5Once scrolling has begun, continue to trace a circle on the touch pad

without removing your finger from the pad.

zAs long as you are tracing a circle, you can continue scrolling using any position

on the touch pad. It is not necessary to trace a circle around the edge of the pad

zTo scroll in the opposite direction, trace a circle in the opposite direction without

removing your finger from the touch pad

6When you finish scrolling, remove your finger from the touch pad.
