Panasonic SC-MAX650 Manuale utente

2013 AUdio

SC-MAX650

EXtrA lArgE AUdio SyStEM

ExtErnal SupEr WoofEr W/ full Digital Bi-amp

Mind blowing amplication with crystal clear sound quality.

4 Way floor StanDing SpEakErS W/ priSm-color illumination

Experience surround sound and unmatched style like never before.

uSB playBack & muSic port muSic inputS

Attach a USB or other device for easy playback.

2300 WattS total SyStEm poWEr

Awesome power to take your sound system to the next level.

1The USB playback only supports MP3 files stored in USB flash drives.

• 2300 Watts Total System Power

• Preset Equalizer

• D. Bass With Smart Control

• Maximized Bass Sound PLUS

• Nano-sized Bamboo Cone Tweeter

• High Force Magnet

• Multi-color Illumincation

(External Super Woofer/ Volume Knob)

• USB Playback*

• AUX & Music Port

• FM/AM Radio

• CD Playback

03/13 Specifications subject to change without notice.

2013 AUdio

SC-MAX650

EXtrA lArgE AUdio SyStEM

PLAYABLE DISCS

CD, CD-R/-RW CD-DA •

MP3 •

AUDIO SYSTEM

Output Channel 2ch

Power Output (RMS) Total Power 2300W

Hi: 330W x 2 (1kHz, 3ohms, 30% THD)

Mid-Low: 330W x 2 (100Hz, 3ohms, 30% THD)

Low: 490W x 2 (100Hz, 2ohms, 30% THD)

Power Output (FTC) Total Power 920W

Hi: 130W x 2 (400-20kHz, 3ohms, 1% THD)

Mid-Low: 170W x 2 (50-200Hz, 3ohms, 1% THD)

Low: 160W x 2(50-100Hz, 2ohms, 1% THD)

USB

Slot • (2)

USB Standard USB 2.0 Full Speed

Playback MP3 •

HIGH QUALITY SOUND

MAX DJ Effect •

Full Digital Amplifier • (Triple-Amp)

High-Force Magnet •

Nanosized Bamboo Cone • (Tweeter)

D.Bass with Smart Control •

Maximized Bass Sound PLUS •

Preset Equalizer •

Manual Equalizer • (Bass / Mid / Treble)

Surround •

EASY OPERATION

Rotary Music Selection while Playback •

Karaoke Function •

Display Fluorescent

Auto Power Off •

Programmable Timer PLAY / SLEEP

DESIGN

Prism Color Illumination •

Multi-Color Illumination —

SPEAKER SYSTEM

Front Conguration 4-way 4 speakers, Bass-reex

Speaker Unit Super Woofer: 15” (38cm) Cone Type

Super Woofer: 7-7/8” (20cm) Cone Type

Woofer: 4” (10cm) Cone Type

Tweeter: 2-3/8” (6cm) Cone Type

External Super Woofer Number of Super Woofer —

Conguration —

Speaker Unit —

TERMINAL

Analog Audio Input RCA • (AUX)

Music Port (3.5mm, 1/8”) •

MIC Jack (3.5mm, 1/8”) •

TUNER

Station Presets 30-FM/ 15-AM

Auto Tuning •

OTHERS

Power Supply AC 120V, 60Hz

Power Consumption Normal Use [Approx.] 195W

Standby [Approx.] 0.3W

DIMENSIONS, WEIGHT

Main Unit Dimensions (W x H x D) [Approx.] 19-1/8 x 9-1/8 x 14-7/8 inch (485 x 231 x 378 mm)

Weight [Approx.] 10.6 lbs (4.8 kg)

Front Speaker Dimensions (W x H x D) [Approx.] 22 x 31-3/8 x 20-5/8 inch (558 x 796 x 525 mm)

Weight [Approx.] 68.3 lbs (31 kg)

External Super Woofer Dimensions (W x H x D) [Approx.] —

Weight [Approx.] —

Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use.
