Panasonic CF-WGP Series Istruzioni per l'installazione e il funzionamento

Addendum

FJ1103-0

DFQX1481ZA

Printed in Japan

Industry Canada

This product complies with RSS210 Industry Canada.

Operation is subject to the following two conditions;

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of the device.

This addendum explains the cases where the operation of the computer differs from that in the Operating Instructions and the

Reference Manual.

First-time Operation “OPERATING INSTRUCTIONS”

Windows 2000 Replace Step 6with the following.

Read Me First “OPERATING INSTRUCTIONS”

Add the following to “For Canada”.

6Turn your computer on and run the Setup Utility.

1Slide the power switch and hold it for approximately one second until the power indicator turns on before releasing it.

2Press F2 while [Panasonic] boot screen is displayed soon after computer begins the startup procedure.

3Press F9 . At the confirmation message, select [Yes] and press Enter .

4Select the [Advanced] menu, then set [GPS] to [Disable]. (If there is a [Wireless Modem] or [CDMA], also set them to

[Disable].)

5Press F10 . At the confirmation message, select [Yes] and press Enter .

The computer will restart.

CAUTION

Do not slide the power switch and hold it for more than four seconds; this will cause the power to be turned off

forcibly.

Do not slide the power switch repeatedly.

Once the computer is powered off, you must wait at least ten seconds before powering it on again.

Windows 2000 Perform the following after setting up Windows.

1Select [Start]-[Run] and input “c:\util\gps\skipenum.reg”, then select [OK].

2Select [Yes] and select [OK].

3Restart the computer as follows:

Select [Start] - [Shut Down], and select [Restart], then select [OK].

4Press F2 while [Panasonic] boot screen is displayed soon after computer begins the startup procedure.

5Press F9 . At the confirmation message, select [Yes] and press Enter .

6Press F10 . At the confirmation message, select [Yes] and press Enter .

The computer will restart.

Setting up GPS

Windows XP Add the following to Step 6.

CAUTION

If you have changed the Setup Utility settings, be sure to reset them to the default settings.

In Device Manager, “Com-

munication Port (COM2)”

or “Communication Port

(COM3)” appear twice un-

der “Ports (COM & LPT)”.

The cursor cannot be con-

trolled properly

Dealing with Problems “OPERATING INSTRUCTIONS”,“Reference Manual”

Touch Pad/Touchscreen

Add the following.

Windows XP

Perform as follows.

1Turn the computer on and Press F2 while [Panasonic] boot screen is displayed soon

after computer begins the startup procedure.

2Press F9 . At the confirmation message, select [Yes] and then press Enter .

3Select [Advanced] menu, then set [GPS] to [Disable]. (If there is [Wireless Modem] or

[CDMA], also set them to [Disable].)

4Press F10 . At the confirmation message, select [Yes] and then press Enter .

The computer will restart.

5Select [Start]-[Run] and input “c:\util\gps\skipenum.reg”, then select [OK].

6Select [Yes] and select [OK].

7Select [Start] - [Turn Off Computer], and select [Restart] to restart.

8Press F2 while [Panasonic] boot screen is displayed soon after computer begins the

startup procedure.

9Press F9 . At the confirmation message, select [Yes] and then press Enter .

Press F10 . At the confirmation message, select [Yes] and then press Enter .

The computer will restart.

Windows 2000

Perform step 6and “Setting up GPS”. ( “First-time Operation” of this leaflet)

The serial port B of the port

replicator does not work

Connecting Peripherals

Set [Serial Port B] in the Setup Utility to [Enable] or [Auto].

Set [GPS] in the Setup Utility to [Enable] or [Auto].

Others

Perform as follows.

1Select one of the two “Communication Port [COM2]” ([COM2] may be [COM3]), se-

lect [Action] - [Uninstall], then select [OK] to uninstall. Uninstall the other one by doing

the same.

2Restart the computer as follows. (If the cursor cannot be controlled properly, use the

keyboard.)

Windows XP

Select [Start] - [Turn Off Computer] and select [Restart].

Windows 2000

Select [Start] - [Shut Down], and select [Restart], then select [OK].

3After Windows has started, shut down the computer as follows.

Windows XP

Select [Start] - [Turn Off Computer] and select [Turn Off].

Windows 2000

Select [Start] - [Shut Down], and select [Shut Down], then select [OK].

4Perform the operation for “The cursor cannot be controlled properly” as mentioned above.

Disable Enable Auto

Setup Utility “Reference Manual”

The following parameters have been added in [Advanced] menu of the Setup Utility.

GPS
