Panasonic SR-DE103 Manuale utente

Order No. PHAT101101CE

(Revision : Jul. 2011)

Service Manual

Electronic Warm Jar

SR-DE103 / SR-DE183

SR-MS103 / SR-MS183

Product Colour

White (W)

Destination

Thailand, Hong Kong, Malaysia,

Singapore (RBD), Indonesia, PSV,

Singapore (DBD), Taiwan,

USA & Canada, Panama,

Australia & New Zealand.

is a violation of law.

There are special components used in this equipment which are important for safety. These parts are marked by

in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that

these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do

not modify the original design without permission of manufacturer.

IMPORTANT SAFETY NOTICE

SR-MS103 / SR-MS183SR-DE103 / SR-DE183

SR-DE103, 183 / SR-MS103, 183

- 3 -

1. WARNING

Accessory

The service information is designed for experienced repair technicians only and is not designed for use by the general

public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting

to service a product. Products powered by electricity should be serviced or repaired only by experienced professional

technicians. Any attempt to service or repair the product or products dealt within this service information by anyone

else could result in serious injury or death.

WARNING

Scoop Measuring cup Steaming

basket

Power cord

Outer lid

Pan

Handle

Body

SR-DE103, 183 / SR-MS103, 183

- 19 -

12. PARTS EXPLODED VIEW AND REPLACEMENT PARTS LIST

12.1 Parts Exploded View

XTN4+8GFJ

XTB4+12GFJ

(FOR MS SERIES) (FOR DE SERIES)

XTL4+10RTW

XTL4+16AVW

(FOR MS SERIES) (FOR DE SERIES)

XYM4+E10FNS

XYC4+CF8FJ

XTB4+12GFJ

- 20 -

SR-DE103, 183 / SR-MS103, 183

12.2 Packing View

(FOR MS SERIES ONLY)
