Panasonic TH-65GX706M Manuale utente

LED Television

Model No. TH-65GX706M

Chassis. 9M40T

WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It dose not contain warnings or cautions to advise non -technical individuals of potential dangers in attempting to service a product.

Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to ser-

vice or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE

There are special components used in this equipment which are important for safety. These parts are marked by 7in the schematic

diagram, circuit board diagrams, exploded views and replacement parts list. It is essential that these critical parts should be replaced

with manufacturer’s specified parts to prevent shock, fire, or other hazards. Do not modify the original design without permission of

manufacturer.

copying and distribution is a violation of law.

Technical Document

2/43

CONTENT

1. Technical Specification··························································································· 3

2. Overview of the terminals configuration·································································· 17

3. System Block and Power Tree··············································································18

4. Wiring Diagram····································································································19

5. List of key parts·································································································· 20

6. IC General Description························································································· 21

7. Software Upgrade································································································ 33

8. Setting Hotle Mode Menu····················································································· 34

9. PCB Silkscreen·································································································· 286

10. Schematic Circuit Diagram·················································································· 38

11. Trouble Shooting································································································ 44

Technical Document

3/43

1. Technical Specification

1 Outlook

Please refer to the p

icture

2 Brief Information

2.1 Product Name 9M40T-65Q20

2.2 Chassis Name 9M40T

2.3 Solution MSD6886

2.4 Key functions DVB Netflix TV

2.5 Target Market Asian area

2.6 Product Category D-LED

2.7 Product Positioning Middle End

2.8 Product size 65"

3 Panel Specification

3.1 Model Number Model Number

3.1.1 Panel Manufacturer Skyworth

3.1.2 Model Number LC650EGY-SMM3

3.2 Mechanical Mechanical

3.2.1 Panel Size 65inches

3.2.2 Dimension 1445.79(H) X 825.39 (V) x 51 mm(D)

3.2.3 Pixel Format (H × V) 3840 horiz. by 2160 vert. Pixels

3.2.4 Backlight Type LED

3.2.5 Pixel Pitch (mm) 0.372(H) x 0.372(V)mm

3.2.6 Visible Area (mm) : H x V 1440.3(H) X 817.9 (V)mm

3.2.7 Diagonal Screen Size 64.53 inches

3.3 Electronic Parameter Electronic Parameter

3.3.1 Brightness (cd/m2)(for panel) 350nit（min）

3.3.2 Power consuption(W，for panel) TBD

3.3.3 Brightness (cd/m2)(for product) 300

3.3.4 Dynamic Contrast Ratio No

Technical Document

4/43

3.3.5 Contrast Ratio 1300:1

3.3.6 Veiwing Angle 178

3.3.7 Response Time (ms) 9ms

3.3.8 Back light Time (Hours) 30000

3.3.9 120Hz(100Hz)/240Hz(200Hz) No

Signal Receiving Syst

4.1 ATV Receiving Syste

ATV Receiving System

4.1.1 PAL BG/I/DK/ No

4.1.2 NTSC-M No

4.1.3 PAL/SECAM BG/DK/I Yes

4.1.4 PAL M/N NTSC-M No

4.2 DTV Receiving Syste

DTV Receiving System

4.2.1 ATSC No

4.2.2 DVB-T Yes

4.2.3 DVB-T with CI Yes

4.2.4 DVB-T2 Yes

4.2.5 DVB-T2 with CI+ Yes

4.2.6 ISDB-T/SBTVD-T No

4.2.7 DTMB No

4.2.8 DVB-C Yes

4.2.9 ISDB-T/ISDB-S No

4.2.10 DVB-S No

4.2.11 DVB-S/S2 No

4.3 Antenna input Antenna input

4.3.1 Antenna Input port: 1 (1 for analogue) No

4.3.2

Antenna Input port: 1 (1 for both analog

ue and digital)

Yes

4.3.3 Antenna Input port: 2 (1 air + 1 Cable) No

4.3.4 Type of Antenna Input Port IEC 169-24,Female*1

4.3.5 Receiving Frequency range (ATV) 47.25MHZ~870.25

Technical Document

5/43

4.3.6 Receiving Frequency range (DTV)

DVB-T/T2:174 MHz ~ 230 MHz, 470 MHz ~ 8

60 MHz, 104MHz ~ 300 MHz, 304 MHz ~ 86

0 MHz

DVB-C: 50 MHz ~ 858 MHz

4.4

External Signal Recei

ving System

4.4.1 Composite Input PAL 50Hz/60Hz Yes

4.4.2 SECAM Yes

4.4.3 NTSC 3.58 Yes

4.4.4 NTSC4.43 Yes

4.4.5 Component Input 480i /480p/720p/1080i (60Hz) No

4.4.6 576i /576p/720p/1080i (50Hz) No

4.4.7 1080P 24Hz/25Hz/30Hz/50Hz/60Hz No

4.4.8 PC Input VGA (640 x 480) No

4.4.9 S-VGA (800 x 600) No

4.4.10 XGA (1024 x 768) No

4.4.11 W-XGA (1280 x 768) No

4.4.12 W-XGA（1360×768）No

4.4.13 S-XGA (1280 x 1024) No

4.4.14 UW-XGA 1920*1080 No

4.4.15 HDMI Input

480i /480p/720p/1080i (60Hz) (Video For

mat)

Yes

4.4.16

576i /576p/720p/1080i (50Hz) (Video For

mat)

Yes/Yes/Yes/Yes

4.4.17

1080P 24Hz/25Hz/30Hz/50Hz/60Hz (Video

Format)

Yes/Yes/Yes/Yes

4.4.18

4K 24Hz/25Hz/30Hz/50Hz/60Hz (Video For

mat)

Yes/Yes/Yes/Yes/Yes

4.4.19 VGA (640 x 480) (PC Format) Yes

4.4.20 S-VGA (800 x 600) (PC Format) Yes

4.4.21 XGA (1024 x 768) (PC Format) Yes

4.4.22 W-XGA (1280 x 768) (PC Format) Yes

4.4.23 W-XGA（1360×768）(PC Format) Yes

4.4.24 S-XGA (1280 x 1024) (PC Format) Yes

Technical Document

6/43

4.4.25 UW-XGA (1920*1080) (PC Format) Yes

4.4.26 USB Media player formats Refer to the attachment

5 Features

5.1 Picture Picture

5.1.1 Picture Mode Standard/Movie/User/Dynamic

5.1.2 Picture Display Size Auto/4:3/16:9/Movie/Panorama/Just Scan

5.1.3 Picture Freeze No

5.1.4 Backlight Adjust Yes

5.1.5 Auto Format Yes

5.1.6 Noise Reduction Yes

5.1.7 MPEG Reduction Yes

5.1.8 Color temperature Cool/Warm/Nature/User

5.1.9 3:2 Pull Down No

5.1.10 4:3 Stretch NO

5.1.11 Comfilter Yes

5.1.12 PIP(Single tuner) No

5.2 Sound Sound

5.2.1 Sound Mode Standard/Music/Movie/Sport/User

5.2.2 For personal mode:Treble/Bass/Balance Balance

5.2.3 Surround Yes

5.2.4 Equalizer 120HZ/500HZ/1.5KHZ/5KHZ/10KHZ

5.2.5 Audio Output Power 10W + 10W

5.2.6 NICAM Yes

5.2.7 A2 Yes

5.2.8 BTSC(MTS) No

5.3 Teletext Teletext

5.3.1 FLOF/TOP Yes

5.3.2 Memory Page 1000

5.3.3 Character Language Asian

5.3.4 Teletext Level 1.0/1.5

5.4 Program Managemen

Program Management

5.4.1 V-Chip No
