VQT5E66

M0214KZ0

Basic Operating Instructions

Digital Camera

Model No. DMC-TZ60/DMC-ZS40

Please read these instructions carefully before using this product, and

save this manual for future use.

More detailed instructions on the operation of this camera

are contained in “Operating Instructions for advanced

features (PDF format)” in the supplied CD-ROM. Install it on

your PC to read it.

GA GH

2 VQT5E66 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic

Digital Camera. Please read these Operating Instructions carefully and keep

them handy for future reference. Please note that the actual controls and

components, menu items, etc. of your Digital Camera may look somewhat

different from those shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may

be restricted.

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or

splashing.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to

qualified service personnel.

The socket outlet shall be installed near the equipment and shall be

easily accessible.

■Product identification marking

Product Location

Digital camera Bottom

(ENG) VQT5E66 3

■About the battery pack

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace

only with the type recommended by the manufacturer.

• When disposing of the batteries, please contact your local

authorities or dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a

long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 °C or incinerate.

■About the AC adaptor (supplied)

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

• The unit is in the standby condition when the AC adaptor is connected. The

primary circuit is always “live” as long as the AC adaptor is connected to an

electrical outlet.

4 VQT5E66 (ENG)

■Cautions for Use

• Do not use any other USB connection cables except the supplied one or a

genuine Panasonic USB connection cable (DMW-USBC1: optional).

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

• Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not

comply with the HDMI standards will not work.

“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m long)

Keep this unit as far away as possible from electromagnetic equipment

(such as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this

unit may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation may adversely affect this unit, disturbing the

pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn

this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded

pictures and/or sound may be adversely affected.

(ENG) VQT5E66 5

For Singapore only

Complies with

IDA Standards

DB01017

For India only

The specifications are exempted for any licensing requirement by

Ministry of Communications and Information Technology, G.S.R. 45

(E)., dated 28th January, 2005.

-If you see this symbol-

Information on Disposal in other Countries

outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact

your local authorities or dealer and ask for the correct

method of disposal.

6 VQT5E66 (ENG)

Contents

Information for Your Safety .... 2

Before use................................ 7

Standard accessories ............. 8

Names and Functions of

Main Parts ................................ 9

Inserting and removing the

battery or SD memory card

(optional) ................................ 12

Charging the battery ............. 13

Setting the clock.................... 15

Setting the menu ................... 17

Taking pictures with

automatic settings

[Intelligent Auto] Mode.......... 18

Recording motion pictures... 21

Using the control ring/

control dial ............................. 23

Registering preferred

functions to the

[Fn] button.............................. 25

Taking pictures with the

composition determined

[Composition Guide]............. 25

Viewing your pictures ........... 26

Deleting pictures ................... 26

What you can do with the

Wi-Fi®function....................... 27

GPS functions........................ 29

Reading the Operating

Instructions (PDF format) ..... 30

Supplied software.................. 31

Copying still pictures and

motion pictures...................... 32

Troubleshooting .................... 33

Specifications ........................ 35

(ENG) VQT5E66 7

Before use

■Camera handling

●Keep the camera away from excessive vibration, force, or pressure.

●The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or where

water can come into contact with the camera.

●Do not allow camera to come into contact with pesticides or volatile

substances (can cause surface damage or coating to peel).

■

Condensation (When the lens, the LCD monitor or the viewfinder is fogged up)

●

Condensation may occur when the camera is exposed to sudden changes of

temperature or humidity. Avoid these conditions, which may make the lens,

the LCD monitor or the viewfinder dirty, cause mould, or damage the camera.

●If condensation does occur, turn off the camera and wait about two hours

before using it. Once the camera adjusts to the surrounding temperature,

the fogging will clear naturally.

■Caring for your camera

●Before cleaning the camera, remove the battery or disconnect the power

plug from the outlet.

●Do not press the LCD monitor with excessive force.

●Do not press the lens with excessive force.

●Do not keep rubber or plastic products in contact with the camera for a long

period of time.

●Do not use solvents such as benzine, thinner, alcohol, kitchen detergents,

etc., to clean the camera, since it may deteriorate the external case or the

coating may peel off.

●Do not leave the camera with the lens facing the sun, as rays of light from

the sun may cause it to malfunction.

●Do not extend the supplied cord or cable.

●While the camera is accessing the card or built-in memory (for an operation

such as picture writing, reading, deleting, or formatting), do not turn off the

camera or remove the battery, card, AC adaptor (supplied).

●The data on the built-in memory or the card may be damaged or lost due to

electromagnetic waves, static electricity or breakdown of the camera or the

card. We recommend storing important data on a PC etc.

●Do not format the card on your PC or other equipment. Format it on the

camera only to ensure proper operation.

8 VQT5E66 (ENG)

Standard accessories

Check that all the accessories are supplied before using the camera. Part

numbers are as of January 2014. These may be subject to change.

Battery pack

DMW-BCM13E

• Charge the battery

before use.

Battery pack is indicated as

battery pack or battery in the text.

AC adaptor

VSK0772

(DMC-TZ60GA)

VSK0775

(DMC-ZS40GH)

Hand strap

VFC4297

USB connection cable

K1HY08YY0031

CD-ROM

VFF1258

• Software:

Use it to install the software on

your PC.

• Operating Instructions for

advanced features

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are

indicated as card in the text.

• Cards are optional. You can record or play back pictures on the built-in

memory when you are not using a card.

•Compatible memory cards (optional)

The following SD standard-based cards (Panasonic brand recommended) can be used.

SD Memory Card (8 MB to 2 GB) / SDHC Memory Card (4 GB to 32 GB) /

SDXC Memory Card (48 GB, 64 GB)

• Consult the dealer or your nearest Service Centre if you lose the supplied

accessories. (You can purchase the accessories separately.)

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

• The illustrations and screens in this manual may differ from the actual product.

• SILKYPIX Developer Studio SE is not provided on the supplied CD-ROM.

Download this software from the website and install it on your computer to use. (→32)

(ENG) VQT5E66 9

Names and Functions of Main Parts

123 4 5678 11

910

24 25

(Top)

15 16 17 19

(Bottom)

21 22 23

14 2018

10 VQT5E66 (ENG)

Names and Functions of Main Parts

1 Flash

2 Self-timer indicator/

AF Assist Lamp

3 Control ring

4 Lens barrel

5 Lens

• Do not touch the lens barrier.

6 Viewfinder (LVF)

7 Diopter adjustment dial

• Adjusts the focus in the viewfinder.

8 [LVF] button

• Use this to switch display between

viewfinder and LCD monitor.

9 LCD Monitor

10 Charging lamp (Red)/

Wi-Fi®connection lamp (Blue)/

GPS status indicator (Green)

• The colour of the lamp differs

depending on the function.

11 Strap eyelet

• We recommend using the supplied

hand strap to avoid dropping the

camera.

12 [HDMI] socket

• Do not connect any other cables

except the HDMI micro cable. Doing

so may cause malfunction.

13 [AV OUT/DIGITAL] socket

• This socket is also used when

charging the battery.

14 Speaker

15 Microphones

16 Mode dial

• Use this to select the recording mode.

17 Shutter button

18 Zoom lever

19 Motion picture button

20 Camera [ON/OFF] button

21 Tripod mount

• Do not attach to a tripod with a

5.5 mm or longer screw. Doing so

may damage this unit.

• If you are not holding the camera,

for example when using self-timer

recording or remote recording, the

camera could tilt when the lens barrel

extends during zooming, so make

sure to secure the camera in place

with a tripod or by other means.

• It may not be possible to attach

certain types of tripods properly.

22 Card/Battery door

23 Release lever

24 [Wi-Fi] antenna

25 GPS antenna

26 NFC antenna

27 [Wi-Fi] button

28 Playback button

• Use this to select the recording mode

or playback mode.

29 [MENU/SET] button

30 [Q.MENU/ ] / [ ] button

• You can display the Quick Menu and

erase pictures.

31 [DISP.] button

• Use this to change display.

32 Control dial

• Turn the dial to select setting items

and change setting values.

33 [Fn] button

34 Cursor button

Altri manuali per Lumix DMC-TZ60

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Macchina fotografica digitale

Panasonic

Panasonic Lumix DMC-FX55 Manuale utente

Panasonic

Panasonic Lumix DMC-FZ8 Manuale utente

Panasonic

Panasonic DMC-GF5XR Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic Lumix DMC-LC1PP Manuale utente

Panasonic

Panasonic Lumix DC-ZS80D Manuale utente

Panasonic

Panasonic Lumix DMC-ZS6 Manuale utente

Panasonic

Panasonic DCGH5SGNK Specifiche tecniche

Panasonic

Panasonic Lumix DMC-SZ10 Specifiche tecniche

Panasonic

Panasonic Lumix S1R Manuale utente

Panasonic

Panasonic HX-DC1P Manuale utente

Panasonic

Panasonic Lumix DMC-FZ50PP Manuale utente

Panasonic

Panasonic KX-TGA593AL Manuale utente

Panasonic

Panasonic LUMIX DMC-FZ28 Specifiche tecniche

Panasonic

Panasonic DMC-FH6K Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic Lumix DMC-GF3 Manuale utente

Panasonic

Panasonic NV-DCF3 Series Manuale utente

Panasonic

Panasonic DMC-TZ81 Manuale utente

Panasonic

Panasonic Lumix DMC-FP3 Specifiche tecniche

Panasonic

Panasonic LUMIX DMC-GM1K Istruzioni per l'installazione e la manutenzione

Panasonic

Panasonic LUMIX DMC-FX38 Manuale utente

Panasonic

Panasonic LUMIX DMC-FZ18 Manuale utente

Panasonic

Panasonic Lumix FZ300K Manuale utente

Panasonic

Panasonic Lumix DMC-LZ30 Manuale utente

Panasonic

Panasonic Lumix S1H Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
