INSTALLATION INSTRUCTIONS PN343C

For Technical Support: www.panduit.com/resources/install_maintain.asp

Page 1 of 2

PANVIEW 24 Port Modular

Angled Patch Panel

Part Numbers: PVMAPU24, PVMAPU246K, PVMAPU246GK, PVMAPU246XK

PVMAPU24 / *PVMAPU246K / *PVMAPU246GK / *PVMAPU246XK

Module Installation

1. 2. 3.

* Part Numbers include 24 MINI-COM Series Jack Modules.

Flat Cable Installation

1. 2.

A(Right)

B(Left)

To Scanner

E-mail:

[email protected]

Fax:

(708) 444-6993

For Instructions in Local Languages

and Technical Support:

www.panduit.com/resources/install_maintain.asp www.panduit.com

INSTALLATION INSTRUCTIONS PN343C

Page 2 of 2

Label†/ Label Cover Installation & Removal - (screwdriver required)

1. 2.

3. 4.

Label †

Label Cover

Label Part #

UILJ4 5 sheets

Computer Printable Labels

Height Length Color Std. Pkg. Qty.

.236” 2.585” White

Non-Adhesive Label Cassette (for use with PANACEA LS7 Thermal Transfer Printer)

*UILS7BW 1/4” 26.2’ Black / White 1

ULTIMATE ID Label Part Numbers

* See PANDUIT LS7 Operations Manual to explain serialized function for label printing and page

function for non-serialized label printing.

† Write on labels are not included with these Patch Panels per TIA/EIA-606-A standard which states: “To maximize legibility, all labels

shall be printed or generated by a mechanical device, and shall not be written by hand.” (Refer to table below for label products)

All cables should flow directly into vertical cable managers

on the corresponding side of the Angled Panel.

Recommended cable routing for terminated modules. Recommended cable routing for patch cords.
