Panasonic Panafax UF-580 Manuale utente

Order Number: MGCS030801C1

H13

Facsimile

UF-580/590/780/790

a violation of law.

The contents of this Service Handbook are subject to change without notice.

Published in Japan.

Information regarding Lead-Free (PbF) solder;

Distinction of PbF PCB:

PCBs (manufactured) using lead free solder will have a mark following

the PCB part numbers in a label on the PCB.

Caution:

Pb free solder has a higher melting point than standard solder; typically

the melting point is 50 - 70 F (30 - 40 C) higher. Please use a soldering iron

with temperature control and adjust it to 700 20 F (370 10 C). Exercise care

while using higher temperature soldering irons, do not heat the PCB for too long

to prevent solder splash or damage to the PCB.

Pb free solder will tend to splash when heated too high (about 1100 F/600 C).

ECO SOLDER M705 (available from Senju Metal Industry Co., Ltd.;

URL: http://www.senju-m.co.jp) is recommended when repairing PbF PCBs.

This Product Uses Lead (Pb) Free Solder Printed Circuit

Boards (PCBs).

Table of Contents

Specifications Table ................................4

1.1. Fax Function .............................................4

1.2. Printer Function ......................................12

Maintenance, Adjustments and

Check Points ..........................................14

2.1. Required Tools .......................................14

2.2. Periodic Check Points.............................14

2.3. Periodic Maintenance Check List ...........15

2.4. Updating the Firmware ...........................16

Troubleshooting ....................................21

3.1. Information Codes Table

(For Facsimile)........................................21

Service Modes........................................26

4.1. Service Modes (For Facsimile) ...............26

Exploded View & Parts List .................. 73

5.1. Destination Codes ..................................73

5.2. Cover Assembly......................................74

5.3. Control Panel Unit...................................76

5.4. Transmitter Assembly .............................80

5.5. Electrical Parts........................................82

5.6. Base Unit ................................................84

5.7. Paper Tansportation ...............................86

5.8. Fuser Unit ...............................................88

5.9. Cassette..................................................90

5.10. Option Cassette

(Except UF-580/780) ..............................92

5.11. PC Board / Harness................................94

5.12. Packing and Accessories........................98

Alphanumerical Parts List .................. 102

1 Specifications Table

1.1. Fax Function

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

Main Specifications

1 Compatibility G3 ITU-T Std. & Non-Std.

(PCC)

2 PSTN Line Port Yes

3 Leased Line Port No

4 V.24 Line Port No

5 Modem Speed 33.6 - 2.4 kbps With Automatic Fallback

6 Coding Scheme MMR/MR/MH

7 ECM Yes Conforms to ITU-T

8 Short Protocol Yes (B, D)

9 Transmission Speed Approx. 3 sec ITU-T Image No. 1

(A4, Std. Resolution)

10 Communication Resolution

(pels / mm x lines / mm)

Transmission

Std 8 x 3.85

Fine 8 x 7.7

S-Fine 8 x 15.4

16 x 15.4*

Reception

Std 8 x 3.85

Fine 8 x 7.7

S-Fine 8 x 15.4

16 x 15.4

* Interpolated 16 pels/mm

Scanner Mechanism

1 Scanning Device CCD

2 Scanning Speed

Std. 2.8 sec Letter sized document

3.0 sec A4 sized document

Fine 5.0 sec Letter sized document

5.3 sec A4 sized document

S-Fine 10.1 sec Letter sized document

10.6 sec A4 sized document

3Scanning Resolution

(pel / mm x lines / mm)

Std. 8 x 3.85

Fine 8 x 7.7

S-Fine 8 x 15.4

16 x 15.4* * Interpolated 16 pels/mm

4 Document Size (Max.) 10.1 x 78.7 in

(257 x 2000 mm)

5 Document Size (Min.) 5.8 x 5.0 in

(148 x 128 mm)

6 Effective Scanning Width

8.3 in (212 mm) Letter size for USA and

Canada

8.2 in (208 mm) A4 size for Other

Destinations

7 Reduction XMT No

8 ADF Capacity

50 sheets*

*For USA and Canada only,

documents must be

inserted by staggered feed

(stairs-shape).

Face Down

A4 / Letter 0.0024”, 12 lb

(0.06 mm, 45 g/m2) to

0.0039”, 16 lb (0.10 mm, 60

g/m2)

Operating Environment

68°F (20°C), 50%RH

30 sheets*

*For Other Destinations.

Face Down

A4 / Letter 0.0024”, 12 lb

(0.06 mm, 45 g/m2) to

0.0039”, 16 lb (0.10 mm, 60

g/m2)

20 sheets

Face Down

A4 / Letter 0.0024”, 12 lb

(0.06 mm, 45 g/m2) to

0.0048”, 20 lb (0.12 mm, 75

g/m2)

9Collation Stack Yes (Face Down)

Printer Mechanism

1 Recording Method LP

2 Recording Speed 6.5 ppm Letter sized paper

6.2 ppm A4 sized paper

3 Recording Resolution

Copy, Fax 406 x 391 dpi

PC Printing Data - 600 x 600 dpi

300 x 300 dpi

4 Recording Paper Size Letter / A4 / Legal

5 Effective Printing Width

8.2 in (208 mm) Letter size for USA and

Canada

8.0 in (202 mm) A4 size for Other

Destinations

6 Recording Paper Capacity 250 sheets A4 / Letter / Legal

(20 lb / 75 g/m2)

7 Collation Stack Yes

Memory Collation

The Tray capacity is up to

100 sheets

8 Consumables See Consumables Section

Memory / Clock

1 Standard Memory 2 MB (120 pages) ITU-T Image No. 1

(A4, Std. Resolution)

2 Memory Backup Yes

3 Document Memory type Flash ROM

4 Clock Backup 30 minutes Use of a Gold Capacitor

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

Copy Quality

1 Halftone (Tx) Yes*

64-Level Error Diffusion

* Halftone (S-Fine) only

with the Resolution key

Super Fine (Tx & Rx)

dpi x lpi

(pels / mm x lines / mm)

406 x 391*

(16 x 15.4) * Interpolated 16 pels/mm

3Original Contrast Selection

(Tx) Yes 3-Levels

4 Smoothing (Rx) With Auto Picture / Text

Recognition

Fax, Copy Yes

PC Printing Data - No

Power Supply

1 Power Requirement 108 - 132 VAC, 47 - 63 Hz, Single Phase 100 VAC Power Supply

198 - 255 VAC, 47 - 63 Hz, Single Phase 200 VAC Power Supply

2 Power Consumption

Standby

100 VAC Power Supply

ES: Energy Saver

Sleep Mode 1.2 Wh

ES=On 6 Wh

ES=Off 21 Wh

Transmission 17 W

Reception 460 W

Copy 470 W

Maximum 470 W

Standby

200 VAC Power Supply

ES: Energy Saver

Sleep Mode 2.4 Wh

ES=On 6.5 Wh

ES=Off 22 Wh

Transmission 17 W

Reception 480 W

Copy 480 W

Maximum 490 W

Environment

1 Temperature

Operation 50 to 95°F ( 10 to 35°C)

Storage -4 to 104°F (-20 to 40°C)

Transport (Max. 72 hours) -4 to 122°F (-20 to 50°C)

2 Relative Humidity

Operation 15 to 70% RH

Storage 5 to 85% RH

Transport

(Max. 480 hours) 15 to 85% RH

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

Standards

1 PSTN FCC Part 68

Industry Canada No. CS-03

2 Safety UL1950 (UL60950 3rd edition)

CSA C22.2 No.950

3EMI Class B computing device

in FCC Part 15

Construction

1 Dimensions (W x D x H)

14.6 x 18.0 x 9.8 in

(370 x 457 x 250 mm)

Excluding projections

LTR

14.6 x 18.7 x 9.8 in

(370 x 474 x 250 mm)

Excluding projections

2 Weight (Excluding paper) 20 lb

(9.0 kg)

Excluding consumable

supplies and options

Attachment & Accessories

Toner Cartridge

Operating Instructions

CD-ROM

Power Cord

Tel Line Cable

Doc. Tray (Rx)

Yes (1)

Yes (1) (PDMS)

Yes (1)

UG-5510 for UF-790

Consumables

1Process Type Toner Cartridge

Yield

(3% Black, ITU-T

Image No. 1 Chart)

Approx.

7,500 pages

Multi Copy Mode Operation

Environment 68°F (20°C),

50% RH, using A4 paper.

3 Low Toner Warning Yes Magnetic Sensor

Options

1Cassette & Deck

250 sheets No Yes A4 / Letter / Legal

(20 lb / 75 g/m2)

2 Document Memory Yes

2 / 4 / 8MB Flash Memory

3 Page Memory No D-RAM

4 Battery Backup 72 hours No

5G3 Optional

Communication Port No

6 Handset Yes Specific Destinations only

7 V.24/Encryption Interface No

8 PDL No

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

Parallel Port Interface No Standard

Printer Interface (GDI) No Standard

Scanner Interface (TWAIN) No Standard

Class 2 Fax Modem

Interface No Standard

PC Fax Interface (PCC) No Standard

PC Fax Interface

(LaserFAX) No No* *HydraFax / LaserFAX Not

Supported

Document Manager No Standard

MFP Utilities No Standard

Languages

Control Panel

Function Label

LCD Display

Printouts

Operating Instructions

English

English, C-French, Spanish

can be selected for USA,

Canada.

Determined by

Destinations.

Multi-Task Operation

1 Multi Task Operation Yes

2 Direct XMT Reserve Yes

3 Memory XMT Reserve Yes

4Number of Memory Job

Files 10 files

Dialing/Telephone Features

1 One-Touch Keys 28

2 One-Touch / Program Keys 4

3 One-Touch Auto Dialers 32

4 Abbr. Auto Dialers 100

5 Total Auto Dialers 132

6 Max. Tel Number Digits 36

7Max. Station Name

Characters 15

8 Directory Search Dialing Yes With Directory Search key

9Full Number Dialing

(Buffered Dialing) Yes Max. 12 stations

10 Direct Dialing

(Monitor Dialing) Yes

Voice mode (Monitor

Dialing Mode)

Requires to press START

to start fax communication.

Automatic Redialing is not

available.

11 Automatic Redialing Yes

12 Manual Redialing Yes

13 Chain Dialing (Hybrid Dial) Yes On Monitor Dialing mode

only

14 Line Monitor Speaker Yes

15 Pulse / Tone Dialing Yes 10 pps / DTMF

16 Pulse to Tone Change Yes

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

17 Flash Key Yes

18 External Telephone Jack 1 Handset or External

Telephone

Transmission Features

1 Direct Transmission Yes ADF Transmission

2 Memory Transmission Yes Page Retransmission

3Quick Memory

Transmission Yes Dialing after 1st page

stored

4Multi-Station Transmission

(Sequential Broadcasting) Yes (Max.144)

5Direct Deferred

Transmission Yes ADF Deferred

Transmission

6Deferred Memory

Transmission Yes Max. 10 timers

7Deferred Multi-Station

Transmission Yes (Max.144) Max. 10 timers

8Priority Direct

Transmission Yes Priority ADF Transmission

9Priority Memory

Transmission No

10 Batch Transmission No

Reception Features

1 Substitute Reception Yes

2 Fixed Reduction Yes

LTR / A4: 70 - 100%,

LGL: 80 -100% (in 1%

Steps),

Top & Center Alignment

3 Auto Reduction Yes

LTR / A4: 70 - 100%,

LGL: 80 -100% (in 1%

Steps),

Top & Center Alignment

4 Overlap Printing Yes Page End Approx. 0.39 in

(10 mm)

5 Receive to Memory Yes

6Distinctive Ring Detector

(DRD) Yes Specific Destinations only

Receive Control

1 Fax / Tel Auto Switch Yes Specific Destinations only

2 Silent Reception No

3 External TAM Interface Yes Specific Destinations only

4 Remote Reception Yes (DTMF) Specific Destinations only

Polling

1 Polling Yes

2 Turnaround Polling No

3 Multi-Station Polling Yes (Max.144)

4 Deferred Polling Yes Max. 10 timers

5Deferred Multi-Station

Polling Yes (Max.144) Max. 10 timers

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

6 Direct Polling Tx No

7 Memory Polling Tx Yes 1 File

8 Preset Polling Password Yes

9Temporary Polling

Password Yes

10 Continuous Polling Yes

Convenience

1 Panel Display Yes 20 x 2 Alphanumeric LCD

2 Voice Contact No

3 Edit File Mode Yes With View Mode

4 Incomplete File Save Yes With View Mode

5 Automatic Cover Sheet Yes

Copy Features

1 Single Copy Yes

2 Multiple Copy Yes Multi Sort Copy only

3 Reduction Copy Yes

Copying Resolution

dpi x lpi

(pels / mm x lines / mm)

406 x 391*

(16 x 15.4) * Interpolated 16 pels/mm

Certainty

1 Verification Stamp Yes

2 Header / Total Page Print Yes

3 Transaction Journal Yes 32 Transactions /

with View Mode

4 Comm. Journal Yes With Image

5 Last Ind. XMT Journal Yes

6 Power Failure Report No

List Printouts

1 One-Touch List Yes

2 ABBR. No. List Yes

3 Program List Yes

4 Directory Search List Yes

5 Fax Parameter List Yes

6 File List Yes With View Mode

7 Ind. XMT Journal Yes

8 Directory Sheet Yes

9 Character Code List No

Identifications

1 Logo Yes 25 Characters

2 Multiple Logo No

3 Character ID Yes 16 Characters

4 Numeric ID Yes 20 Digits

Items

Description

Remarks

UF-580

UF-780

UF-590

UF-790

Altri manuali per Panafax UF-580

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Fax

Panasonic

Panasonic UF-8300 Manuale utente

Panasonic

Panasonic KX-FP145C Manuale utente

Panasonic

Panasonic UF-6300 Manuale utente

Panasonic

Panasonic KXF1150 - MFD FAX PRINTER Manuale utente

Panasonic

Panasonic KX-FL612CX Manuale utente

Panasonic

Panasonic KX-FT982LS-B Manuale utente

Panasonic

Panasonic KX-FP701LA Manuale utente

Panasonic

Panasonic KX-FP701ME Manuale utente

Panasonic

Panasonic KX-FP80 Manuale utente

Panasonic

Panasonic UF-780 - Panafax B/W Laser Manuale utente

Panasonic

Panasonic KX-FL611BL Manuale utente

Panasonic

Panasonic KX-FT988FX Manuale utente

Panasonic

Panasonic KX-PW504E2 Manuale utente

Panasonic

Panasonic KX-PD502DL Manuale utente

Panasonic

Panasonic KX-FP207FX-S Manuale utente

Panasonic

Panasonic Panafax UF-6100 Manuale utente

Panasonic

Panasonic KX-FM106 Manuale utente

Panasonic

Panasonic Panafax UF-490 Manuale utente

Panasonic

Panasonic Panafax UF-733 Manuale utente

Panasonic

Panasonic UF 885 - Panafax B/W Laser Manuale utente

Panasonic

Panasonic Panafax DX-2000 Manuale utente

Panasonic

Panasonic KX-FP121 Manuale utente

Panasonic

Panasonic KX-FM255 Manuale utente

Panasonic

Panasonic KX-FKN514 Manuale utente

Manuali Fax popolari di altre marche

Samsung

Samsung SF-515 Manuale utente

Radio Shack

Radio Shack TFX-1031 Manuale utente

imagistics

imagistics 2030 Manuale

Furuno

Furuno FAX-30 Manuale utente

Savin

Savin 3740 Manuale

Sharp

Sharp FO-51 Manuale utente

Muratec

Muratec MFX-C3035 Manuale utente

Canon

Canon FAX-L400 Manuale utente

Ricoh

Ricoh 1000L Guida rapida

Sharp

Sharp FO-3150 Manuale utente

Kyocera

Kyocera KM-F1060 Manuale utente

Sharp

Sharp FO-2970M Manuale utente

Canon

Canon JX510P Manuale utente

Mita

Mita LDC-870 Manuale

Brother

Brother MFC 640CW - Color Inkjet - All-in-One Manuale utente

Samsung

Samsung FX100 Manuale

Sharp

Sharp MX-FXX1 Manuale utente

Develop

Develop ineo 25e Manuale utente
