Basic Owner’s Manual

Digital Camera

Model No. DMC-SZ7

Before connecting, operating or adjusting this product,

please read the instructions completely.

More detailed instructions on the

operation of this camera are

contained in “Owner’s Manual for

advanced features (PDF format)” in the supplied

CD-ROM. Install it on your PC to read it.

VQT3Y79

F1211MR0

For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,

until

2012/01/13

DMC-SZ7P-VQT3Y79_eng.book 1 ページ２０１１年１２月２０日　火曜日　午後８時１０分

VQT3Y79 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products on the market

today. Used properly, we’re sure it will bring you and your family years of enjoyment.

Please take time to fill in the information on the below. The serial number is on the tag

located on the underside of your camera. Be sure to retain this manual as your

convenient camera information source.

Please note that the actual controls and components, menu items, etc. of your Digital

Camera may look somewhat different from those shown in the illustrations in this

Owner’s Manual.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast material for

purposes other than your own private use may infringe copyright laws. Even for the purpose

of private use, recording of certain material may be restricted.

-If you see this symbol-

A lithium ion battery that is recyclable powers the product you have

purchased. Please call 1-800-8-BATTERY for information on how

to recycle this battery.

Information on Disposal in other Countries outside the

European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local

authorities or dealer and ask for the correct method of disposal.

Date of Purchase

Dealer Purchased From

Dealer Address

Dealer Phone No.

Model No.

Serial No.

DMC-SZ7P-VQT3Y79_eng.book 2 ページ２０１１年１２月２０日　火曜日　午後８時１０分

(ENG) VQT3Y79

Information for Your Safety

∫Product identification marking

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Do not place objects filled with liquids, such as vases, on this unit.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified service personnel.

The socket outlet shall be installed near the equipment and shall be easily

accessible.

Product Location

Digital Camera Bottom

DMC-SZ7P-VQT3Y79_eng.book 3 ページ２０１１年１２月２０日　火曜日　午後８時１０分

VQT3Y79 (ENG)

FCC Note:

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, follow the attached installation

instructions and use only shielded interface cables with ferrite core when connecting

to computer or peripheral devices.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

Declaration of Conformity

Trade Name: Panasonic

Model No.: DMC-SZ7

Responsible Party: Panasonic Corporation of North America

One Panasonic Way, Secaucus, NJ 07094

Support Contact: Panasonic Consumer Marketing Company of North America

1-800-211-PANA (7262)

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

DMC-SZ7

DMC-SZ7P-VQT3Y79_eng.book 4 ページ２０１１年１２月２０日　火曜日　午後８時１０分

(ENG) VQT3Y79

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with

doors and windows closed.

CAUTION

Battery pack (Lithium ion battery pack)

•Use the specified unit to recharge the battery pack.

•Do not use the battery pack with equipment other than the specified unit.

•Do not get dirt, sand, liquids, or other foreign matter on the terminals.

•Do not touch the plug terminals (iand j) with metal objects.

•Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes, wash it off

thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse

eyes thoroughly with water, and then consult a doctor.

CAUTION

•Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

•When disposing the batteries, please contact your local authorities or dealer and ask for

the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC (140 oF) or

incinerate.

DMC-SZ7P-VQT3Y79_eng.book 5 ページ２０１１年１２月２０日　火曜日　午後８時１０分

VQT3Y79 (ENG)

∫About the AC adaptor (supplied)

∫Cautions for Use

•Do not use any other USB connection cables except the supplied one.

•Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

•Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30: optional).

Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet)

Keep this unit as far away as possible from electromagnetic equipment (such as

microwave ovens, TVs, video games etc.).

•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be

disrupted by electromagnetic wave radiation.

•Do not use this unit near cell phones because doing so may result in noise adversely

affecting the pictures and/or sound.

•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields

created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,

disturbing the pictures and/or sound.

•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,

turn this unit off and remove the battery or disconnect AC adaptor (supplied). Then reinsert

the battery or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound

may be adversely affected.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

•Do not obstruct this unit’s ventilation openings with newspapers, tablecloths,

curtains, and similar items.

•Do not place sources of naked flames, such as lighted candles, on this unit.

AC adaptor

This AC adaptor operates on AC between 110 V and 240 V.

But

•In the U.S.A. and Canada, the AC adaptor must be connected to a 120 V AC power

supply only.

•When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to

suit the AC outlet configuration.

Information about the software used by this product can be viewed by pressing

[MENU/SET], selecting [Setup] >[Version Disp.], and then pressing [MENU/SET].

DMC-SZ7P-VQT3Y79_eng.book 6 ページ２０１１年１２月２０日　火曜日　午後８時１０分

(ENG) VQT3Y79

Contents

Information for Your Safety......................................................................................... 3

Before Use .................................................................................................................... 7

Standard Accessories ................................................................................................. 8

Names and Functions of Main Parts .......................................................................... 9

Inserting and Removing the Card (optional)/the Battery ....................................... 10

Charging the Battery.................................................................................................. 11

Sequence of operations ............................................................................................ 12

Reading the Owner’s Manual (PDF format) ............................................................. 13

Installing supplied software...................................................................................... 14

Specifications............................................................................................................. 15

Digital Camera Accessory System........................................................................... 17

Digital Camera Accessory Order Form.................................................................... 18

Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO) ................................... 19

Before Use

∫Care of the camera

•Do not subject to strong vibration, shock, or pressure.

•This camera is not dust/splash/water proof.

Avoid using the camera in places with a lot of dust, water, sand, etc.

∫About Condensation (When the lens is fogged up)

•Condensation occurs when the ambient temperature or humidity changes. Be careful of

condensation since it causes lens stains, fungus and camera malfunction.

•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will

disappear naturally when the temperature of the camera becomes close to the ambient

temperature.

DMC-SZ7P-VQT3Y79_eng.book 7 ページ２０１１年１２月２０日　火曜日　午後８時１０分

VQT3Y79 (ENG)

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of January 2012. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or battery

in the text)

Charge the battery before use.

2 AC Adaptor

Can be used for charging and

playback.

3 USB Connection Cable

4 CD-ROM

•Software

•Owner’s Manual for advanced features

Install on your PC before use.

5 Hand Strap

•SD Memory Card, SDHC Memory Card and

SDXC Memory Card are indicated as card in

the text.

•The card is optional.

You can record or play back pictures on

the built-in memory when you are not

using a card.

•For information about optional accessories,

refer to the “Digital Camera Accessory

System”.

•If any accessories are lost, customers should

contact Panasonic’s parts department at

1-800-833-9626 for further information about

obtaining replacement parts.

VFC4297

VFF0932K1HY08YY0025

DMW-BCK7PP VSK0768

DMC-SZ7P-VQT3Y79_eng.book 8 ページ２０１１年１２月２０日　火曜日　午後８時１０分

(ENG) VQT3Y79

Names and Functions of Main Parts

1 Motion picture button

2 Shutter button

3 Camera ON/OFF switch

4Flash

5 Microphone

6 Speaker

•Be careful not to cover the speaker

with your finger. Doing so may make

sound difficult to hear.

7 Zoom lever

8Lens

9 Lens barrel

10 Self-timer indicator

AF Assist Lamp

11 LCD monitor

12 [MODE] button

13 Charging lamp

14 REC/PLAY switch

15 Strap eyelet

•Be sure to attach the strap when

using the camera to ensure that you

will not drop it.

16 Cursor buttons

17 [DISP.] button

18 [MENU/SET] button

19 [Q.MENU]/[ ] (Delete/Cancel)

button

20 [HDMI] socket

21 [AV OUT/DIGITAL] socket

22 Tripod receptacle

23 Card/Battery door

24 Release lever





789

1916 17

23 6

54 14 1511

22 23

12 13

18 20

DMC-SZ7P-VQT3Y79_eng.book 9 ページ２０１１年１２月２０日　火曜日　午後８時１０分

VQT3Y79 (ENG)

Inserting and Removing the Card

(optional)/the Battery

•Check that this unit is turned off.

•We recommend using a Panasonic card.

Slide the release lever in the direction

of the arrow and open the card/battery

door.

•Always use genuine Panasonic batteries

(DMW-BCK7PP).

•If you use other batteries, we cannot

guarantee the quality of this product.

Battery: Being careful about the

battery orientation, insert all the way

until you hear a locking sound and

then check that it is locked by lever A.

Pull the lever Ain the direction of the

arrow to remove the battery.

Card: Push it securely all the way until

you hear a “click” while being careful

about the direction in which you insert

it.

To remove the card, push the card until it clicks, then pull the

card out upright.

B: Do not touch the connection terminals of the card.

1:Close the card/battery door.

2:Slide the release lever in the

direction of the arrow.

Note

•Keep the Memory Card out of reach of children to prevent

swallowing.

DMC-SZ7P-VQT3Y79_eng.book 10 ページ２０１１年１２月２０日　火曜日　午後８時１０分

Altri manuali per DMC-SZ7K

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Macchina fotografica digitale

Panasonic

Panasonic Lumix DMC-ZS10 Manuale utente

Panasonic

Panasonic Lumix DMC-TS4 Manuale utente

Panasonic

Panasonic Lumix DMC-FX30P Manuale utente

Panasonic

Panasonic DMC-L1K - Lumix Digital Camera SLR Manuale utente

Panasonic

Panasonic GPUS522H - COLOR CAMERA Manuale utente

Panasonic

Panasonic Lumix DC-TS7 Manuale utente

Panasonic

Panasonic Lumix DMC-GF7K Manuale utente

Panasonic

Panasonic AG-FC100 Manuale per l'uso e la cura

Panasonic

Panasonic Lumix DMC-LZ20 Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic Lumix DMC-XS3 Specifiche tecniche

Panasonic

Panasonic DMC-FX90K Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic Lumix DMC-LX100 Specifiche tecniche

Panasonic

Panasonic LUMIX DMC-F1PP Manuale utente

Panasonic

Panasonic Lumix DC-G9 Specifiche tecniche

Panasonic

Panasonic Lumix DMC-ZS35 Manuale utente

Panasonic

Panasonic Lumix DMC-ZS9 Manuale utente

Panasonic

Panasonic Lumix DMC-SZ1 Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic LUMIX DMC-FX66 Specifiche tecniche

Panasonic

Panasonic Lumix DMC-LC1 Manuale utente

Panasonic

Panasonic WV-BWC4000 Manuale operativo

Panasonic

Panasonic Lumix DMC-G85MK Manuale utente

Panasonic

Panasonic Lumix DMC-GM1SK Manuale utente

Panasonic

Panasonic LUMIX DMC-FZ100 Manuale utente

Panasonic

Panasonic Lumix DMC-FH6P Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
