Personal Computer

Reference Manual

Model No. CF-T2 Series

XP We recommend that this Reference Manual be printed.

Read Me First

zSome of the illustrations in this manual may differ slightly in shape from the actual items in

order to make the explanation easier to understand.

zIf the user has logged on without the administrator authority, some functions may not be

executable, and some screens may not be displayed as shown in this manual.

If this happens, log on with the administrator authority to enable these functions.

zConfirm the latest information on optional products in catalogs, etc.

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in minor

or moderate injury.

Enter

This illustration means to press the [Enter] key.

This illustration means to press and hold the [Fn] key,

then press the [F5] key.

When using with the [Fn] and [Ctrl] functions

interchanged, read with [Fn] and [Ctrl] reversed.

[start] - [Run] This illustration means to click [start], then to click [Run].

For some applications, you may need to double-click.

Îor ⇒These symbols indicated related pages.

Î: Refer to the page in this Reference Manual

⇒: Refer to the Operating Instructions

Orange*1 If *1 is selected, it will jump to a related explanatory note.

Read Me First

The terminology in ( ) is the one used in [Intel(R) 82852/82855 GM/GME Graphics Controller

properties].

To display [Intel(R) 82852/82855 GM/GME Graphics Controller properties]:

Select [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics].

About Display Mode

Internal LCD (Notebook) This computer's display

External Display (PC monitor) External display connected to this computer

Simultaneous display

(Intel(R) Dual Display Clone)

To display the same screen on both the LCD and

external display

Extended Desktop To use both the internal LCD and the external display as

an extended display domain. You can drag a window

between the internal LCD and the external display each

other.

Key Combinations

CAUTION

zDo not press the following key combinations repeatedly in (quick) succession. Also, do

not press different key combinations quickly one after another.

zDo not press the following key combinations while using the touch pad (external

mouse), touchscreen or other keys.

NOTE

zDo not press the following key combinations until you log on to Windows and the hard

disk drive indicator turns off. Note, however, that the key combinations

and

are operable in the Setup Utility.

zThe key combinations below may not work while some applications are running.

Besides, the popup window may not be displayed depending on the state of the

application you are using (e.g., when [Command Prompt] is set to "Full Screen").

zWhen using with the

and

Ctrl

functions interchanged. (Îpage 82)

• Press

Ctrl

instead of

• It is not possible to replace the markings on the keys, or the keys themselves.

Key Functions Popup Window

(Displayed after logging

on to Windows)

LCD brightness control (down)

LCD brightness control (up)

Pressing this key combination adjusts the

brightness of LCD.

The brightness setting is stored in memory

separately under the condition the AC adaptor is

connected and under the condition the AC adaptor

is not connected.

Key Combinations

Display change

(When the external display is connected)

By pressing this key combination, you can select

either an external display, internal LCD or

simultaneous. (Îpage 61)

CAUTION

zDo not press another key until the display

destination has been completely switched.

zDo not press this key combination in the

following conditions.

• While MPEG files are playing.

• When the Extended Desktop is being

utilized.

• When a game such as pinball is

displayed.

NOTE

zThis key combination does not work when

[Command Prompt] is set to "Full Screen".

zWhen switching to a different user with the

Fast User Switching function, this key

operation may not work. In this case, log off

all users and restart the computer.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Speaker on/off switch

Pressing this key combination turns on/off audio

from the internal speaker and headphone jack.

NOTE

zDisabling the speakers will also disable the

warning beep.

zSpeakers connected to the USB port

cannot be muted.

OFF

(MUTE)

Volume control (down)

Volume control (up)

Pressing this key combination adjusts the volume

of the internal speaker and headphone jack.

NOTE

zThis key combination cannot be used to

adjust the volume of the warning beep or

speakers connected to the USB port.

Shut down using the standby function

Pressing this key combination causes the current

status of the computer to be saved to memory, and

shuts down the computer. (Îpage 23)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Remaining capacity of the battery pack

When the battery pack is

inserted in the computer

(example)

When the battery pack is

not inserted in the

computer

F10

Shut down using the hibernation function

Pressing this key combination causes the current

status of the computer to be saved to the hard disk,

and shuts down the computer. (Îpage 23)

NumLk

Home

The functions differ depending on the application

software being used.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

There are two Fn key functions as follows:

zFn key lock function

After

is pressed once, it stays in the "pressed" position until another key is pressed.

This is convenient when it is difficult to press two buttons simultaneously.

zPopup windows display ON/OFF

NOTE

zThe Hotkey settings can be set separately for each user.

zWhen using with the

and

Ctrl

functions interchanged (Îpage 82), read with

and

Ctrl

reversed.

1Run the Hotkey Settings.

Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings].

2Set the parameters.

A. Use Fn key lock

Add the check mark if you want to enable the Fn key lock function. The following

Fn key lock function will then be enabled.

zTo use

only once:

APress

once. (Locked)

BPress another key for combination. (Lock released)

zTo use

successively:

APress

twice. (Locked)

BPress another key for combination.

Fn key remains locked until

is pressed once more.

B. Notification

This setting is only available when [Use Fn key lock] is checked.

[Make sounds when Fn key is pressed]*1

Notifies the user with a sound when

is locked or released.

[Show status on screen]:

Displays the Fn key status on the taskbar.

is locked

is not locked

Hotkey Settings

Key Combinations

C. Disable popup

Add the check mark if you want to turn the popup window display function OFF.

"Full Screen" of [Command Prompt] or MPEG files may change to a window

display if

*2 keys are pressed. To prevent this, turn the popup window

display function OFF.

3Select [OK].

*1 If MUTE is set, you will not hear a beep.

*2 "

" indicates any function key from

F10

LED Indicators

Power status zNot lit

Power off / Hibernation mode

zGreen

Power on

zBlinking green

Standby mode

Battery pack status Îpage 37

Caps Lock This indicator lights green when

Caps Lock

pressed. Subsequent non-shifted input is

capitalized.

NumLk

(Numeric key)

This indicator lights green when

NumLk

pressed. When the green light is on, if

pressed along with keys on certain other

segments of the keyboard, then those keys will

operate as numeric keys. The [Enter] key

functions differently depending on the

application.
