Panasonic Diga DMR-ES35V Manuale utente

VHS DVD

COPYING

VHS DVD

COPYING

DVD VHS

DVDVHS

COPYINGCOPYING

DMR-ES35V

Connect and set as shown overleaf.

Let’s begin!

Play

1Display the title

view.

Select,

play

(_Information_)

• To play DVD-R, DVD-R DL, DVD-RW,

+R, +R DL on other equipment

Finalize them on this unit ﬁrst

(“Please read”)

2Start playing.

Record

1Select the channel.

2Select the recording

mode.

3Start recording.

Discs you can record on

Repeated

recording 

Copy-once

recording

(digital broadcasts)



(CPRM compatible

discs only)



Playing

on other

equipment



(DVD-RAM compatible

equipment only)



* You can record onto the second layer of dual- or double-layer discs after closing the ﬁrst layer.

Please read

To play on other equipment,

Use the Finalize feature!

DVD-R, etc. recorded on this unit cannot be played on other players immediately after recording. Using the

Finalize feature allows you to play these discs on other players. (However, once the disc is ﬁnalized you will no

longer be able to record to the disc.)

Preparation: Select DVD side with pressing [DRIVE SELECT].

Insert the disc you want to ﬁnalize and stop play.

1Display the Functions screen.

• Finalizing takes up to 15 minutes.

(Do not disconnect the AC mains lead while ﬁnalizing!)

2Display the Finalize screen.

3Follow the on-screen instructions to start

ﬁnalizing.

Select,

set

FUNCTIONS Not Finalized Disc

ENTER

RETURN

DVD-R

Recording

Copy

ToOthers

Delete

Playback

Titles 7

DVD

MANAGEMENT

Disc Name

Finalize

Used Time

0 : 58

Remain

0 : 42 (SP)

Top Menu

Auto-Play Select

DVD-R

ENTER

FUNCTIONS Not Finalized Disc

ENTER

RETURN

DVD-R

ecor

thers

elet

Flexible Rec

DV Auto Rec

Setup

DVD Management

G-Code Record

SELECT

RETURN

To Others DVD Management Finalize

RQCAV0013-1

Before performing operations,

be sure to sele

ct drive .

Before performing operations,

be sure to sele

ct drive .

DVD

VHS

The VHS indicator

lights up on the unit.

The DVD indicator

lights up on the unit.

DRIVE

SELECT

DVD

VHS

DRIVE

SELECT

DVD

VHS

REC MODE

Remaining time on the disc

XP SP LP EP

SP EP VP

DVD

VHS

REC

Elapsed recording time

• To stop

STOP

Playing discs

ENTER

• To stop

STOP

Copy (One Touch Transfer)

While both DVD and VHS are stopped, press and

hold for about 3 seconds or more.

Main unit

DRIVE

SELECT

DVD

: Can do : Cannot do

SET UP GUIDE

DMR-ES35VGNSetupG.indd4-Sec1:1DMR-ES35VGNSetupG.indd4-Sec1:1 2006/03/3121:59:222006/03/3121:59:22

OUT

AC IN

AUDIO IN VIDEO

VHF/UHF

RF IN

DVD/VHS COMMON OUT

DVD PRIORITY OUT

R L

This unit

Audio/Video cable

(Included)

AC mains lead (Included)

coaxial

cable

(Included)

Cable from wall or

antenna signal

Aerial

leadl

124 3

Red White YellowRed White Yellow

Connection Setting

• Before doing any connection, turn off all equipment (refer to

the operating instructions of equipment for any operation).

• Other connections (when you also want to connect an

ampliﬁer, etc.).

Operating instructions (P. 12, 13).

Connecting a TV

Preparing TV

1 Switch on the TV.

2 Select the AV input on your TV.

e.g. the TV/VIDEO or INPUT button

On your TV’s

remote control

• To return to a

previous screen

3Turn this unit on.

4Select the country.

5Set the clock.

• If you make a mistake, press

RETURN.

6Select the type of TV you are using.

• Complete the settings.

DVD/VHS

Select,

set

Select,

set

Select,

set

DVD output and DVD/VHS output

The unit has DVD/VHS COMMON output terminals and DVD PRIORITY output terminals.

DVD/VHS COMMON OUT

For DVD/VHS COMMON output terminals, both DVD and VHS signals

can be output.

DVD PRIORITY OUT

You can also playback a tape with the DVD PRIORITY output terminals

except while recording, or making a timer recording, on the DVD.

DVD/VHS COMMON OUT

R-AUDIO-L VIDEO

S VIDEO

YPBPR

OPTICAL

DIGITALAUDIO OUT

(PCM/BITSTREAM)

R-AUDIO-L VIDEO

COMPONENT VIDEO OUT (NTSC:480p /480i PAL: 576p /576i)

DVD PRIORITY OUT

DVD/VHS COMMON output

DVD PRIORITY output

Next,

DMR-ES35VGNSetupG.inddSec1:2-Sec1:3DMR-ES35VGNSetupG.inddSec1:2-Sec1:3 2006/03/3121:59:552006/03/3121:59:55
